2020 TOYOTA C-HR stop start

5
1
8 7 5 4
3
2
9
C-HR_OM_USA_OM10634U
6
7-1. Essential informationEmergency flashers .......... 408
If your vehicle has to be stopped in
an emergency ................. 409
If the vehicle is trapped in rising water .................. 411
7-2. Steps to take in an emergency
If your vehicle needs to be towed ..................... 412
If you think something is wrong .............................. 419
Fuel pump shut off system............................. 420
If a warning light turns on or a warning buzzer
sounds ............................ 421
If a warning message is displayed ......................... 431
If you have a flat tire .......... 436
If the engine will not start ................................. 447
If the electronic key does not operate
properly (vehicles with
a smart key system) ........ 449
If the vehicle battery is discharged ...................... 452
If your vehicle overheats ........................ 457 If the vehicle becomes
stuck ................................ 460
8-1. Specifications Maintenance data (fuel, oil level, etc.) .......... 464
Fuel information ................. 472
Tire information.................. 475
8-2. Customization Customizable features ....... 488
8-3. Items to initialize Items to initialize ................ 499
Reporting safety defects for U.S. owners ........................ 502
Seat belt instructions for Canadian owners
(in French)................................ 503
SRS airbag instructions for Canadian owners
(in French)................................ 505
What to do if... (Troubleshooting) ..................... 516
Alphabetical index ...................... 520
7When trouble arises
8Vehicle specifications
9For owners
Index
Refer to “MULTIMEDIA OWNER’S MANUAL” for information regard-
ing the equipment listed below.
• Hands-free system (for cellular phone)• Rear view monitor system
• Audio system
• Connected services

14Pictorial index
C-HR_OM_USA_OM10634U
■Instrument panel
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178, 181
Starting the engine/changing the positions
*1 . . . . . . . . . . . . . P. 178
Starting the engine/changing the modes
*2 . . . . . . . . . . . . . . . P. 181
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . P. 409
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . P. 447
Warning messages
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 431
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 412
When the shift lever does not move . . . . . . . . . . . . . . . . . . . . P. 191
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 94
Reading the meters/adjusting the instrument panel . . . . . . P. 94, 96
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 86
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . P. 421

251-1. For safe use
1
For safety and security
C-HR_OM_USA_OM10634U
Make sure that you can see the rear of the vehicle clearly by adjusting
the inside and outside rear view mirrors properly. ( P. 151, 152)
Adjusting the mirrors
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the s eat
tracks and stop the seat from locking in place. This may lead t o an acci-
dent and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
● When driving over long distances, take regular breaks before yo u start to
feel tired.
Also, if you feel tired or sleepy while driving, do not force y ourself to con-
tinue driving and take a break immediately.

811-4. Theft deterrent system
1
For safety and security
C-HR_OM_USA_OM10634U
Engine immobilizer system
Vehicles without a smart key sys-
tem:
The indicator light flashes after
the key has been removed from
the engine switch to indicate that
the system is operating.
The indicator light stops flashing
after the registered key has been
inserted into the engine switch to
indicate that the system has been
canceled.
Vehicles with a smart key system:
The indicator light flashes after the engine switch has been tu rned off
to indicate that the sy stem is operating.
The indicator light stops flashi ng after the engine switch has been
turned to ACCESSORY or IGNITION ON mode to indicate that the
system has been canceled.
The vehicle’s keys ha ve built-in transponder chips that prevent
the engine from starting if a key has not been previously regis -
tered in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehi-
cle.
This system is designed to help prevent vehicle theft but does
not guarantee absolute security against all vehicle thefts.

932. Instrument cluster
2
Instrument cluster
C-HR_OM_USA_OM10634U
■Eco Driving Indicator Light
Eco Driving Indicator Light will not operate in the following c onditions:
● The shift lever is in anything other than D.
● The vehicle is being driven in “SPORT” mode ( P. 267)
● The vehicle speed is approximately 80 mph (130 km/h) or higher.
During Eco-Friendly acceleration (Eco
driving), Eco Driving Indicator Light will
turn on. When the acceleration exceeds
Zone of Eco driving, and when the vehicle
is stopped, the light turns off.
Eco Driving Indicator Light availability can
be customized. The default setting is on.
(
P. 490)
WARNING
■ If a safety system warning light does not come on
Should a safety system light such as ABS and SRS airbag warning light not
come on when you start the engine, this could mean that these s ystems are
not available to help protect you in an accident, which could r esult in death
or serious injury. Have the vehicle inspected by your Toyota de aler.

1373-2. Opening, closing and locking the doors
3
Operation of each component
C-HR_OM_USA_OM10634U■
When the vehicle is not driven for extended periods
●To prevent theft of the vehicle, do not leave the electronic ke y within 6 ft.
(2 m) of the vehicle.
● The smart key system can be deactivated in advance. ( P. 488)
■ To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from the
outside of the vehicle.
Depending on the position and holding condition of the electron ic key, the key
may not be detected correctly and the system may not operate pr operly. (The
alarm may go off accidentally, or the door lock prevention may not operate.)
■ If the smart key system does not operate properly
●Locking and unlocking the doors: Use the mechanical key. ( P. 449)
● Starting the engine system: P. 450
■ Customization
Settings (e.g. smart key system) can be changed.
(Customizable features: P. 488
■ If the smart key system has been d eactivated in a customized setting
● Unlocking and locking the doors:
Use the wireless remote control or mechanical key. ( P. 118, 449)
● Starting the engine and changing engine switch modes: P. 450
● Stopping the engine: P. 182

1573-5. Opening and closing the windows
3
Operation of each component
C-HR_OM_USA_OM10634U■
When the side window cannot be opened or closed
When the jam protection function or catch protection function o perates
unusually and the side window cannot be opened or closed, perfo rm the fol-
lowing operations with the power window switch of that door.
● Stop the vehicle. With the engine switch is in the “ON” positio n (vehicles
without a smart key system) or IGNITION ON mode (vehicles with a smart
key system), within 4 seconds of the jam protection function or catch protec-
tion function activating, continuously operate the power window switch in
the one-touch closing direction or one-touch opening direction so that the
side window can be opened and closed.
● If the side window cannot be opened and closed even when perfor ming the
above operations, perform the following procedure for function initialization.
Turn the engine switch to the “ON” position (vehicles without a smart key
system) or IGNITION ON mode (vehicles with a smart key system).
Pull and hold the power window switch in the one-touch closing direction
and completely close the side window.
Release the power window switch for a moment, resume pulling the
switch in the one-touch closing direction, and hold it there for approxi-
mately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direc-
tion. After the side window is completely opened, continue holding the
switch for an additional 1 second or more.
Release the power window switch for a moment, resume pushing th e
switch in the one-touch opening direction, and hold it there fo r approxi-
mately 4 seconds or more.
Pull and hold the power window switch in the one-touch closing direction
again. After the side window is completely closed, continue hol ding the
switch for a further 1 second or more.
If you release the switch while the window is moving, start aga in from the
beginning. If the window reverses and cannot be fully closed or opened, have
the vehicle inspected by your Toyota dealer.
1
2
3
4
5
6

1624-1. Before driving
C-HR_OM_USA_OM10634U
Driving the vehicle
P. 178, 181
With the brake pedal depressed, shift the shift lever to D. ( P. 1 8 8 )
Release the parking brake. ( P. 1 9 5 )
If the parking brake is in automatic mode, the parking brake is released
automatically when shifting the shift lever to any position oth er than P.
( P. 194)
Gradually release the brake pedal and gently depress the accele ra-
tor pedal to accelerate the vehicle.
With the shift lever in D , depress the brake pedal.
If necessary, set the parking brake.
If the vehicle is to be stopped for an extended period of time, shift the shift
lever to P or N. ( P. 188)
The following procedures should be observed to ensure safe
driving:
Starting the engine
Driving
Stopping
1
2
3
1
2
