SAFETY207
Crew Cab Trucks:
The top tether anchorages in this
vehicle are tether strap loops located
between the rear glass and the back
of the rear seat. There is a tether
strap loop located behind each seating position.
Follow the steps below to attach the tether strap
of the child restraint.
Right Or Left Outboard Seats:

1. Raise the head restraint and reach between the rear seat and rear glass to
access the tether strap loop.

Head Restraint In Raised Position Tether Strap Loop With Center Head Restraint In
Raised Position

2. Place a child restraint on the seat and adjust the tether strap so that it will reach
over the seat back, under the head
restraint, through the tether strap loop
behind the seat and over to the tether strap
loop behind the center seat.
3. Pass the tether strap hook under the head restraint behind the child seat, though the
tether strap loop behind the seat and over
to the center tether strap loop.
Tether Strap Through Outboard Tether Strap Loop

4. Attach the hook to the center tether strap loop (see diagram). Tighten the tether strap
according to the child seat manufacturer’s
instructions.

Tether Strap Through Outboard Tether Strap Loop And Attached To Center Tether Strap Loop

4

20_DJD2_OM_EN_USC_t.book Page 207

208SAFETY
NOTE:
If there are child seats in both of the outboard
(left and right) seating positions, the tether
strap hooks of both child seats should be
connected to the center tether strap loop. This
is the correct way to tether two outboard child
seats.
Center Seat:

1. Raise the head restraint and reach
between the rear seat and rear glass to
access the tether strap loop.

Tether Strap Loop With Head Restraint In Raised Position

2. Place a child restraint on the seat and adjust the tether strap so that it will reach
over the seat back, under the head restraint, through the tether strap loop
behind the seat and over to the tether strap
loop behind either the right or left outboard
seat.
3. Pass the tether strap hook under the head restraint behind the child seat, though the
tether strap loop behind the seat and over
to the right or left outboard tether strap
loop.

Tether Strap Through Center Tether Strap Loop

4. Attach the hook to the outboard tether strap loop (see diagram). Tighten the tether strap
according to the child seat manufacturer’s
instructions.
Tether Strap Through Center Tether Strap Loop And
Attached To Outboard Tether Strap Loop

Installing Three Child Restraints:

1. Place a child restraint on each outboard rear seat. Route the tether straps following
the directions for right and left seating
positions, above.

2. Attach both hooks to the center tether strap loop, but do not tighten the straps yet.
3. Place a child restraint on the center rear seat. Route the tether strap following the
directions for the center seating position,
above.
4. Attach the hook to the outboard tether strap loop.

20_DJD2_OM_EN_USC_t.book Page 208

SERVICING AND MAINTENANCE445
(Continued)
increase tread life, help to maintain mud, snow
and wet traction levels and contribute to a
smooth, quiet ride.
Refer to the “Maintenance Plan” for the proper
maintenance intervals. More frequent rotation
is permissible if desired. The reasons for any
rapid or unusual wear should be corrected prior
to rotation being performed.
The suggested rotation method is the “rearward
cross” shown in the following diagram. This
rotation pattern does not apply to some
directional tires that must not be reversed.
Tire Rotation (Rearward Cross)
Dual Rear Wheels — If Equipped
The tires used on dual wheel assemblies should
be matched for wear to prevent overloading one
tire in a set. To check if tires are even, lay a
straight edge across all four tires. The straight
edge should touch all the tires.
Tire Rotation

NOTE:
If your vehicle is equipped with a Tire Pressure
Information System (TPIS):
The Tire Pressure Information System (TPIS)
uses unique sensors in the inner rear wheels
to help identify them from the outer rear
wheels, because of this, the inner and outer
wheel locations can’t be switched.
After a tire rotation is completed, as shown
below, the system can auto learn the loca -
tions of each sensor ID. Auto learning/local -
ization occurs when the vehicle ignition
status is changed from Off to On and speeds
of greater than 5 mph (8km/h) are obtained
and remain over 5 mph (8km/h) for at about
a 15 minute period. You may need to drive
for 20 minutes to account slower speeds and
stops.
If the tires are rotated incorrectly, The auto
localization of the TPIS sensors will fail to
locate correctly resulting in incorrect loca -
tions for the pressure values displayed in the
instrument cluster.
CAUTION!
3500 Dual Rear Tires may only have one
approved direction of rotation. This is to
accommodate the asymmetrical design
(tread pattern) of the On/Off-Road tire and
the use of Outline White Letter (OWL) tires.
7

20_DJD2_OM_EN_USC_t.book Page 445
