2020 NISSAN X-TRAIL start


> (GLW    0RGHO 7$@
8-12
Maintenance anddo-it-yours elf
JVM0421X
MR20DD engine
*
1
Oil filler cap
*
2
Oil drain plug
*
3
Oil filter
1. Place alarge drainpanunder thedrain plug.
2. Remove thedrain plugwithawrench.
3. Remove theoilfiller capand completely drainthe
oil.
If the oilfilter isto be changed, removeand
replace itat this time.
CAUTION:
Waste oilmust bedisposed ofproperly. Check
your local regulations.
4. Remove theplastic coverovertheoilfilter location
by removing thesmall plastic clipsasillustrated.
(For QR25DE engine)
5. Loosen theoilfilter withanoilfilter wrench.
6. Remove theoilfilter byturning itby hand.
7. Wipe theengine oilfilter mounting surfacewitha
clean cloth.
Be sure toremove anyoldgasket remaining onthe
mounting surface. 8.
Apply newengine oiltothe gasket ofthe new oil
filter.
9. Screw inthe oilfilter untilaslight resistance isfelt
and then tighten anadditional 2/3ofaturn to
secure thefilter.
Oil filter tightening torque:
15 to20 N´m
(1.5 to2.0 kg-m, 11to15 ft-lb)
10. Clean andreinstall thedrain plugandnew washer.
Securely tightenthedrain plugwithawrench. Do
not use excessive force.
Drain plugtightening torque:
29 to39 N´m
(3.0 to4.0 kg-m, 22to29 ft-lb)
11. Refill therecommended engineoiland quantity .
(See ªRecommended Fluids/lubricants andcapa-
citiesº (P.9-2) .)
When fillingtheengine oil,donot remove
the dipstick.
12. Securely installtheoilfiller cap.
13. Start theengine.
14. Check thedrain plugforany sign ofleakage.
15. Dispose ofthe used oilinthe proper manner.
Check yourlocal regulations.
16. Check theengine oillevel according tothe proper
procedure. (SeeªChecking engineoillevelº (P.8-
10) .) R9M
engine:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVM0436X
*
1
Oil filler cap
*
2
Oil drain plug
*
3
Oil filter
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
SDI2149
1 Oilfiller element
2 O-ring
3 Oilfilter cover
1. Place alarge drainpanunder thedrain plug.
2. Remove thedrain plugwithawrench.
3. Remove theoilfiller capand completely drainthe
oil.
If the oilfilter isto be changed, removeand
replace itat this time.
CAUTION:
Waste oilmust bedisposed ofproperly. Check
your local regulations.
4. Loosen theoilfilter cover withawrench.
5. Remove theengine oilfilter cover thentheoilfilter
element.
6. Remove therubber O-ring fromthefilter cover.
7. Wipe theentire oilfilter cover withaclean cloth.
Be sure toremove anyoldO-ring remaining onthe
mounting surface. 8.
Apply newengine oiltothe O-ring.
Install thenew O-ring onthe new oilfilter element.
9. Insert theoilfilter element intotheengine oilfilter
cover.
10. Screw inthe oilfilter cover untilaslight resistance
is felt, and then tighten thefilter completely .
Oil filter cover tightening torque:
25 N´m
(2.6 kg-m, 18ft-lb)
11. Clean andreinstall thedrain plugandnew washer.
Securely tightenthedrain plugwithawrench. Do
not use excessive force.
Drain plugtightening torque:
50 N´m
(5.1 kg-m, 36.9ft-lb)
12. Refill therecommended engineoiland quantity .
(See ªRecommended Fluids/lubricants andcapa-
citiesº (P.9-2) .)
13. Securely installtheoilfiller cap.
14. Start theengine.
15. Check thedrain plugforany sign ofleakage.
16. Dispose ofthe used oilinthe proper manner.
Check yourlocal regulations.
17. Check theengine oillevel according tothe proper
procedure. (SeeªChecking engineoillevelº (P.8-
10) .)
After operation
T32A1308 27-3D1A869 1-255E-47E3-9C50-DDE5 E8CFBD36
1. Lower thevehicle carefully tothe ground.
2. Dispose ofwaste oiland filter properly .
PRO TECT ENVIRONMENT
T32A1308 27-208605 74-F3E8-4014 -8CD9-B62C347302 4F
It is illegal topollute drains,watercourses andsoil. Use
authorized wastecollection facilities,including civil
amenity sitesandgarages providing facilitiesfor
disposal ofused oiland used oilfilters. Ifin doubt,
contact yourlocal authority foradvice ondisposal.
The regulations concerningthepollution ofthe
environment willvary from country tocountry.
Maintenance anddo-it-yours elf
8-13
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
T32A1308 27-25E462 0C-DE5B-4B 75-B071-642C43C0D2 7B
CHECKING PARKING BRAKE
T32A130 827-B3B65B 74-4F6E-4C29-8235-6 9F87496ED8 E
Pedal type
GUID-7CD8 8690-D8CF-43E1-96DF-F C6437C 41039
SDI1391D
From thereleased position,depresstheparking brake
pedal slowly andfirmly .If the number ofclicks isout of
the range listed, seeaNISSAN dealer.
6 to 7clicks
Depressing force196N(20 kg,44lb)
Switch type
GUID-56D 5F3BC-8A8 D-4E65-838 8-10DE21AC 8A13
Periodically checktheholding abilityofthe parking
brake byparking onasteep hilland restraining the
vehicle byusing onlytheparking brake.Ifitdoes not
hold satisfactorily ,see aNISSAN dealer.
CHECKING FOOTBRAKE PEDAL
T32A130 827-1F622C6 B-DF2B-4E16-B146-D21BEC4F89C 4
DI1020MR
WARNING:
See aNISSAN dealerforabrake system checkif
the foot brake pedalheight doesnotreturn to
normal.
With theengine running, checkthedistance between
the upper surface ofthe pedal andthemetal floor.Ifit
is out therange listed, seeaNISSAN dealer.
Depressing force
490 N(50 kg,110 lb)
LHD model RHDmodel
*
A
: 75 mm (3.0 in)or
more
*
A
: 85 mm (3.3 in)or
more
Self-adjusting brakes
T32A130827-D 013BB8E-379E-4FA2-A485- E22643A173 FA
Y our vehicle isequipped withself-adjusting brakes.
The disc-type brakesself-adjust everytimethefoot
brake pedalisapplied.
Brake padwear warning
T32A130827-4 DBFEE6A-552E-465B-9 896-BF7E8484B818
The disc brake padshaveaudible wearwarnings.
When abrake padrequires replacement, itwill make a
high pitched scraping soundwhenthevehicle isin
motion. Thisscraping soundwillfirst occur onlywhen
the brake pedalisdepressed. Aftermore wearofthe
brake pad,thesound willalways beheard evenifthe
brake pedal isnot depressed. Havethebrakes
checked assoon aspossible ifthe wear warning
sound isheard.
Under somedriving orclimate conditions, occasional
brake squeaks, squealsorother noises maybeheard.
Occasional brakenoiseduring lighttomoderate stops
is normal anddoes notaffect thefunction or
performance ofthe brake system.
Proper brakeinspection intervalsshouldbefollowed.
For additional information, seeaseparate maintenance
booklet.
BRAKE BOOSTER
T32A1308 27-44610C 9A-C5C7-4D F3-80B7-849 08CFA7E50
Check thebrake booster function asfollows:
1. With theengine off,depress andrelease thefoot
brake pedalseveral times.When thebrake pedal
movement (distanceoftravel) remains thesame
from onepedal application tothe next, continue on
to the next step.
2. While depressing thefoot brake pedal, startthe
engine. Thepedal height should dropalittle.
3. With thefoot brake pedaldepressed, stopthe
engine. Keep thepedal depressed forabout 30
seconds. Thepedal height should notchange.
Maintenance anddo-it-yours elf
8-15
BRAKES
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
Outer sideofthe instrument panel
GUID-98D 0498D-295 5-47C0-AA0 9-13C3DDEC AE27
JVM0387X
For allLHD model
JVM0445X
For Stop/Start SystemorIdling StopSystem (ifequipped)
1. Be sure theignition switchisin the ªOFFº
position.
2. Besure theheadlight switchisin the ªOFFº
position.
3. Remove thefuse boxcover.
4. Locate thefuse thatneeds tobe replaced.
5. Remove thefuse using thefuse puller
*
A
.
SDI1754
6. Ifthe fuse isopen
*
A
, replace itwith anew fuse
*
B
.
If the new fuse alsoopens, afterinstalling, havethe
electrical systemchecked, andifnecessary repaired,
by aNISSAN dealer.
Maintenance anddo-it-yours elf
8-25
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
