2020 MAZDA MODEL CX-9 Owners Manual (in English)

9Specifications
Technical information about your Mazda.
Identification Numbers..................... 9-2 Vehicle Information Labels.......... 9-2
Specifications..................................... 9-4 Specifications............................... 9-4
Personalization Featur es...................9-9
Personalization Features............... 9-9
9-1
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

Vehicle InformationLabels
▼Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on a
plate attached to the cowl panel located on
the left corner of the dashboard. This plate
can easily be seen through the windshield.
▼Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
▼ Chassis Number
Open the cover shown in the figure to
check the chassis number.
▼Vehicle Emission Control
Information Label (U.S.A. and
Canada)
Specifications
Identification Numbers
9-2
CX-9_8HT8-EA-19I_Edition2_old
2019-9-24 13:14:55

▼Tire Pressure Label
▼Engine Number
Forward
Specifications
Identification Numbers
9-3
CX-9_8HT8-EA-19I_Edition2_old
2019-9-24 13:14:55

Specifications
▼Engine
Item
Specification
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 2,488.5 ml (2,488.5 cc)
Compression ratio 10.5
▼Electrical System
Item
Classification
Battery 12V-60Ah/20HR or 12V-65Ah/20HR
Spark-plug number Mazda Genuine spark plug
*1PY8V-18-110
*1 The spark plugs provide the SKYACTIV-G its optimum performance. Consult an Authorized Mazda Dealer
for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-22.
Coolant FL-22 type
Automatic transaxle fluid Mazda Genuine ATF FZ
Transfer case oil Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
▼Capacities
(Approximate Quantities)
Item
Capacity
Engine oil With oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
Without oil filter replacement 4.6 L (4.9 US qt, 4.0 Imp qt)
Specifications
Specifications
9-4
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

ItemCapacity
Coolant U.S.A. and Canada
9.9 L (10.5 US qt, 8.7 Imp qt)
Mexico 9.8 L (10.4 US qt, 8.6 Imp qt)
Automatic transaxle fluid 8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil 0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Fuel tank FWD
72.0 L (19.0 US gal, 15.8 Imp gal)
AWD 74.0 L (19.5 US gal, 16.3 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
▼Dimensions
U.S.A. and Canada
Item
Vehicle specification
Overall length 5,075 mm (199.8 in)
Overall width 1,969 mm (77.5 in)
Overall height 1,752 mm (69.0 in)
Front tread 1,659 mm (65.3 in)
Rear tread 1,656 mm (65.2 in)
Wheelbase 2,928 mm (115.3 in)
Mexico
ItemVehicle specification
Overall length 5,075 mm (199.8 in)
Overall width 1,969 mm (77.5 in)
Overall height 1,747 mm (68.8 in)
Front tread 1,659 mm (65.3 in)
Rear tread 1,656 mm (65.2 in)
Wheelbase 2,928 mm (115.3 in)
▼We i g h t s
U.S.A. and Canada
Item We i gh t
FWD AWD
GVWR (Gross Vehicle Weight Rating) 2,572 kg (5,670 lbs) 2,641 kg (5,822 lbs)
GAWR (Gross Axle Weight Rating) Front 1,225 kg (2,701 lbs) 1,250 kg (2,756 lbs)
Rear 1,383 kg (3,049 lbs) 1,427 kg (3,146 lbs)
Specifications
Specifications
9-5
CX-9_8HT8-EA-19I_Edition2_old
2019-9-24 13:14:55

Mexico
ItemWe i g h t
FWD AWD
GVW (Gross Vehicle Weight) Total 2,495 kg (5,500 lbs) 2,565 kg (5,655 lbs)
Front 1,180 kg (2,601 lbs) 1,205 kg (2,657 lbs)
Rear 1,315 kg (2,899 lbs) 1,360 kg (2,998 lbs)
GAW (Permissible axle load) Front 1,200 kg (2,646 lbs) 1,225 kg (2,701 lbs)
Rear 1,370 kg (3,020 lbs) 1,420 kg (3,131 lbs)
▼
Air Conditioner
The type of refrigerant used is indicated on a label attached to the inside of the engine com-
partment. Check the label before recharging
the refrigerant. Refer to Climate Control Sys-
tem on page 5-4.
Item Specification
Refrigerant Type HFC134a (R-134a)
▼Light Bulbs
Exterior light
Light bulb Category
Wat tage UN-R*1 (SAE)
HeadlightsDaytime running lightsParking lights*
Front side-marker lights*
Fog lights*
Signature wing illumination*
Side turn signal lightsHigh-mount brake lightRear side-marker lightsBrake lightsTaillightsLicense plate lights LED
*2―
(― )
Parking lights/Front side-marker lights
*5W Y5W (― )
Front turn signal lights LED type
LED
*2― (― )
Bulb type 21 WY21W (7443NA)
Rear turn signal lights 21WY21W (7443NA)
Reverse lights 18W16W (921)
*1 UN-R stands for United Nations Regulation.*2 LED is the abbreviation for Light Emitting Diode.
Specifications
Specifications
9-6*Some models.
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

Interior light
Light bulbCategory
Wattage UN-R*1
Overhead lights (Front)/Map lights
(Front) LED type
LED*2―
Bulb type 8 ―
Overhead lights (Center)/Map lights
(Center) LED type
LED
*2―
Bulb type 8 ―
Overhead light (Rear) LED type
LED
*2―
Bulb type 10―
Ambient lights
*LED*2―
Vanity mirror lights
*LED type LED*2―
Bulb type 2―
Luggage compartment light LED type
LED
*2―
Bulb type 8 ―
*1 UN-R stands for United Nations Regulation.*2 LED is the abbreviation for Light Emitting Diode.
▼Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Inflation Pressure on page 6-38.
Standard tire
(U.S.A. and Canada)
Tire size Inflation pressure
Front Rear
P255/60R18 107H 230 kPa (34 psi)230 kPa (34 psi)
P255/50R20 104V 230 kPa (34 psi)230 kPa (34 psi)
(Mexico)
Tire size Inflation pressure
Front Rear
P255/50R20 104V 230 kPa (2.3 bar, 33 psi) 230 kPa (2.3 bar, 33 psi)
Specifications
Specifications
*Some models.9-7
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

Temporary spare tire
(U.S.A. and Canada)
Tire sizeInflation pressure
T155/90D17 101M 420 kPa (60 psi)
(Mexico)
Tire sizeInflation pressure
185/80R17 99M 320 kPa (3.2 bar, 46 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 N·m (12―14 kgf·m, 80 ―108 ft·lbf)
▼Fuses
Refer to Fuses on page 6-50.
