2020 MAZDA MODEL CX-5 display

SignalWarning Page
Electric Parking Brake (EPB) Warning Indication/Warning Light*17-26
Check Engine Light*17-26
*Selective Catalytic Reduction (SCR) system Warning Indication/Warning
Light*17-26
Automatic Transaxle Warning Indication 7-26
*AWD Warning Indication7-26
Air Bag/Front Seat Belt Preten
sioner System Warning Light*17-26
Tire Pressure Monitoring System Warning Light*1
Flashing
7-26
Turns on 7-33
(Amber/White) KEY Warning Indication Amber
7-26
White 7-33
(Amber) High Beam Control System (HBC) Warning Indication/Warning Light
*17-26
Blind Spot Monitoring (B
SM) Warning Indication 7-26
(Amber)Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop &
Go function) Warning Indication
7-26
Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Warning Indication7-26
LED Headlight Warning Light*17-26
Smart Brake Support/Smart City Brak
e Support (SBS/SCBS) Warning Indi-
cation 7-33
Low Fuel Warning Indication/Warning Light
7-33
Check Fuel Cap Warning Indication/Warning Light*17-33
Engine Oil Level Warning Light*17-33
Seat Belt Warning Light (Front seat)7-33
When Driving
Instrument Cluster and Display
*Some models.4-25
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

SignalWarning Page
(Red)Seat Belt Warning Light (Rear seat) 7-33
Low Washer Fluid Level Warning Indication
7-33
Door-Ajar Warning Indication7-33
Liftgate-Ajar Warning Indication 7-33
Door-Ajar Warning Light7-33
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
▼ Indication/Indicator Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Indicator Page
(Green)Seat Belt Indicator Light (Rear seat) 2-30
*Front Passenger Air Bag Deactivation Indicator Light*12-71
Security Indicator Light*13-48
Wrench Indication
4-28
*Glow Indicator Light*14-29
*Diesel Particulate Filter Indication4-227
Shift Position Indication
4-66
When Driving
Instrument Cluster and Display
4-26*Some models.
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

SignalIndicator Page
Lights-On Indication/Indicator Light 4-75
Headlight High-Beam Indicator LightHeadlight
High-Low Beam 4-78
Flashing the Headlights 4-78
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-81
Hazard Warning Flasher4-89
AUTOHOLD Active Indicator Light*14-103
Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop &
Go function) indicator Light 4-158
TCS/DSC Indicator Light*1
Traction Control
System (TCS) 4-108
Dynamic Stabil- ity Control(DSC)4-110
Turns on 7-26
*TCS OFF Indicator Light*14-108
*Off-Road Traction Assist Indicator Light*14-111
Select Mode Indication 4-117
(Green)High Beam Control System
(HBC) Indicator Light 4-126
Blind Spot Monitoring (BSM) OFF Indicator Light*1
Malfunction
7-26
Except malfunc- tion
4-132
When Driving
Instrument Cluster and Display
*Some models.4-27
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

SignalIndicator Page
(White)Mazda Radar Cruise Control with St
op & Go function (MRCC with Stop &
Go function) Main Indication 4-152
(Green)Mazda Radar Cruise Control with St
op & Go function (MRCC with Stop &
Go function) Set Indication 4-152
Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Indication4-164
Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) OFF Indicator Light*14-169
Smart City Brake Sup
port (SCBS) Indication Advanced Smart
City Brake Sup- port (Advanced SCBS)4-174
Smart City
Brake Support (SCBS)4-177
Smart Brake Support/Smart City Br ake Support (SBS/SCBS) OFF Indica-
tor Light*1
Advanced Smart City Brake Sup- port (Advanced
SCBS)4-174
Smart City
Brake Support (SCBS)4-177
Smart Brake
Support (SBS) System4-180
*1 The light turns on when the i gnition is switched on for an operation check, and turns off
a few seconds later or when the engine is sta rted. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda Dealer.
▼ Wrench Indication
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to Maintenance Monitor on page
6-16.
When the engine oil replacement period
has arrived.
When Driving
Instrument Cluster and Display
4-28
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

(SKYACTIV-D 2.2)
When the engine oil is deteriorated or
exceeds the specified amount.
When fuel filter (sedimentor) draining
is required. Consult an Authorized
Mazda Dealer.
NOTE
The wrench indication may display
earlier than the preset period depending
on vehicle usage conditions.
Whenever the engine oil is replaced, a
reset of the vehicle engine control unit is
necessary.
Refer to Maintenance Monitor on page
6-16.

▼ Glow Indicator Light
(SKYACTIV-D 2.2)
When the ignition is switched ON, the
glow indicator light turns on. The glow
indicator light turns off when preheating is
finished.

The maintenance period for the glow plug
or a problem in the system may be
indicated under the following conditions.
Have your vehicle inspected by an
Authorized Mazda Dealer.
The glow indicator light does not turn
on when the ignition is switched ON or
it remains on.
The glow indicator light is flashing.
NOTE
If the vehicle is left with the ignition
switched ON without starting the engine
and a long period of time has elapsed
since preheating finished, the preheating
may be performed again and the glow
indicator light may turn on.
When Driving
Instrument Cluster and Display
4-29
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

Instrument Cluster (Type B)

ƒSpeedometer.......................................................................................................... page 4-30
„ Tachometer............................................................................................................ page 4-30
… Multi-information Display (Type B)..................... ................................................ page 4-31
† Dashboard Illumination.........................................................................................page 4-35
▼Speedometer
The speedometer indicates the speed of the
vehicle.
▼Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.

STRIPED
ZONE
RED ZONE
*
1The range varies depending on the type
of gauge. *
1
*1
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
When Driving
Instrument Cluster and Display
4-30
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

▼Multi-information Display (Type B)
INFO switchMulti-information Display (Type B)
The multi-information display indi
cates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Distance-to-empty
Average fuel economy
Current fuel economy
Maintenance Monitor (Except SKYACTIV-D 2.2)
Remaining Diesel Exhaust Fluid (DEF) and Maximum Driving Distance Display
(SKYACTIV-D 2.2)
Blind Spot Monitoring (BSM) Display
Distance Recognition Support System (DRSS) Display
Mazda Radar Cruise Control wi th Stop & Go function (MRCC with Stop & Go function)
System Display
Lane Departure Warning System (LDWS) Display
Lane-keep Assist System (LAS) & Lane De parture Warning System (LDWS) Display
Cruise Control Display
Compass Display
Message Display
When Driving
Instrument Cluster and Display
4-31
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

The screen content changes each time the INFO switch is pressed.
Press the INFO switchPress the INFO switch
Press the INFO switch Press the INFO switch
Press the INFO switch
Press the INFO switch
Current Fuel Economy,
Trip Meter A, Average
Fuel Economy, Outside
Temperature,
Odometer, Fuel Gauge
Current Fuel Economy,
Trip Meter B, Average
Fuel Economy, Outside
Temperature,
Odometer, Fuel Gauge
Engine Coolant
Temperature Gauge,
Maintenance Monitor,
Outside Temperature,
Odometer, Fuel Gauge i-ACTIVSENSE display,
Outside Temperature,
Odometer, Fuel Gauge Warning message,
Outside Temperature,
Odometer, Fuel Gauge
*3
*1
*2 *3: Displayed only when a warning occurs. *1: Except SKYACTIV-D 2.2
*2: SKYACTIV-D 2.2
Engine Coolant
Temperature Gauge,
Remaining Diesel
Exhaust Fluid (DEF),
Maximum Driving
Distance Display,
Outside Temperature,
Odometer, Fuel Gauge
Engine Coolant
Temperature Gauge,
Compass,
Distance-to-empty,
Outside Temperature,
Odometer, Fuel Gauge
When Driving
Instrument Cluster and Display
4-32
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07
