6788-2. Steps to take in an emergency
RX350/RX350L_U
Lay the tire on the ground with the
outer surface (valve stem) facing up.
Before raising the tire, make sure
that the hoist assembly is perpendic-
ular to the wheel opening. (Try to
place the tire directly beneath the
vehicle, near where the wire cable is
hanging from.)
Using the jack handle and adapter socket, tighten the tire clamp bolt by turn-
ing it clockwise until the tire is in the correct position and two clicks are heard
as the jack handle skips.
Confirm it is not loose after tighten-
ing:
Push and pull the tire
Try rotating
Visually check to ensure tire is not
hung on surrounding parts.
If looseness or mi sassembly exists,
repeat steps
to .
Repeat step , any time the tire is lowered or disturbed.
Stow the jack and all tools.
4
Valve stem
5
6
7
1
2
27
87
9

6818-2. Steps to take in an emergency
8
When trouble arises
RX350/RX350L_U
NOTICE
■Be careful when driving over bumps with the compact spare tire installed on the vehi-
cle
When driving with the compact spare tire installed, the vehicle height will be different
than when driving with standard tires. Be careful when driving over uneven road sur-
faces, etc.
■Driving with tire chains and the compact spare tire
Do not fit tire chains to the compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving performance.
■When replacing the tires
When removing or fitting the wheels, tires or the tire pressure warning valve and trans-
mitter, contact your Lexus dealer as the tire pressure warning valve and transmitter
may be damaged if not handled correctly.
■When stowing the flat tire (RX350L)
●Ensure that there is no object caught between the tire and the vehicle underbody.
●Securely tighten the spare tire clamp bolt to hold the spare wheel carrier by the hook.
●Stow the flat tire in the spare tire location. Failure to do so may cause damage to the
spare tire carrier. Proper storage reduces the possibilit y of injury in a collision or
during sudden braking.
●Have the flat tire repaired and the spare tire replaced with it as soon as possible.
■Proper storage of the spare tire (RX350L)
●If the spare tire clamp bolt is turned withou t a tire on the hoist assembly, the wire cable
may not be able to be lowered. If the wire cable cannot be lowered, contact your
Lexus dealer.
●If the hoist assembly is slanted when stowing a
tire, the hoist assembly may become stuck in
the wheel opening and the tire may not be
raised properly, causing damage to the wheel
or the wire cable.

6968-2. Steps to take in an emergency
RX350/RX350L_U
WARNING
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surrounding
area is clear to avoid striking other vehicles, objects or people. The vehicle may also
lunge forward or lunge back suddenly as it becomes free. Use extreme caution.
■When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may cause an acci-
dent resulting in deat h or serious injury.
NOTICE
■To avoid damage to the tran smission and other components
●Avoid spinning the front wheels and depre ssing the accelerator pedal more than nec-
essary.
●If the vehicle remains stuck even after th ese procedures are performed, the vehicle
may require towing to be freed.
●When a warning message for the automatic transmission fluid temperature is dis-
played while attempting to free a stuck vehicle, immediately remove your foot from
the accelerator pedal and wait until the warning message disappears. Otherwise, the
transmission may become damaged. ( P. 662)

698
RX350/RX350L_U9-1. Specifications
*1:RX350
*2:RX350L
*3:Unladen vehicle
*4: Vehicles with towing package
*5: For GGL25L-BWZGBA models*9
*6: Except for GGL25L-BWZGBA models*9
*7: Vehicles with separate seat
*8: Vehicles with bench seat
*9: The model code is indicated
on the Certification Label. (P. 699)
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
Overall length192.5 in. (4890 mm)*1
196.9 in. (5000 mm)*2
Overall width74.6 in. (1895 mm)
Overall height*367.7 in. (1720 mm)
Wheelbase109.8 in. (2790 mm)
Tread
Front64.4 in. (1635 mm)*1
64.5 in. (1640 mm)*2
Rear64.0 in. (1625 mm)*1
64.1 in. (1630 mm)*2
Vehicle capacity weight
(Occupants + luggage)
1050 lb. (480 kg)*1, 5
920 lb. (420 kg)*1, 6
1140 lb. (520 kg)*2, 7
1235 lb. (560 kg)*2, 8
Trailer Weight Rating*4
(Trailer weight + cargo weight)3500 lb. (1585 kg)

7009-1. Specifications
RX350/RX350L_U
■Engine number
The engine number is stamped on
the engine block as shown.
*: The engine oil capacity is a reference quantity to be used when changing the engine oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.
Engine
Model3.5 L 6-cylinder (2GR-FKS)
Type6-cylinder V type, 4-cycle, gasoline
Bore and stroke3.70  3.27 in. (94.0  83.0 mm)
Displacement210.9 cu. in. (3456 cm3)
Valve clearance (engine cold)Automatic adjustment
Drive belt tensionAutomatic adjustment
Fuel
Fuel typeUnleaded gasoline only
Octane Rating87 (Research Octane Number 91) or higher
Fuel tank capacity (Reference)19.2 gal. (72.5 L, 15.9 Imp. gal.)
Lubrication system
Oil capacity
(Drain and refill - reference
*)
With filterVehicles with towing package
5.8 qt. (5.5 L, 4.8 Imp. qt.)
Vehicles without towing package
5.7 qt. (5.4 L, 4.8 Imp. qt.)
Without filter5.6 qt. (5.3 L, 4.7 Imp. qt.)

7029-1. Specifications
RX350/RX350L_U
*: The coolant capacity is a reference quantity. If replacement is necessary, contact your Lexus dealer.
Cooling system
Capacity*
RX350 (Vehicles with out towing package)
9.5 qt. (9.0 L, 7.9 Imp. qt.)
RX350 (Vehicles with towing package)
10.5 qt. (9.9 L, 8.7 Imp. qt.)
RX350L
13.1 qt. (12.4 L, 11 Imp. qt.)
Coolant type
Use either of the following: • “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based
non-silicate, non-amine, non-nitrite, and non-
borate coolant with long-life hybrid organic
acid technology
Do not use plain water alone.
Ignition system (spark plug)
MakeDENSO FK20HBR8
Gap0.03 in. (0.8 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
Electrical system
Battery
Open voltage at 68F (20C):12.6 V or higher: Fully charged
12.2 — 12.4 V: Half charged
12.0 V or lower: Discharged
(Turn the engine switch off and turn on the head-
lights for 20 to 30 seconds.)
Charging rates5 A max.

761Alphabetical index
RX350/RX350L_U
Daytime running light system .......... 254
DefoggerOutside rear view mirrors .............. 513
Rear window ......................................... 513
Windshield ............................................. 513
Differential ............................................... 703
Dimensions ............................................. 698
Dinghy towing........................................ 230
Display Dynamic radar cruise control with full-speed range ................... 300
LKA (Lane-Keeping Assist) .........296
Multi-information display ..................90
Warning messages............................ 661
Do-it-yourself maintenance .............590
Doors Automatic door locking and unlocking system .............................. 127
Door lock ................................................ 126
Outside rear view mirrors .............. 184
Power back door ................................ 130
Rear door child-p rotectors ............ 127
Side doors ...............................................124
Side windows ........................................ 187 Drive information .....................................94
Drive-start control ........ 203, 238, 243
Driver’s seat belt
reminder light .... 656
Driver’s seat position memory.......... 172
Driving Break-in tips ......................................... 204
Correct posture .................................... 30
Driving mode select switch .......... 373
Procedures ........................................... 202
Winter drive tips ................................384
Driving position memory .................... 172 Memory recall function .................... 175
Power easy access system ............. 172
Dynamic radar cruise control with full-speed range....................... 300
Dynamic Torque Control AWD system .....................................................379
D

762Alphabetical index
RX350/RX350L_U
Eco drive mode ..................................... 373
Eco Driving Indicator........................... 105
EDR (Event data recorder) ...................10
Electric Power Steering (EPS) ....... 378Warning light ...................................... 655
Electronic key ......................................... 120 Battery-saving function .....................147
If the electronic key does not operate properly............................ 684
Replacing the battery .......................623
Emergency flashers ............................. 644
Emergency, in case of If a warning buzzer sounds.......... 654
If a warning light turns on.............. 654
If a warning message is displayed.............................................. 661
If the battery is discharged ........... 687
If the electronic key does not operate properly............................ 684
If the engine will not start............... 682
If you have a flat tire ......................... 666
If you lose your keys .................. 121, 123
If you think something is wrong ...................................................652
If your vehicle becomes stuck .... 695
If your vehicle has to be stopped in an emergency .. 645
If your vehicle needs to be towed................................................... 646
If your vehicle overheats ................692 Engine
ACCESSORY mode ..................... 232
Compartment ..................................... 594
Engine switch ........................................ 231
Hood........................................................ 592
How to start the engine.................... 231
Identification number.......................700
If your vehicle has to be stopped in an emergency.......... 645
Ignition switch (engine switch) ..... 231
Overheating......................................... 692
Engine coolant Capacity................................................. 702
Checking .............................................. 598
Preparing and checking before winter ....................................384
Engine coolant temperature gauge ........................................................ 86
Engine immobilizer system .................. 74
Engine oil Capacity.................................................700
Checking ...............................................595
Preparing and checking before winter ....................................384
Engine oil maintenance data ............597
Engine switch ........................................... 231
Enhanced VSC ..................................... 378
EPS (Electronic Power Steering) ........ 378 Warning light .......................................655
Event data recorder (EDR)................... 10
E
