2020 LEXUS RX350 Owners Manual

4979-1. For owners
9
For owners
Véhicules avec phares à faisceau
unique
2 Tournez le boulon B du même
nombre de tours dans le même
sens qu'à l'étape 1 .
Si vous n'arrivez pas à régler le phare en
procédant de la sorte, confiez le véhicule à
votre concessionnaire Lexus pour qu'il
règle le faisceau des phares.
Véhicules sans phares à faisceau
unique
Véhicules avec phares à faisceau
unique

4989-1. For owners

499
Index
.What to do if... (Troubleshooting)........................................................ 500
Alphabetical Index.................... 503

500What to do if... (Troubleshooting)
1-1.What to do if... (Troubleshooting)What to do if... (Troubleshooting)
If you lose your mechanical keys,
new genuine mechanical keys can
be made by your Lexus dealer.
( P.440)
 If you lose your electronic keys, the
risk of vehicle theft increases signifi-
cantly. Contact your Lexus dealer
immediately. ( P.440)
 Is the electronic key battery weak or
depleted? ( P.389)
 Is the engine switch in IGNITION
ON mode?
When locking the doors, turn the engine
switch off. ( P.179)
 Is the electronic key left inside the
vehicle?
When locking the doors, make sure that
you have the electronic key on your per-
son.
The function may not operate prop-
erly due to the condition of the radio
wave. ( P.114)
 Is the child-protector lock set?
The rear door cannot be opened from
inside the vehicle when the lock is set.
Open the rear door from outside and then
unlock the child-protector lock. ( P.100)
 Did you press the engine switch
while firmly depressing the brake
pedal? ( P.176)
 Is the shift lever in P? ( P.176)
 Is the electronic key anywhere
detectable inside the vehicle?
( P.113)
 Is the steering wheel unlocked?
( P.177)
 Is the electronic key battery weak or
depleted?
In this case, the engine can be started in a
temporary way. ( P.442)
 Is the battery discharged?
( P.443)
If you have a problem, check the
following before contacting your
Lexus dealer.
The doors cannot be locked,
unlocked, opened or closed
You lose your keys
The electronic key does not
operate properly
The doors cannot be locked or
unlocked
The rear door cannot be opened
If you think something is wrong
The engine does not start
The shift lever cannot be shifted
from P even if you depress the
brake pedal

501What to do if... (Troubleshooting)
Is the engine switch in IGNITION
ON mode?
If you cannot release the shift lever by
depressing the brake pedal with the engine
switch in IGNITION ON mode ( P.181)
It is locked automatically to prevent
theft of the vehicle. ( P.177)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( P.147)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not running) for
a period of time. ( P.179)
 The seat belt reminder light is flash-
ing
Are the driver and the passengers wearing
the seat belts? ( P.416)
 The parking brake indicator is on
Is the parking brake released? ( P.185)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.413, 422)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.67)
Do one of the following to stop the
alarms:
 Unlock the doors.
 Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.422)
 When a warning light turns on or a
warning message is displayed, refer
to P.413, 422.
The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed
When a problem has occurred
If you have a flat tire

502What to do if... (Troubleshooting)
Stop the vehicle in a safe place and
replace the flat tire with the spare
tire. ( P.426)
 Try the procedure for when the vehi-
cle becomes stuck in mud, dirt, or
snow. ( P.449)
The vehicle becomes stuck

503Alphabetical Index
Alphabetical Index
A
A/CAir conditioning filter ...............................386
Front automatic air conditioning system......................................................................... 296
Micro dust and pollen filter...................303
Rear automatic air conditioning system ......................................................................... 307
ABS (Anti-lock Brake System)...............277 Warning light .................................................415
ACA (Active Cornering Assist) ........... 278
Active Cornering Assist (ACA) ........... 278
Adaptive Front-lighting System (AFS) .192
Adaptive Variable Suspension System278
AFS (Adaptive Front-lighting System) .192
Air conditioning filter ................................. 386
Air conditioning system Air conditioning filter ...............................386
Front automatic air conditioning system......................................................................... 296
Micro dust and pollen filter...................303
Rear automatic air conditioning system ......................................................................... 307
Airbags Airbag operating conditions................... 33
Airbag precautions for your child ........ 36
Correct driving posture ............................ 25
Curtain shield airbag operating condi- tions .................................................................. 33
Curtain shield airbag precautions ....... 36
Front passenger occupant classification system ............................................................. 39
General airbag precautions ................... 36
Locations of airbags.................................... 30
Modification and disposal of airbags . 38
Side airbag operating conditions ......... 33
Side airbag precautions ............................ 36
Side and curtain shield airbags operating conditions...................................................... 33
Side and curtain shield airbags precau- tions .................................................................. 36 SRS airbags......................................................30
SRS warning light.........................................414
Alarm ....................................................................67 Warning buzzer ...........................................413
Anchor brackets ..................................... 46, 57
Antennas (smart acc ess system with
push-button start)........................................ 113
Anti-lock Brake System (ABS)...............277 Warning light ................................................ 415
Approach warning...................................... 235
Armrest............................................................ 335
Assist grips ..................................................... 335
Audio system-linked display ...................... 83
Automatic headlight leveling system ..... 191
Automatic High Beam ................................193
Automatic light control system............... 190
Automatic transmission ............................. 180 M mode ........................................................... 183
Paddle shift switches .......................182, 183
Auxiliary boxes ................................... 321, 324
Average fuel economy................................. 80
Average vehicle speed ................................ 80
AWD Control....................................................81
B
Back door .......................................................... 101
Back-up light Wattage ......................................................... 458
Back-up lights Replacing light bulbs .....................395, 401
Battery Battery checking ....................................... 369
If the battery is discharged .................... 443
Preparing and checking before winter..........................................................................283
Warning light .................................................414
Blind Spot Monitor (BSM)....................... 239
Bottle holders ................................................ 320
Brake Brake hold ......................................................188
Fluid...................................................... 368, 457
Parking brake ............................................... 185

504Alphabetical Index
Warning light .................................................413
Brake assist .....................................................277
Break-in tips..................................................... 157
Brightness control Instrument panel light control ................ 78
BSM (Blind Spot Monitor)....................... 239
Buzzer Hands off steering wheel warning (LTA)......................................................................... 226
C
Care Aluminum wheels ..................................... 350
Exterior .......................................................... 350
Interior ............................................................. 353
Seat belts........................................................ 353
Cargo capacity...................................... 161, 164
Cargo hooks ................................................. 322
Cargo net hooks .......................................... 322
Center Display ............................................. 292
Chains .............................................................. 284
Child restraint system Fixed with a LATCH system .................. 54
Fixed with a seat belt...................................50
Front passenger occupant classification system ............................................................. 39
Points to remember .................................... 45
Riding with children ..................................... 45
Types of child restraint system installation method ........................................................... 46
Using an anchor bracket .......................... 57
Child safety Airbag precautions...................................... 36
Battery precautions ......................370, 446
Child restraint system................................. 46
Heated steering wheel and seat heater precautions................................................. 310
How your child should wear the seat belt .............................................................................27
Moon roof precautions ............................149
Panoramic moon roof precautions ....152
Power back door precautions............... 101 Power window lock switch .....................147
Power window precautions .................. 146
Rear door child-protectors ................... 100
Removed electronic key battery precau-
tions .............................................................. 390
Seat belt extender precautions.............. 27
Seat belt precautions .................................. 45
Child-protectors........................................... 100
Cleaning Aluminum wheels ..................................... 350
Exterior........................................................... 350
Interior .............................................................353
Radar sensor ............................................... 205
Seat belts ........................................................353
Clock ........................................................ 75, 336
Coat hooks..................................................... 336
Coin box............................................................321
Compass ......................................................... 346
Condenser ..................................................... 368
Console box ................................................... 318
Consumption screen .................................... 90
Cooling system............................................. 367 Engine overheating................................... 447
Cornering lights .............................................192 Replacing light bulbs ............................... 395
Cruise control Dynamic radar cruise control with full-speed range ......................................230
Cup holders .....................................................319
Current fuel consumption .......................... 80
Curtain shield airbags .................................. 30
Customizable features .............................. 470
D
Daytime running light system .................. 190
Defogger Outside rear view mirrors.................... 298
Rear window ............................................... 298
Windshield ................................................... 298
Differential Rear differential oil......... ..................... ...... 456
Dimension ...................................................... 452
