2020 LEXUS NX300 navigation system

2745-1. Remote Touch
LEXUS NX300 Owners Manual_USA_M78389_en
5-1.Remote Touch
■Switches
10.3-inch display model
“MAP” button
Press this button to display the vehicle’s
current position.
8-inch display model“HOME” button
Press this button to display the home
screen.
“MENU” button
Press this button to display the menu
screen.
Back button
Press this button to display the previous
Touchpad
Slide your finger on the touchpad and move the pointer to select a function, letter
and screen button.
Press the touchpad to enter the selected
function, letter or screen button. Certain
finger movements on the touchpad can
perform functions, su
ch as changing map
scalings and scrolling list screens.
Sub function button
When is displayed on the screen, a
function screen assigned to the screen can
be displayed.
■Using the touchpad
1 Select: Touch the touchpad to
select the desired button on the
screen.
2 Enter: The buttons on the screen
can be selected by either depress-
ing or double tapping on the touch-
pad. Once a button has been
selected, the screen will change.
■Touch operation
Operations are performed by touching
the touchpad with your finger.
 Trace
Trace the pad surface while maintaining
contact with the touchpad. Moving the
cursor and the pointer.
Remote Touch
The Remote Touch can be used to
operate the navigation/multimedia
system display. Owners of models
equipped with a navigation system
should refer to the “NAVIGATION
AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
Remote Touch operation
A
A
B
C
D
E

2765-1. Remote Touch
LEXUS NX300 Owners Manual_USA_M78389_en
8-inch display model
10.3-inch display model
*1: Refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
*2: This function is not made available in some countries or areas.
*3: This function is not made available on some models.
SwitchFunction
Select to displa y the “Destina-
tion” screen.
*1
Select to display the radio con-
trol screen.
*1, 2
Select to display the media con-
trol screen.
*1
Select to display the hands-free
operation screen.
*1
Select to display the “Apps”
screen.
*1, 2
Select to display the Information
screen.
*1 (  P.92)
When an Apple CarPlay con-
nection is established and this
button displays “Apple Car-
Play”, select to display the home
screen of Apple CarPlay.
*1, 2
Select to display the “Setup”
screen.
Select to display the air condi-
tioning control screen.
( P.282)
Select to adjust the contrast and
brightness of the screens, turn
the screen off, etc.
*1, 3
SwitchFunction

2775-1. Remote Touch
LEXUS NX300 Owners Manual_USA_M78389_en
5
Interior features
8-inch display models
The home screen can be display multiple information screens. For details about the
functions and operation of the display, re fer to the respective section and “NAVI-
GATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”
10.3-inch display models
 Split-screen display
Different information can be disp layed on the left and right of the screen. For example, air
conditioning system screen can be displayed and operated while the fuel consumption
information screen is being disp layed. The large screen on the left of the display is called
the main display, and the small screen to the right is called the side display.
Main display
For details about the functions and opera-
tion of the main display, refer to the respec-
tive section and “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
Side display
The following functions can be displayed
and operated on the side display.
Select or to display the desired
screen.
Navigation system*
Audio*
Vehicle information
Air conditioning system ( P.282)
Display overview
A
B
C
D

2785-1. Remote Touch
LEXUS NX300 Owners Manual_USA_M78389_en
Show/hide the side display.*
*: Refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
■Screen display during low temperatures
When the ambient temperature is
extremely low, screen response may be
delayed even if the Re mote Touch is oper-
ated.
E

3947-2. Steps to take in an emergency
LEXUS NX300 Owners Manual_USA_M78389_en
WARNING
■When the compact spare tire is
attached
The vehicle speed may not be correctly
detected, and the following systems may
not operate correctly:
• ABS & Brake assist
• VSC
• TRAC
• Dynamic radar cruise control with full- speed range
• PCS (Pre-Collision System)
• EPS
• AVS (Adaptive Variable Suspension System) (if equipped)
• LTA (Lane Tracing Assist) (if equipped)
• LDA (Lane Departure Alert with steering control) (if equipped)
• Panoramic view monitor (if equipped)
• Lexus parking assist monitor (if equipped)
• Intuitive parking assist (if equipped)
• Navigation system (if equipped)
• BSM (Blind spot monitor) (if equipped)
• Automatic high Beam (if equipped)
Also, not only can the following system
not be utilized fully, but it may even nega-
tively affect the drive-train components:
• AWD system (if equipped)
■Speed limit when using the compact
spare tire
Do not drive at speeds in excess of 50
mph (80 km/h) when a compact spare
tire is installed on the vehicle.
The compact spare tire is not designed
for driving at high speeds. Failure to
observe this precaution may lead to an
accident causing deat h or serious injury.
■After using the tools and jack
Before driving, make sure all the tools
and jack are securely in place in their
storage location to reduce the possibility
of personal injury during a collision or
sudden braking.
NOTICE
■Be careful when driving over bumps
with the compact spare tire installed
on the vehicle
The vehicle becomes lower when driving
with the compact spar e tire compared to
when driving with standard tires. Be
careful when driving over uneven road
surfaces.
■Driving with tire chains and the com-
pact spare tire
Do not fit tire chains to the compact
spare tire.
Tire chains may damage the vehicle body
and adversely affect driving perfor-
mance.
■When replacing the tires
When removing or fitting the wheels,
tires or the tire pr essure warning valve
and transmitter, contact your Lexus
dealer as the tire pressure warning valve
and transmitter may be damaged if not
handled correctly.

LEXUS NX300 Owners Manual_USA_M78389_en
Alphabetical Index467
Wheels ............................................................. 353
Replacing wheels.......................................353
Size......................................................................413
Window glasses ............................................ 138
Window lock switch .....................................139
Windows Power windows........................................... 138
Rear window defogger ..........................280
Washer ..................................................184, 189
Windshield wiper de-ice r ........................ 284
Windshield wipers Intermittent windshield wipers ............. 184
Rain-sensing windshield wipers.......... 186
Winter driving tips....................................... 266
Wireless charger .......................................... 301
Wireless remote control key ......................97 Battery-saving function ..............................117
Locking/Unlocking ..................................... 97
Panic mode...................................................... 98
Replacing the battery...............................356
For information regarding the equipment listed below, refer to
the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S
MANUAL”.
· Audio/visual system
· Navigation system
· Lexus parking assist monitor
· Panoramic view monitor
· Lexus Enform
