3266-3. Do-it-yourself maintenance
The 12-volt battery is located on the
right-hand side of the trunk.
■Before recharging
When recharging, the 12-volt battery pro-
duces hydrogen gas which is flammable
and explosive. Therefore, observe the fol-
lowing precautions before recharging:
●If recharging with the 12-volt battery
installed on the vehicle, be sure to discon-
nect the ground cable.
●Make sure the power switch on the char-
ger is off when connecting and discon-
necting the charger cables to the 12-volt
battery.
■After recharging/reconnecting the 12-
volt battery
●Unlocking the doors using the smart
access system with pu sh-button start may
not be possible immediately after recon-
necting the 12-volt battery. If this hap-
pens, use the wireless remote control or
the mechanical key to lock/unlock the
doors.
●Start the hybrid system with the power
switch in ACCESSORY mode. The
hybrid system may not start with the
power switch turned off. However, the
hybrid system will operate normally from
the second attempt.
●The power switch mode is recorded by
the vehicle. If the 12-volt battery is recon-
nected, the vehicle will return the power
NOTICE
■Do not use any fluid other than
washer fluid
Do not use soapy water or engine anti-
freeze instead of washer fluid.
Doing so may cause streaking on the
vehicle’s painted surfaces, as well as
damaging the pump leading to problems
of the washer fluid not spraying.
■Diluting washer fluid
Dilute washer fluid with water as neces-
sary.
Refer to the freezing temperatures listed
on the label of the washer fluid bottle.
12-volt battery
Location

3466-3. Do-it-yourself maintenance
■If the electronic key battery is depleted
The following symptoms may occur:
●The smart access system with push-but-
ton start and wireless remote control will
not function properly.
●The operational range will be reduced.
Prepare the following before replacing
the battery:
 Flathead screwdriver
 Small flathead screwdriver
 Lithium battery CR2032
■Use a CR2032 lithium battery
●Batteries can be purchased at your Lexus
dealer, local electrical appliance shops or
camera stores.
●Replace only with the same or equivalent
type recommended by the manufacturer.
●Dispose of used batteries according to
the local laws.
1Take out the mechanical key.
NOTICE
■To prevent damage to the vehicle
●Do not allow water or foreign matter to
enter the air intake vent when the
cover is removed.
●Carefully handle the removed filter so
that it will not be damage.
If the filter is damaged, have it replaced
with a new filter by your Lexus dealer.
●Make sure to reinstall the filter and
cover to their original positions after
cleaning.
●Do not install anything to the air intake
vent other than the exclusive filter for
this vehicle or use the vehicle without
the filter installed.
■If “Maintenance Required for Trac-
tion Battery Cooling Parts See
Owner’s Manual” is displayed on the
multi-information display
If the vehicle is continuously driven with
the warning message (indicating that
charging/discharging of the hybrid bat-
tery (traction battery) may become lim-
ited) displayed, the hybrid battery
(traction battery) may malfunction.
Electronic key battery
Replace the battery with a new one
if it is depleted.
Items to prepare
Replacing the battery

3887-2. Steps to take in an emergency
■When the electronic key does not work
properly
●Make sure that the smart access system
with push-button start has not been deac-
tivated using the Remote Touch or at your
Lexus dealer. If it is off, turn the function
on.
●Check if battery-saving mode is set. If it is
set, cancel the function. ( P.111)
Use the mechanical key ( P.98) in
order to perform the following opera-
tions:
■Unlocking the door
1
Pull the driver’s door handle and
insert the mechanical key.
2
Unlock the door.
3
Remove the key, return the handle,
and then pull the handle again.
■Locking the door
1
With the door open, push down the
inside lock button.
2
Close the door.
■Opening the trunk
Turn the mechanical key clockwise to
If the electronic key does not
o
perate properly
If communication between the
electronic key and vehicle is inter-
rupted ( P.112) or the electronic
key cannot be used because the
battery is depleted, the smart
access system with push-button
start and wireless remote control
cannot be used. In such cases, the
doors and trunk can be opened and
the hybrid system can be started by
following the procedure below.
NOTICE
■In case of a smart access system with
push-button start malfunction or
other key-related problems
Take your vehicle with all the electronic
keys provided with your vehicle to your
Lexus dealer as soon as possible.
Locking and unlocking the
doors, opening the trunk and
using the key linked functions

3927-2. Steps to take in an emergency
6Open and close any of the doors of
your vehicle with the power switch
off.
7 Maintain the engine speed of the
second vehicle and start the hybrid
system of your vehicle by turning
the power switch to ON mode.
8 Make sure the “READY” indicator
comes on. If the indicator does not
come on, contact your Lexus
dealer.
9 Once the vehicle’s hybrid system
has started, remove the jumper
cables in the exact reverse order
from which they were connected.
10 Close the exclusive jump starting
terminal cover, and reinstall the fuse
box cover to its original position.
Once the hybrid system starts, have the
vehicle inspected at your Lexus dealer as
soon as possible.
■Starting the hybrid system when the 12-
volt battery is discharged
The hybrid system cannot be started by
push-starting.
■To prevent 12-volt battery discharge
●Turn off the headlights and the audio sys-
tem while the hybrid system is stopped.
●Turn off any unnecessary electrical com-
ponents when the vehicle is running at a
low speed for an extended period, such
as in heavy traffic.
■When the 12-volt battery is removed or
discharged
●Information stored in the ECU is cleared.
When the 12-volt battery is depleted,
have the vehicle inspected at your Lexus
dealer.
●Some systems may require initialization.
(  P.429)
■When removing the 12-volt battery ter-
minals
When the 12-volt battery terminals are
removed, the information stored in the
ECU is cleared. Before removing the 12-
volt battery terminals, contact your Lexus
dealer.
■Charging the 12-volt battery
The electricity stored in the 12-volt battery
will discharge gradually even when the
vehicle is not in use, due to natural dis-
charge and the draining effects of certain
electrical appliances. If the vehicle is left for
a long time, the 12-volt battery may dis-
charge, and the hybrid system may be
unable to start. (The 12-volt battery
recharges automatically while the hybrid
system is operating.)
■When recharging or replacing the 12-
volt battery
●In some cases, it may not be possible to
unlock the doors using the smart access
system with push-button start when the
12-volt battery is discharged. Use the
wireless remote control or the mechani-
cal key to lock or unlock the doors.
●The hybrid system may not start on the
first attempt after the 12-volt battery has
recharged but will start normally after the
second attempt. This is not a malfunction.
●The power switch mode is memorized by
the vehicle. When the 12-volt battery is
reconnected, the system will return to the
mode it was in before the 12-volt battery
was discharged. Before disconnecting
the 12-volt battery, turn the power switch
off.
If you are unsure what mode the power
switch was in before the 12-volt battery
discharged, be especially careful when
reconnecting the 12-volt battery.
■When replacing the 12-volt battery
●Use a 12-volt battery that conforms to
European regulations.
●Use a 12-volt battery that the case size is
same as the previous one (LN2), 20 hour
rate capacity (20HR) is equivalent
(60Ah) or greater, and performance rat-
ing (CCA) is equivalent (345A) or
greater.

4218-2. Customization
8
Vehicle specifications
■Smart access system with push-button start and wireless remote control
(  P.99, 110)
■Smart access system with push-button start ( P.99, 110)
■Wireless remote control ( P.96, 99, 103)
FunctionDefault settingCustomized set-
ting
Operating signal (Buzzers)5OffOO1 to 7
Operation signal (Emergency
flashers)OnOffOO
Time elapsed before automatic
door lock function is activated if
door is not opened after being
unlocked
60 seconds
Off
OO30 seconds
120 seconds
Open door warning buzzerOnOffO
FunctionDefault settingCustomized set-ting
Smart access system with push-
button startOnOffO
Smart door unlockingDriver’s doorAll the doorsOO
Time elapsed before unlocking
all the door when gripping and
holding the driver’s door handle
2 seconds
Off
O1.5 seconds
2.5 seconds
Number of consecutive door
lock operations2 timesAs many as desiredO
FunctionDefault settingCustomized set-ting
Wireless remote controlOnOffO
Unlocking operation
Driver’s door
unlocked in one step, all doors
unlocked in two step
All doors unlocked in one stepOO
ABC
ABC
ABC

Alphabetical index449
Door courtesy lights ....................................277
Door lockDoors .................................................................. 99
Smart access system with push-button start ................................................................... 110
Wireless remote control........................... 97
Doors ................................................................... 99 Automatic door lock ing and unlocking
system ............................................................102
Door glasses ..................................................128
Door lock.......................................................... 99
Open door warning bu zzer .......100, 102
Outside rear view mirrors ......................125
Rear door child-protectors ....................102
Drive distance .................................................. 80
Drive info 1/Drive info 2 .............................. 80
Driver’s seat position memory .................. 118 Driving position memory .......................... 118
Memory recall function ............................. 119
Drive-start control ........................................135
Driving................................................................134 Break-in tips ...................................................135
Correct driving posture .............................23
Driving Mode Select switch ................... 212
Hybrid vehicle driving tips ......................251
Procedures ..................................................... 134
Winter drive tips......................................... 253
Driving information display ........................ 80
Driving Mode Select switch...................... 212
Driving range ................................................... 80
Driving support system information display ...............................................................................81
Dynamic radar cruise control with full- speed range..................................................196Warning message..................................... 204
E
ECB (Electronically Controlled Brake Sys- tem) .................................................................247
Eco drive mode .............................................. 212
EDR (Event data recorder) ........................... 8
Elapsed time ..................................................... 80 Electric motor (traction motor) ................ 60
Electric Power Steering (EPS)
Function .......................................................... 247
Warning light .............................................. 366
Electronically Controlled Brake System (ECB) .............................................................247
Electronic key .................................................. 96 Battery-saving function................................ 111
If the electronic key does not operate properly ...................................................... 388
Replacing the battery ...............................346
Emergency, in case of If a warning buzzer sounds...................364
If a warning light turns on.......................364
If a warning message is displayed ..... 374
If the 12-volt battery is discharged ... 390
If the electronic key does not operate properly ...................................................... 388
If the fuel filler do or cannot be opened
..........................................................................387
If the hybrid system will not start ....... 385
If the vehicle is trapped in rising water ..........................................................................357
If you have a flat tire ..................................378
If you lose your keys .................................387
If you think something is wrong..........362
If your vehicle becomes stuck ............ 398
If your vehicle has to be stopped in an emergency ................................................ 356
If your vehicle needs to be towed .... 359
If your vehicle overheats ....................... 395
Emergency flashers .................................... 356
Energy monitor ............................................... 88
Engine ACCESSORY mode............................... 146
Compartment................................................321
Hood ................................................................. 319
How to start the hybrid system.............143
Identification number ................................ 401
If the hybrid system will not start ....... 385
If your vehicle has to be stopped in an emergency ................................................ 356

452Alphabetical index
Jack handle .................................................... 379
Jam protection functionMoon roof ........................................................ 131
Power trunk opener and closer ...........107
Power windows............................................128
K
Keyless entrySmart access system with push-button start ................................................................... 110
Wireless remote control........................... 97
Keys...................................................................... 96 Battery-saving function ............................... 111
Electronic key ................................................. 96
If the electronic key does not operate properly...................................................... 388
If you lose your keys................................. 387
Key number plate ......................................... 96
Keyless entry ............................... 99, 105, 110
Mechanical key.............................................. 96
Power switch ................................................. 143
Replacing the battery............................... 346
Warning buzzer ............................................ 110
Wireless remote control........................... 97
Knee airbags .................................................... 28
L
Lane Tracing Assist (LTA) ........................ 185 Operation....................................................... 185
Warning messages ....................................193
Language (multi-information display) ... 82
LATCH anchors ............................................. 49
Lever Auxiliary catch lever ...................................319
Hood lock release lever...........................319
Internal trunk release lever .....................107
Shift lever......................................................... 150
Turn signal lever ...........................................154
Wiper lever.....................................................164
Lexus climate concierge .......................... 263
Lexus Enform Safety Connect.................. 54 Lexus Safety System + 2.0 ........................ 172
Automatic High Beam ..............................162
Dynamic radar cruise control with full-
speed range ............................................... 196
LTA (Lane Tracing Assist) ..................... 185
PCS (Pre-Collision System) ................. 178
RSA (Road Sign Assist)........................... 194
License plate lights........................................159 Light switch .................................................... 159
Replacing light bulbs ................................. 351
Light bulbs Replacing ........................................................ 351
Wattage ......................................................... 406
Lights Automatic High Beam system ..............162
Front interior lights .................................... 278
Front personal lights.................................278
Headlight switch.......................................... 159
Interior lights list .......................................... 277
Interior lights ................................................. 277
Rear interior lights .....................................278
Rear personal lights .................................. 278
Trunk light ....................................................... 107
Turn signal lever .......................................... 154
Vanity lights ..................................................284
Wattage ......................................................... 406
Welcome light illumination control ... 160
Lock steering column ..................................143
Low profile tire.............................................. 329
LTA (Lane Tracing Assist) ........................ 185 Operation ....................................................... 185
Warning messages.................................... 193
Luggage mat ................................................. 283
M
Maintenance
Do-it-yourself maintenance ...................317
General maintenance .............................. 313
Maintenance data ..................................... 400
Maintenance requirements ....................312
Malfunction indicator la mp ..................... 365
Master warning light .................................... 371

454Alphabetical index
.......................................................................... 156
Warning light ............................................... 370
Warning message...................................... 156
Parking lights ...................................................159 Light switch .................................................... 159
Parking Support Brake function (rear- crossing vehicles) ..........................228, 240Function .......................................................... 240
Parking Support Brake function (rear pedestrians) ..................................... 228, 244Function .......................................................... 244
Parking Support Brake function (static objects) ..............................................228, 234Function .......................................................... 234
PCS (Pre-Collision System) .....................178 Function ............................................................178
PCS OFF switch ......................................... 180
Warning light ............................................... 370
Personal lights................................................277
PKSA (Parking Support Alert) ................ 214
PKSB (Parking Support Brake)............. 228 Warning message..................................... 232
Power control unit.......................................... 63
Power control unit coolant ...................... 323 Capacity .........................................................403
Checking ....................................................... 323
Preparing and checking before winter......................................................................... 253
Power easy access system ......................... 118
Power outlet .................................................. 284
Power steering (Elect ric power steering
system)...........................................................247 Warning light ...............................................366
Power switch ...................................................143 Auto power off function ...........................146
Changing the power switch modes ..146
If your vehicle has to be stopped in an
emergency ................................................356
Starting the hybrid system....................... 143
Power trunk lid .............................................. 103
Power windows ..............................................128 Door lock linked window operation.. 129 Jam protection function ............................129
Operation ....................................................... 128
Window lock switch...................................129
Pre-Collision System (PCS) .....................178 Function ........................................................... 178
PCS OFF switch ......................................... 180
Warning light ...............................................370
R
Radar cruise control (dynamic radar cruise control with full-speed range)...............196
Radiator ........................................................... 324
RCD (Rear Camera Detection) ............. 214 Function .......................................................... 225
Warning message ..................................... 226
RCTA (Rear Cross Traffic Alert) . 214, 221
RCTA Function ............................................................ 221
Warning message ..................................... 222
Rear Cross Traffic Alert (RCTA) . 214, 221
Rear door sunshades ................................. 293
Rear seats Head restraints............................................... 121
Rear side marker lights ...............................159 Light switch .................................................... 159
Rear sunshades ............................................ 293
Rear turn signal lights ..................................154 Replacing light bulbs ................................. 351
Turn signal lever .......................................... 154
Rear view mirror Inside rear view mirror ..............................124
Outside rear view mirrors...................... 125
Rear window defogger ............................. 266
Refueling ...........................................................170 Capacity .......................................................... 401
Fuel types ........................................................ 401
If the fuel filler do or cannot be opened
..........................................................................387
Opening the fuel tank cap ..................... 170
Regenerative braking ..................................... 61
Remote Touch .............................................. 258
Replacing
