2020 KIA NIRO EV Navigation System Quick Reference Guide

2-27
Scheduling a charge and climate controls
You can schedule the charging and climate controls based on the
departure time.
[Setting the departure time
1 On the Charge Management screen, touch
Charging and Climate.
2 Touch on the right of Next Departure.
Using the charging management
features (EV only)
You can configure various features such as scheduling battery
charge and climate controls according to the preset departure
time.
1 On the Electric Vehicle screen, touch Charge
Management.
2 Select and then change the settings.
0000
A
To access the online user’s manual on the Charge
Management screen, touch Menu >
User’s Manual on Web
(QR Code) and then scan the displayed QR code.

2-28
3 Select and then change the settings.
\037
\036\035
a You can set the off-peak electricity time.
b You can charge the battery for the Next Departure,
primarily using the off-peak electricity time.
c You can charge the battery only at the off-peak electricity
time.
4 Touch OK.
0000
A
Scheduled charging is performed only when the charging
connector is connected to the vehicle.
3 Select the departure time and then touch for
the item.
4 Set the time and day and then touch OK.
[Scheduling a charging
1 On the Charge Management screen, touch
Charging and Climate.
2 Check
Scheduled Charging and then touch .

2-29
Setting for location-based charging
You can set to use the scheduled charging and climate controls
only in specific locations and select the current type to use while
charging.
1 On the Charge Management screen, touch
Charging Location.
2 Check Use Location-based Charging and then
set the following details:
\037
\036
\035
a Can set the location to use the scheduled charging and
climate controls.
b Can use the scheduled charging and climate controls only
in the set location.
c Can set the charging current to use in the set location.
0000
A
The charging time may vary depending on charging
conditions.
0000
A
If a problem occurs while charging, lower the charging
current and try again. When the charging current is lowered,
charging may take longer.
[Scheduling climate controls
1 On the Charge Management screen, touch
Charging and Climate.
2 Check
Scheduled Climate and then touch .
3 Set the desired temperature and auto defogging
and then touch OK.

2-30
Setting for charging current
Select the charging current to be used for AC Charging.
1 On the Charge Management screen, touch
Charging Current.
2 Select a charging type to set the charging current.
3 Set the charging current and then touch OK.
0000
A
The charging time may vary depending on charging
conditions.
0000
A
If a problem occurs while charging, lower the charging
current and try again. When the charging current is lowered,
charging may take longer.
Setting the target battery level
You can set the battery amount to charge.
1 On the Charge Management screen, touch Max.
% Charge.
2 Select a charging type to set the target battery
level.
3 Set the target battery level and then touch OK.
0000
A
AC charging ensures the optimal battery performance for a
long time compared to DC charging.
0000
A
When the battery amount reaches the target level, charging
stops. When you charge only the required battery amount, it
can ensure the optimal battery performance for a long time,
compared to full battery charging.

2-31
Seeing the environmental contribution
information
You can check the amount of carbon dioxide reduction compared
to driving with gasoline.
On the ECO Driving screen, touch ECO Contrib..
Seeing the eco-driving information
(EV only)
You can see the eco-driving information of the vehicle.
1 On the Electric Vehicle screen, touch ECO
Driving.
2 Select the desired item to see its information.
0000
A
To access the online user’s manual on the ECO Driving
screen, touch Menu >
User’s Manual on Web (QR Code)
and then scan the displayed QR code.

2-32
Configuring the EV settings (EV only)
You can set to display the warning message when the remaining
battery amount is low for the destination and you can also see
the drivable distance. In winter, you can also set to increase the
battery temperature in advance.
1 On the Electric Vehicle screen, touch EV Settings.
2 Select and then change the settings.
0000
A
Available options may differ depending on the vehicle
model and specifications.
0000
A
To access the online user’s manual on the EV Settings
screen, touch Menu >
User’s Manual on Web (QR Code)
and then scan the displayed QR code.
Seeing the EV economy history
You can check the driving dates, distances, and average EV
economy for previous driving records.
On the ECO Driving screen, touch EV Economy
History.
0000A When there is the best fuel economy, appears before the
record.
0000
A
To delete a record, touch Menu >
Delete History.

2-33
Winter Mode
000EWinter Mode: Can increase the battery temperature in
advance to enhance the charging and driving performance
when scheduling charge or climate controls in winter. This
decreases the drivable distance because it causes to drain the
battery faster.
Warning
000ERange Warning: When the destination is beyond your reach
with the remaining battery amount during route guidance,
the range warning appears.
EV Route
000EShow on the Map: When the destination is guided using the
navigation system, the drivable range under the remaining
battery amount appears on the route. The drivable range
appears in blue, the range beyond reach appears in gray, and
the icon to search for charging stations also appears.
