2020 INFINITI Q50 Towing Guide

TABLE OF CONTENTS

1
Introduction

2
Towing Equipment

3
What I s Right for You

9
Preparing Your V ehicle

13
Towing Safety

16
Towing Tips

20
Towing Glossary

2 2
Protection

23
The Total Ownership Experience

INFINITI
TOWING GUIDE

The 2020 IN FINITI Towing Guide provides information for
currently available 2020 INFINITI vehicles. This publication will
be amended as new vehicles are introduced.

2020

For important safety warnings, please read and follow your vehicle owner’s manual.

2020 INFINITI Towing Guide


1
SAFETY IS PRIORITY ONE
Obviously, your first concern should be safety. Your vehicle was designed to be used
primarily to carry passengers and cargo. Always remember that towing a trailer places
additional loads on your vehicle’s engine, drivetrain, suspension, steering, braking, and
other systems. Therefore, be certain that your vehicle can meet the demands of the towing
application you have in mind.

Rent or purchase only the highest -quality towing and safety equipment you can find.
Rein forced tow hitches designed especially for certain INFINITI vehicles are available from
your INFINITI retailer. Hitches for other INFINITI models — if INFINITI recommends towing
with that vehicle — should be bought from and installed by a professional supplier of towing
equipment . Carefully review all information and literature provided with any hitch you
purchase for safety and proper use information. Finally, it is important to follow the towing
capacity limit set for your specific vehicle and to ensure that your vehicle is in top
mechanical condition, especially the tires, brakes, suspension , and engine cooling system.
See your vehicle owner’s manual for details.

NEVER EXCEED THE ESTABLISHED TOWING CAPACITY
Towing capacities vary from vehicle to vehicle . See the towing information in your vehicle
owner’s manual to confirm whether your 20 20 INFINITI vehicle can be used for towing and
if so it’s towing capacity .

EQUIP YOUR INFINITI FOR TOWING
The frequency and type of towing dictate the manner in which y ou equip your vehicle. If
you plan to tow often, either for recreation or work, select the engine size, transmission
type, suspension , and towing capacity that are best suited to your requirements. This guide
can help you select the proper equipment.

RE AD THIS GUIDE BEFORE YOU TOW
This guide was designed to provide an overview of safe towing practices. Here, y ou will
find information on towing equipment, safety, proper loading and driving techniques,
towing tips , and much more.

It is also a good idea to discuss your towing requirements with either your INFINITI retailer
or a professional supplier of towing equipment before you equip your INFINITI vehicle for
towing. Finally, there are state and local laws on towing that you should review to ensure
compli ance with all regulations.

CAUTION : INFINITI recommends you do not use your new vehicle to tow a trailer or
haul a heavy load for the first 500 miles (800 km) of use . Your engine, axle or other parts
could be damaged. For the first 500 miles that you tow a trailer, do not drive over 50 mph
and do not make starts at full throttle. This helps your engine and other parts of your
vehicle wear in at heavier loads.







INTRODUCTION

2020 INFINITI Towing Guide


2
RENTING
The first thing to keep in mind when renting any type of tow equipment, trailer, tow dolly, is
to rent only from professional companies that specialize in towing and towing equipment.
S pecialized companies should hire professional staff that can assist you in selecting and
installing the proper towing equipment for your INFINITI vehicle.

When renting, make sure you have your vehicle owner’s manual on hand so that you can
reference the towing capacities for your specific vehicle . Make certain that the tow
equipment and components you rent do not exceed yo ur maximum towing capacity. Make
sure that any related towing equipment you rent has the proper weight class rating for your
maximum intended towed load weight, and the maximum Gross Combined Weight Rating.

While you a re at the rental company , ask questions. How much does the empty trailer
weigh? How much weight will the trailer hold? What is the trailer ’s tongue load? W ith what
type of brakes is it equipped (if any) ? All of these factor s have an effect on whether your
INFINITI vehicle is capable of safely pulling that type of trailer, dolly, or piece of tow
equipment.

Make certain that the trailer stoplights, taillights, turn signals, and brakes (if equipped) are
connected and are operat ing correctly, and that all safety equipment is properly installed.
C heck the safety chain s/cables , tie-downs, etc.

For safer operation, carefully inspect the condition of the trailer and towing equipment.
Specifically, check to make sure the tires are not worn excessively and are properly inflated.
Make sure there are no t any broken welds, missing bolts, and that the hitch components
are not damaged. Towing safety should be a high priority when choosing and renting
towing equipment, including hitches.

WARNING: NEVER RENT A CLAMP -ON -TYPE HITCH . The hitch should not be
attached to or affect the operation of the impact -absorbing bumper. Use only a
permanent -type hitch properly attached to the vehicle to help avoid personal injury or
property damage.

PURCHASING
If you are buying a trailer, be sure that your INFINITI vehicle has the towing capacity to pull
it. Refer to your vehicle owner’s manual for detailed information regarding the towing
capacity of your specific vehicle. Your vehicle owner’s manual should ALWAYS be
referenced before making any towing decisions.

Natu rally, you will want to select the towing and safety equipment that adheres to federal
safety regulations, as well as any regulations in any state in which you may travel.
TOWING EQUIPMENT

2020 INFINITI Towing Guide


3
And if you plan to tow often, consider convenience. Quick -disconnect trailer light
c onnectors and ratchet -type tie -downs, for example, make the job go faster and easier and
are usually worth the extra small investment. Purchase towing items such as hitches and
hitch balls only from your INFINITI retailer or a professional supplier of towing equipment.

If you are intending to use your vehicle to tow a trailer you already own, you must ensure
that your loaded trailer remains well within your vehicle's towing capacity as specified in
the vehicle owner's manual. In addition, you should purcha se the right type, style, and class*
of hitch and towing equipment to properly adapt the trailer to your vehicle.


TYPES OF EQUIPMENT
Towing requires a variety of equipment, and , depending upon the application, there can be
several types or styles of eac h piece of equipment. Working with your INFINITI retailer or a
professional supplier of towing equipment , it should be relatively simple to determine the
proper type of equipment for your specific vehicle given the intended application. This
section explains the most common pieces of towing equipment available .

HITCHES
Whichever type of hitch you use, it should be firmly bolted to your vehicle, and should be of
the appropriate weight class for the trailer, tow dollies or towing equipment you intend to
tow. In addition, keep the following in mind:

WARNING - Never modify the vehicle’s braking or exhaust systems or its body
structure/frame when installing the hitch. Altering the brakes or structure on a vehicle
could increase the likelihood of a crash.

 I nstalling an aftermarket hitch may affect the rear crash performance of your vehicle.
Changing the crash performance of a vehicle could lead to more severe vehicle damage,
personal injury or death in a crash. Be sure that the hitch does not interfere in a ny way
with the vehicle’s impact -absorbing bumper.
 Never attach a hitch or towing device to the vehicle bumper. This may affect the
operation of the impact -absorbing bumper. Use only a permanent -type hitch properly
attached to the vehicle to help avoid pe rsonal injury or property damage.


Regularly check to see that all hitch -mounting bolts are securely fastened to ensure
the hitch will not come loose, and remains properly attached to the vehicle to help
avoid property damage, personal injury or death.

CAUTION- If you have a receiver -type hitch using a ball mount ; remove the ball mount
when not towing, or protect it with a special cover, this will help keep it from damage, and
prevent rust from forming on it.

 If you install a hitch yourself, remember that it must be securely attached to the frame
or underbody, according to the manufacturer’s instructions. Never attach a hitch or
towing device to the vehicle axle housing. This may damage the housing, wheel
bearings, wheels, o r tires.


*
Refer to your owner’s manual for the equipment clas s information specific to your vehicle.

WHAT IS RIGHT FOR

2020 INFINITI Towing Guide


4
Hitch Types
Receiver Hitch – A receiver hitch is bolted
directly to the vehicle structure for added
strength and durability. INFINITI bolt-on
recei ver hitches are designed spe cifically for
INFINITI vehicles and include the necessary
reinforcements, with ample clearance around
bumpers, frame members, etc. These hitches
allow for the removal of the ball mount when
not towing. Choose a proper class bal l mount
based on the trailer weight.


Clamp -On Bumper Hitch – This is a temporary
hitch that clamps onto the bumper assembly.

WARNING: DO NOT USE this type of
clamp -on bumper hitch on any INFINITI vehicle
because using it may result in the trailer
separating from the towing vehicle. If the trailer
separates from the vehicle, it could cause a
crash, resulting in property damage and
personal injury, or death. Use of this type of
hitch can also damage the towing vehicle.

Weight-Distributing Hitch System – This type of
system uses a “load -leveling” or “equalizing” hitch.
The weight -distributing feature helps shift the
trailer tongue weight to all the axles of the tow
vehicle and the trailer axles.

Weight –distributing hitches should be used in many
towing conditions. In general, a weight -distributing
hitch system is recommended and should be used if
you plan to tow trailers with a maximum weight
over 5,000 lbs. Refer to trailer and hitch manufacturer for detailed information on load
limits. W eight distributing hitch es are available in many styles and with sway control
accessory options to accommodate trailers with maximum loaded weight and for different
driving conditions.

NOTE – A weight -distribut ing hitch system may affect the operation of trailer surge
brakes. If you are considering use of a weight -distributing hitch system with a surge brake -
equipped trailer, check with the surge brake , hitch , or trailer manufacturer to determine if
and how this can be done. Follow the instructions provided by the manufacturer for
installing and using the weight -distributing hitch system.

2020 INFINITI Towing Guide


5



BALL MOUNT
A ball mount ( also known as a drawbar) is a bar that holds a hitch ball and is inserted into a
receiver -type hi tch. Ball mounts are available for a number of weight capacities (3,500 lbs.,
5,000 lbs. , etc.) , heights, fit different hitch sizes ( 1 1 /4 ”, 2”, etc.), and can be weight -
distributing or non -weight -distributing. Choose a proper ball mount based on class, h itch
size, weight rating , and the vehicle’s tow capacity.


HITCH BALL
A hitch ball is bolted through a ball mount or a h itch
hole in the tow vehicle’s rear bumper. The coupler on
the trailer tongue attaches over the hitch ball.
Like ball mounts, hitch ba lls are available in a
number of weight capacities and sizes. A lways make
sure the hitch ball selected has the proper shank
diameter and weight rating for the ball mount as
well as the coupler on your trailer. Using a 1 7 /8 ”
hitch ball in a 2 ” coupler, for example, could result in the trailer separating from the tow
vehicle. The required hitch ball size is stamped on most trailer couplers.
The diameter of the hitch ball shank must be matched to the ball mount hole diameter. The
shank should be no more tha n 1/ 16 ” smaller than the hole in the ball mount . T o keep the
hitch ball in top condition , a simple maintenance routine is recommended . Coating it with
light grease will minimize wear of both the coupler and hitch ball. Also, by removing the
hitch ball wh en not towing, or by protecting it with a special cover, you will help prevent
rust from forming on it.

TRAILER TONGUE
The tongue is th e part of the trailer that extends forward to meet the tow vehicle , and it
also carries the coupler assembly. Knowledge of the trailer minimum and max imum tongue
load is critical as it can have a significant effect on th e handling and capacity of the tow
vehicle. Refer to your vehicle owner’s manual to view the maximum conventional trailer
tongue load listed for your vehicle. Trailer tongue weight is the amount of downward
pressure exerted onto the hitch ball. Keep the tongue load between 10 -15% of the total
trailer weight. DO NOT exceed the maximum tongue load specification. If the tongue
weight is below the recommended amount, you must move some of the load forward or
add weight to the front frame of the trailer.

2020 INFINITI Towing Guide


6

SAFETY CHAINS/CABLES
Always use suitable safety chains/cables between the tow vehicle and the trailer . If the
hitch should break or become disengaged for s ome reason, these chain s/cables will provide
an emergency connection between the vehicle and the trailer. The ultimate combined
breaking strength of the two chains must be equal to the gross weight of the towed
vehicle(s).

The chains /cables should be cro ssed under the trailer tongue and attached to the hitch or
vehicle frame. Crossing the chain s/cables under the tongue will help prevent the tongue
from hitting the ground should the trailer become disconnected .
B e sure to leave enough slack in the chain s/ cables to turn corners without binding;
however, note that excessive slack will allow the chains/cables to drag on the ground.

WARNING - Do not use S -hooks for attaching the safety chains as they may become
un- hooked while towing. If the S -hook unhooks, the emergency chains/cables will become
detached, so if the tow hitch breaks or becomes disengaged, it will allow the trailer to
completely break away causing property damage and possibly personal injury or death.
The use of S -hooks is illegal in many states.

CAUTION- To avoid damage to the bumper and chains/cables when making a sharp
turn, do not attach the chains /cables too close to the coupler. Consult your trailer
manufacturer for the proper location of the chain /cable attachment to the trailer.

REAR VIEW MIRRORS

WARNING - In many cases, a trailer can block your rear vision when you are using only
the standard INFINITI rear view and outside mirrors. Be careful when changing lanes or
turning. Using only these mirror s could cause an accident as they were not designed for
towing.

“Extended” mirrors specifically designed for trailer towing should be used when your
rearward vision is obstructed. Before using these mirrors, make certain that they comply
with state and l ocal regulations. Telescoping Tow Mirrors are available as an accessory for
certain INFINITI vehicles. Contact your INFINITI retailer for details.

SWAY CONTROL DEVICE
Sudden maneuvers, wind gusts, and buffeting caused by other vehicles can affect trailer
handling. Sway control devices may help control the pivoting motion between tow vehicle
and trailer and make trailer towing easier on the driver . If you choose to use one, contact a
reputable trailer hitch supplier to make sure the sway control device will work with the
vehicle, hitch, trailer and the trailer’s brake system.

A sway control device is recommended for all t owing above 2,000 lb (907 kg). Too low a
percentage of tongue weight can also cause sway. Follow the instructions provided by the
manufacturer for installing and using the sway control device.

2020 INFINITI Towing Guide


7

BREAKAWAY SWITCH
On a trailer with electric brakes, a breakaway switch can automatically activate the trailer
brake system if the trailer becomes separated from the tow vehicle. Should the trailer
become detached, a breakaway switch may help prevent the trailer from wandering into
another lane.

WARNING - A brea kaway switch relies on the power of a trailer battery, so make
sure it is not discharged. Never use the breakaway switch to “park” the trailer on a grade.
The battery would eventually discharge and release the brake, allowing the trailer to roll.

Be sure to leave enough slack in the tether on the breakaway switch to turn corners
without binding. If you do not, the electric trailer brakes will lock-up and not release. See
your trailer manufacturer for proper installation of a breakaway switch that is compatible
with your trailer braking system.

TRAILER LIGHTS
Trailer lights should comply with all applicable federal, state, and local regulations, and
should be in proper working order at all times. If your vehicle is equipped with a towing
package, a 7 -pin trailer harness connector is located at the trailer hitch, under a cover on
the rear bumper on some models for connecting trailer lights. For trailers that use a
different style plug, contact your INFINITI retailer or a professional supplier of towin g
equipment for adaptors to the 7- pin trailer harness.

A trailer’s taillights, stoplights, and turn signal lights must be wired into the towing vehicle’s
electrical system.* Most trailers operate on a four -wire system in which the stoplights and
turn sig nal lights utilize the same wire. Most all INFINITI vehicles have separate wires for
the stoplights and turn signal lights, therefore a device called a “converter” is needed.**
Specifically, a “powered converter” must be used, as a converter of this type c reates only
minimal additional electrical demand (draw) on the vehicle lighting circuits, which helps to
ensure protection for the vehicle’s sensitive electronics.* Always check for correct operation
of the taillights, stoplights, and turn signal lights every time you connect a trailer for
towing. Never replace vehicle fuses with fuses of a higher amperage rating than the
original.

*Vehicles equipped with LED taillights require that wiring be connected at a specific location. For
assistance in
hooking up trailer lights, contact your INFINITI retailer or a professional supplier of
towing equipment.
**QX80 and QX60 vehicles are pre -wired for trailer lighting and do not require a converter.

CAUTION – Improper ly installed or poor quality t railer harness wiring may adversely
affect your vehicle’s electrical system. Use only a n INFINITI approved wiring harness ,
or consult your retailer or a professional supplier of towing equipment for compatible
equipment.
