6-84
Whilst driving
i Information
‡ 'uring normal cruise control opera-
tion, when the SE 7 switch is activat-
ed or reactivated after applying the
brakes, the cruise control will acti-
vate after approximately 3 seconds.
7his delay is normal.
‡ Before activating the cruise control
function, the system will check to
verify that the brake switch is oper-
ating normally. 'epress the brake
pedal at least once after turning 2 1
the ignition or starting the vehicle.
Cruise control switch
2 $ ,
CRUISE/ 7 X U Q V F U X L V H F R Q-
trol system on or
off.
5 ( 6 5 H V X P H V R U L Q F U H D V H V F U X L V H
control speed.
6 ( 7 6 H W V R U G H F U H D V H V F U X L V H F R Q-
trol speed.
& $ 1 & ( / & D Q F H O V F U X L V H F R Q W U R O
operation.
To set Cruise Control speed
2 $ ,
3 X V K W K H & 5 8 , 6 ( button
on the steering wheel to turn the
system on. The CRUISE/
indicator on the LCD display will
illuminate.
2. Accelerate to the desired speed,
Z K L F K P X V W E H P R U H W K D Q P S K
N P K
i Information
For manual transmission vehicles, you
should depress the brake pedal at least
once to set the cruise control after
starting the engine.
Page 347 of 486
6-91
06
The severe weather conditions of
winter quickly wear out tyres and
cause other problems. To minimise
winter driving problems, you should
W D N H W K H I R O O R Z L Q J V X J J H V W L R Q V
Snow or icy conditions
You need to keep sufficient distance
between your vehicle and the vehicle
in front of you.
Apply the brakes gently. Speeding,
rapid acceleration, sudden brake
applications, and sharp turns are
potentially very hazardous practices.
During deceleration, use engine brak-
ing to the fullest extent. Sudden brake
applications on snowy or icy roads
may cause the vehicle to skid.
To drive your vehicle in deep snow, it
may be necessary to use snow tyres
or to install tyre chains on your tyres.
Always carry emergency equipment.
Some of the items you may want to
carry include tyre chains, tow straps
or chains, a flashlight, emergency
I O D U H V V D Q G D V K R Y H O M X P S H U F D E O H V
a window scraper, gloves, ground
cloth, coveralls, a blanket, etc.
Snow tyres
WARNING
Snow tyres should be equivalent
in size and type to the vehicle’s
standard tyres. Otherwise, the
safety and handling of your vehi-
cle may be adversely affected.
If you mount snow tyres on your vehi-
cle, make sure to use radial tyres of
the same size and load range as the
R U L J L Q D O W \ U H V 0 R X Q W V Q R Z W \ U H V R Q D O O
four wheels to balance your vehicle’s
handling in all weather conditions.
The traction provided by snow tyres
on dry roads may not be as high as
your vehicle’s original equipment
tyres. Check with the tyre dealer for
maximum speed recommendations.
i Information
'o not install studded tyres without
first checking local and municipal reg-
ulations for possible restrictions
against their use.
WINTER DRIVING
Page 350 of 486
6-94
Whilst driving
To prevent locks from freezing
To prevent the locks from being fro-
zen, spray approved de-icing fluid or
glycerin into key holes. When a lock
opening is already covered with ice,
spray approved de-icing fluid over the
ice to remove it. When an internal
part of a lock freezes, try to thaw it
with a heated key. Carefully use the
K H D W H G N H \ W R D Y R L G D Q L Q M X U \
Use approved window washer anti-
freeze solution in system
To prevent the window washer from
being frozen, add authorized window
washer anti-freeze solution, as speci-
fied on the window washer container.
Window washer anti-freeze solution
is available from a HYUNDAI autho-
rised repairer, and most vehicle
accessory outlets. Do not use engine
coolant or other types of anti-freeze
solution to prevent any damage to the
vehicle paint.
Do not let your parking brake
freeze
Under some conditions your parking
brake can freeze in the engaged posi-
tion.
This is most likely to happen when
there is an accumulation of snow or
ice around or near the rear brakes or
if the brakes are wet. When there is
the risk that your parking brake may
freeze, temporarily apply it with the
V K L I W O H Y H U L Q 1 I R U $ X W R P D W H G 0 D Q X D O
Transmission) or in first or reverse
gear (for manual transmission). Also,
block the rear wheels in advance, so
the vehicle may not roll. Then, release
the parking brake.Do not let ice and snow
accumulate underneath
Under some conditions, snow and ice
can build up under the fenders and
interfere with the steering. When driv-
ing in such conditions during the
severe winter, you should check
underneath the vehicle on a regular
basis, to ensure that the front wheels
and the steering components is
unblocked.
Carry emergency equipment
In accordance with weather condi-
tions, you should carry appropriate
emergency equipment, whilst driving.
Some of the items you may want to
carry include tyre chains, tow straps
or chains, flashlight, emergency
I O D U H V V D Q G V K R Y H O M X P S H U F D E O H V
window scraper, gloves, ground cloth,
coveralls, blanket, etc.
Do not place objects or materials
in the engine compartment
3 X W W L Q J R E M H F W V R U P D W H U L D O V L Q W K H
engine compartment may cause an
engine failure or combustion,
because they may block the engine
cooling. Such damage will not be
covered by the manufacturer’s war-
ranty.
Page 353 of 486
Hazard warning flasher ...................................................................................... 7-3
In case of an emergency whilst driving ............................................................ 7-3
If the engine stalls whilst driving .................................................................... 7-3
If the engine stalls at a crossroad or crossing ............................................... 7-3
If you have a flat tyre whilst driving ............................................................... 7-4
If the engine will not start .................................................................................. 7-5
If the engine doesn’t turn over or turns over slowly ..................................... 7-5
If the engine turns over normally but doesn’t start ...................................... 7-5
Jump starting ...................................................................................................... 7-6
If the engine overheats ...................................................................................... 7-9
Tyre Pressure Monitoring System (TPMS) ........................................................7-10
TPMS reset procedure .....................................................................................7-11
Tyre pressure monitoring system .................................................................. 7-12
Low tyre pressure telltale ............................................................................... 7-14
Low tyre pressure position telltale and tyre pressure telltale ..................... 7-14
TPMS (Tyre Pressure Monitoring System) malfunction indicator ............... 7-15
Changing a tyre with TPMS ...........................................................................7-16
If you have a flat tyre (with spare tyre) .............................................................7-18
Jack and tools ................................................................................................7-18
Changing tyres................................................................................................7-19
Jack label ....................................................................................................... 7-23
EC Declaration of conformity for Jack......................................................... 7-24
If you have a flat tyre (with tyre mobility kit) .................................................. 7-25
Introduction ................................................................................................... 7-25
Notes on the safe use of the tyre Mobility Kit ............................................. 7-26
Components of the Tyre Mobility Kit ............................................................7-27
Using the Tyre Mobility Kit ............................................................................ 7-28
Distributing the sealant ................................................................................. 7-30
Checking the tyre inflation pressure ............................................................ 7-30
7. Emergency situations
7
Page 360 of 486
7-8
Emergency situations
8. Start the engine of the assisting
vehicle and let it run at approxi-
mately 2,000rpm for a few minutes.
Then start your vehicle.
If your vehicle will not start after a few
attempts, it probably requires servic-
ing. In this event please seek quali-
fied assistance. If the cause of your
battery discharging is not apparent,
have your vehicle checked by a
HYUNDAI authorised repairer.Disconnect the jumper cables in the
exact reverse order you connected
them:
1. Disconnect the jumper cable from
the black, negative (-) chassis
ground of your vehicle (4).
2. Disconnect the other end of the
jumper cable from the black, nega-
tive (-) battery/chassis ground of
the assisting vehicle (3).
3. Disconnect the second jumper
cable from the red, positive (+) bat-
tery/jumper terminal of the assist-
ing vehicle (2).
4. Disconnect the other end of the
jumper cable from the red, positive
(+) jumper terminal of your vehicle
(1).
Page 361 of 486
7-9
07
If your temperature gauge indicates
overheating, you experience a loss of
power, or hear loud pinging or knock-
ing, the engine may be overheating. If
this happens, you should:
1. Pull off the road and stop as soon
as it is safe to do so.
2. Place the shift lever in N (Neutral,
for Automated manual transmis-
sion vehicle) or neutral (for Manual
transmission vehicle) and set the
parking brake. If the air condition-
ing is ON, turn it OFF.
3. If engine coolant is running out
under the vehicle or steam is com-
ing out from the bonnet, stop the
engine. Do not open the bonnet
until the coolant has stopped run-
ning or the steaming has stopped.
If there is no visible loss of engine
coolant and no steam, leave the
engine running and check to be
sure the engine cooling fan is oper-
ating. If the fan is not running, turn
the engine off.
WARNING
: K L O V W W K H H Q J L Q H L V U X Q-
Q L Q J N H H S K D Q G V F O R W K-
L Q J D Q G W R R O V D Z D \ I U R P
W K H P R Y L Q J S D U W V V X F K
D V W K H F R R O L Q J I D Q D Q G
G U L Y H E H O W W R S U H Y H Q W
V H U L R X V L Q M X U \ 4. Check for coolant leaking from the
radiator, hoses or under the vehi-
cle. (If the air conditioning had
been in use, it is normal for cold
water to be draining from it when
you stop.)
5. If engine coolant is leaking out,
stop the engine immediately and
we recommend that you call a
HYUNDAI authorised repairer for
assistance.
WARNING
1 ( 9 ( 5 U H P R Y H W K H U D G L-
D W R U F D S R U W K H G U D L Q
S O X J Z K L O V W W K H H Q J L Q H
D Q G U D G L D W R U D U H K R W + R W
F R R O D Q W D Q G V W H D P P D \
E O R Z R X W X Q G H U S U H V V X U H F D X V L Q J
V H U L R X V L Q M X U \
7 X U Q W K H H Q J L Q H R I I D Q G Z D L W X Q W L O
W K H H Q J L Q H F R R O V G R Z Q 8 V H
H [ W U H P H F D U H Z K H Q U H P R Y L Q J W K H
U D G L D W R U F D S : U D S D W K L F N W R Z H O
D U R X Q G L W D Q G W X U Q L W F R X Q W H U F O R F N-
Z L V H V O R Z O \ W R W K H I L U V W V W R S 6 W H S
E D F N Z K L O V W W K H S U H V V X U H L V
U H O H D V H G I U R P W K H F R R O L Q J V \ V W H P
: K H Q \ R X D U H V X U H D O O W K H S U H V V X U H
K D V E H H Q U H O H D V H G S U H V V G R Z Q R Q
W K H F D S X V L Q J D W K L F N W R Z H O D Q G
F R Q W L Q X H W X U Q L Q J F R X Q W H U F O R F N Z L V H
W R U H P R Y H L W
IF THE ENGINE OVERHEATS
Page 397 of 486
Engine compartment .........................................................................................8-3
Maintenance services ....................................................................................... 8-4
Owner’s responsibility .................................................................................... 8-4
Owner maintenance precautions.................................................................. 8-4
Owner maintenance ...........................................................................................8-5
Owner maintenance schedule .......................................................................8-5
Scheduled maintenance services ..................................................................... 8-7
Explanation of scheduled maintenance items ................................................ 8-8
Engine oil ............................................................................................................ 8-11
Checking the engine oil level ........................................................................ 8-11
Checking the engine oil and filter ................................................................ 8-12
Engine coolant .................................................................................................. 8-13
Checking the coolant level ........................................................................... 8-13
Changing the engine coolant ....................................................................... 8-15
Brake/clutch fluid ............................................................................................. 8-16
Checking the brake/clutch fluid level .......................................................... 8-16
Washer fluid ...................................................................................................... 8-18
Checking the washer fluid level ................................................................... 8-18
Checking the parking brake.......................................................................... 8-18
Parking brake .................................................................................................... 8-18
Air cleaner ......................................................................................................... 8-19
Filter replacement ......................................................................................... 8-19
Climate control air filter ................................................................................... 8-21
Filter inspection ............................................................................................. 8-21
Filter replacement ......................................................................................... 8-21
Wiper blades .....................................................................................................8-23
Blade inspection ............................................................................................8-23
Blade replacement ......................................................................................8-23
Battery ............................................................................................................... 8-25
For best battery service ................................................................................ 8-25
Battery capacity label ................................................................................... 8-27
Battery recharging ......................................................................................... 8-27
Reset items ....................................................................................................8-28
8. Maintenance
8
Page 398 of 486
8
Tyres and wheels...............................................................................................8-29
Tyre care .........................................................................................................8-29
Recommended cold tyre inflation pressures ............................................. 8-30
Check tyre inflation pressure ....................................................................... 8-30
Tyre rotation ................................................................................................... 8-31
Wheel alignment and tyre balance ..............................................................8-32
Tyre replacement ...........................................................................................8-32
Wheel replacement .......................................................................................8-34
Tyre traction ...................................................................................................8-34
Tyre maintenance ..........................................................................................8-34
Tyre sidewall labelling ...................................................................................8-34
Low aspect ratio tyres ................................................................................... 8-37
Fuses ................................................................................................................. 8-38
Instrument panel fuse replacement ........................................................... 8-39
Fuse switch ................................................................................................... 8-39
Engine compartment panel fuse replacement .......................................... 8-40
Fuse/relay panel description ....................................................................... 8-42
Light bulbs ........................................................................................................ 8-50
Headlight, Position Light, Turn signal Light, Fog Light and
Daytime Running Light, Low Beam Assist-Static light bulb
replacement .................................................................................................. 8-51
Headlight and front fog light aiming............................................................8-55
Side repeater light replacement .................................................................. 8-59
Rear combination light bulb replacement ................................................. 8-60
High mounted stop light replacement ........................................................ 8-61
License plate light bulb replacement ......................................................... 8-62
Interior light bulb replacement ................................................................... 8-62
Appearance care .............................................................................................. 8-63
Exterior care .................................................................................................. 8-63
Interior care................................................................................................... 8-69
Emission control system .................................................................................. 8-72
Crankcase emission control system ............................................................ 8-72
Evaporative emission control system .......................................................... 8-72
Exhaust emission control system ................................................................. 8-73
