264 Driving and Operating
display when a camera
view is active. Each
press of the button will
toggle through the Rear
Trailer View, Trailer Tow
mirror View and Combo
View. To access this
view when in a forward
gear above 12 km/h
(8 mph), touch
CAMERA on the
infotainment display and
touch the Rear Trailer
View/Rear Side View
with Available
Articulation
Functionality/
Picture-in-Picture Side
View icon. Touch X
to exit.
HD Surround Vision with Trailer
Camera Provisions
If equipped, this feature provides
additional views to aid in trailering/
towing. The system shows multiple
views in the infotainment display
using five cameras mounted around
the vehicle and up to two additional
accessory cameras that can be mounted on or in a trailer. The front
camera is in the grille under the
front emblem, the side cameras are
on the bottom of the outside mirrors,
the rear camera is in the tailgate
handle and the bed camera is
mounted on the rear of the cab.
Additionally, up to two accessory
cameras can be mounted to the rear
and/or interior of the trailer. See
your dealer for accessory trailer
cameras. To access, touch
CAMERA on the infotainment
display or shift to R (Reverse). To
return to the previous screen when
not in reverse, touch the Home or
Back buttons on the infotainment
display.
Available camera views:
.
Front/Rear Standard View
. Front/Rear Top-Down View
. Rear Bowl View
. Front/Rear Side View
. Hitch View
. Bed View
. Rear trailer View .
Rear Side view with a available
articulation functionality
. Picture-in-Picture Side View
. Interior Trailer View
. Transparent trailer View
. Surround View
. Guidance Lines
. Hitch Guidance
Surround Vision (360 Degrees)
If equipped, the Surround Vision
system can display various views
surrounding the vehicle in the
infotainment display using four
cameras mounted around the
vehicle. The front camera is in the
grille under the front emblem, the
side cameras are on the bottom of
the outside mirrors, and the rear
camera is in the tailgate handle.
The Surround Vision system can be
accessed by selecting CAMERA in
the infotainment display or when the
vehicle is shifted into R (Reverse).
To return to the previous screen
sooner, when not in R (Reverse),
press the Home or Back button on

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/4/19
Driving and Operating 265
the infotainment system, shift into
P (Park), or, while in D (Drive),
reach a vehicle speed of
approximately 12 km/h (8 mph).
Available camera views:
.Front/Rear Standard View
. Front/Rear Top-Down View
. Rear Bowl View
. Front/Rear Side View
. Hitch View
. Surround View
. Guidance Lines
. Hitch Guidance
Surround Vision
If equipped, this feature provides,
additional views to aid in trailering/
towing. The Front Vision Camera
and Surround Vision cameras are
not supported. The system can
show various views in the
infotainment display using cameras
mounted in and around the vehicle
and trailer. The rear camera is in the
tailgate handle and the cargo bed
camera is mounted on the rear of the cab. Up to two accessory
cameras can be mounted to the rear
and/or interior of the trailer. See
your dealer for these accessory
cameras.
The system can be accessed by
selecting CAMERA in the
infotainment display or when the
vehicle is shifted into R (Reverse).
To return to the previous screen
sooner, when not in R (Reverse),
press the Home or Back button on
the infotainment system or shift into
P (Park).
Available camera views:
.
Rear Standard View
. Hitch View
. Bed View
. Rear Trailer View
. Interior Trailer View
. Guidance Lines
. Hitch Guidance Troubleshooting
The Transparent Trailer calibration
may take longer than expected or
not calibrate if:
.
The vehicle is driven too fast
during calibration. Speed should
be maintained below 50 km/h
(31 mph).
. The vehicle is not driven straight
during calibration. Steering
should be maintained as straight
as possible, excessive steering
during calibration may extend
calibration time.
. The calibration is attempted in
low light. Calibration should be
attempted when there is enough
light.
. The calibration is attempted
during adverse weather
conditions. Calibration during
conditions such as snow or
heavy rain should be avoided.
. The road surface is not ideal for
calibration. Calibration should be
attempted on an alternate road
surface.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/10/19
368 Vehicle Care
Taillamps, Turn Signal,
Stoplamps, and Back-Up
Lamps
Base Level Taillamp Assembly
1. Stoplamp/Turn Signal Lamp
2. Back-Up Lamp
Uplevel Taillamp Assembly
See your dealer for taillamp
replacement.
It is recommended to replace the
grommets when replacing a bulb.
See your dealer.
To replace one of these bulbs:1. Open the tailgate.
2. Remove the two rear lamp assembly screws.
4. Pull the rear lamp assembly
outward and rearward away
from the box side to remove it
from the vehicle.
5. Turn the bulb socket counterclockwise.
6. Pull the bulb straight out from the socket.
7. Replace the bulb and reverse Steps 1–5 to reinstall.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/4/19
446 Service and Maintenance
Maintenance Schedule
Additional Required
Services - Normal12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi 180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
For GVW over 3 900 kg (8,600 lb), change
transfer case fluid, if equipped with 4WD. (4)@ @@
Drain and fill engine cooling system. (5)@
Visually inspect accessory drive belts. (6)@
Replace brake fluid. (7)
Replace windshield wiper blades. (8)
@ @ @ @ @ @ @ @ @ @
Replace hood gas struts and tailgate
dampener. (9)@ @
Replace air conditioning desiccant. (10)
Footnotes—Maintenance
Schedule Additional Required
Services - Normal
(1) Or every two years, whichever
comes first. More frequent
replacement may be needed if the
vehicle is driven in areas with heavy
traffic, poor air quality, areas with
high dust levels or are sensitive to
environmental allergens. Filter
replacement may also be needed if you notice reduced airflow, windows
fogging up, or odors. Your local GM
Service location can help you
determine when it is the right time to
replace your filter.
(2)
Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
See Engine Air Cleaner/Filter 0344. (3)
Visually check all fuel and vapor
lines and hoses for proper
attachment, connection, routing, and
condition.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/4/19
448 Service and Maintenance
Maintenance Schedule
Additional Required
Services - Severe12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi 180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services.
Check engine oil level and oil life percentage.
Change engine oil and filter, if needed. Check
engine air filter life percentage and status.
Change engine air filter, if needed.
@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
If the vehicle is not equipped with the engine air
filter life system, replace engine air cleaner
filter. (2)@ @@
Inspect evaporative control system. (3)@@@
Replace spark plugs. Inspect spark plug wires.
(Except 2.7L L4 Turbo Engine)@
Replace spark plugs. Inspect spark plug wires.
(2.7L L4 Turbo Engine Only)@ @
Change automatic transmission fluid and filter.@@@
For GVW under 3 900 kg (8,600 lb), change
transfer case fluid, if equipped with 4WD. (4)@@@
For GVW over 3 900 kg (8,600 lb), change
transfer case fluid, if equipped with 4WD. (4)@@@@@@
Drain and fill engine cooling system. (5)@
Visually inspect accessory drive belts. (6)@
Replace brake fluid. (7)
Replace windshield wiper blades. (8)
@ @ @ @ @ @ @ @ @ @
Replace hood gas struts and tailgate
dampener. (9)@ @
Replace air conditioning desiccant. (10)

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/4/19
454 Service and Maintenance
UsageFluid/Lubricant
Front Axle (Four-Wheel Drive) and Rear Axle See your dealer.
Hydraulic Brake System (Vehicles with DOT 3 brake fluid) DOT 3 Hydraulic Brake Fluid (GM Part No. 19353126, in
Canada 19353127). See
Brake Fluid0357.
Hydraulic Brake System (Vehicles with DOT 4 brake fluid) DOT 4 Hydraulic Brake Fluid (GM Part No. 19299570, in
Canada 19299571). See
Brake Fluid0357.
Hydraulic Power Steering System (2500/3500 Series Only) GM Power Steering Fluid (GM Part No. 19329450, in Canada 19329451).
Key Lock Cylinders, Hood Hinges, Body Door Hinge Pins, Tailgate
Hinge and Linkage, Fuel Door Hinge, Tailgate Handle Pivot Points, Hinges, Latch Bolt, and Linkage Multi-Purpose Lubricant, Superlube (GM Part No. 12346241, in
Canada 10953474).
Transfer Case (Four-Wheel Drive) DEXRON-VI Automatic Transmission Fluid. Weatherstrip Conditioning Weatherstrip Lubricant. See your dealer.Weatherstrip Squeaks Synthetic Grease with Teflon, Superlube (GM Part No. 12371287).
Windshield Washer Automotive windshield washer fluid that meets regional freeze protection requirements.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-13337776) - 2020 - CRC - 4/4/19
Index 489
Assistance Program,Roadside . . . . . . . . . . . . . . . . . . . . . . 467
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 268
Assistance Systems for Parking and Backing . . . . . . . . . . 257
Auto Stop
Stop/Start System . . . . . . . . . . . . 213
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . 44
Door Locks . . . . . . . . . . . . . . . . . . . . . 26
Emergency Braking (AEB) . . . . 270
Headlamp System . . . . . . . . . . . . 168
Transmission . . . . . . . . . . . . . . . . . 221
Transmission Fluid . . . . . . . . . . . 343
Automatic Transmission
Manual Mode . . . . . . . . . . . . . . . . . 224
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 363
Axle, Front . . . . . . . . . . . . . . . . . . . . . . 361
Axle, Rear . . . . . . . . . . . . . . . . . . . . . . 362
B
Battery Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 174
Load Management . . . . . . . . . . . . 174 Battery (cont'd)
Power Protection . . . . . . . . . . . . . 174
Battery - North America . . . . 358, 419
Blade Replacement, Wiper . . . . . 364
Blind Spot Mirrors . . . . . . . . . . . . . . . 44
Brake Electric Boost . . . . . . . . . . . . . . . . . 232
Parking, Electric . . . . . . . . . . . . . . 233
System Warning Light . . . . . . . . 140
Brake Pad Life System . . . . . . . . . 356
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 355 Antilock . . . . . . . . . . . . . . . . . . . . . . . 232
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 234
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 357
Pad Life System . . . . . . . . . . . . . . 356
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 188 AutomaticEmergency (AEB) . . . . . . . . . . . 270
Braking System Front Pedestrian (FPB) . . . . . . . 272
Break-In, New Vehicle . . . . . . . . . . 208
Bulb Replacement Center High-Mounted
Stoplamp (CHMSL) and
Cargo Lamp . . . . . . . . . . . . . . . . . 369
Halogen Bulbs . . . . . . . . . . . . . . . . 367
Headlamp Aiming . . . . . . . . . . . . . 366
Headlamps . . . . . . . . . . . . . . . . . . . 367 Bulb Replacement (cont'd)
Headlamps, Front Turn
Signal, Sidemarker, and
Parking Lamps . . . . . . . . . . . . . . 367
License Plate Lamps . . . . . . . . . 369
Taillamps, Turn Signal, Stoplamps, and Back-up
Lamps . . . . . . . . . . . . . . . . . . . . . . 368
Buying New Tires . . . . . . . . . . . . . . . 399
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 121
California Perchlorate Materials
Requirements . . . . . . . . . . . . . . . 329
California Proposition
65 Warning . . . . . . . . . .329, 358, 419, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 459
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 220
Tailgate . . . . . . . . . . . . . . . . . . . . . . . . . 28
Winter Driving . . . . . . . . . . . . . . . . 197
Cargo Tie-Downs . . . . . . . . . . . . . . . . . . . . .116

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-13337776) - 2020 - CRC - 4/4/19
498 Index
Steering Column Lock . . . . . . . . . . . 38
StepsPower Assist . . . . . . . . . . . . . . . . . . . 36
Stop/Start System . . . . . . . . . . . . . . 213
Stoplamps and Back-up Lamps Bulb Replacement . . . . . . . . . . . . 368
Storage
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Storage Areas Center Console . . . . . . . . . . . . . . . .114
Floor Console . . . . . . . . . . . . . . . . .115
Glove Box . . . . . . . . . . . . . . . . . . . . .113
Underseat . . . . . . . . . . . . . . . . . . . . .114
Storage Compartments . . . . . . . . . 113
Struts Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . 365
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 199
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 51
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Brake Pad Life . . . . . . . . . . . . . . . . 356
Engine Air Filter Life . . . . . . . . . . 343
Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 268
Infotainment . . . . . . . . . . . . . 176, 476
Noise Control . . . . . . . . . . . . . . . . . 362 Systems
Driver Assistance . . . . . . . . . . . . . 256
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 132
Tailgate . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Taillamps
Bulb Replacement . . . . . . . . . . . . 368
Task Lighting . . . . . . . . . . . . . . . . . . . 171
Text Telephone (TTY) Users . . . . 466
Theft-Deterrent Systems . . . . . . . . . 39 Immobilizer . . . . . . . . . . . . . . . . . . . . . 39
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 379 All-Season . . . . . . . . . . . . . . . . . . . . 379
All-Terrain . . . . . . . . . . . . . . . . . . . . 381
Buying New Tires . . . . . . . . . . . . . 399
Chains . . . . . . . . . . . . . . . . . . . . . . . . 404
Changing . . . . . . . . . . . . . . . . . . . . . 407
Designations . . . . . . . . . . . . . . . . . 383
Different Size . . . . . . . . . . . . . . . . . 401
Full-Size Spare . . . . . . . . . . . . . . . 418
If a Tire Goes Flat . . . . . . . . . . . . 405
Inspection . . . . . . . . . . . . . . . . . . . . 396
Low Profile . . . . . . . . . . . . . . . . . . . 380
Pressure . . . . . . . . . . . . . . . . . 387, 389
Pressure Light . . . . . . . . . . . . . . . . 145
Pressure Monitor Operation . . 390 Tires (cont'd)
Pressure Monitor System . . . . . 389
Rotation . . . . . . . . . . . . . . . . . . . . . . 396
Sidewall Labeling . . . . . . . . . . . . . 381
Terminology and Definitions . . 385
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 401
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 403
Wheel Replacement . . . . . . . . . . 403
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 398
Winter . . . . . . . . . . . . . . . . . . . . . . . . 380
Top Tier Fuel . . . . . . . . . . . . . . . . . . . 280
Tow/Haul Mode . . . . . . . . . . . . . . . . . 226
Tow/Haul Mode Light . . . . . . . . . . . 142
Towing Driving Characteristics . . . . . . . . 287
Equipment . . . . . . . . . . . . . . . . . . . . 296
General Information . . . . . . . . . . 287
Recreational Vehicle . . . . . . . . . . 424
Trailer . . . . . . . . . . . . . . . . . . . . . . . . 292
Trailer Sway Control (TSC) . . . 308
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 424
Traction Limited-Slip Differential . . . . . . . 242
Off Light . . . . . . . . . . . . . . . . . . . . . . 143
