Engine compartment

fuses
2
29, 233 -234
.
Over view

13
C5_EN_CHAP00C_ECO-CONDUITE_ED01-2016.
Limit the causes of excess consumption
Spread loads throughout the vehicle; place the heaviest items in the
bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance (roof
bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and refit your summer tyres.
Observe the recommendations on
maintenance
Check the tyre pressures regularly, when cold, referring to the label in
the door aperture, driver's side.
Carry out this check in particular:
-
b
efore a long journey,
-

a
t each change of season,
-

a
fter a long period out of use.
Don't forget the spare wheel and the tyres on any trailer or caravan.
Have your vehicle serviced regularly (engine oil, oil filter, air filter,
passenger compartment filter...) and observe the schedule of
operations recommended in the manufacturer's service schedule.
With a BlueHDi Diesel engine, if the SCR system is faulty your vehicle
becomes polluting; go to a CITROËN dealer or a qualified workshop
without delay to have the emissions of nitrogen oxides brought back to
the legal level.
When refuelling, do not continue after the third cut-off of the nozzle to
avoid any over flow.
At the wheel of your new vehicle, it is only after the first 1 800 miles
(3 000 kilometres) that you will see the fuel consumption settle down to
a consistent average.
.
Eco-driving

20
C5 _en_Chap01_instruments-bord_ed01-2016
Return to the main
instrument panel screen
display
Successive rotations of the left-hand thumb
wheel on the steering wheel allow you to return
to the main instrument panel screen display
(vehicle speed), via the navigation information
screen, then the screen displaying only the
total mileage and the trip mileage (bottom of
screen).You can display navigation information in
the
instrument panel screen by rotating the
left-hand thumb wheel on the steering wheel. This function allows you to check certain
indicators and display the log of alerts.
F

P
ress on button A.
The following information appears in turn in the
instrument panel screen:
-

R
epeat of the service indicator.
-

R
epeat of the range indicator for the
AdBlue
® and the SCR system for BlueHDi
Diesel versions.
-

R

epeat of the engine oil level indicator.
-

A

ny alert messages.
Check function
Display of navigation
information in the
instrument panel screen
Instruments

21
C5 _en_Chap01_instruments-bord_ed01-2016
Engine oil temperature
gauge
Under normal operating conditions, the bars
should be within section 1.
In severe operating conditions, the bars may
extend into section 2 .
In this event, slow down, and if necessary,
stop the engine and check the levels (see the
corresponding section).
Coolant temperature
gauge
Under normal operating conditions, the bars
should be within section 1 .
In severe operating conditions, the bars may
extend into section 2 , the engine coolant
temperature warning lamp A and the STOP
warning lamp come on in the instrument panel.
Stop as soon as it is safe to do so . Switch off
the ignition. The cooling fan may continue to
operate for a cer tain time .
Contact a CITROËN dealer or a qualified
workshop.
If the SERVICE warning lamp comes on, check
the levels (see the corresponding section). On horizontal ground, illumination of the fuel
low warning lamp indicates that you are at the
reser ve level.
An alert message is displayed in the instrument
panel.
Fuel gauge
Indicators
1
Instruments

24
C5 _en_Chap01_instruments-bord_ed01-2016
Engine oil level indicator
The engine oil level is displayed in the
instrument panel screen for a few seconds
when the ignition is switched on, after the
servicing information.Oil level correct
This is indicated by the display of the message
"Oil level incorrect" in the instrument panel
screen, accompanied by the service warning
lamp and an audible signal.
Oil level indicator fault
In the event of a fault with the electric
indicator, the oil level is no longer
monitored.
If the system is faulty, you must check
the engine oil level using the manual
dipstick located under the bonnet.
For more information on Checking
levels, refer to the corresponding
section.
Oil level incorrect
This is signalled by the display of the message
"Oil level measurement invalid" in the
instrument panel screen.
Contact a CITROËN dealer or a qualified
workshop.
If the low oil level is confirmed by a
check using the dipstick, the level must
be topped-up to avoid damage to the
engine.
For more information on Checking
levels , refer to the corresponding
section.
The level read will only be correct if
the vehicle is on level ground and the
engine has been off for more than
30
m

inutes.
Instruments

29
C5 _en_Chap01_instruments-bord_ed01-2016
Dynamic
stability control
(DSC/ASR)flashing.
The DSC/ASR regulation is
operating. The system optimises traction and improves the
directional stability of the vehicle in the event of loss of
grip or trajectory.
fixed. The DSC/ASR system has a fault. Have the system checked by a CITROËN dealer or a
qualified workshop.
Warning
/indicator lampis on Cause Action / Observations
Brake pad wear fixed, accompanied
by an audible signal
and a message in the
display screen. The brake pads are at an advanced
state of wear.
Have the brake pads replaced by a CITROËN dealer
or a qualified workshop.
Deactivation of
the automatic
functions of the
electric parking
brake
fixed.
The "automatic application" (on
switching off the engine) and
"automatic release" functions are
deactivated or faulty. Activate the function (depending on the country of
sale) via the vehicle parameters menu or contact a
CITROËN dealer or a qualified workshop if automatic
application / release is no longer possible.
For more information on the Electric parking brake
,
refer to the corresponding section.
Under-inflation fixed. The pressure in one or more wheels
is too low. Check the pressure of the tyres as soon as possible.
This check should preferably be carried out when the
tyres are cold.
+ flashing then fixed,
accompanied by the
Service warning lamp.The tyre pressure monitoring system
has a fault or no sensor is detected
on one of the wheels. Under-inflation detection is not assured.
Have the system checked by a CITROËN dealer or a
qualified workshop.
1
Instruments

31
C5 _en_Chap01_instruments-bord_ed01-2016
Warning/indicator lampis on Cause Action / Observations
Engine
autodiagnosis
system fixed.
The emission control system has a
fault.
The warning lamp should go off when the engine is started.
If it does not go off, contact a CITROËN dealer or qualified
workshop without delay.
flashing.The engine management system has
a fault. Risk of destruction of the catalytic converter.
Have it checked by a CITROËN dealer or a qualified
workshop.
Low fuel
level
fixed.
When it first comes on there remains
approximately 5 litres of fuel
in the
tank. You must refuel as soon as possible to avoid running
out of fuel.
This warning lamp wil come on every time the ignition
is switched on, until a sufficient addition of fuel is
made.
Fuel tank capacity: 71 litres.
Never continue to drive until you run out of fuel, this
could damage the emission control and injection
systems.
1
Instruments
