44 Storage
{Warning
For safety, close the glove box
during driving. There is a risk of
injury from the open lid or items
stored in the glove box.
You and others could be seriously
injured.
The glove box lid will automatically
spring open when it is unlocked. Do
not put your face or head near
the lid.
{Warning
Do not leave eyeglasses or a
lighter in the vehicle. Lighters
may explode and plastic lenses or
frames may deform or crack if the
interior temperature becomes
very hot.
You and others could be seriously
injured.
Caution
When closing the glove box lid,
do not allow stored items to pass
the line shown in the illustration.
The glove box lid may break if it
is closed when items inside have
passed the line and are sticking
out from the box.
Do not place items such as vehicle
registration documents or owner
manuals in the glove box, but store
them in the seat back pocket
located on the back side of the
driver seat.
Refer to Storage Compartments
0 42.
Cupholders
Pull the cupholder towards you to
open it.
Do not place a cup that is too full in
the cupholder. Spillages could
cause damage to the radio and
other electrical circuits. If there is a
spill, wipe it up immediately with a
dry cloth.
Do not tilt the cab with a filled cup in
the cupholder. There may be a
danger of the cupholder breaking if
the weight on each holder exceeds

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
Storage 45
0.75 kg (1.65 lbs). Doing so may
also result in damage to the radio or
other electronic components.
Use the cupholders for storing small
articles or cups.
Rear Storage
Single Cab Model Only
{Warning
Do not use the back panel tray to
hold any object that may fly or fall
out during vehicle operation.
Doing so would be dangerous.
Items may fly or fall out when the
cab is tilted.
You and others could be seriously
injured.
The center area of the back panel
tray can be used as a storage
receptacle. The warning triangle and
fire extinguisher can be carried in
both sides.
Additional Storage
Features
Shopping Bag Hooks
This can be used to hold plastic
shopping bags. Do not hang
anything weighing over 3 kg
(6.6 lbs) or the hook will break.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
46 Storage
Information on
Loading the Vehicle
Overloading
{Warning
Overloading can result in loss of
vehicle control and personal
injury or death, either by causing
component failures or by affecting
vehicle handling. It can also
shorten the service life of your
vehicle.
The components of your truck are
designed to provide satisfactory
service if the vehicle is not loaded in
excess of either the gross vehicle
weight rating (GVWR) or the
maximum front and rear gross axle
weight ratings (GAWRs). These
ratings are listed on the vehicle
identification number (VIN) plate,
which is located on the left side rear
pillar panel below the striker (single cab) or on the left center pillar panel
beside the shoulder seat belt anchor
(crew cab).
Gross vehicle weight (GVW) is the
weight of the originally equipped
vehicle and all items added to it
after it has left the factory. This
would include bodies, lift gates,
refrigeration systems, winches,
booms, etc., the driver and all
occupants, and the load the vehicle
is carrying. The GVW must not
exceed the GVWR. Also, gross
weight on each of the front and rear
axles must not exceed the front and
rear GAWRs respectively.
Your dealer can advise you of the
proper loading conditions for your
vehicle. Using selected heavier
suspension components for added
durability may not increase any of
the weight ratings shown on the VIN
and weight rating plate.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
48 Storage
Load Cargo Correctly
{Warning
Overloading can result in a crash
because it places too much strain
on the wheel studs with the result
that they break and the wheels
come off.
The weight of the payload must
be limited within the gross vehicle
weight (GVW) rating and(Continued)
Warning (Continued)
distributed over the front and rear
axles so as not to exceed the
axle capacities.
It is extremely dangerous to
overload the vehicle or to load the
vehicle with the cargo positioned
on one side. Load the vehicle
correctly, observing the maximum
loading capacity.
Incorrect loading can make the
cargo unstable. It can also cause
an overload condition confined to
a small area, resulting in damage
to the cargo bed and frame.
Overloading places undue strain
on vehicle parts. It can shorten
the vehicle's service life and
cause a crash. You and others
could be seriously injured.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
52 Instruments and Controls
Instruments and
Controls
Controls
Steering Wheel Adjustment . . . . 53
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Windshield Wiper/Washer . . . . . . 54
Power Outlets . . . . . . . . . . . . . . . . . 55
Warning Lights, Gauges, and
Indicators
Warning Lights, Gauges, andIndicators . . . . . . . . . . . . . . . . . . . . 56
Instrument Cluster . . . . . . . . . . . . . 57
Speedometer . . . . . . . . . . . . . . . . . . 58
Odometer . . . . . . . . . . . . . . . . . . . . . . 58
Trip Odometer . . . . . . . . . . . . . . . . . 58
Tachometer . . . . . . . . . . . . . . . . . . . . 59
Fuel Gauge . . . . . . . . . . . . . . . . . . . . 59
Engine Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . . . 60
Diesel Exhaust Fluid (DEF) Gauge . . . . . . . . . . . . . . . . . . . . . . . . 60
Seat Belt Reminders . . . . . . . . . . . 60
Battery Warning Light . . . . . . . . . . 61
Malfunction Indicator Lamp (Check Engine Light) . . . . . . . . . 61
Service Vehicle Soon Light . . . . 62 Brake System Warning Light
(Parking Brake Light) . . . . . . . . . 62
Antilock Brake System (ABS) Warning Light . . . . . . . . . . . . . . . . 64
Exhaust Brake Light . . . . . . . . . . . 65
Service Transmission Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . 65
Automatic Transmission Fluid Temperature Warning Light . . . 66
Overdrive Off Light . . . . . . . . . . . . . 66
Wait-to-Start Light . . . . . . . . . . . . . 67
Engine Oil Pressure Light . . . . . . 67
Engine Oil Level Indicator Light . . . . . . . . . . . . . . . . . . . . . . . . . 67
Diesel Exhaust Fluid (DEF) Warning Light . . . . . . . . . . . . . . . . 68
Engine Shutdown Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . 68
Idle Shutdown Light . . . . . . . . . . . . 68
Reduced Engine Power Light . . . . . . . . . . . . . . . . . . . . . . . . . 69
High-Beam On Light . . . . . . . . . . . 69
Daytime Running Lamps (DRL) Indicator Light . . . . . . . . . . . . . . . . 69
Cruise Control Light . . . . . . . . . . . 70
Information Displays
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . 70
Vehicle Messages
Vehicle Messages . . . . . . . . . . . . . 74
Warning Buzzers . . . . . . . . . . . . . . 79

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
Instruments and Controls 53
Controls
Steering Wheel
Adjustment
{Warning
.Adjust the position of the
steering wheel before you
start driving.
. To reduce the risk of
personal injury, apply force
to the steering wheel to
make certain the steering
column is firmly locked
before driving. Also, do not
try to tilt or adjust the
steering wheel while the
vehicle is moving. If these
steps are not followed, the
steering column could move
suddenly while the vehicle
is in motion which could
cause a temporary loss of
steering control which may
result in personal injury or
death.
The steering wheel is adjustable up
and down as well as forward and
backward.
Before adjusting, position the seat
as desired.
1. Lift the lock lever toward you to unlock the steering column.
2. Sit in the correct driving position, and then move the
steering wheel up and down
and forward and backward to
select the optimum steering
wheel position. 3. Firmly lock the steering wheel
at the selected position by
moving the lock lever to the
lock position.
Horn
To sound the horn, press the pad
with a horn symbol on the steering
wheel.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
54 Instruments and Controls
Windshield Wiper/Washer
To use the windshield wiper and
washer switches, the engine control
switch must be in the ON position.
The windshield wiper switch has the
following positions, which
correspond to the states of the
wiper.
9:Stopped.
3:Intermittent, light rain.
Low Speed : Low speed,
moderate rain.
High Speed : High speed,
heavy rain. If the wiper frequently stops during
operation, contact your nearest
Dealer.
Clear snow and ice from the wiper
blades and windshield before using
them. If frozen to the windshield,
carefully loosen or thaw them.
Damaged blades should be
replaced. See
Wiper Blade
Replacement 0265.
Do not operate the wiper on a dry
windshield surface. Otherwise, the
windshield surface may sustain
damage.
Windshield Washer
{Warning
In freezing weather, do not use
the washer until the windshield is
warmed. Otherwise the washer
fluid can form ice on the
windshield, blocking your vision.
{Warning
Before driving the vehicle, always
clear snow and ice from the hood,
windshield, roof, and rear of the
vehicle, including all lamps and
windows. Reduced visibility from
snow and ice buildup could lead
to a crash.
Windshield washer fluid is sprayed
over the windshield when this switch
is pressed. At the same time, the
windshield wiper operates.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
56 Instruments and Controls
Warning Lights,
Gauges, and
Indicators
Warning lights and gauges can
signal that something is wrong
before it becomes serious enough
to cause an expensive repair or
replacement. Paying attention to the
warning lights and gauges could
prevent injury.Some warning lights come on briefly
when the engine is started to
indicate they are working. When
one of the warning lights comes on
and stays on while driving, or when
one of the gauges shows there may
be a problem, check the section that
explains what to do. Waiting to do
repairs can be costly and even
dangerous.
For safety reasons, do not place
packages, tools, or other items in
the driver
’s area that may restrict
access to the controls or sight of the
gauges.
