2019 VOLVO S90 TWIN ENGINE key

||
KEY, LOCKS AND ALARM
244
Turn the key over, move the button to theside and slide the rear cover slightly upward.
The cover will loosen and can beremoved from the key.
Use a screwdriver or similar object to turnthe battery cover counterclockwise so themarkers point to OPEN.
Remove the cover carefully by pressing e.g. afingernail into the indentation.
Pry the cover up.
The battery's positive side (+) faces upward.Carefully pry out the battery as shown in theillustration.

CAUTION
Avoid touching new batteries and their con-tact surfaces with your fingers as this willimpair their function.
Insert a new battery with the positive side (+)facing upward. Do not touch the contact sur-faces of the remote key battery.
Place the edge of the battery downwardinto the holder. Slide the battery forward untilit locks into place under the two plasticcatches.
Press the battery downward until it locksinto place under the upper black plasticcatch.

NOTE
Use batteries with the designation CR2032,3 V.

KEY, LOCKS AND ALARM
245

NOTE
Volvo recommends that batteries used in theremote control key satisfy UN Manual of Testand Criteria, Part III, sub-section 38.3. Thefactory installed batteries and batteriesreplaced by an authorized Volvo workshopsatisfy the above criterion.
Replace the battery cover and turn it clock-wise until it points to CLOSE.
Put the rear cover back into position andpress it down until it clicks into place.
Slide the cover back.
> A second click indicates that the cover iscorrectly positioned and locked into place.
Turn the remote key over and press thefront cover down until it clicks into place.
Slide the cover back.
>An additional click indicates that the coveris correctly in place.
CAUTION
Be sure to dispose of end-of-life batteries ina way that protects the environment.

WARNING
California Proposition 65
Operating, servicing and maintaining a pas-senger vehicle can expose you to chemicalsincluding engine exhaust, carbon monoxide,phthalates, and lead, which are known to theState of California to cause cancer and birthdefects or other reproductive harm. To mini-mize exposure, avoid breathing exhaust, donot idle the engine except as necessary, serv-ice your vehicle in a well ventilated area andwear gloves or wash your hands frequentlywhen servicing your vehicle. For more infor-mation go to www.P65Warnings.ca.gov/passenger-vehicle.

Related information
Remote key (p. 237)

KEY, LOCKS AND ALARM
* Option/accessory.246
Ordering additional remote keys
Two remote keys are provided with the vehicle.One Key Tag is also included if the vehicle isequipped with keyless locking/unlocking*. Addi-tional keys can be ordered.
A total of 12 keys can be programmed and usedfor the same vehicle. An additional driver profilewill be added for each new remote key. This alsoapplies to the key tag.

Loss of a remote key
If you lose your remote key, you can order areplacement from a workshop - an authorizedVolvo workshop is recommended. Bring the otherremaining remote keys to the workshop. As ananti-theft measure, the code of the lost remotekey must be erased from the system.
The current number of keys registered for thevehicle can be checked via driver profiles in the
center display's Top view. Select Settings
SystemDriver Profiles.
NOTE
Volvo recommends that you order a new orduplicate remote control key from an author-ized Volvo workshop.
You can also obtain additional or duplicateremote control keys from certain independentrepair facilities and locksmiths that are quali-fied to make remote control keys. Each keymust be programmed to work with your vehi-cle.
A list of independent repair facilities and/orlocksmiths known to Volvo that can cut andcode replacement keys can be found:
on Volvo's website www.volvocars.com/us
by calling Volvo Customer Care1-800-458-1552.

Related information
Remote key (p. 237)
Red Key - restricted remote key*
A Red Key makes it possible for the vehicleowner to set limitations for certain vehicle prop-erties. The limitations are intended to promotesafe use of the vehicle, e.g. when it is loanedout.
For a Red Key, it is possible to define the vehi-cle's maximum speed, set speed reminders andlimit the audio system's volume. Several of thedriver support systems will also always be active.Otherwise, the Red Key functions in the sameway as a standard remote key.
One or more Red Key can be ordered from aVolvo retailer. A total of twelve keys can be pro-grammed and used for the same vehicle. Up toten may be restricted keys, but at least two mustbe standard remote keys.
These restrictions are intended to help reducethe risk of accidents and help the driver feel more

KEY, LOCKS AND ALARM
* Option/accessory.247
secure when handing over the vehicle to e.g. ayoung driver, parking attendant or workshop. Thesettings for a Red Key cannot be changed by itsuser; a regular remote key is needed to changesettings.

Related information
Red Key* settings (p. 247)
Remote key (p. 237)
Red Key* settings
The holder of a regular remote key can adjustsettings for a Red Key. Certain driver supportfunctions are always active.
1.Tap Settings in the center display's Topview.
2. Tap SystemDriver ProfilesRed Key.
> The following settings can be made:
Set Time Gap For Adaptive CruiseControl
Reduced Maximum Volume
Max Speed Limit
Speed Limit Warning

Adaptive Cruise Control * :
Default setting: Longest interval

Reduced maximum volume (On/Off):
Default setting: On

Speed Limiter (On/Off):
Setting interval: 50-250 km/h (30-160 mph)
The default setting is 120 km/h (75 mph)
Increments: 1 km/h (1 mph)
The following symbol and message willbe shown in the instrument panel
Red key Speed limitation cannotbe exceeded.
Speed reminder (On/Off):
Setting interval: 0-250 km/h (0-160 mph)
Default setting: 50, 70 and 90 km/h (30, 45and 55 mph)
Increments: 1 km/h (1 mph)
Maximum number of simultaneous remind-ers: 6

Driver support functions
The following driver support functions will alwaysbe active for a Red Key user:
Blind Spot Information (BLIS)*
Lane Keeping Aid (LKA)*
Distance Alert*
City Safety
Driver Alert Control (DAC)*
Road Sign Information*

Related information
Red Key - restricted remote key* (p. 246)

KEY, LOCKS AND ALARM
* Option/accessory.248
Detachable key blade
The remote key contains a detachable metal keyblade that can be used to activate a number offunctions and preform certain actions.
A Volvo workshop can provide you with the keyblade's unique code, which is recommended incase you need to order a new key blade.

Using the detachable key blade
The detachable key blade can be used to:
manually open the left-side front door if cen-tral locking cannot be activated with theremote key.
emergency lock all doors.
activate/deactivate the rear door mechanicalchild safety locks.
The button-less Key Tag10 does not have adetachable key blade. If needed, use the standardremote key's detachable key blade.
Detaching the key blade
Hold the remote key with the front side(with the Volvo logo) facing up and move thebutton on the key ring section to the right.Slide the front cover slightly upward.
The cover will loosen and can beremoved from the key.
Remove the key blade by pulling it up.
Put the key blade back into its designatedspot in the remote key after use.
Replace the cover by pressing it downuntil it clicks into place.
Slide the cover back.
> An additional click indicates that the coveris correctly in place.

Related information
Locking and unlocking with detachable keyblade (p. 249)
Remote key (p. 237)
10Supplied with vehicles equipped with keyless locking/unlocking (Passive Entry*).

KEY, LOCKS AND ALARM
}}
249
Locking and unlocking withdetachable key blade
The detachable key blade can be used to unlockthe vehicle from the outside, e.g. if the battery inthe remote key is discharged.

Unlocking
Pull the front left-hand door handle to its endposition to access the lock cylinder.
Put the key in the lock cylinder.
Turn the key clockwise 45 degrees so thatthe key blade is pointing straight rearward.
Turn the key blade back 45 degrees to itsoriginal position. Remove the key from thelock cylinder and release the handle so that itreturns to its original position against thevehicle.
5. Pull the door handle.
>The door will open.
Lock the door in the same way, but turn the key45 degrees counterclockwise in step (3).
Turning off the alarm
NOTE
When the door is unlocked using the detach-able key blade and then opened, the alarmwill be triggered.
Location of the backup key reader in the cup holder.
Turn off the alarm by:
1. Place the remote control key on the key sym-bol in the backup reader in the bottom of thecup holder in the tunnel console.
2.Turn the start knob clockwise and release it.
> The start knob will automatically return toits original position - the alarm signal willstop and the alarm will be turned off.
Locking
The vehicle can also be locked using the remotekey's detachable key blade, e.g. if either the vehi-cle's or remote key's batteries are discharged.
The left-hand front door can be locked by insert-ing the detachable key into the door's lock cylin-der.
This is the only door with a lock cylinder. Theother doors have lock mechanisms in the side ofthe door that must be pushed in using the keyblade. The door will then be locked mechanicallyand cannot be opened from the outside.
The doors can still be opened from inside.
Manual door lock. This is not the child lock.

||
KEY, LOCKS AND ALARM
250
–Remove the detachable key blade from theremote key. Insert the key blade into theopening for the lock mechanism and pushthe key in as far as possible, about 12 mm(0.5 in).
The door can be opened from both the out-side and the inside.
The door cannot be opened from the outside.To return to position A, open the door usingthe inside door handle.
The doors can also be unlocked by pressing theunlock button on the remote key or the centrallock button in the driver's door.

NOTE
The door's lock controls only lock thatspecific door, not all doors simultane-ously.
A manually locked rear door with an acti-vated manual or electric child safety lockcannot be opened from either the outsideor inside of the vehicle. A rear doorlocked in this way can only be unlockedusing the remote key or the centralunlocking button.

Related information
Detachable key blade (p. 248)
Arming and disarming the alarm (p. 267)
Replacing the remote key's battery (p. 243)
Remote key (p. 237)Electronic immobilizer
The electronic immobilizer is a start inhibitor thathelps prevent the vehicle from being started byan unauthorized person.
The vehicle can only be started with the rightremote key.
The following instrument panel error messagesare related to the electronic immobilizer:
Symbol Message Meaning
Vehicle keynot found
SeeOwner'smanual
Remote key notrecognized duringstart. Place theremote key on thekey symbol in thecup holder and tryto start the vehicleagain.

KEY, LOCKS AND ALARM
}}
* Option/accessory.251

Remote immobilizer with tracking
system 11
The vehicle is equipped with a system that makesit possible to track and locate the vehicle and toremotely activate the immobilizer to prevent thevehicle from being started. Contact your nearestVolvo retailer for more information and assistanceactivating the system.
The following instrument panel error messagesare related to the remote immobilizer with track-ing system:
Symbol Message Meaning
Remotelyimmobilised
Vehicle notpossible tostart
The remoteimmobilizer withtracking system isactivated. Thevehicle cannot bestarted. ContactVolvo On CallService Center.

Related information
Remote key (p. 237)
Ordering additional remote keys (p. 246)
Start and lock system typedesignations
The following information contains type designa-tions for the start and lock system.
Alarm system
USA FCC ID: MAYDA 5823(3)
This device complies with part 15 of the FCCrules. Operation is subject to the following condi-tions: (1) This device may not cause harmfulinterference, and (2) this device must accept anyinterference received, including interference thatmay cause undesired operation.
Canada IC: 4405A-DA 5823(3)
This device is subject to the following conditions:(1) this device may not cause interference, and(2) this device must accept any interference,including interference that may cause undesiredoperation of the device.

Remote keys (Passive entry/Passive
start * )
USA
Volvo Standard Key FCC ID: YGOHUF8423
Volvo Tag ID FCC ID: YGOHUF8432
This device complies with part 15 of the FCCrules. Operation is subject to the following twoconditions:
(1) This device may not cause harmful interfer-ence, and
(2) this device must accept any interferencereceived, including interference that may causeundesired operation.
Any changes or modification not expresslyapproved by the party responsible for compliancecould void the user's authority to operate thisequipment.
Canada
Volvo Standard Key IC: 4008C-HUF8423
Volvo Tag ID IC: 4008C-HUF8432
This device complies with Industry Canadalicense-exempt RSS standards. Operation is sub-ject to the following two conditions:
(1) This device may not cause harmful interfer-ence, and (2) this device must accept any inter-ference received, including interference that maycause undesired operation.

Immobilizer and Passive entry/Passive
start * systems
USA-FCC ID: LTQVO3134
This device complies with part 15 of the FCCrules. Operation is subject to the following twoconditions:

11
Only certain markets and in combination with Volvo On Call * .
