2019 VOLKSWAGEN E-GOLF Armrest

x Push down on the lever ⇒ fig. 42 (1).
x Adjust the steering wheel so that it can be held with hands at the 9 o'clock and 3 o'clock positions on the outside of the steering wheel rim and with the arms slightly bent at the elbow.
x Pull the lever up firmly until it is flush with the steering column ⇒ .
WARNING
Improper use of the steering column adjustment feature can result in serious personal injury and even death.
x Always pull the lever (1) firmly upward after adjusting the steering column so that the steering wheel does not change position suddenly while the vehicle is moving.
x Never adjust the steering column while the vehicle is moving. If you find that you need to adjust the steering wheel while driving, stop the vehicle in a safe place and make the proper adjustment.
x Never adjust the steering wheel so that it points toward your face. Always make sure that the steering wheel points toward your chest. Otherwise, the airbag system cannot protect you properly in the event of a crash.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of serious personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands anywhere inside the steering wheel or on the steering wheel hub. Holding the steering wheel the wrong way increases the risk of severe injury to the arms, hands, and head if the driver airbag de-ploys.
Center armrest

Fig. 43 Front center armrest.

Fig. 44 Folding down the rear center armrest (arrow).

Closing the pass-through
x Fold the pass-through cover back until it engages securely. The red marking on the luggage com-partment side should not be visible.
x Close the rear hatch.
x If necessary, fold the center armrest up.
The pass-through can also be opened from the luggage compartment. Press the release lever
⇒ fig. 91 in the direction of the arrow and push the cover forward.
Tie-downs

Fig. 92 In the luggage compartment: Tie-downs.

Storage compartment in the front center armrest

Fig. 109 In the front center armrest: Storage compartment.

To open, fold the center armrest down.
To close, fold the center armrest up.
WARNING
Always keep the armrest folded up when the vehicle is moving to reduce the risk of injury.
x Never let anybody, especially children, ride on the rear center armrest or in the center position on the rear seat when the armrest is folded down. An improper seating position can increase the risk of serious injury in a crash.
Cup holders in the rear trim

Fig. 116 In the trim next to the rear seats (2-door models only): Cup holder.

If the ignition is on but the electric motor is not activated, the vehicle battery will be drained by any device that is plugged in and turned on. For this reason, never use the electrical sockets unless the electric motor is activated.
To help prevent damage from voltage fluctuations, switch off all electrical devices connected to a 12 Volt socket before switching the ignition on or off or starting the electric motor.
The vehicle may have 12 Volt sockets at the following places:
x In the lower center console ⇒ fig. 117.
x In the luggage compartment ⇒ fig. 118.
x In the front center armrest storage compartment ⇒  Storage compartment in the front center arm-rest.
NOTICE
x Follow the manufacturer's instructions for connected devices!
x Never exceed the maximum power consumption, or the entire vehicle electrical system may be damaged.
x 12 Volt socket:
– Only use equipment that has been tested for electromagnetic compatibility and complies with applicable guidelines.
– Never feed current into the socket, with a solar panel, for example.
Unshielded devices may interfere with radio reception or the vehicle's electrical system.
