3415-10. Bluetooth® phone (Multimedia system)
5
Audio system
PRIUS c_U
Press the “ ” button.
Select .
When an e-mail/SMS/MMS is received, the incoming message screen
pops up with sound and is ready to be operated on the screen.
Select to check the message.
Select to refuse the message.
Select to call the message
sender.
Bluetooth® phone message function
Received messages can be forwarded from the connected
Bluetooth® phone, enabling checking and replying using the
multimedia system.
Depending on the type of Bluetooth
® phone connected, received
messages may not be transferred to the message inbox.
If the phone does not support the message function, this func-
tion cannot be used.
Displaying messag e inbox screen
Receiving a message
1
2
1
2
3

4207-3. Do-it-yourself maintenance
PRIUS c_U
Engine compartment
Fuse boxes (P. 4 5 2 )
Engine oil filler cap ( P. 4 2 2 )
Engine coolant radiator cap
Power control unit
coolant reservoir ( P. 4 2 4 )
Brake fluid reservoir ( P. 4 2 6 )
Engine coolant reservoir ( P. 4 2 4 ) Engine/power control unit
coolant radiator (
P. 426)
Electric cooling fan
Condenser ( P. 426)
Engine oil level dipstick ( P. 421)
Washer fluid tank ( P. 428)1
2
3
4
5
6
7
8
9
10
11

4527-3. Do-it-yourself maintenance
PRIUS c_U
Vehicles without a smart key system: Turn the power switch to the
“LOCK” poison.
Vehicles with a smart key syst em: Turn the power switch off.
Engine compartment
Push the tab in and lift the cover off.
Under the instrument panel
Remove the cover.
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may
have blown. If this happens, che ck and replace the fuses as nec-
essary.
1
2
Type A fuse boxType B fuse box
2

4547-3. Do-it-yourself maintenance
PRIUS c_U
Check if the fuse is blown.4
Ty p e AType B
Ty p e CType D
Ty p e E
Normal fuse
Blown fuse
Type A, B, C and D:
Replace the blown fuse with a new fuse of an appropriate amperage rat-
ing. The amperage rating can be found on the fuse box lid.
Type E:
Contact your Toyota dealer.
1
2

4557-3. Do-it-yourself maintenance
7
Maintenance and care
PRIUS c_U
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been repla ced, a bulb may
need replacement. ( P. 456)
● If the replaced fuse blows again, have the vehicle inspected by your Toyota
dealer.
■ If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness f rom damage.
WARNING
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or
injury.
● Never use a fuse of a higher amperage rating than that indicate d, or use
any other object in place of a fuse.
● Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
● Do not modify the fuses or fuse boxes.
■ Fuse box near the power control unit
Never check or replace the fuses as there are high voltage parts and wiring
near the fuse box.
Doing so may cause electric shoc k, resulting in death or serious injury.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired b y your
Toyota dealer as soon as possible.

5198-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U
If you have a set of jumper (or booster) cables and a second vehicle
with a 12-volt battery, you can jump start your vehicle by foll owing the
steps below.
Open the hood and remove the
fuse box cover.
Push the tab in and lift the cover
off.
Open the exclusive jump start-
ing terminal cover.
Push the tab in and open the cover.
If the vehicle 12-volt batter y is discharged
The following procedures may be used to start the hybrid sys-
tem if the 12-volt battery is discharged.
You can also call your Toyota de aler or a qualified repair shop.
1
2

5218-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U
Vehicles without a smart key system:
Maintain the engine speed of the second vehicle and start the
hybrid system of your vehicle by turning the power switch to the
“ON” position.
Vehicles with a smart key system:
Maintain the engine speed of the second vehicle and start the
hybrid system of your vehicle by turning the power switch to ON
mode.
Make sure the “READY” indicator comes on. If the indicator does
not come on, contact your Toyota dealer.
Once the hybrid system has started, remove the jumper cables in
the exact reverse order from which they were connected.
Close the exclusive jump starting terminal cover, and reinstall the
fuse box cover to it s original position.
When installing, first hook the fuse box cover onto the two rea r tabs.
Once the hybrid system starts, have the vehicle inspected at yo ur
Toyota dealer as soon as possible.
6
7
8
9

589Alphabetical index
PRIUS c_U
Floor mat .................................... 26
FluidBrake .................................... 540
Washer ................................. 428
Fog lights
Replacing light bulbs............. 462
Switch ................................... 210
Front fog lights
Replacing light bulbs............. 462
Switch ................................... 210
Front passenger occupant
classification system .............. 52
Front passenger’s seat belt reminder light ................. 479
Front seats Adjustment ............................ 148
Front sensor............................. 224
Automatic High Beam ........... 224
LDA (Lane Departure Alert)........ 224
PCS (Pre-Collision System)........ 224
Precautions ........................... 225
Front side marker lights Replacing light bulbs............. 463
Switch ................................... 206
Wattage ................................ 542
Front turn signal lights Replacing light bulbs............. 458
Switch ................................... 204
Wattage ................................ 542
Fuel Capacity ................................ 536
Fuel gauge .............................. 97
Information ............................ 543
Refueling............................... 219
Type ...................................... 536
Fuel door .................................. 219
Fuel filler door.......................... 219
Fuses ........................................ 452 Gauges ....................................... 97
Glove box ................................. 387
Hazard lights
Switch ................................... 466
Head restraints Adjusting .............................. 153
Headlights Replacing light bulbs ............ 462
Switch ................................... 206
Heaters Seat heaters ......................... 382
Side mirrors .......................... 376
Hill-start assist control ........... 263
Hood ......................................... 417
Horn .......................................... 156
Hybrid system Emergency shut off system .... 80
Energy monitor/consumption screen ........... 110
High voltage components ....... 79
Hybrid system indicator ........ 108
Power switch ........................ 190
Vehicle Proximity Notification System .............. 75
