2019 SUBARU IMPREZA Quick Guide

23
Location of Spare Tire and Jack
A jack handle is stored under the floor of the trunk (4-door) or the cargo area
(5-door). A jack and a towing hook are stored in the tool bucket in the center of
the spare tire. Also, a tool bag that contains a wheel nut wrench and a screwdriver
is included with the vehicle.
Emergency Towing Your All-Wheel Drive Vehicle
Since Subaru Symmetrical All-Wheel Drive distributes engine power to all\
four
wheels, improper towing will severely damage your AWD system. A flatbed truck
is the only recommended way to properly transport your AWD vehicle. If towing is
necessary, it is best done by your Subaru Retailer or a commercial towing service.
Subaru Roadside Assistance
Subaru Roadside Assistance is free and standard on your vehicle. Coverage
is automatic; there are no forms to complete. Subaru Roadside Assistance
is available anytime during the 3-year/36,000-mile Subaru Limited Warranty,
whichever comes first.* A Subaru Roadside Assistance decal has been af\
fixed to
the driver’s door window.
Subaru Roadside Assistance:
1-800-261-2155
Exclusions
Specifically excluded from Subaru Roadside Assistance coverage are service
requests or claims resulting from: accidents, vandalism, acts of God, violation
of any laws, misuse and abuse, or vehicle modifications not recommended by
the manufacturer.
*See your Retailer for details.
4-door:
5-door:
Safety/In Case of Emergency
3641428_19b_Impreza_QRG_072518.indd 237/25/18 11:19 AM
Getting
Started Instrument
Panel Gauges
Personalize ControlsWhile
Operating Safety/In Case
of Emergency Additional
Information

24
Fuel
Use regular unleaded gasoline with an octane rating of 87 AKI or higher. Consult the Owner’s
Manual for more detailed information.
Fuel Capacity
• 13.2 US gal (50 liters, 11.0 Imp gal)
• When the low fuel indicator light is displayed on the instrument panel, \
approximately
2 US gal (7.5 liters, 1.65 Imp gal) of fuel remain.
• If you have recently fueled your vehicle, the Check Engine light on the instrument pa\
nel
may stay on due to a missing or loose fuel filler cap (the cap should\
be tightened until
a click is heard).
Fuel Filler Lid Release
The fuel filler lid release is located on the floor to the left of the driver’s
seat. To open the fuel filler lid, pull the fuel filler lever up and release.
Additional Information
3641428_19b_Impreza_QRG_072518.indd 247/25/18 11:19 AM

25
Engine Oil
Use only the following oils:
• ILSAC GF-5, which can be identified with the ILSAC certification mar\
k
(Starburst mark).
• Or API classification SN with the words “RESOURCE CONSERVING.”
- Use 0W-20 synthetic, replacement intervals 6,000 miles under normal
driving conditions. No requirement at the first 3,000 miles.
Engine Oil Capacity
• 4.7 US qt (4.4 liters, 3.9 Imp qt)
Tire Pressure Monitoring System (TPMS)
Your vehicle is equipped with a Tire Pressure Monitoring
System (TPMS). The individual tire pressure is found in the
Combination Meter Display. Tire pressure specifications
may be found on the tire information placard found on
the driver’s side door pillar. Please refer to your Owner’s
Manual for more information.
Additional
Information
3641428_19b_Impreza_QRG_072518.indd 257/25/18 11:19 AM
Getting
Started Instrument
Panel Gauges
Personalize ControlsWhile
Operating Safety/In Case
of Emergency Additional
Information

26
Engine Compartment
Additional
Information
Please refer to your Owner’s Manual for more information.
2.0 L Engine
1 Brake Fluid Reservoir

2 Main Fuse Box

3 Battery

4 Windshield Washer Tank

5 Radiator Cap
6
Engine Oil Filler Cap

7 Engine Coolant Reservoir

8 Engine Oil Filter

9 Engine Oil Dipstick

10 Air Cleaner Element
1
9
3
86
7
10
2
5
4
3641428_19b_Impreza_QRG_072518.indd 267/25/18 11:19 AM
