12
Personalize
Tilt and Telescopic Steering Column
Pull the lever down firmly to adjust the height and lengthwise positio\
n of the column; firmly
push the lever back up to lock the column in place. Do not adjust while \
driving.
Power Exterior Mirrors
Turn the knob to the “L” side to adjust the left-hand mirror or to the “R” side to
adjust the right-hand mirror. Move the knob in the direction you want to move the
mirror. Then return the knob to the neutral/center position.
i/SET Combination Meter Display Controls (if equipped)
Use the controls to display and switch
selected items in the combination meter
display. Please refer to your Owner’s Manual
for details on these controls.
3640014_19b_Crosstrek_QG_072318.indd 127/23/18 3:34 PM

13
Personalize
HomeLink® 5 Accessory Mirror (if equipped)
The HomeLink 5 accessory mirror provides three buttons to replace up to three
hand-held radio frequency remotes used to activate devices such as garage
door openers, gate openers, entry door locks, security systems and home \
lighting. Please see your Owner’s Manual for programming instructions or visit
www.subaru.com/homelink to view a how-to video.
Power Moonroof (if equipped)
With the moonroof in the fully closed position, press and hold the switch 1 to tilt
the rear of the moonroof up. Press and hold the switch
2 to lower the moonroof.
Press and hold the switch
3 to fully open the moonroof. Press and hold the switch
4 to close the moonroof. To stop the moonroof in a midway position while opening
or closing, momentarily press the switch to side
3 or side 4.
13
24
3640014_19b_Crosstrek_QG_072318.indd 137/23/18 3:34 PM
Getting
Started Instrument

Panel Gauges
Personalize ControlsWhile

Operating Safety/In Case

of Emergency Additional

Information

16
Controls
Manual Climate Control System (if equipped)
1 Air Flow Control Dial
The air flow control dial allows you to
choose the direction of air flow. Rotate
the dial for the desired air flow position.

Defrost/Defog
To clear the windshield and front door
windows of fog or frost, rotate the air
flow control dial to the defrost position,
set the temperature control to the red
position, and set the fan speed control
to the fastest speed.
2 Rear Window Defogger Button
Press the rear window defogger button
to turn on the defogger. The defogger
will automatically shut off after about
15 minutes. If the window clears before
that time, you can press the button again
to turn it off. If equipped, the outside
mirror defogger and windshield wiper
deicer will also activate.
3 Fan Speed Control Dial
Rotate the fan speed control dial to select
the desired fan speed.
4 Recirculated/Outside Air Button
Press the air inlet selection button to
prevent outside air from being drawn
into the passenger compartment. If the
button is pushed in, press it again to draw
outside air into the compartment. TO
PREVENT WINDSHIELD FOGGING, DO
NOT REMAIN IN THE RECIRCULATED
MODE FOR AN EXTENDED PERIOD
OF TIME.
5 Temperature Control Dial
Rotate the temperature control dial from
blue for cool, to red for warm.
6 Air Conditioning Button
Press the “A/C” button to activate the air
conditioning. Press it again to turn off the
air conditioning.
3
51
246
3640014_19b_Crosstrek_QG_072318.indd 167/23/18 3:34 PM

17
Controls
Automatic Climate
Control System
(if equipped)
1 Automatic On and Off
This system automatically controls
outlet air temperature, fan speed,
air flow distribution, air inlet control,
and air conditioner compressor
operation. Press “AUTO” to activate.
Press “OFF” to turn off the system.
2 Temperature Control Dial
Rotate the dial clockwise to
increase the temperature or
rotate the dial counterclockwise
to decrease the temperature and
maintain a comfortable climate
within the driver and passenger
compartment. The temperature is
displayed digitally on the screen.
Operation in Manual Mode
3 Recirculated/Outside Air Button
Press the air inlet selection button to
prevent outside air from being drawn
into the passenger compartment.
Press the button again to allow
outside air into the compartment.
TO PREVENT WINDSHIELD
FOGGING, DO NOT REMAIN IN
THE RECIRCULATED MODE FOR
AN EXTENDED PERIOD OF TIME.
4 Fan Speed Control Knob
Rotate the fan speed control knob
to select the desired fan speed.
5 Air Flow Mode Selection Dial
Turn the “MODE” dial to select
the desired air flow mode. The
selected air flow mode – either
ventilation, bi-level, heat or heat-
defrost – is shown on the display.
6 Air Conditioner Button
Press the “A/C” button to activate
the air conditioning. Press it again
to turn off the air conditioning.
7 Defroster Button
Press the button to defrost
or dehumidify the windshield
and front door windows.
8 Rear Window Defogger Button
Press the button to turn on the
defogger. It will automatically shut
off after about 15 minutes. If the
window clears before that time,
you can press the button again to
turn it off. If equipped, the outside
mirror defogger and windshield
wiper deicer will also activate.
9 Maximum Air Conditioner Button
For quicker cooling, press
the “MAX A/C” button.
Located in the multi-function
display; top center of dash
1
3
4
582
796
3640014_19b_Crosstrek_QG_072318.indd 177/23/18 3:35 PM
