Fuses and bulbs
Replace a blown fuse Fig. 53
Image of a blown fuse. Preparations

Emergencies
No. Consumer/Amps
40 Light switch, diagnosis input, head-
lamp range regul
at
or, LSS steering
column: lamps, halogen lamps,
switch, reverse gear, electrochromic
mirror, RKA without radio. 7.5
41 Regulation of unfolded exterior mir-
rors, 7.5
42 Clutch pedal
, ignition r

elays, CNG
relay coil, AC pr essur

e sensor7.5
43 DWP relay coil, rear window wiper motor, heated no zzl

es 15
44 Airbag 7.5
45 Left full LED headlight 7.5
46 Right full LED headlight 7.5
48 Steering column lock, Kessy Control
Unit 7.5
49 SCR relay 7.5
53 Automatic gearbox lever, ZSS 7.5
58 Windscreen washer pump 7.5
59 Heated rear view mirrors 10
60 Tow hook 30
61 Tow hook 30 Fuse arrangement in engine compartment
No. Consumer/Amps
1 MPI Engine Injection Module
10
TSI Engine Injection Module 15
Diesel Engine Injection Module 30
2 Fuel metering valve (TJ4/T6P/TJ7),
Low temper
at

ure coolant pump
(TJ4/T6P/TJ7); Oil pressure regulat-
ing valve (TJ1), AGR coolant valve
(TJ1), High and low pressure water
pumps (TJ1), SCR relay coil, cylin-
der head water valve 7.5
3 Lambda probes 15
4 Engine petrol pump relay (MPI),
Gauge control unit (TSI and diesel) 15
5 Electric f
an (EC), LDR v

alve, canni-
ster and variable distribution val
ve,
oil pressure regulating valve, cylin-
der disconnection valves, WIV sen-
sor and CNG pressure regulator 10
6 Spark plugs (MPI and TSI)
20
Glow plug relay, Suction hose resis-
t or (diesel) 7.5
7 Vacuum pump (TSI, CNG) 15
8 Inject

ors and EKP relay coil (MPI),
Fuel metering valve (diesel) 10
9

Servo sensor 7.5 No. Consumer/Amps
10 Vref Battery: Gateway, BDM and
BCM 7.5
12 Detachable compressor 10
14 Injection Module, Engine Hauptre-
lay, ESC / ABS, Relay Coil 87 7.5
15 Aut
omatic gearbo

x DQ200 and
AQ160 30
17 50 Diag 7.5
18 BDM starter motor 30
20 ESC (Pump)
60
ABS (Pump) 40
21 ESC/ABS (Valves) 25
24 TH4 Electric fan without A/C for
moder
ate climate countries 30
25 TH4 f
an with A/C or T5I f

or moder-
ate climate countries 20
PTC1 40
26 T

J1/TJ4/TJ7/T6P or TH4/T5I Electric
fan for warm climate countries 50
27 TH4 f

an with A/C or T5I for moder-
ate climate countries 30
PT C2 40
28

PTC3 4056

Fuses and bulbs
Note

Emergencies
Bulb light Left Right
Brake lights 2 x P21WLL 2 x P21WLL
Side lights
Retro fog light W21W

Fuses and bulbs

Emergencies

Fuses and bulbs

Emergencies
Interior light and front reading
lights Fig. 63
Front reading light. To remove the glass
