Overview
ofclimat econtrol systems General
notes
Observe thesettings recom mended onthe fol-
lowing pages. Thewindows couldotherwisefog
up.
To preven tthe windows fromfogging up:
R switch offclimate control only briefly
R switch onair-rec irculation modeonlybriefly
R switch onthe cooling withairdehumidifica-
tion function
R switch onthe defrost windshield function
briefly, ifrequired
The air-con ditionin gsystem ordual-zon eauto-
matic climate control regulates thetemper ature
and thehumidity ofthe vehicle interiorand fil-
ters undesirable substancesfrom theair.
The air-con ditionin gsystem ordual-zon eauto-
matic climate control can only beoperated
when theengin eis runn ing.Optimum operation
is only achieved withtheside windows andpan-
orama roofwith power tilt/sliding panelclosed.
If you start theengine usingyoursmart phone,
the last select edclimate control settingisreac-
tivat ed(Ypage 83).
The residual heatfunctioncanonly beactivat ed
or deactivat edwith theignition switched off
(Y page 120). Always
keepthevent ilation flapsbehind the
side trimpanel inthe cargo compart mentclear
(Y page 107). Otherwisethevehicle willnotbe
vent ilated correctly.
i Vent
ilate thevehicle forabrief period during
warm weather, e.g.using theconvenien ce
opening feature(Ypage 83).This willspeed
up the cooling process andthedesired inte-
rior temper aturewillbereached more
quickly.
i The
integ rated filterfilters outmost parti-
cles ofdust andsoot andcomplet elyfilters
out pollen. Italso reduces gaseous pollutant s
and odors. Aclogged filterreduces the
amount ofair supplied tothe vehicle interior.
For this reason, youshould alwaysobserve
the inter valforreplacing thefilter, which is
specified inthe Mainten anceBooklet.Asit
depends onenviro nmentalcon ditions ,e.g.
heavy airpollution, theinter valmay be
short erthan statedinthe Mainten anceBook-
let.
i It
is possible thatunder certaincirc umstan -
ces theresidual heatfunction may beactiva-
ted automatic allyanhour after theSmart Key
has been removed inorder todry the auto-
matic climate control. Thevehicle isthen ven-
tilated for30minut es. Overview
ofclimat econtrol systems
111Climat econtrol

Canada
only
0043 Setsth ete mper ature,left (Ypage 117)
0044 Setsclim atecontrol to auto matic(Y page 117)
0087 Defrost sth ewind shield(Y page 118)
0085 Incr eases theairf low (Ypage 118)
0083 Setsth eair dist ribut ion(Ypage 117)
0084 Display
006B Swit ches air- recirculatio nmode on/of f(Y page 120)
006C Activate s/deac tivate sclim atecontrol (Y page 116)
006D Setsth ete mper ature,righ t(Y page 117)
006E Swit ches theres idual heatonoroff (Ypage 120)
006F Swit ches coo ling with airdehum idification on/of f(Y page 116)
0070 Reduc estheairf low (Ypage 118)
0071 Swit ches therear wind owdefr osteron/of f(Y page 119)
0072 Swit ches theZONE function on/of f(Y page 118) Opt
imu muse ofdual-zone autom atic
clim atecontr ol
Clim atecontr olsyst em The
followin gcon tain sins truct ionsand recom-
men dationsto enab leyou toget themos tout of
your dual-zone auto maticclim atecontrol.
R Ac tivate clim atecontrol usin gth e0058 and
005A buttons.The indicat orlamps inthe
0058 and005A buttonslight up.
R Set thete mper atureto 72 ‡(22 †).
R On lyuse the"Win dshielddefr osting"fun ction
brie flyunt ilth ewind shieldiscle aragain .
R On lyuse air-recirculatio nmode briefly,e.g.if
th ere areunpl easan tout side odor sor when in
a tun nel.The wind owscouldot her wise fogup, sin
ce no fresh airisdrawn intoth eveh icle in
air- recirculatio nmode .
R Use theZONE function toadopt thete mper -
atur eset tings on thedriv er'sside forthe
fr on t-passe nger side aswell. Theindicat or
lamp inthe00D6 buttongoes out.
R Use theres idual heatfunction ifyou want to
heat orven tilate theveh icle interio rwhen the
ign ition isswit ched off.The residual heat
fun ction can onlybe act ivat edordeac tivate d
with theign ition swit ched off.
R Ifyou chang eth eset tings oftheclim atecon-
tr ol syst em, theclim atestatus display
appear sfor appro ximatelythree seconds at
th ebot tom of thesc reen onthemult imed ia
syst emdisplay; seeDigital Oper ator'sMan - Over
view ofclima tecontr olsyst ems
115Climatecontr ol

Problems
withthe"Cool ingwith airdehum idification" function Problem
Possible
causes/co nsequences and0050 0050
Solutions The
indicator lampinthe
005A button flashes
three times orremains
off. The "Cooli ngwith air
<00470048004B00580050004C0047004C0049004C004600440057004C00520051
0005[ func-
tion cannot beswitched
on. Cooling
withairdehumidification hasbeen deactivated duetoamal-
funct ion.
X Visit aquali fiedspecialist workshop. Setting
climate controltoautom atic
General notes The
automatic climatecontrolfunct ionisonly
availa bleinconj unction withdual-zone auto-
matic climate control.
In automatic mode,thesettemperature ismain-
tained automatically ataconst antlevel. The
system automatically regulatesthetemperature
of the dispensed air,the airflow andtheairdis-
tribution.
The "Cooli ngwith air<00470048004B00580050004C0047004C0049004C004600440057004C00520051
0005[ function
is activated automatically inautomatic mode.
Setting climate controltoautom atic X
Turn theSmartK eytoposition 0044inthe igni-
tion lock (Ypage 123).
X Set thedesired temperature.
X To activate: pressthe0058 button.
The indicator lampinthe 0058 button lights
up. Automatic airdistribution andairflow are
activated.
X To switch tomanua lmode: pressthe004F
or 004A button.
or X Press the0097 or0095 button.
The indicator lampinthe 0058 button goes
out. Automatic airdistribution andairflow are
deactivated. Setting
thetemp eratu re
Air-conditioning system You
cansetthe temperature forthe entire vehi-
cle. The settemperature isautomatically main-
tained ataconst antlevel.
X Turn theSmartK eytoposition 2in the ignition
lock (Ypage 123).
X To increase orreduce: turncontrol0043 coun-
ter- clockwise orclockwise (Ypage 112). Only
change thetemperature settingin small
incremen ts.Start at72 ‡(22 †).
Dual-zone automaticclimate control Differen
ttemperatures canbeset forthe driv-
er's andfront -passenger sides.Thesettemper-
ature isautomatically maintainedataconst ant
level.
X Turn theSmartK eytoposition 2in the ignition
lock (Ypage 123).
X To increase ordecrease: turncontrol0043 or
006D counter -clockwiseorclockwise
(Y page 114). Onlychange thetemperature
settin gin small incremen ts.Start at72 ‡
(22 †). Setting
theairdistr ibution
Air-conditioning system Air
distr ibution settings
0061 Directsair through thedefroster vents
009C Directsair through thecent erand side air
vent s
009B Directsair through thefootwell airvent s Operat
ingthe climate controlsystems
117Climat econ trol

The
climate controlsystem switches tothe
following functions:
R high airflow
R high temperat ure
R air distribution tothe windshield andfront
side windows
R air-recirc ulationmodeoff
i The
"Windshield defrosting"funct ionauto-
matically setstheblower leveltothe optimum
defrost ingeffect .As aresult, theairflow may
increase ordecrease automatically afterthe
0064 button ispressed.
i You
canadjust theblower levelmanually
while the"Windshield defrosting"funct ionis
in operation:
R Air- condit ioning system: turnairflow con-
trol 0083count er-clockwise orclock wise
(Y page 112).
R Dual-zon eautomatic climatecontrol:press
the 00F2 or00F3 button .
X To deactivat e:press the0064 button .
The indicator lampinthe 0064 button goes
out. Thepreviously selectedsettings are
restor ed.Air-recirc ulation moderemains
deactivated.
or
X Dual-zon eclimate control:press the0058
button .
The indicator lampinthe 0064 button goes
out. Airflow andairdistribution aresetto
automatic mode.
or X Air- condit ioning system: turntemperat ure
cont rol0043 count er-clockwise orclock wise
(Y page 112).
Dual-zon eautomatic climatecontrol:turn
temperat urecont rol0043 or006D count er-clock-
wise orclock wise(Ypage 114). MAX
COOL maxim umcooli ng
The MAX COOL functionisonly availabl ein vehi-
cles forthe USA .
MAX COOL isonly operational whentheengine
is runnin g. X
To activat e:press the00C9 button .
The indicator lampinthe button lightsup.
X To deactivat e:press the00C9 button .
The indicator lampgoesout.Thepreviously
selected settings arerestor ed.
When youactivate MAXCOOL, climate control
switches tothe following functions:
R maximum cooling
R maximum airflow
R air-recirc ulationmodeon Removing
condensation fromthewin-
dows
Windows foggeduponthe inside Air-conditioning
system
X Act ivate the005A "Cooling withairdehumid-
ification" function.
X Ifthe windows continue tofog up,activate the
0064 "Windshield defrosting"funct ion.
i You
should onlyselect thissettinguntil the
windshield isclear again.
Dual-zone automat icclimate control
X Act ivate the005A "Cooling withairdehumid-
ification" function.
X Act ivate automatic mode0058.
X Ifthe windows continue tofog up,activate the
0064 "Windshield defrosting"funct ion.
i You
should onlyselect thissettinguntil the
windshield isclear again.
Windows foggeduponthe outside X
Act ivate thewindshield wipers.
X Set theairdistribution to009C or009B.
i You
should onlyselect thissettinguntil the
windshield isclear again. Rear
window defroster
General notes The
rear window defroster hasahigh current
draw. Youshould therefor eswitch itoff assoon
as the rear window isclear. Otherwise, therear
window defroster switchesoffautomatically
after several minutes. Opera
tingtheclimate controlsystems
119Climatecontrol

If
the battery voltage istoo low, therear window
defroster mayswitch off. Ac
tivating/de activating X
Turn theSmartKey topositio n0048 inthe igni-
tion lock (Ypage 123).
X Press the006C button.
The indicator lampinthe 006C button lights
up orgoes out.
Proble mswith therear window defroster Proble
m Possi
blecauses /consequen cesand 0050 0050
Solutio ns The
rear window
defroster hasdeactiva -
ted premature lyor can-
not beactivated. The
battery hasnotbeen sufficie ntlycharged.
X Switch offany consumers thatarenot requi red,e.g.readi nglamp s,
interior lighting orthe seat heating.
When thebattery issufficie ntlycharged, therear window defroster
can beactivated again. Swi
tching air-recirculatio nmode
on/ off
Gene ralnotes You
candeactiva tethe flow offresh airif
unple asantodors areentering thevehicle from
outsid e.The airalrea dyinside thevehicle will
then berecircula ted.
If you switch onair-recircu lationmode, thewin-
dows canfogupmore quickly, inparticul arat
low temperature s.Only useair-recircul ation
mode brieflyto prevent thewindow sfrom fog-
ging up.
The opera tionofair-recircul ationmode isthe
same forallcontrol panels.
Ac tivating/de activating X
Turn theSmartKey topositio n0048 inthe igni-
tion lock (Ypage 123).
X To activate: pressthe008A button.
The indicator lampinthe 008A button lights
up.
Air-recircula tionmode switches onautoma ti-
cally :
R at high outsid etemperature s
R at high levelsof poll ution
When air-recircu lationmode isactivated auto-
matical ly,the indicator lampinthe 008A button
is not lit.Outside airisadde dafter about
30 minutes . X
To deactivate: pressthe008A button.
The indicator lampinthe 008A button goes
out.
i Air-recircula tionmode deactiva tesauto-
matical ly:
R after appro ximately fiveminutes atoutsid e
temperature sbelo wappro ximately 45‡
(7 †)
R after appro ximately fiveminutes ifthe
"Co oling withairdehu midifi cation" func-
tion isdeactiva ted
R after appro ximately 30minutes atoutsid e
temperature sabove approximately 45‡
(7 †) ifthe "Cooling withdehu midifi cation"
function isactivated Swi
tching theresidual heatonoroff
Gene ralnotes The
residu alheat function isonly availablein
vehicle sfor Cana dawith dual-zone automa tic
climate control.
It is possib leto make useofthe residu alheat of
the engine tocontinue heatingthevehicle for
appro ximately 30minutes aftertheengine has
been switched off.The heating timedepends on
the setinterior temperature .
i The
blow erwil lrun atalow speed regard less
of the airflowsetting. 120
Operating
theclimat eco ntrol systemsClimate control

G
WARNING
Flamma blemateria lsintrodu cedthrough
environmental influence orby anima lscan
ignite ifin contact withtheexhau stsystem or
parts ofthe engine thatheatup. There isarisk
of fire.
Ca rry out regu larchecks tomake surethat
there arenoflamma bleforeig nmateria lsin
the engine compartment orinthe exhau st
system.
Gene ralnote s During
acold start, theengine runsathigh er
spee dstoenabl ethe catal yticconverter to
reach itsopera tingtempera ture.Thesound of
the engine maychange duringthis time.
Automatic transmissio n X
Shift thetransmissi ontoposi tion 005D
(Y pag e132) .
The transmissi onposi tion indica toronthe
multi function displayshow s005D
(Y pag e131) .
i You
canstart theengine intransmissi on
posi tions 005Dand 005C.
Starting procedurewith the SmartKey To
start theengine using the SmartKey instead
of the Start/Stop button,pullthe Start/Stop
button outofthe ignitio nlock.
X Turn theSmartKey toposi tion 0049inthe igni-
tion lock (Ypag e123) andrelease itas soon
as the engine isrunning.
Starting procedurewith the Start/Stop
button The
Start/Stop buttoncanbeused tostart the
vehicl emanua llywitho utinserting theSmartKey
into theignitio nlock. TheStart/Stop button
must beinserted inthe ignitio nlock andthe
SmartKey mustbeinthe vehicl e.This mode for
starting theengine operatesindep endently of
the ECO start/stop automatic enginestartfunc-
tion.
You canstart theengine ifavali dSmartKey isin
the vehicl e.Switch offthe engine andalways
take theSmartKey withyouwhen leaving the vehicl
e,even ifyou only leaveitfor ashort time.
Pay attention tothe importa ntsafety notes.
X Depress thebrake pedaland keep it
depre ssed.
X Press theStart/Stop buttononce
(Y pag e123) .
The engine starts.
Starting procedureviasmartphone Observe
theimporta ntsafety notesonstarting
the engine (Ypag e124) .
You canalsostart yourengine viayou rsmart-
phone fromoutsidethe vehicl e.In this case, the
previ ouslysele cted clima tecontrol settingis
activa ted.Inthis way youcan cool orheat the
interior ofthe vehicl ebefore starting thejour-
ney.
Only start theengine viayou rsmartpho neifit is
safe tostart andruntheengine whereyourvehi-
cle isparked .
Observe thelega lstipu lations inthe area where
you rvehicl eis parked .Engine startviasmart-
phone maybelimi ted tocertain countries or
regio ns.
You canexecute amaximu mof two consecutive
starting attempts viayou rsmartpho ne.Ifyou
insert theSmartKey intotheignitio nlock, you
can carry outtwo more starting attempts.
Once youhave started theengine, youcan
swi tch the engine offvia you rsmartpho neatany
time.
You canonly start theengine viayou rsmart-
phone if:
R the SmartKey isin the ignitio nlock
R park position 005Dissele cted
R the accele ratorpedalis not depre ssed
R the alarm for the anti-theft alarm system is
not set
R the pani cala rm isnot activa ted
R the hazard warninglamp sare switched off
R the hood isclosed
R the doors areclosed andlocked
R the windo wsand sliding sunroof areclosed
Also make surethat:
R the fuel tank issuffi ciently filled
R the starter battery hasbeen sufficiently
charge d Drivi
ng
125Drivi ngand parking Z

act
ivat ed.For further inf orm ationabout start ing
th eeng ine,see (Ypage 124). X
Pres sDYN AMICSELECT butt on0043 asman y
tim esasnec essar yunt ilth edesir eddriv e
prog ramisselec ted.
The selec teddriv eprog ramappear sin the
mult ifunction display. Afterfiv esec onds, the
display goesoutand thest atus symbo lof the
selec teddriv eprog ramappear s.
In addit ion,th ecur ren tdriv eprog ramsettings
are displaye dbrie flyinthemult imed iasyst em
display.
i In
afew coun tries, theECO start /stopfun c-
tio nis deac tivate dat thefac tory due tothe
availabl efuel grad e.In this cas e,theECO
st art /stopfun ction isno tavailabl ein any
driv eprog ram,reg ardle ssofthedisplay inthe
mult imed iasyst emdisplay.
Avai labledr ive progr ams: C
Comf ort Comf
ortable andeconomi-
cal driv ingcharac terist ics S
Spo rt Spo
rty driv ingcharac teris-
tic s I
In divid ual In
divid ualsettings E
Ec on omy Part
icular lyeco nomic al
driv ingcharac terist ics Add
ition alinf orm ationfor driv eprog rams
(Y page 135).
You canalso chang egear yours elfusin gth e
st eeri ngwheel paddle shifters. For further inf or-
mat ionontheman ualdriv eprog ram
(Y page 137). DYNAM
ICSELECT controller
(Mer cedes- AMGvehicles)
Use theDYN AMICSELECT con troller tochang e
th edriv eprog ram.De pen dingon thedriv epro-
gram selectedth efoll owin gveh icle charac ter-
ist ics will chang e:
R thedriv e
R thetrans miss ionman agem ent
R ES P®
R thesuspe nsion (veh icleswith AMGadapt ive
spor tsuspe nsion syst em)
R thesoun dof theexh aust system
R theavailabi lityof theECO start /stopfun ction
R theavailabi lityof glidin gmode
Eac htim eyou start theeng inewith theSm art-
Key ortheSt art /S topbutt on,driv eprog ramCis
act ivat ed.For further inf orm ationabout start ing
th eeng ine,see (Ypage 124). X
Turn DYNAMICSE LECT con troller 0043asman y
tim esasnec essar yunt ilth edesir eddriv e
prog ramisselec ted.
The selec teddriv eprog ramappear sin the
mult ifunction display. Afterfiv esec onds the
display goesoutand thesymbo lof theselec -
te ddriv eprog ramappear s.
The driveprog ramindicat oron DYN AMIC
SE LECT con troller 0043light sup inred.
Avai labledr ive progr ams: I
In divid ual In
divid ualsettings C
Comf ort Comf
ort-orien ted, opt i-
mum- economy eng ineand
tr ans miss ionsettings S
Spo rt Spo
rty eng ineand trans -
miss ionsettings 130
DYNAMIC
SELECTcontroller(Mercedes- AMGvehicles )Drivingand parking

R
gliding modeisnot availa ble.
R the ECO start/stop functionisnot availa ble.
Drive programS+(Sport Plus)
Drive program S+ischaracter izedbythe fol-
lowing:
R the vehicle exhibits particularly sportydriving
character istics.
R the automatic transmissionshiftsuplater.
R the fuel consumpt ionpossibly beinghigher as
a result ofthe later automatic transmission
shift points.
R the suspension exhibitsparticularly stiff
springing anddamping settings (vehicles with
AMG adaptive sportsuspension system).
R gliding modeisnot availa ble.
R the ECO start/stop functionisnot availa ble.
Drive programRACE (vehicle swith AMG
adap tivesport suspension system)
The RACE driveprogram ischaracter izedbythe
following:
R the vehicle exhibits drivingcharacter istics
suitable forthe racetrac k.
R all vehicle systems aresetformaximum
sportiness .
R the automatic transmissionshiftsuplater.
R the fuel consumpt ionpossibly beinghigher as
a result ofthe later automatic transmission
shift points.
R the suspension exhibitsparticularly stiff
springing anddamping settings.
R gliding modeisnot availa ble.
R the ECO start/stop functionisnot availa ble. Manual
gearshifting
General notes You
canchange gearyourself usingthesteering
wheel paddle shifters. Thetransm issionmustbe
in position 005Btodo this.
Depending onwhich steering wheelpaddle
shifter ispulled, theautomatic transmission
immediately shiftsintothenext gear down or
up, ifpermitt ed. Mercedes-AMG
vehicles:touse manual shift-
ing, youhave twooptions:
R temporary setting
R permanent setting
If you activate manualgearshifting, themulti-
funct iondisplay willshow thecurrent gear
instead oftransm issionposition 005B.
If manual gearshifting isdeactivated, thegears
will beselected automatically.
Temp orarysetting X
To activat e:shift theDIRECT SELECT lever to
position 005B.
X Pull steering wheelpaddle shifter0043or0044.
Temporary settingwill beactive foracert ain
amount oftime. Under certaincondit ionsthe
minimum amountoftime isexten ded,e.g.inthe
case oflateral acceleration, duringanoverrun
phase orwhen driving onsteep terrain.
X To deactivat e:pull steering wheelpaddle
shifter 0044and hold itin place.
or
X Use theDIRECT SELECT lever toswitch the
transm issionposition.
or X All vehicles (exceptMercedes-A MGvehicles):
use theDYNAMI CSEL ECT button tochange
the drive program.
Mercedes-A MGvehicles: usetheDYNAMI C
SEL ECT controller tochange thedrive pro-
gram. Automa
tictransmission
137Drivingandparking Z
