2019 MAZDA MODEL 6 fuel type

Fuel Economy Monitor
The Control Status*1 and Fuel Consumption are switched and displayed by operating each
icon in the display.
In addition, after completing a t rip, the total energy efficiency to date is displayed in the
ending display when the ending display is turned on.
1. Select the
icon on the home screen to display the Applications screen.
2. Select the “Fuel Economy Monitor”.
3. Select the
icon at the bottom left of the screen to display the menu in t he lower part
of the screen.
4. Select the icon in the menu and perform the operation. Each i con operates as follows:
Indication on display Control status
Hides the menu display.
Displays the Applications screen.
Switches the Fuel Economy Monitor in the order of
Control Status*1 and Fuel Consumption.
Resets the fuel economy data.
Displays the followi ng setting screen.
Ending display on/off switching(With Type C instrument cluster)
On/off switching for function which synchronizes
(links) reset of fuel econo my data with trip meter
(TRIP A)
*1 With Cylinder Deactivation.
NOTE
The fuel economy monitor screen after the ignition is switched from ON to OFF is changed
to the original fuel economy monitor screen wh en the ignition is switched ON the next time.
When Driving
Fuel Economy Monitor
4-109
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Fuel Consumption Display
Information regarding the fuel economy is displayed.
Indication on display
Control status
Displays the fuel economy for the past 60 minutes.
Displays the fuel economy every minute for the past
1 to 10 minutes.
Displays the fuel economy every 10 minutes for the
past 10 to 60 minutes.
Displays the average fuel economy over the past 5
resets and after the current reset.
Calculates the average fuel economy every minute
after vehicle travel begins, and displays it.
NOTE
(With Type A/B instrument cluster)
The fuel economy data is synchronized (linked) with the average fuel economy
displayed in the tripmeter (TRIP A).
To reset the fuel economy data, press the icon in the menu. (The average fuel
economy and TRIP A displayed in the tripmeter (TRIP A) reset at the same time.)
After resetting the fuel economy data, “- - -” is displayed while the average fuel
economy is being calculated.
(With Type C instrument cluster)
The fuel economy data is synchronized (linked) with the average fuel economy
displayed in the trip computer.
To reset the fuel economy data, press the icon in the menu. (The average fuel
economy displayed in the trip comp uter resets at the same time.)
After resetting the fuel economy data, “- - -” is displayed while the average fuel
economy is being calculated.
When Driving
Fuel Economy Monitor
4-110
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Control Status Display
The operation status of the cyli
nder deactivation is displayed.
Indication on display Control status
The condition of each cylinder is displayed by col‐
ors. The operating cylinders are displayed in red.
Calculates the average fu el economy every minute
after vehicle travel b egins, and displays it.
Instrument Cluster (Type A)
Synchronized (linked) with the average fuel econo‐
my displayed in the trip meter (TRIP A).
Refer to Average Fuel Economy on page 4-21.
To reset, press the icon in the menu. (The aver‐
age fuel economy and TRIP A displayed in the trip
meter (TRIP A) reset at the same time.)
Instrument Cluster (Type B)
Synchronized (linked) with the average fuel econo‐
my displayed in the trip meter (TRIP A).
Refer to Average Fuel Economy on page 4-37.
To reset, press the icon in the menu. (The aver‐
age fuel economy and TRIP A displayed in the trip
meter (TRIP A) reset at the same time.)
Instrument Cluster (Type C)
Synchronized (linked) with the average fuel econo‐
my displayed in the trip computer.
Refer to Trip Computer on page 4-51.
To reset, press the icon in the menu. (The aver‐
age fuel economy displayed in the trip computer re‐
sets at the same time.)
▼ Ending Screen Display
If the ending display
on the fuel economy m onitor is on when the ignition is switched from
ON to OFF, the information regarding the fuel economy is displa yed.
When Driving
Fuel Economy Monitor
4 - 111
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Except U.S.A., Canada
Use SAE 5W-30 engine oil.
Oil container labels provide important
information.
A chief contribution this type of oil makes
to fuel economy is reducing the amount of
fuel necessary to overcome engine
friction.

For maintenance service, Mazda
recommends Mazda Genuine Parts and
Castrol
® (Mexico only).


(ILSAC)
(Mexico)
80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
SKYACTIV-G 2.5
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 5W-20
engine oil.

The quality designation SM or SN, or
ILSAC must be on the label.

SKYACTIV-G 2.5T
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 0W-30
or SAE 10W-30 engine oil.

The quality designation SM or SN, or
ILSAC must be on the label.

Maintenance and Care
Owner Maintenance
6-25
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Tires
For reasons of proper performance, safety,
and better fuel economy, always maintain
recommended tire inflation pressures and
stay within the recommended load limits
and weight distribution.
WA R N I N G
Using Different Tire Types:
Driving your vehicle with different types of
tires is dangerous. It could cause poor
handling and poor braking; leading to loss
of control.
Except for the limited use of the temporary
spare tire, use only the same type tires
(radial, bias-belted, bias-type) on all four
wheels.
Using Wrong-Sized Tires:
Using any other tire size than what is
specified for the vehicle (page 9-8) is
dangerous. It could seriously affect ride,
handling, ground clearance, tire clearance,
and speedometer calibration. This could
cause you to have an accident. Use only
tires that are the correct size specified for
the vehicle.
▼ Tire Inflation Pressure
WA R N I N G
Always
inflate the tires to the correct
pressure:
Overinflation or underinflation of tires is
dangerous. Adverse handling or
unexpected tire failure could result in a
serious accident.
Refer to Tires on page 9-8.
Use only a Mazda-genuine tire valve cap:
Use of a non-genuine part is dangerous as
the correct tire air pressure cannot be
maintained if the tire valve becomes
damaged. If the vehicle is driven under this
condition, the tire air pressure will decrease
which could result in a serious accident. Do
not use any part for the tire valve cap that
is not a Mazda-genuine part.
Inspect all tire pressures monthly
(including the spare) when the tires are
cold. Maintain recommended pressures for
the best ride, handling, and minimum tire
wear.
Refer to the specification charts (page
9-8).
NOTE
Always check tire pressure when tires
are cold.
Warm tires normally exceed
recommended pressures. Do not release
air from warm tires to adjust the
pressure.
Underinflation can cause reduced fuel
economy, uneven and accelerated tire
wear, and poor sealing of the tire bead,
which will deform the wheel and cause
separation of tire from rim.
Overinflation can produce a harsh ride,
uneven and accelerated tire wear, and a
greater possibility of damage from road
hazards.
Keep your tire pressure at the correct
levels. If one frequently needs inflating,
have it inspected.
Maintenance and Care
Owner Maintenance
6-39
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Specifications
▼Engine
Item Specification
SKYACTIV-G 2.5 SKYACTIV-G 2.5T
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 2,488.5 ml (2,488.5 cc)
Compression ratio 13.010.5
▼Electrical System
Battery
Classification
Specification
SKYACTIV-G 2.5,
SKYACTIV-G 2.5T 12V-60Ah/20HR or 12V-65Ah/20HR
Spark-plug
Classification
Specification
SKYACTIV-G 2.5 Mazda Genuine spark plug
*1PE5R-18-110 or PE5S-18-110
SKYACTIV-G 2.5T Mazda Genuine spark plug
*1PY8V-18-110
*1 The spark plugs provide the SKY ACTIV-G its optimum performance. Consult an Authorized Mazda Dealer
for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The
fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-23.
Coolant FL-22 type
Manual transaxle oil Mazda Long Life Gear Oil G7
*1
Automatic transaxle fluid Mazda Genuine ATF FZ
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
*1 Mazda Long Life Gear Oil G7 is superior oil for low fuel cost and optimum shift-feel. Using Mazda Long Life
Gear Oil G7 is recommended.
If Mazda Long Life Gear Oil G7 cannot be obtained, use standard oil (API Service GL-4 (SAE 75W-80)).
Specifications
Specifications
9-4
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Warning light............................... 4-97
Break-In Period.......... ....................... 3-39
C
Capacities............................................ 9-5
Cell Phones....................................... 8-21
Center Console.................................. 5-93
Child Restraint Categories of child-restraint
systems.........................................2-35
Child-restraint system
installation................................... 2-35
Child-restraint system suitability for
various seat positions table..........2-37
ISOFIX child-restraint systems
(Mexico)...................................... 2-47
LATCH child-restraint systems
(Except Mexico).......................... 2-47
Child-Restraint Child-restraint precautions.......... 2-30
Installing child-restraint
systems.........................................2-40
Climate Control System...................... 5-2 Fully Automatic Type....................5-5
Gas specifications.......................... 9-7
Operating Tips............................... 5-2
Vent Operation...............................5-3
Collision warning.............................. 7-46
Coming Home Light......................... 4-77
Control Status Display.................... 4-111
Courtesy Lights................................. 5-84
Cruise Control................................. 4-215 Cruise control switc h.................4-215
Cruise main indication (white)/cruise
set indication (green)................. 4-216
Cup Holder........................................ 5-90
Customer Assistance.... ....................... 8-2
Cylinder Deactivation... .................... 4-11
D
Daytime Running Lights................... 4-78
Defogger
Mirror...........................................4-84
Rear window........... .................... 4-83
Dimensions.......................................... 9-5
Display.............................................. 4-12
Distance Recognition Support System
(DRSS)............................................ 4-136 Indication on display................. 4-136
Door Locks........................................3-10
Drive Selection................................ 4-112
Driving In Flooded Ar ea...................3-43
Driving on Uneven Road.................. 3-45
Driving Tips...................................... 3-39
Automatic transaxle.....................4-72
Break-in period............................ 3-39
Driving in flooded a rea............... 3-43
Driving on uneven road...............3-45
Floor mat..................................... 3-40
Hazardous driving.. ..................... 3-40
Overloading............. .................... 3-44
Rocking the vehicle. .................... 3-41
Saving fuel and protection of the
environment................................. 3-39
Turbocharged vehicles.................3-46
Winter driving............................. 3-41
Dynamic Stability Control (DSC)... 4-107 DSC OFF indicator light........... 4-107
DSC OFF switch....................... 4-108
TCS/DSC indicator light........... 4-107
E
Electric parking brake (EPB)............ 4-95
Electric Parking Brake (EPB) Warning
Beep...................................................7-44
Emergency Starting
Push-starting................................ 7-17
Starting a flooded engine............ 7-17
10-3
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Emergency TowingTiedown hooks......... ................... 7-21
Towing description...................... 7-20
Emission Control System (SKYACTIV-
G 2.5, SKYACTIV-G 2.5T).............. 3-20
Ending Screen Display.................... 4-111
Engine
Coolant.........................................6-26
Engine compartment overview.... 6-22
Exhaust gas.................................. 3-21
Hood release............................ .... 6-20
Oil................................................ 6-23
Starting...........................................4-5
Essential Information.......................... 6-2
Event Data Recorder......................... 8-22
Excessive Speed Warning................. 7-46
Exterior Care..................................... 6-54 Aluminum wheel maintenance.... 6-59
Bright-metal maint enance........... 6-58
Maintaining the finish................. 6-55
Plastic part maintenance.............. 6-59
F
Flasher Hazard warning........................... 4-85
Headlights.................................... 4-74
Flat Tire............................................... 7-3 Mounting the spare tire............... 7-11
Removing a flat tire...................... 7-7
Floor Mat.......................................... 3-40
Fluid Brake/Clutch................................ 6-28
Washer......................................... 6-28
Fluids Classification................................. 9-4
Foot Brake.........................................4-94
Forward Sensing Camera (FSC)..... 4-204
Fuel Filler lid and cap......................... 3-22
Requirements (SKYACTIV-G 2.5,
SKYACTIV-G 2.5T)....................3-19
Tank capacity.................................9-5
Fuel Consumption Display..............4-110
Fuel Economy Monitor. .................. 4-109
Control Status Display...............4-111
Ending screen display................ 4-111
Ending Screen Display.............. 4-111
Fuel consumption display.......... 4-110
Fuel Consumption Display........ 4-110
Fuses.................................................. 6-47 Panel description......................... 6-49
Replacement................................ 6-47
G
Gauges............................................... 4-12
Glove Compartment.......................... 5-93
H
Hazardous Driving............................ 3-40
Hazard Warning Flasher....................4-85
HeadlightsComing home light......................4-77
Control......................................... 4-74
Flashing....................................... 4-77
Headlight flashing....................... 4-77
High-low beam............................ 4-77
Leaving home light..................... 4-78
Leveling....................................... 4-78
Head Restraint................................... 2-17
High Beam Control System
(HBC).............................................. 4-119 High Beam Control System (HBC)
indicator light (green)................4-120
Hill Launch Assist (HLA).......... .... 4-103
HomeLink Wireless Control System
(Type A)............................................ 4-86
HomeLink Wireless Control System
(Type B)............................................ 4-89
Hood Release............. ....................... 6-20
10-4
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
