2019 MASERATI QUATTROPORTE Washer fluid

to lift the arms for cleaning or
replacing the wiper blades.
WARNING!
It is dangerous to operate or service
the wiper blades with the windshield
wipers in an active position (any
position different from “OFF”) and
with the ignition switch in the RUN
position. The rain sensors may
suddenly activate the wipers. Always
use the “Service” position for any
intervention on the windshield wiper
blades.
Windshield Wiper Maintenance
Life
expectancy of wiper blades varies
depending on the geographical area’s
weather conditions where the car is
used and frequency of use. Poor
performance of blades may be present
with chattering, marks on the glass,
water lines or wet spots. If any of
these conditions are present, clean the
wiper blades or replace if necessary.
Clean the rubber edges of the wiper
blades and the windshield/rear
window glasses periodically with a
sponge or soft cloth and a mild
nonabrasive cleaner. This will remove
accumulations of salt or road film. Operation of the wipers on dry glass
for long periods may cause
deterioration of the wiper blades.
Always use washer fluid when using
the wipers to remove salt or dirt from
a dry windshield.
Avoid using the wiper blades to
remove frost or ice from the
windshield. Keep the blade rubber out
of contact with petroleum products
such as engine oil, gasoline, etc.
Spray nozzles
If the jet does not work, first check
that there is fluid in the tank (see
paragraph “Level checks” in this
section) then check that the nozzles
are not clogged.
Windshield Wiper Blades Replacement
• Move the wiper arms into “Service”
position, (see chapter “Windshield
Wipers and Washers” in section
“Understanding the Vehicle”) and
lift them.
• Press the indicated button, slip off
the blade support from the arm and
replace it. • Return the blade to its original
position on the windshield.
• Turn the multifunction lever to one
of the automatic settings (see
chapter “Windshield Wipers and
Washers” in section “Understanding
the Vehicle”) and move the ignition
switch to the RUN position: the
wiper arms will return to the resting
position.
NOTE:
Due to the difficulty of this operation,
we recommend that you contact an
Authorized Maserati Dealer for
replacement of the blades.Maintenance and Care
7
343

Refillings NOTE:
Maserati reserves the right to change or revise specifications without prior notification.
Refillings and Recommended Products Parts to be refilled Quantity Product Specifications
Fuel tank 21 Gallons/80 litres (including 4.2
Gallons/16 litres of reserve) Premium unleaded fuel with no less than 91 CLC or
AKI (95 RON/85 MON).
Engine (V8 Engine)
8.8 Quarts/8.3 litres (max) (Difference
among MIN and MAX level:
1.5 Quarts/1.4 litres) Synthetic multigrade lubricants SAE 5W-40 that meet
API SL/CF and ACEA A3, B3, B4 specifications.
Recommended oil: PENNZOIL Platinum Maserati
5W-40 (1).
Engine (V6 Engine) 7.7 Quarts/7.3 litres (max) (Difference
among MIN and MAX level:
1.1 Quarts/1 litre) Synthetic multigrade lubricants SAE 10W-60 that
meet API SN/CF and ACEA A3, B3, B4 specifications.
Recommended oil: PENNZOIL Platinum Maserati
10W-60 (2).
Engine (V6 Engine - AWD
version) 8.8 Quarts/8.3 litres (max) (Difference
among MIN and MAX level:
1.1 Quarts/1 litre)
Windshield washer fluid
tank 3.7 Quarts/3.5 litres Mix of water and detergent fluid, in the proportions
indicated on the product package. If the temperature
is below –4°F (–20°C), use pure detergent fluid.
Detergent fluid: Mix of CUNA NC 956-II surfactants
and alcohols.
Recommended fluid: WUERTH Windshield Washer
Fluid with antifreeze or AREXONS DP1.Features and Specifications
8
370
