2019 LEXUS RX450H driver

601-2. Child safety
RX450h_RX450hL_U
WARNING
■When using a child restraint system
If the head restraint interferes with the installation of the child restraint system, and the
head restraint can be removed, remove the head restraint.
If the head restraint cannot be removed, raise it to the uppermost position.
●When a booster seat is installed, always en sure that the shoulder belt is positioned
across the center of the child’s shoulder. The belt should be kept away from the child’s
neck, but not so that it coul d fall off the child’s shoulder.
●Use child restraint system suitable to the age and size of the child and install it to the
rear seat.
●A forward-facing child restraint system may
be installed on the front passenger seat only
when it is unavoidable. When installing a for-
ward-facing child restrain t system on the front
passenger seat, raise the seatback as much as
possible, move the seat to the rearmost posi-
tion, and raise the seat to the highest position,
even if the “AIR BAG OFF” indicator light is
illuminated.
●Do not allow the child to lean his/her head or
any part of his/her body against the door or
the area of the seat, front or rear pillars, or
roof side rails from which the SRS side air-
bags or SRS curtain shield airbags deploy
even if the child is seat ed in the child restraint
system. It is dangerous if the SRS side airbags
and curtain shield airbags inflate, and the
impact could cause death or serious injury to
the child.
●If the driver’s seat interferes with the child
restraint system and prevents it from being
attached correctly, atta ch the child restraint
system to the right-hand rear seat.
●Adjust the front passenger seat so that it does
not interfere with the child restraint system.

90
RX450h_RX450hL_U2. Instrument cluster
Except F SPORT models
F SPORT models
The units used on the meter and some indicators may differ depending on the target
region.
Warning lights and indicators
The warning lights and indicators on the instrument cluster, center panel and
outside rear view mirrors inform the driver of the status of the vehicle’s vari-
ous systems.
For the purpose of explanation, the following illustrations display all warning
lights and indicators illuminated.

912. Instrument cluster
2
Instrument cluster
RX450h_RX450hL_U
Warning lights inform the driver of malfunctions in any of the vehicle’s systems.
Warning lights
*1
(U.S.A.)
Brake system warning light
( P. 660)
(U.S.A.)
Parking brake indicator
( P. 661)
*1
(Canada)
Brake system warning light
( P. 660)
(Canada)
Parking brake indicator
( P. 661)
*1Brake system warning light
( P. 660)*1, 2
Brake hold operated
indicator ( P. 661)
*1
(if equipped)
Charging system warning
light ( P. 660)
*1Electric power steering
system warning light
( P. 661)
*1
(U.S.A.)
Malfunction indicator lamp
( P. 660)*1Electric power steering
system warning light
( P. 661)
*1
(Canada)
Malfunction indicator lamp
( P. 660) LKA indicator (
P. 661)
*1SRS warning light
( P. 660)*1
Slip indicator ( P. 661)
*1
(U.S.A.)
ABS warning light
( P. 661)*1, 3PCS warning light
( P. 662)
*1
(Canada)
ABS warning light
( P. 661)*1, 2
(if equipped)
ICS OFF indicator
( P. 662)

922. Instrument cluster
RX450h_RX450hL_U
*1: These lights turn on when the power switch is turned to ON mode to indicate that a system check is being performe d. They will turn off after the hybrid system is on, or
after a few seconds. There ma y be a malfunction in a system if a light does not come
on, or turn off. Have the vehicl e inspected by your Lexus dealer.
*2: This light flashes to indicate a malfunction.
*3: This light flashes or illuminates to indicate a malfunction.
*4: This light illuminates on the center panel.
*5:RX450h
*6:RX450hL
The indicators inform the driver of the op erating state of the vehicle’s various sys-
tems.
Low fuel level warning light
(  P. 662)*4,6Rear passengers’ seat
belt reminder light
( P. 662)
Driver’s and front
passenger’s seat belt
reminder light ( P. 662)
*1Tire pressure warning light
( P. 662)
*4, 5Rear passengers’ seat
belt reminder light
( P. 662)*1Master warning light
( P. 663)
Indicators
Turn signal indicator
( P. 252) Fog light indicator
(
 P. 266)
(U.S.A.)
Headlight indicator
( P. 258) Cruise control indicator
(
 P. 306)
(Canada)
Tail light indicator
( P. 258) Radar cruise control
indicator (
P. 306)
Headlight high beam
indicator ( P. 259) Cruise control “SET”
indicator (
P. 306)
*1Automatic High Beam
indicator ( P. 262) LKA indicator (
P. 297)

972. Instrument cluster
2
Instrument cluster
RX450h_RX450hL_U
Engine coolant temperature gauge
Displays the engine coolant temperature
Hybrid System Indicator
Displays hybrid system power output or regeneration level (P. 99)
This display changes to a tachometer depending on the drive mode, and can be set
to show the tachometer in any driv e mode on the settings display. (P. 108)
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F
(50°C). Low outside temperature indicator comes on when the ambient tempera-
ture is 37°F (3°C) or lower.
Multi-information display
Presents the driver with a variety of vehicle data ( P. 101)
Displays warning messages in case of a malfunction ( P. 667)
Clock
Vehicles with a navigation system:
Time displayed is linked to the analog clock on the instrument panel. ( P. 548)
Vehicles with a Lexus Display Audio system:
Time displayed on the clock can be adju sted on of the multi-information dis-
play. ( P. 108)
Speedometer
Fuel gauge
Shift position display
( P. 246)
Odometer and trip meter ( P. 115)
1
2
3
4
5
6
7
8
9

1012. Instrument cluster
2
Instrument cluster
RX450h_RX450hL_U
The multi-information display presents the driver with a variety of driving-related
data, such as the current outside temperature. The multi-information display can
also be used to change the display settings and other settings.
Except F SPORT models
Menu icon display area
Displays the following items.
When a menu icon is not selected, the outside temperature and clock are displayed. •Menu icons ( P. 104)
• Outside temperature ( P. 96)
•Clock ( P. 96)
Content display area
A variety of information can be displayed by selecting a menu icon. Additionally,
warning or suggestion/advice pop-up displa ys will be displayed in some situations.
• Menu icon content ( P. 104)
• Suggestion function ( P. 116)
• Warning message ( P. 702)
Indicator/shift position display area
Displays the following items:
•Indicators ( P. 90)
• Shift position display ( P. 246)
Multi-information display
Summary of functions
1
2
3

1062. Instrument cluster
RX450h_RX450hL_U
*1:Resetting: P. 103
*2: Use the displayed fuel consumption as a reference.
*3: When only a small amount of fuel is added to the tank, the display may not be
updated.
When refueling, turn the power switch off. If the vehicle is refueled without turning the
power switch off, the display may not be updated.
*4: This distance is computed based on your average fuel consumption. As a result, the
actual distance that can be driven may differ from that displayed.
■Energy monitor
 P. 124
■Sway warning
Detects the sway of the vehicle within a lane, which is often associated with a
decrease in the driver’s at tention level, and displays the decrease in attention
using a bar display.
The shorter the bar length, the more the driver may need to rest.
This display is a part of the LKA (Lan e-Keeping Assist) system. The display is
enabled when the operating conditions of the vehicle sway warning are met.
(  P. 297)
■ AWD Control
Displays the driving force applie d to each wheel using segments.
The greater the number of segments di splayed, the greater the driving force
applied.

1082. Instrument cluster
RX450h_RX450hL_U
◆Changing settings
Use the meter control switches on th e steering wheel to change settings.
Press or to select .
Operate the switches to select a desired item.
Change the setting by referring to the message displayed on the screen.
◆Setting items
■ LKA (Lane-Keeping Assist) ( P. 297)
The following LKA system settings can be changed:
*1: If the lane centering function is enabled/ disabled, steering wheel assistance will also
be enabled/disabled accordingly.
*
2: If the steering wheel assistance is disabled, lane cent ering function will also be dis-
abled automatically.
Settings display ( )
1
2
3
ItemSettingsDetails
Lane center tracing On
Select to enable/disable the lane cen-
tering function.
*1Off
Steering assistOnSelect to enable/disable steering
wheel assistance.
*2Off
Alert
Select to set a vibrator or buzzer as
the notification method used to warn
the driver.
Alert sensitivityHighSelect to set the warning sensitivity.Normal
Sway warningOnSelect to enable/disable the vehicle
sway warning.
Off
Sway sensitivity
High
Select to set the vehicle sway warning
sensitivity.Medium
Low
