RX350/RX350L_U 2. Instrument cluster 
Except F SPORT models 
F SPORT models
The units used on the meter and some indicators may differ depending on the
target region.Warning lights and indicators The warning lights and indicators on th e instrument cluster, center panel and
outside rear view mirrors inform the driv er of the status of the vehicle’s vari-
ous systems.
For the purpose of explanation, the following illustrations display all warning
lights and indicators illuminated.

84 2. Instrument cluster
RX350/RX350L_U ●
Drive mode indicators 
Except F SPORT models 
F SPORT models
* 1
: These lights turn on when the engine switch is turned to the IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a sy stem if a light does
not come on, or turn off. Have the ve hicle inspected by your Lexus dealer.
* 2
: In order to confirm operation, the BSM ou tside rear view mirror indicators illuminate
in the following situations:
• When the BSM function is enabled on of the multi-information display, the
engine switch is turned to IGNITION ON mode.
• When the engine switch is in IGNITION ON mode, the BSM function is enabled
on of the multi-information display.
If the system is functioning correctly, the BSM outside rear view mirror indicators will
turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not turn off,
there may be a malfunction in the system.
If this occurs, have the vehicle inspected by your Lexus dealer.
* 3
: This light illuminates on the outside rear view mirrors.
* 4
: This light flashes to indicate that the system is operating.
* 5
: The light comes on when the system is turned off.
* 6
: This light illuminates on the center panel.
* 7
: When the outside temperature is approximately 37  F (3  C) or lower, this indicator
will flash for approximately 10 seconds, then stay on. Eco drive mode indicator
(  P. 373) “SPORT” indicator
(  P. 373)
Eco drive mode indicator
(  P. 373) “SPORT S” indicator
(  P. 373)
“SPORT S+” indicator
(  P. 373) “CUSTOMIZE” indicator
(  P. 373)

86 2. Instrument cluster
RX350/RX350L_U 
Except F SPORT models 
F SPORT models
The units used on the meters may differ depending on the target region.Gauges and meters

872. Instrument cluster
2
Instrument cluster
RX350/RX350L_U Engine coolant temperature gauge Displays the engine coolant temperature
Tachometer Displays the engine speed in revolutions per minute
F SPORT models: When sport mode is selected for the driving mode, the periph-
ery of the tachometer will change color and the scale of the tachometer will be
emphasized.
Outside temperature Displays the outside temperature within the range of -40°F (-40°C) to 122°F
(50°C). Low outside temperature indicator comes on when the ambient tempera-
ture is 37°F (3°C) or lower.
Multi-information display Presents the driver with a variety of vehicle data (  P. 90)
Displays warning messages in case of a malfunction (  P. 661)
Clock Vehicles with a navigation system:
Time displayed is linked to the analog clock on the instrument panel. (  P. 544)
Vehicles with a Lexus Display Audio system:
Time displayed on the clock can be adju sted on of the mu lti-information dis-
play. (  P. 97)
Speedometer
Fuel gauge
Shift position display (  P. 236, 240)
Odometer and trip meter (  P. 104)1
2
3
4
5
6
7
8
9

88 2. Instrument cluster
RX350/RX350L_U ■
Rev indicator (F SPORT models)
When the engine speed reaches a
set speed, a ring-shaped indicator
will be displayed on the tachometer. The desired engine speed at which
the Rev indicator will begin to be dis-
played can be set on of the multi-
information display. (  P. 97)
■
Rev peak (F SPORT models)
The engine speed reaches or
exceeds 5000 rpm, an afterimage
of the tachometer will be displayed
at the highest engine speed for
approximately 1 second.
The brightness of the instrument panel lights can be adjusted.
Darker
Brighter • The brightness of the instrument
panel lights can be adjusted individu-
ally for day mode and night mode
* .
• If the brightness is adjusted when the
surroundings are bright and the tail
lights are on (day mode brightness
adjustment), the brightness level of
night mode will be adjusted at the
same time.
* : Day mode and night mode:  P. 89Instrument panel light control 1
2

90 2. Instrument cluster
RX350/RX350L_U The multi-information display presents the driver with a variety of driving-related
data, such as the current outside temperature. The multi-information display can
also be used to change the display settings and other settings. 
Except F SPORT models
Menu icon display area Displays the following items.
When a menu icon is not selected, the outside temperature and clock are displayed.
•Menu icons (  P. 93)
• Outside temperature (  P. 86)
•Clock (  P. 86)
Content display area A variety of information can be displayed by selecting a menu icon. Additionally,
warning or suggestion/advice pop-up displa ys will be displayed in some situations.
• Menu icon content (  P. 93)
• Suggestion function (  P. 105)
• Warning message (  P. 661)
Indicator/shift position display area Displays the following items:
•Indicators (  P. 80)
• Shift position display (  P. 236, 240)Multi-information display Summary of functions
1
2
3

912. Instrument cluster
2
Instrument cluster
RX350/RX350L_U Odometer/trip meter display area (  P. 104)Displays the following items:
• Odometer/trip meter
• Distance until next engine oil change
Meter control switches (  P. 92)
“ODO/TRIP” switch (  P. 93)
F SPORT models
Outside temperature (  P. 86)
Menu icons (  P. 93)
Content display area A variety of information can be displayed by selecting a menu icon. Additionally,
warning or suggestion/advice pop-up displa ys will be displayed in some situations.
• Menu icon content (  P. 93)
• Suggestion function (  P. 105)
• Warning message (  P. 661)
Indicators/clock •Indicators (  P. 80)
•Clock (  P. 86)
Shift position display (  P. 236, 240)
Odometer/trip meter display area (  P. 104)Displays the following items:
• Odometer/trip meter
• Distance until next engine oil change
Meter control switches (  P. 92)
“ODO/TRIP” switch (  P. 93)4
5
6
1
2
3
4
5
6
7
8

1032. Instrument cluster
2
Instrument cluster
RX350/RX350L_U Pop-up display Intersection guid-
ance (if equipped)
Select to enable/disable the pop-up
display.Incoming calls
Brightness adjust-
ment
Color (except F
SPORT models) 2 available colors Select to set the color of the cursor on
the multi-information display.
Needle (F SPORT
models) 3 available colors Select to set the tachometer needle
color.
Rev indicator (F
SPORT models) On
Select to enable/disable the Rev indi-
cator. (  P. 88)
Off
Rev setting Select to set the desired engine speed
at which the Rev indicator will begin
to be displayed.
Selectable engine speed range:
2000 rpm to 6500 rpm
Rev peak (F SPORT
models) On
Select to enable/disable the Rev peak.
(  P. 88)
Off
Default setting Select to reset the meter display set-
tings to the default setting.Item Settings Details
