2019 LEXUS RX350 flat tire

6798-2. Steps to take in an emergency
8
When trouble arises
RX350/RX350L_U ■
The compact spare tire ●
The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the
tire sidewall.
Use the compact spare tire tempor arily, and only in an emergency.●
Make sure to check the tire inflation pressure of the compact spare tire. (  P. 704)■
When using the compact spare tire
As the compact spare tire is not equipped wi th a tire pressure warning valve and trans-
mitter, low inflation pressure of the spare tire will not be indicated by the tire pressure
warning system. Also, if you replace the compac t spare tire after the tire pressure warn-
ing light comes on, the light remains on. ■
When the compact spare tire is equipped
When driving with the compact spare tire inst alled, the vehicle height will be different
than when driving with standard tires. ■
If you have a flat front tire on a road covered with snow or ice
Install the compact spare tire on one of the re ar wheels of the vehicle. Perform the follow-
ing steps and fit tire chains to the front tires:
Replace a rear tire with the compact spare tire.
Replace the flat front tire with the tire removed from the rear of the vehicle.
Fit tire chains to the front tires. 1
2
3

6818-2. Steps to take in an emergency
8
When trouble arises
RX350/RX350L_U NOTICE ■
Be careful when driving over bumps with th e compact spare tire installed on the vehi-
cle
When driving with the compact spare tire installed, the vehi cle height will be different
than when driving with standard tires. Be careful when driving over uneven road sur-
faces, etc. ■
Driving with tire chains and the compact spare tire
Do not fit tire chains to the compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving performance.■
When replacing the tires
When removing or fitting the wheels, tires or the tire pressure warning valve and trans-
mitter, contact your Lexus dealer as the tire pressure warning valve and transmitter
may be damaged if not handled correctly. ■
When stowing the fl at tire (RX350L)●
Ensure that there is no object caught between the tire and the vehicle underbody. ●
Securely tighten the spare tire clamp bolt to hold the spare wheel carrier by the hook. ●
Stow the flat tire in the spare tire location. Failure to do so may cause damage to the
spare tire carrier. Pr oper storage reduces the possibilit y of injury in a collision or
during sudden braking. ●
Have the flat tire repaired and the spare tire replaced with it as soon as possible. ■
Proper storage of the spare tire (RX350L)
●
If the spare tire clamp bolt is turned withou t a tire on the hoist assembly, the wire cable
may not be able to be lowered. If the wire cable cannot be lowered, contact your
Lexus dealer. ●
If the hoist assembly is slanted when stowing a
tire, the hoist assembly may become stuck in
the wheel opening and the tire may not be
raised properly, causing damage to the wheel
or the wire cable.

704 9-1. Specifications
RX350/RX350L_U * : Minimum pedal clearance when depressed wi th a force of 110 lbf (490 N, 50.0 kgf)
while the engine is running. 
Type ABrakes Pedal clearance
* 3.4 in. (86 mm) Min.
Brake pad wear limit 0.04 in. (1.0 mm)
Pedal free play 0.04 — 0.24 in. (1.0 — 6.0 mm)
Fluid type FMVSS No. 116 DOT 3 or SAE J1703
Steering Free play Less than 1.2 in. (30 mm)
Tires and wheels Tire size 235/65R18 106V, T165/90D18 107M (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure) 
Front tire
33 psi (230 kPa, 2.3 kgf/cm 2
or bar) 
Rear tire
33 psi (230 kPa, 2.3 kgf/cm 2
or bar) 
Spare tire
60 psi (420 kPa, 4.2 kgf/cm 2
or bar)
Driving at high speeds (above 100 mph [160 km/h])
(in countries where such speeds are permitted by
law)
Add 5 psi (30 kPa, 0.3 kgf/cm 2
or bar) to the
front and rear tires. Never exceed the maximum
cold tire inflation pressu re indicated on the tire
sidewall.
Wheel size 18  8 J, 18  4 T (spare)
Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)

7059-1. Specifications
9
Vehicle specifications
RX350/RX350L_U 
Type B
A: Wedge base bulbs (amber)
B: Wedge base bulbs (clear)
* 1
: Vehicles with single-beam headlights
* 2
: Vehicles without door trim ornament lightsTire size 235/55R20 102V, T165/90D18 107M (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure) 
Front tire
33 psi (230 kPa, 2.3 kgf/cm 2
or bar) 
Rear tire
33 psi (230 kPa, 2.3 kgf/cm 2
or bar) 
Spare tire
60 psi (420 kPa, 4.2 kgf/cm 2
or bar)
Driving at high speeds (above 100 mph [160 km/h])
(in countries where such speeds are permitted by
law)
Add 11 psi (70 kPa, 0.7 kgf/cm 2
or bar) to the
front and rear tires. Never exceed the maximum
cold tire inflation pressu re indicated on the tire
sidewall.
Wheel size 20  8 J, 18  4 T (spare)
Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)
Light bulbs Light bulbs Bulb No. W Type
Exterior Front side marker lights
* 1
 5 B
Front turn signal lights
* 1
7444NA 28/8 A
Rear turn signal lights
* 1
 21 A
Back-up lights 921 16 B
Interior Door courtesy lights
* 2
 5 B
Vanity lights  8 B
Luggage compartment light  5 B

710 9-1. Specifications
RX350/RX350L_U Tire size (  P. 712)
DOT and Tire Identification Number (TIN) (  P. 711)
Location of treadwear indicators (  P. 604)
Tire ply composition and materials Plies are layers of rubber-c oated parallel cords. Cords are the strands which form the
plies in a tire.
Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply
tire.
TUBELESS or TUBE TYPE A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire
has a tube inside the tire and the tube maintains the air pressure.
Load limit at maximum cold tire inflation pressure (  P. 608)
Maximum cold tire inflation pressure (  P. 704)This means the pressure to which a tire may be inflated.
Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows.
Summer tires or all season tires (  P. 608)An all season tire has “M+S” on the side wall. A tire not marked “M+S” is a summer
tire.
“TEMPORARY USE ONLY” A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded
on its sidewall. This tire is design ed for temporary emergency use only.1
2
3
4
5
6
7
8
9
10
11

7159-1. Specifications
9
Vehicle specifications
RX350/RX350L_U ■
Temperature A, B, C
The temperature grades are A (the highes t), B, and C, representing the tire’s
resistance to the generation of heat and its ability to dissipate heat when
tested under controlled conditions on a specified indoor laboratory test
wheel. Sustained high temperature can cause the ma terial of the tire to degenerate and
reduce tire life, and excessive temperature can lead to sudden tire failure.
Grade C corresponds to a level of perfor mance which all passenger car tires must
meet under the Federa l Motor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of performance on the laboratory test
wheel than the minimum required by law.
Warning: The temperature grades of a tire assume that it is properly inflated and
not overloaded.
Excessive speed, underi nflation, or excessive loading, either separately or in com-
bination, can cause heat buildup and possible tire failure.

716 9-1. Specifications
RX350/RX350L_U Glossary of tire terminology Tire related term Meaning
Cold tire inflation pressure Tire pressure when the vehicle has been parked for
three hours or more, or has no t been driven more than 1
mile or 1.5 km un der that condition
Maximum inflation pres-
sure The maximum cold inflated pr essure to which a tire may
be inflated, shown on the sidewall of the tire
Recommended inflation
pressure Cold tire inflation pressure recommended by a manu-
facturer
Accessory weight The combined weight (in exce ss of those standard items
which may be replaced) of automatic transmission,
power steering, power brakes, power windows, power
seats, radio and heater, to the extent that these items are
available as factory-installed equipment (whether
installed or not)
Curb weight The weight of a motor vehicle with standard equipment,
including the maximum capacity of fuel, oil and coolant,
and if so equipped, air co nditioning and additional
weight optional engine
Maximum loaded vehicle
weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant weight 150 lb. (68 kg) times the numb er of occupants specified
in the second column of Table 1
* that follows
Occupant distribution Distribution of occupants in a vehicle as specified in the
third column of Table 1
* below

7179-1. Specifications
9
Vehicle specifications
RX350/RX350L_U Production options weight The combined weight of in stalled regular production
options weighing over 5 lb. (2.3 kg) in excess of the
standard items which they re place, not previously con-
sidered in curb weight or accessory weight, including
heavy duty brakes, ride leve lers, roof rack, heavy duty
battery, and special trim
Rim A metal support for a tire or a tire and tube assembly
upon which the tire beads are seated
Rim diameter
(Wheel diameter) Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designation The industry manufacturer’s designation for a rim by
style or code
Rim width Nominal distance between rim flanges
Vehicle capacity weight
(Total load capacity) The rated cargo and luggage load plus 150 lb. (68 kg)
times the vehicle’s desi gnated seating capacity
Vehicle maximum load on
the tire The load on an individual tire that is determined by dis-
tributing to each axle its share of the maximum loaded
vehicle weight, and dividing by two
Vehicle normal load on the
tire The load on an individual tire that is determined by dis-
tributing to each axle its sh are of curb weight, accessory
weight, and normal occupant weight (distributed in
accordance with Table 1
* below), and dividing by two
Weather side The surface area of the rim not covered by the inflated
tire
Bead The part of the tire that is made of steel wires, wrapped
or reinforced by ply cords an d that is shaped to fit the
rimTire related term Meaning
