2019 LEXUS RX350 turn signal

6377-3. Do-it-yourself maintenance
7
Maintenance and care
RX350/RX350L_U ■
Rear turn signal lights (vehic les with single-beam headlights)
Open the back door and apply
protective tape to the vehicle
body around the taillight. Use masking tape, etc. Do not use
duct tape, as it may leave residue or
damage the paint when removed.
Using a flathead screwdriver,
remove the cover. To prevent scratching the vehicle,
wrap the tip of the flathead screw-
driver with a cloth, etc.
Remove the 2 screws. 1
2
3

6417-3. Do-it-yourself maintenance
7
Maintenance and care
RX350/RX350L_U Install the cover. Align the tabs of the cover with the
grooves and install the cover.
■
Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by your Lexus
dealer. ●
Headlight low beams ●
Headlight high beams ●
Front turn signal lights (vehic les with triple-beam headlights)●
Parking lights and daytime running lights ●
Fog lights ●
Cornering lights (if equipped) ●
Front side marker lights (vehicles with triple-beam headlights) ●
Side turn signal lights ●
Stop/tail lights ●
Rear turn signal light (vehicles with triple-beam headlights) ●
Rear side marker lights ●
High mounted stoplight ●
License plate lights ●
Outer foot lights 5

642 7-3. Do-it-yourself maintenance
RX350/RX350L_U ■
LED lights
The headlight low beams, headlight high beams, front turn signal lights (vehicles with tri-
ple-beam headlights), parking lights and da ytime running lights, fog lights, cornering
lights (if equipped), front side marker lights (vehicles with triple-b eam headlights), side
turn signal lights, stop/tail lights, rear turn signal light (vehicles with triple-beam head-
lights), rear side marker lights, high mounted stoplight, license plate lights, and outer foot
lights consist of a number of LEDs. If any of the LEDs has burned out, take your vehicle to
your Lexus dealer to have the light replaced. ■
Condensation build-up on the inside of a lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact your Lexus dealer for mo re information in the following situations:●
Large drops of water have built up on the inside of a lens. ●
Water has built up inside a headlight. ■
When replacing light bulbs
 P. 626
WARNING ■
To prevent injury
Before performing any light bulb replacement procedure, be sure to turn the engine
switch off. Failure to do so may result in burns from hot components or a part of your
body may get caught on an operating co mponent, possibly causing serious injury.■
Replacing light bulbs ●
Turn off the lights. Do not attempt to replac e the bulb immediately after turning off the
lights.
The bulbs become very hot and may cause burns. ●
Do not touch the glass portion of the light bu lb with bare hands. When it is unavoid-
able to hold the glass portion, use and hold with a clean dry cloth to avoid getting
moisture and oils on the bulb.
Also, if the bulb is sc ratched or dropped, it may blow out or crack.●
Fully install light bulbs and any parts used to secure them. Failure to do so may result
in heat damage, fire, or water entering th e headlight unit. This may damage the head-
lights or cause condensation to build up on the lens.●
Do not attempt to repair or disassemble th e light bulbs, connector s, electric circuits
or component parts.
Doing so may result in death or se rious injury due to electric shock.■
To prevent damage or fire ●
Make sure bulbs are fully seated and locked. ●
Check the wattage of the bulb before installing to prevent heat damage.

644
RX350/RX350L_U 8-1. Essential information
Press the switch. All the turn signal lights will flash. To turn
them off, press the switch once again.
■
Emergency flashers
If the emergency flashers are used for a long time while the engine is not operating, the
battery may discharge.
Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has
to be stopped on the road due to a breakdown, etc.

7059-1. Specifications
9
Vehicle specifications
RX350/RX350L_U 
Type B
A: Wedge base bulbs (amber)
B: Wedge base bulbs (clear)
* 1
: Vehicles with single-beam headlights
* 2
: Vehicles without door trim ornament lightsTire size 235/55R20 102V, T165/90D18 107M (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure) 
Front tire
33 psi (230 kPa, 2.3 kgf/cm 2
or bar) 
Rear tire
33 psi (230 kPa, 2.3 kgf/cm 2
or bar) 
Spare tire
60 psi (420 kPa, 4.2 kgf/cm 2
or bar)
Driving at high speeds (above 100 mph [160 km/h])
(in countries where such speeds are permitted by
law)
Add 11 psi (70 kPa, 0.7 kgf/cm 2
or bar) to the
front and rear tires. Never exceed the maximum
cold tire inflation pressu re indicated on the tire
sidewall.
Wheel size 20  8 J, 18  4 T (spare)
Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)
Light bulbs Light bulbs Bulb No. W Type
Exterior Front side marker lights
* 1
 5 B
Front turn signal lights
* 1
7444NA 28/8 A
Rear turn signal lights
* 1
 21 A
Back-up lights 921 16 B
Interior Door courtesy lights
* 2
 5 B
Vanity lights  8 B
Luggage compartment light  5 B

730 9-2. Customization
RX350/RX350L_U ■
Turn signal lever (  P. 246)
■
Automatic light control system (  P. 252)
■
Lights ( 
P. 252)
* 1
:Except for Canada
* 2
: If equipped
■
Rain-sensing windshield wipers
* ( 
P. 261)
* : If equipped Function Default setting Customized setting
The number of times the turn sig-
nal lights flash automatically
when the turn signal lever is
moved to the first position during
a lane change 3 5
— O7
Off 1 2
Function Default setting Customized setting
Light sensor sensitivity Standard -2 to 2 O O
Time elapsed before headlights
automatically turn off after doors
are closed 30 seconds Off
OO
60 seconds
90 seconds 1 2
Function Default setting Customized setting
Daytime running lights On Off
* 1
O O
Welcome lighting On Off — O
AFS (Adaptive Front-lighting
System)
* 2
On Off — O
Windshield wiper linked head-
light illumination On Off — O 1 2
Function Default setting Customized setting
Wiper operation when the wiper
switch is in the “AUTO” position Rain-sensing oper-
ation Intermittent opera-
tion linked to vehi-
cle speed (with
interval adjuster) — O 1 2

734 9-2. Customization
RX350/RX350L_U ■
Seat belt reminder (  P. 656)■
Vehicle customization ●
When the smart access system with push-button start is off, the entry unlock function
cannot be customized. ●
When the doors remain closed after unlocking the doors and the timer activated auto-
matic door lock function activates, signals will be generated in accordance with the
operation buzzer volume and operational si gnal (Emergency flashers) function set-
tings. ●
Some settings can be changed using a switch or the audio system screen. If a setting is
changed using a switch , the changed setting will not be reflected on the audio system
screen until the engine switch is turn ed off and then to IGNITION ON mode.Function Default setting Customized setting
Vehicle speed linked seat belt
reminder buzzer On Off — O
WARNING ■
Cautions during customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE ■
During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures. 1 2

763Alphabetical index
RX350/RX350L_U Flat tire ...................................................... 666
Floor mats ................................................... 28
Fluid
Automatic transmission ..................703
Brake ........................................................704
Washer .................................................. 603
Fog lights
Replacing light bulbs ....................... 630
Switch...................................................... 260
Front automatic air
conditioning system .........................503
Front passenger footwell hooks ..... 554
Front passenger occupant
classification system .............................47
Front passenger’s seat belt
reminder light ..................................... 656
Front seat heaters................................. 522
Front seats .................................................156
Adjustment ............................................. 156
Cleaning .................................................. 581
Correct driving posture ....................30
Driving position memory ................. 172
Head restraints ...................................... 177
Power easy access system ............. 172
Seat heaters .......................................... 522
Seat position memory........................ 172 Front side marker lights
Light switch........................................... 252
Replacing light bulbs .......................630
Wattage ................................................. 705
Front turn signal lights
Replacing light bulbs .......................630
Turn signal lever ................................. 246
Wattage ................................................. 705
Fuel
Capacity.................................................700
Fuel gauge ............................................... 86
Information............................................ 706
Refueling ................................................ 269
Type..........................................................700
Fuel filler door.........................................269
Refueling ................................................ 269
When the fuel filler door
cannot be opened ..........................272
Fuses.......................................................... 625F
