2019 LEXUS RX350 clock

640 7-3. Do-it-yourself maintenance
RX350/RX350L_U ■
Back-up lights
Open the back door and remove
the cover. Using a flathead screwdriver, remove
the cover.
To prevent scratching to the vehicle,
wrap the tip of the flathead screw-
driver with a cloth, etc.
Turn the bulb base counterclock-
wise and remove it.
Remove the light bulb.
Install a new light bulb and then
install the bulb base to the light
unit by inserting it and turning it
clockwise. After installing th e bulb base, wiggle
it lightly to make sure it is securely
installed and turn on the back-up
lights to visually check that there is no
light leaking from between the bulb
base and light unit. 1
2
3
4

6718-2. Steps to take in an emergency
8
When trouble arises
RX350/RX350L_U Attach the adapter socket to the
spare tire clamp bolt.
Assemble the jack handle extension.
Connect the jack handle to the
adapter socket. Turn the jack handle
counterclockwise. The tire will be lowered completely to
the ground.
Turn the jack handle slowly to lower the
spare tire. If the handle is turned quickly,
the wire cable may come off the shaft
inside the unit and the tire may not be
lowered.
If the spare tire cannot be lowered:  P. 674
Pull out the spare tire and stand it
against the bumper. 3
4
5
6

674 8-2. Steps to take in an emergency
RX350/RX350L_U Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and the
tire. When resting the tire on the ground,
place the tire so that the wheel design
faces up to avoid scratching the wheel
surface. ■
If the spare tire cannot be lowered (RX350L)
If the spare tire cannot be lowered, it may not have been stowed properly. Perform the
following procedure:
If the spare tire still cannot be lowered, the wire cable may be severed. Have the vehicle
inspected by your Lexus dealer. 4
5
Fully tighten the spare tire clamp bolt by turn-
ing the jack handle clockwise until two clicks
are heard and the jack handle skips.
Turn the jack handle counterclockwise to
lower the spare tire.
If the spare tire still cannot be lowered,
attempt to fully tighten the spare tire clamp
bolt again by turning the jack handle clock-
wise. Then turn it counterclockwise at least 2
turns to lower the spare tire. 1
2

678 8-2. Steps to take in an emergency
RX350/RX350L_U Lay the tire on the ground with the
outer surface (valve stem) facing up.
Before raising the tire, make sure
that the hoist assembly is perpendic-
ular to the wheel opening. (Try to
place the tire directly beneath the
vehicle, near where the wire cable is
hanging from.)
Using the jack handle and adapter socket , tighten the tire clamp bolt by turn-
ing it clockwise until the tire is in the correct position and two clicks are heard
as the jack handle skips.
Confirm it is not loose after tighten-
ing:
Push and pull the tire
Try rotating Visually check to ensure tire is not
hung on surrounding parts.
If looseness or mi sassembly exists,
repeat steps
to .
Repeat step , any time the tire is lowered or disturbed.
Stow the jack and all tools. 4
Valve stem5
6
7
1
2
2 7
8 7
9

760 Alphabetical index
RX350/RX350L_U Child-protectors..................................... 127
Cleaning......................................... 576, 581
Aluminum wheels .............................. 577
Exterior....................................................576
Interior ...................................................... 581
Seat belts ............................................... 582
Clock .................................................86, 544
Coat hooks.............................................. 556
Compass .................................................. 564
Condenser .............................................. 599
Console box ...........................................530
Consumption screen ..................... 94, 114 Coolant
Capacity................................................. 702
Checking .............................................. 598
Preparing and checking
before winter ....................................384
Cooling system ..................................... 598
Engine overheating .......................... 692
Cornering lights.................................... 253
Cruise control
Dynamic radar cruise control
with full-speed range .................. 300
Cup holders.............................................. 531
Curtain shield airbags ............................ 37
Customizable features ....................... 722
Customized mode................................373

767Alphabetical index
RX350/RX350L_U Maintenance
Do-it-yourself maintenance......... 590
General maintenance .................... 586
Maintenance data ............................. 698
Maintenance requirements.......... 584
Malfunction indicator lamp .............. 654
Memory recall function .......................175
Meter
Head-up display..................................108
Indicators.................................................. 80
Instrument panel light control ........ 88
Meters.........................................................86
Multi-information display ..................90
Settings ....................................................... 97
Warning lights .................................... 654
Warning messages............................ 661
Microphone ............................................ 456
Mirrors
Inside rear view mirror ..................... 182
Outside rear view mirror
defoggers ............................................ 513
Outside rear view mirrors .............. 184
Vanity mirrors ......................................543
Moon roof
Door lock linked moon roof
operation ............................................. 189
Jam protection function ................... 192
Operation ................................................. 191 MP3 disc .................................................. 427
Multi-information display
AWD Control display........................ 95
Clock .......................................................... 86
Drive information.................................. 94
Dynamic radar cruise control
with full-speed range .................. 300
G-force display ..................................... 96
Language.................................................102
LKA (Lane-Keeping Assist)......... 296
Outside temperature.......................... 86
PCS
(Pre-Collision System) .................281
Settings .......................................................97
Suggestion function........................... 105
Sway warning display......................... 95
Warning messages ............................661
Navigation system
* Noise from under vehicle ........................8M
N
* : Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
