2019 Lexus LC500 lexus LC500 2019 Owner's Manual / LEXUS 2019 LC 500,LC 500H OWNER'S MANUAL QUICK GUIDE (OM11489U)

73
LC500_LC500h_QG_OM11489U_(U)
Select “Answer” or press the switch on the steering wheel to talk on the phone.
“Decline”: Select to refuse to receive the call.Volume control switch
• Press the “+” side to increase the vol-ume.
• Press the “-” side to decrease the vol- ume.
Talk switch
• Press the talk switch to start the voice command system.
• To cancel voice recognition, press and hold the talk switch.
TEL switch
• Start talking
• End talking
•End dialing
Receiving a call
 Main display Side display
Steering switches
A
B
C

74
LC500_LC500h_QG_OM11489U_(U)
The audio control screen can be reached by the following methods:
Using the audio control switch
Press the “RADIO” or “MEDIA” button.
 Using the Remote Touch
Press the “MENU” button on the Re mote Touch, then select “Audio”.
 Using the audio control switch
1Display the audio control screen.
2Each time the “RADIO” or “MEDIA”
button is pressed, the audio source
changes.
“RADIO” button: To change radio
modes.
“MEDIA” button: To change media
modes.
 From the audio source selection screen
1Display the audio control screen.
2Select “Source” on the sub menu.
3Select the desired source.
Audio System
Audio control screen
Selecting an audio source

75
LC500_LC500h_QG_OM11489U_(U)
Some parts of the audio/visual system can be adjusted using the switches on the steering
wheel.
Volume control switch
“MODE” switch
switch
■Volume control switch
●Press: Volume up/down
● Press and hold (0.8 sec. or mo re): Volume up/down continuously
■“MODE” switch
AM, FM, SXM
● Press: Change audio modes
● Press and hold (0.8 sec. or more): Pause
 AUX
● Press: Change audio modes
● Press and hold (0.8 sec. or more): Mute
 CD, MP3/WMA/AAC disc, DVD, USB
*, iPod, Bluetooth® audio*, APPS*
●Press: Change audio modes
● Press and hold (0.8 sec. or more): Pause
*: When an Apple CarPlay connect ion is established, this function will be unavailable.
Steering switch operation
A
B
C

76
LC500_LC500h_QG_OM11489U_(U)
■ switch
AM, FM, HD
● Press: Preset station up/down
● Press and hold (0.8 sec. or more): Seek up /down continuously while the switch is being
pressed
 SXM
● Press: Preset channel up/down
● Press and hold (0.8 sec. or more): Type seek up/down
● Press and hold (1.5 sec. or more): Fast up/down
 CD
● Press: Track up/down
● Press and hold (0.8 sec. or more): Fast forward/rewind
 MP3/WMA/AAC disc
● Press: File up/down
● Press and hold (0.8 sec. or more): Fast forward/rewind
 DVD
● Press: Chapter up/down
● Press and hold (0.8 sec. or more): Fast forward/rewind
 USB
*
●Press: File/Track up/down
● Press and hold (0.8 sec. or more): Fast forward/rewind
 iPod
● Press: Track up/down
● Press and hold (0.8 sec. or more): Fast forward/rewind
 Bluetooth
® audio*
●Press: Track up/down
● Press and hold (0.8 sec. or more): Fast forward/rewind
*: When an Apple CarPlay connection is establ ished, this function will be unavailable.

77
LC500_LC500h_QG_OM11489U_(U)
■Audio control switch
Turn to seek up/down
Turn to step up/down frequencies/
channels
Turn to move up/down the list.
■Control screen
Displays cover art
Select to display HD) multicast chan-
nels available
Displays the artist info and song title or
album and genre. Press to change the
displayed information.
Displays messages when available
from RBDS
Select to tune to preset stations/chan-
nels
Display items on the channels regis-
tered to smart favorites
■Presetting a station
Radio mode has a mix preset function, which can store up to 36 stations (6 stations per
page x 6 pages) from any of the AM, FM or SXM bands.
1Tune in the desired station.
2Select “(Add New)”.
● To change the preset station to a differ-
ent one, select and hold the preset sta-
tion.
3Select “Yes” on the confirmation
screen.
4Select “OK” after setting the new pre-
set station.
Radio
A
B
A
B
C
D
E

78
LC500_LC500h_QG_OM11489U_(U)
■Audio control switch
Turn to select a track/file
Turn and hold to fast forward/rewind.
Turn to select a track/file
Turn to move up/down the list.
■Control screen
Audio CD
Displays cover art
Select to set repeat playback
Select to change the track/file
Select and hold to fast rewind.
Select to play/pause
Select to change the track/file
Select and hold to fast forward.
Select to set random playback
 MP3/WMA/AAC disc
Displays cover art
Select to change the folder
Select to set repeat playback
Select to change the track/file
Select and hold to fast rewind.
Select to play/pause
Select to change the track/file
Select and hold to fast forward.
Select to set random playback
CD
A
B
A
B
C
D
E
F
A
B
C
D
E
F
G

79
LC500_LC500h_QG_OM11489U_(U)
■Audio control switch
Turn to select a chapter
Turn and hold to fast forward/rewind.
Turn to select a chapter
■Control screen
Select to display the menu control key
Select to display the menu screen
Select to change the chapter
Select and hold to rewind.
Select to stop the video screen
Select to play/pause
Select to change the chapter
During playback: Select and hold to
fast forward.
During a pause: Select and hold to
slow forward.
Select to display expanded screen
video
DVD
A
B
A
B
C
D
E
F
G

80
LC500_LC500h_QG_OM11489U_(U)
■Audio control switch
Turn to select a track
Turn and hold to fast forward/rewind.
Turn to select a track
Turn to move up/down the list.
■Control screen
Displays cover art
Select to change the artist
*
Select to change the album*
Select to change the playlist*
Select to set repeat playback
Select to change the track
Select and hold to fast rewind.
Select to play/pause
Select to change the track
Select and hold to fast forward.
Select to set random playback
*: When an Apple CarPlay connection isestablished, this switch will not be dis-
played.
iPod/iPhone
A
B
A
B
C
D
E
F
G
H
I
