2019 Lexus ES300h automatic folding mirrors

1183-4. Adjusting the steering wheel and mirrors
2To adjust the mirror, press the
switch.
Up
Right
Down
Left
■Mirror angle can be adjusted when
The power switch is in ACCESSORY or
ON mode.
■Defogging the mirrors
The outside rear view mirrors can be
cleared using the mirror defoggers. Turn on
the rear window defogger to turn on the
outside rear view mirror defoggers.
(  P.254)
■Auto anti-glare function
When the anti-glare insi de rear view mirror
is set to automatic mode, the outside rear
view mirrors will activate in conjunction with
the anti-glare inside rear view mirror to
reduce reflected light. ( P.116)
■Automatic adjustment of the mirror
angle (vehicles with driving position
memory)
A desired mirror face angle can be entered
to memory and recalled automatically by
the driving position memory. ( P.110)
Push the mirror back in the direction of
the vehicle’s rear.
When the mirror select switch is in the
“L” or “R” position, the outside rear
view mirrors will automatically angle
downwards when the vehicle is revers-
ing in order to give a better view of the
ground.
To disable this function, move the mir-
ror select switch to the neutral position
(between “L” or “R”).
A
B
C
D
WARNING
■When the outside rear view mirror
defoggers are operating
Do not touch the outside rear view mir-
ror surfaces, as they can become very
hot and burn you.
Folding the mirrors
WARNING
■When a mirror is moving
To avoid personal injury and mirror mal-
function, be careful not to get your hand
caught by the moving mirror.
Linked mirror function when
reversing (vehicles with driving
position memory)

449What to do if... (Troubleshooting)Alphabetical index449
Fuses .................................................................. 341
Light bulbs..................................................... 344
Tires .................................................................. 372
Resetting the message indicating mainte- nance is required ...................................... 309
Road Sign Assist ........................................... 185
RSA (Road Sign Assist) ............................. 185
S
SCB (Secondary Collision Brake) ....... 236
Seat belt reminder ligh t...............................361
Seat belts............................................................ 24 Adjusting the seat belt................................ 26
Automatic Locking Retractor ................ 26
Child restraint system installation......... 43
Cleaning and maintaining the seat belt.........................................................................303
Emergency Locking Retractor .............. 26
How to wear your seat belt ..................... 25
How your child should wear the seat belt ............................................................................ 25
Pregnant women, proper seat belt use .............................................................................24
Reminder light and buzzer .....................361
Seat belt extender ........................................ 25
Seat belt pretensioners .............................. 26
SRS warning light ......................................359
Seat heaters ..................................................... 261
Seating capacity.............................................133
Seat position memory................................... 110
Seats................................................................... 109 Adjustment precautions .......................... 109
Adjustment..................................................... 109
Child seats/child restraint system installa-tion .....................................................................42
Cleaning.........................................................303
Driving position memory .......................... 110
Head restraints .............................................. 113
Power easy access system ...................... 110
Properly sitting in the seat .........................23
Seat heaters .................................................... 261
Seat position memory ................................ 110 Seat ventilators ..............................................261
Seat ventilators ...............................................261
Secondary Collision Brake (SCB) ....... 236
Sensor Automatic headlight system .................. 150
Automatic High Beam system ............. 153
Inside rear view mirror ............................... 117
Intuitive parking assist ............................. 205
LTA (Lane Tracing Assist) ......................176
Parking Support Brake function (rear-crossing vehicles)................................... 229
Parking Support Brake function (static objects) ........................................................ 225
Radar sensor ...................................... 163, 198
Rain-sensing windshield wipers .......... 158
RCTA................................................................. 212
Service plug ...................................................... 56
Service reminder message ..................... 309
S-FLOW mode ............................................ 258
Shift lever Hybrid transmission..................................... 141
Shift lever light .............................................. 265
Side airbags ...................................................... 28
Side marker lights......................................... 150 Light switch .................................................... 150
Side mirrors ...................................................... 117 Adjustment ....................................................... 117
BSM (Blind Spot Monitor)......................197
Folding................................................................ 118
Linked mirror functi on when reversing
............................................................................. 118
Mirror position memory ............................ 110
RCTA function ............................................... 211
Side turn signal lights ...................................145 Replacing light bulbs ................................344
Turn signal lever .......................................... 145
Side windows ..................................................120
Smart access system with push-button start...................................................................102Antenna location ......................................... 102
Entry functions ......................................... 91, 97
Starting the hybrid system ...................... 135
