6. Remove any additional slack from the seat
belt; press downward and rearward firmly
in the center of the child restraint with
your knee to compress the vehicle seat
cushion and seatback while pulling up on
the seat belt.
7. Tighten the tether strap according to the
manufacturer's instructions to remove
any slack.8. After attaching the child restraint, test it
before you place the child in it. Push it
from side to side while holding the child
restraint near the seat belt path. The
child restraint should not move more than
1 inch (25 mm), from side to side. Try to
tug it forward and check to see if the belt
holds the restraint in place. If the restraint
is not secure, tighten the seat belt as nec-
essary, or put the restraint in another seat
and test it again. You may need to try a
different child restraint. Not all child re-
straints fit in all types of vehicles.
9. Check to make sure the child restraint is
properly secured prior to each use. If the
seat belt is not locked, repeat steps 2
through 8.10. If the child restraint is installed in the
front passenger seat, place the ignition
switch in the ON position. Either the
indicator
light or
indicator light will illuminate depending
on the size of the child and the type of
child restraint used. See "Front passen-
ger air bag and status light". After the
child restraint is removed and the seat
belt is fully retracted, the ALR mode
(child restraint mode) is canceled.
If necessary, system operation can be
checked by using a special tool. It is rec-
ommended that you visit an INFINITI
retailer for this service. Until you have
confirmed system operation, move the
child restraint to another position. See
"Troubleshooting" later in this section.
WRS0681Z
Forward-facing — step 6
WRS0698Z
Forward-facing — step 8
SSS0676Z
Forward-facing — step 10
1-32Safety — seats, seat belts and supplemental restraint system

•The front passenger seat is occupied by a
properly restrained child up to the approxi-
mate size and weight of a one year old, the
indicator
light lights up after the system self-test
and remains lit. This indicates that the
front passenger front air bag is disabled.
If neither the OFF> or the
indicator lights light up, or if either indica-
tor light only lights up intermittently during
the journey, the front passenger seat
may not be used for a child restraint. Use
another seating position for the child re-
straint. For further information see
"Troubleshooting" later in this section.
•The front passenger seat is occupied by a
properly restrained child who is larger than
the approximate size and weight of a one
year old, either the BAG ON> or
indicator light lights up and remains lit af-
ter the system self-test depending on the
result of the classification. The result of
the classification is dependent on, among
other factors, the child restraint system
and the child's build.
Move the front passenger seat as far back
as possible. See "Child restraints" earlier in
this section.
•The front passenger seat is occupied by a
person with a smaller build (e.g. a teenager
or small adult), either the AIRBAG ON> or OFF> indicator light lights up and remains
lit after the system self-test depending on
the result of the classification.
– If the indi-
cator light lights up, move the front
passenger seat as far back as possible.
Alternatively, a person with a small
build can sit on a rear seat.
– If the
indicator light is lit, a person with a
smaller build should not use the front
passenger seat.
•The front passenger seat is occupied by an
adult or a person with a build correspond-
ing to that of an adult, the AIRBAG ON> indicator light lights up after
the system self-test and remains lit. This
indicates that the front passenger front air
bag is enabled.If the automatic front passenger front air bag
deactivation system is malfunctioning, the
red
restraint system warning light in the
combination meter and the AIRBAG OFF> indicator light light up simul-
taneously. The front passenger front air bag
is disabled in this case and does not deploy
during an accident. Have the system checked
as soon as possible by qualified technicians. It
is recommended that you visit an INFINITI
retailer for this service.
Safety — seats, seat belts and supplemental restraint system1-47

Troubleshooting
Problem Possible causes/consequences and solutions
The indicator lamp
lights up and remains lit, even though the front
passenger seat is occupied by an adult or a person
with a build corresponding to that of an adult
•Make sure the conditions for a correct classification of the person on the front passenger seat are met
(see "Front passenger air bag" earlier in this section).
•If the indicator light remains lit, the front passenger seat may not be used.•Have the automatic front passenger front air bag deactivation system checked as soon as possible. It is
recommended that you visit an INFINITI retailer for this service.
The indicator lamp
does not light up and/or does not stay on.
•Make sure there is nothing between the seat and the child restraint system.•Make sure that the entire base of the child restraint system rests on the seat cushion of the front
passenger seat.
•When installing the child restraint system, make sure that the seat belt is tight. Do not pull the seat belt
tight with the front passenger seat adjustment. This could result in the seat belt and the child restraint
system being pulled too tightly.
•Check that the child restraint system is installed correctly.•Make sure that no objects are applying additional weight to the seat.•Have the automatic front passenger front air bag deactivation system checked as soon as possible. It is
recommended that you visit an INFINITI retailer for this service.
1-48Safety — seats, seat belts and supplemental restraint system

FUEL GAUGE
The fuel gauge indicates theapproximate
fuel level in the tank when the ignition switch
is in the ON position.The gauge may move slightly during braking,
turning, accelerating, or going up and down
hills due to movement of fuel in the tank.
The gauge needle returns to 0 (Empty) after
the ignition switch is placed in the OFF posi-
tion.
The low fuel warning
appears on the
vehicle information display when the fuel
level in the tank is getting low.
Refill the fuel tank before the gauge regis-
ters 0 (Empty).
The arrow,
, indicates that the fuel-filler
lid is located on the left side of the vehicle.
CAUTION
•If the vehicle runs out of fuel, the Mal-
function Indicator Light (MIL) may
come on. Refuel as soon as possible.
After a few driving trips. the light should
turn off. If the light remains on after a
few driving trips, have the vehicle in-
spected. It is recommended that you
visit an INFINITI retailer for this service.
•For additional information, refer to
" Malfunction Indicator light (MIL)
(yellow)".NIC2653
Instruments and controls2-7

Anti-lock Braking System (ABS)
warning lightSeat belt (driver and front passenger)
warning lightHigh beam assist indicator light *
Brake warning light (red)Supplemental Restraint System (SRS)
air bag warning lightHigh beam indicator light
Low tire pressure warning light*Low fuel warning lightRear fog light indicator light
Malfunction indicator light (yellow)Vehicle Dynamic Control (VDC)
warning lightSide light indicator light
Distance warning light*Turn signal/hazard indicator lightsFront passenger air bag status light**
Electric parking brake warning light (red)Low beam indicator light
Electric parking brake warning light
(yellow)Vehicle Dynamic Control (VDC) OFF
indicator light
Coolant warning lightFront fog light indicator light* *: if equipped
**: located above heater and air conditioner controls
Some indicators and warnings are also dis-
played in the vehicle information display be-
tween the speedometer and tachometer see
"Vehicle information display".CHECKING LIGHTS
With all doors closed, apply the parking brake,
fasten the seat belts and place the ignition
switch in the ON position without starting the
engine. The following lights (if so equipped) will
come on, ,
,,,,
,,,,. These lights
should go out within a few seconds after start-
ing the engine. If any light fails to come on oroperates in a way other than described, it may
indicate a burned out bulb and/or a system
malfunction. Have the system checked. It is rec-
ommended you visit an INFINITI retailer for this
service.
WARNING LIGHTS, INDICATOR
LIGHTS AND AUDIBLE REMINDERS
2-8Instruments and controls

Malfunction Indicator light
(MIL) (yellow)
When the ignition switch is turned to the ON
position, the yellow Malfunction Indicator
light illuminates. This means that the system
is operational.
If the yellow engine malfunction indicator
light lights up while the engine is running,
there may be a fault, for example:
•In the engine management
•In the fuel injection system
•In the exhaust system
•In the ignition system (for vehicles with
gasoline engines)
•In the fuel system (including a loose or
missing fuel filler cap).
•In other monitored items, for example the
automatic transmission.
The emission limit values may be exceeded
and the engine may be running in emergency
mode.
CAUTION
Continued vehicle operation without having
the engine control system checked and re-
paired as necessary could lead to poor drive-
ability, reduced fuel economy and possible
damage to the engine control system.
Incorrect setting of the engine control system
may lead to non-compliance of local and na-
tional emission laws and regulations.
Have the vehicle checked as soon as possible.
It is recommended you visit an INFINITI re-
tailer for this service.
Distance warning light
(if equipped)
This light illuminates if the distance to the
vehicle in front is too small for the speed
selected.
If a warning tone also sounds, you are ap-
proaching a vehicle or stationary obstacle in
your line of travel at too high a speed. For
additional information see " Forward emer-
gency braking (FEB) system (if equipped)".
Electric parking brake
warning light
The red indicator illuminates when the elec-
tric parking brake is engaged.
If the red indicator light for the electric park-
ing brake flashes or is lit and/or the yellow
warning light for the electric parking brake is
lit, observe the additional messages dis-
played in the vehicle information display.
For further parking brake operation informa-
tion see "Parking brake".
Seat belt (driver and front
passenger) warning light
The seat belt warning light reminds you to
fasten your seat belts. The light illuminates if
the engine is started, all doors are closed and
the driver’s and/or front passenger’s seat
belt is unfastened. It will remain illuminated
until the driver and/or front passenger fas-
tens their seat belt. A chime will sound once
the vehicle is in motion, see "Seat belt re-
minder chime" later in this section. See "Seat
belts" for precautions on seat belt usage.
The seat belt warning light may also illumi-
nate if there are objects on the front passen-
ger seat. Remove the objects and stow them
in a safe place.
Instruments and controls2-11

Have the system checked. It is recommended
you visit an INFINITI retailer for these services.
If an abnormality occurs in the system, the
VDC system function will be canceled, but
the vehicle is still driveable. For additional
information, see "Vehicle Dynamic Control
(VDC) system".
WARNING
VDC should remain on unless freeing a ve-
hicle from mud or snow.
While the VDC system is operating, you
might feel a slight vibration or hear the sys-
tem working when starting the vehicle or ac-
celerating, but this is normal.
Front fog light indicator light
(if equipped)
The light comes on when the front fog lights
are switched on (see " Fog light switch (If so
equipped)" later in this section).
High beam assist indicator
light (if equipped)
The indicator light illuminates when the
headlights come on while the headlight
switch is in the AUTO position with the high
beam selected. This indicates that the high
beam assist system is operational. (See 2-65.)
High beam indicator light
This blue light comes on when the headlight
high beams are on and goes out when the
low beams are selected.
The high beam indicator light also comes on
when the passing signal is activated.
Rear fog light indicator light
The light comes on when the rear fog light is
switched on (see " Fog light switch (If so
equipped)" later in this section).
Side light and headlight
indicator light
This light comes on when the side light or
headlight position is selected, see "Headlight
and turn signal switches" later in this section
for further details.
/Front passenger air
bag status light
The front passenger air bag status light
() located on the center console above
the shift lever will illuminate when the front
passenger air bag is turned OFF. When the
front passenger air bag is turned on, the front
passenger air bag status light ON (
) will
illuminate.For more details, see "Front passenger air
bag and status light".
AUDIBLE REMINDERS
Parking brake reminder chime
A chime will sound when driving away if the
parking brake has not been released. Stop the
vehicle and release the parking brake.
Light reminder chime
With the ignition switch placed in the OFF
position, a chime sounds when the driver's
door is opened if the side lights are on. Turn
the headlight control switch off before leav-
ing the vehicle.
Seat belt reminder chime
A chime will sound for approximately 120
seconds if the vehicle's speed exceeds
16 MPH (25 km/h) and the driver's seat belt
or front passenger's seat belt, if occupied is
not securely fastened. See "Seat belt warning
light".
2-14Instruments and controls

Message Possible causes/consequences and solutions
[Inoperative See Operator's
Manual]BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are not available due to a malfunction.
Forward Emergency Braking (FEB) may also have failed.
In addition, theandwarning lights may light up in the combination meter.
WARNING
The brake system continues to function normally, but without the functions listed above.
The braking distance may increase in an emergency braking situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Drive on carefully and have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Inoperative See Operator's
Manual]EBD (Electronic Brake Force Distribution) ABS (Anti-Lock Braking System), BAS (Brake Assist System), VDC (Vehicle Dynamic
Control), and hill start assist are not available due to a malfunction.
Forward Emergency Braking (FEB) may also have failed.
A warning tone sounds.
In addition, the,andwarning lights may light up in the combination meter.
WARNING
The brake system continues to function normally, but without the functions listed above. The front and rear wheels could
therefore lock if you brake hard, for example.
The steering and braking characteristics may be severely affected. The braking distance may increase in an emergency braking
situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Drive on carefully and have the system checked immediately. It is recommended you visit an INFINITI retailer for this service.
[Turn On The Ignition to
Release the Parking Brake]The redindicator light lights up.
You attempted to release the electric parking brake while the ignition was switched off.
Key: turn the key to the ON position in the ignition switch
2-32Instruments and controls
