2019 INFINITI QX30 buttons

If you see this symbol, it means“Do not do
this”or“Do not let this happen”.
If you see a symbol similar to these in an
illustration, it means the arrow points to the
front of the vehicle.
Arrows in an illustration that are similar to
these indicate movement or action.
Arrows in an illustration that are similar to
these call attention to an item in the illustra-
tion.
[]:
Square brackets are used to indicate mes-
sages, keys, or items displayed on a screen.
<>:
Chevrons or angle brackets are used to indi-
cate texts on controls like buttons or
switches inside or on the vehicle.
CALIFORNIA PERCHLORATE
ADVISORY
Some vehicle parts, such as lithium batteries,
may contain perchlorate material. The fol-
lowing advisory is provided: “Perchlorate
Material - special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/
perchlorate.”
© 2018 NISSAN MOTOR CO., LTD.
All rights reserved. No part of this Owner’s
Manual may be reproduced or stored in a
retrieval system, or transmitted in any form,
or by any means, electronic, mechanical, pho-
tocopying, recording or otherwise, without
the prior written permission of Nissan Motor
Co., Ltd.

1. Rear armrest* (P. 1-7)
2. Rear personal lights (P. 2-88)
3. Overhead control panel (P. 2-78)
4. Sunshade switch* (P. 2-78)
5. Sun visor (P. 2-18)
6. Security system buttons (P. 3-60)7. Interior rear-view mirror (P. 3-18)
8. Door handle (P. 3-6)
9. Door armrest
— Power windows controls (P. 2-75)
— Exterior rear view mirror remote control
switch (P. 2-18)10. Front cup holders (P. 2-82)
11. Air conditioner controls (P. 4-29)
12. Glove box/storage (P. 2-80)
*: if equipped
NIC2701
PASSENGER COMPARTMENT
Illustrated table of contents0-5

VANITY MIRROR LIGHTS
To access the vanity mirror, pull the sun visor
down and flip open the mirror cover.
The vanity mirror light illuminates when the
vanity mirror cover is opened. When the cover
is closed, the light will turn off.
LUGGAGE COMPARTMENT
LIGHT
The light illuminates while the lift gate is
opened. When the lift gate is closed, the light
will turn off.
BATTERY SAVER SYSTEM
The interior light will automatically turn off
after a period of time when the ignition
switch has been put in the OFF position. To
turn on the light again, put the ignition switch
in the ON position.The HomeLink® Universal Transceiver, inte-
grated in the vehicle's inside rear view mirror,
provides a convenient way to consolidate the
functions of up to three individual hand-held
transmitters into one built-in device.
HomeLink® Universal Transceiver:
•Will operate most Radio Frequency (RF)
devices such as garage doors, gates, home
and office lighting, entry door locks and
security systems.
•Is powered by your vehicle’s battery. No
separate batteries are required. If the ve-
hicle’s battery is discharged or is discon-
nected, HomeLink® will retain all pro-
gramming.
When the HomeLink® Universal Transceiver
is programmed, retain the original trans-
mitter for future programming procedures
(Example: new vehicle purchases). Upon sale
of the vehicle, the programmed HomeLink®
Universal Transceiver buttons should be
erased
for security purposes. For addi-
tional information, refer to"Programming
HomeLink® " later in this section.
SIC3869Z
HOMELINK® UNIVERSAL
TRANSCEIVER (IF EQUIPPED)
Instruments and controls2-89

WARNING
•Do not use the HomeLink® Universal
Transceiver with any garage door
opener that lacks safety stop and re-
verse features as required by federal
safety standards. (These standards be-
came effective for opener models manu-
factured after April 1, 1982). A garage
door opener which cannot detect an ob-
ject in the path of a closing garage door
and then automatically stop and re-
verse, does not meet current federal
safety standards. Using a garage door
opener without these features increases
the risk of serious injury or death.
•During the programming procedure
your garage door or security gate will
open and close (if the transmitter is
within range). Make sure that people or
objects are clear of the garage door,
gate, etc. that you are programming.
•Your vehicle’s engine should be turned
off while programming the HomeLink®
Universal Transceiver.NOTE
Certain garage door drives are incompatible
with the integrated garage door opener.
If you have difficulty programing the inte-
grated garage door opener, it is recom-
mended you contact your INFINITI retailer.
PROGRAMMING HOMELINK®
If you have any questions or are having diffi-
culty programming your HomeLink® but-
tons, refer to the HomeLink® web site at:
www.homelink.com or call 1-800-355-3515.1. Turn the ignition key to the ON position.
2. Press and hold one of buttons
2to4on
the HomeLink®.
HomeLink® is now in programing mode.
After a short time, indicator light
1lights
up yellow.
Indicator light
1lights up yellow as soon
as button
2,3or4is programed for
the first time. If the selected button has
already been programed, indicator light
1will only light up yellow after ten sec-
onds have elapsed.
3. Release button
2,3or4. Indicator
light
1flashes yellow.
4. Position the end of your hand-held trans-
mitter
52–8 inches (5–20 cm) away
from the HomeLink® surface, keeping the
HomeLink® indicator light
1in view.
NDI1631
2-90Instruments and controls

5. Press and hold button6on the hand held
transmitter until indicator light
1lights
up green. When indicator light
1: lights
up green: programing is finished.
When indicator light
1flashes green:
programing was successful. The next step
is to synchronize the rolling code.
6. Release button
6on the hand held trans-
mitter
5for the garage door drive sys-
tem.
If indicator light
1lights up red: repeat
the programing procedure for the corre-
sponding button on the rear-view mirror.
When doing so, vary the distance be-
tween the hand held transmitter
5and
the rear-view mirror.
The required distance between the hand
held transmitter
5and the integrated ga-
rage door opener depends on the garage
door drive system. Several attempts might
be necessary. You should test every posi-
tion for at least 25 seconds before trying
another position.
Synchronizing the rolling code
If the garage door system uses a rolling code,
you will also have to synchronize the garage
door system with the integrated garage door
opener in the rear-view mirror. To do this you
will need to use the programing button on thedoor drive control panel. The programing
button may be positioned at different loca-
tions depending on the manufacturer. It is
usually located on the door drive unit on the
garage ceiling.
Familiarize yourself with the garage door
drive operating instructions before carrying
out the following steps.
Your vehicle must be within reach of the ga-
rage door or gate opener drive. Make sure
that neither your vehicle nor any persons/
objects are present within the sweep of the
door or gate.
1. Turn the ignition key to the ON position.
2. Get out of the vehicle.
3. Press the programing button on the door
drive unit.
Usually, you now have 30 seconds to ini-
tiate the next step.
4. Get into the vehicle.
5. Press previously programed button
2,3or4on the HomeLink® until the door
closes.
The rolling code synchronization is then
complete.
If you live in Canada
Canadian radio frequency laws require a
"break" (or interruption) of the transmission
signals after broadcasting for a few seconds.
Therefore, these signals may not last long
enough for the integrated garage door
opener. The signal is not recognized during
programing. Comparable with Canadian law,
some U.S. garage door openers also feature a
"break".
Proceed as follows:
•If you live in Canada
•If you have difficulties programing the ga-
rage door opener (regardless of where you
live) when using the programing steps.
1. Press and hold one of buttons
2to4on
the HomeLink®. After a short time, indi-
cator light
1lights up yellow.
2. Release the button.
Indicator light
1flashes yellow.
3. Press button
6of the hand held trans-
mitter
5for two seconds, then release it
for two seconds.
4. Press button
6again for two seconds.
5. Repeat this sequence on button
6of the
hand held transmitter
5until indicator
light
1lights up green.
Instruments and controls2-91

CLEARING THE PROGRAMMED
INFORMATION
Make sure that you clear the memory of the
integrated garage door opener before selling
the vehicle.
1. Turn the ignition key to the ON position.
2. Press and hold buttons
2and4.
The indicator light initially lights up yellow
and then green.
3. Release buttons
2and4.
The memory of the integrated garage door
opener in the rear-view mirror is cleared.
IF YOUR VEHICLE IS STOLEN
If your vehicle is stolen, you should change
the codes of any non-rolling code device that
has been programmed into HomeLink®.
Consult the Owner’s Manual of each device
or call the manufacturer of those devices
for additional information or contact an
INFINITI retailer.
Instruments and controls2-93

1Locks the vehicle.
2Unlocks the vehicle.
3Panic button.
WARNING
•Radio waves could adversely affect
electric medical equipment. Those who
use a pacemaker should contact the
electric medical equipment manufac-
turer for the possible influences before
use.
•The Intelligent Key transmits radio
waves when the buttons are pushed.
The FAA advises that the radio waves
may affect aircraft navigation and com-
munication systems. Do not operate the
Intelligent Key while on an airplane.
Make sure that the buttons are not op-
erated unintentionally when the unit is
stored for a flight.
The Intelligent Key system can operate all the
door locks using the remote control function
or touching the request switch on the vehicle
without taking the key out from a pocket or
purse. The operating environment and/or
conditions may affect the Intelligent Key sys-
tem operation.
Be sure to read the following before using the
Intelligent Key system.
CAUTION
•Be sure to carry the Intelligent Key with
you when operating the vehicle.
•Never leave the Intelligent Key in the
vehicle when you leave the vehicle.
The Intelligent Key is always communicating
with the vehicle as it receives radio waves.
The Intelligent Key system transmits weakradio waves. Environmental conditions may
interfere with the operation of the Intelligent
Key system under the following operating
conditions:
•When operating near a location where
strong radio waves are transmitted, such
as a TV tower, power station and broad-
casting station.
•When in possession of wireless equip-
ment, such as a cellular telephone, trans-
ceiver or a CB radio.
•When the Intelligent Key is in contact with
or covered by metallic materials.
•When any type of radio wave remote con-
trol is used nearby.
•When the Intelligent Key is placed near an
electric appliance such as a personal com-
puter.
•When the vehicle is parked near a parking
meter.
In such cases, correct the operating condi-
tions before using the Intelligent Key function
or use the mechanical key.
Although the life of the battery varies de-
pending on the operating conditions, the bat-
tery's life is approximately two years. If the
battery is discharged, replace it with a new
one.
NPA1493
INFINITI INTELLIGENT KEY SYSTEM
3-8Pre-driving checks and adjustments

4. All doors and the lift gate will lock.
5. The turn signals flash three times.
NOTE
•Doors do not lock by pushing the door
handle request switch while any door is
open. However, doors lock with the me-
chanical key even if any door is open.
•The driver's door and the door at which
the handle is used, must both be closed.
•The doors may not lock when the Intelli-
gent Key is in the same hand that is oper-
ating the request switch to lock the door.
Put the Intelligent Key in a purse, pocket
or your other hand.
CAUTION
•When locking the doors using the re-
quest switch, make sure to have the In-
telligent Key in your possession before
operating the request switch to prevent
the Intelligent Key from being left in the
vehicle.
•The request switch is operational only
when the Intelligent Key has been de-
tected by the Intelligent Key system.
Unlocking doors
1. Carry the Intelligent Key.
2. Touch the inner surface of the door
handle.
3. All doors and the lift gate will unlock.
4. The turn signals flash once.
Deactivating and activating
If you do not intend to use the vehicle for an
extended period of time, you can deactivate
the Intelligent Key. The key will then use very
little power, thereby conserving battery
power. For the purposes of activation/
deactivation, the vehicle does not have to be
nearby.
To deactivate:press the
button on the
key twice in rapid succession The battery
check lamp of the key lights up twice briefly
and Intelligent Key is deactivated.
To activate:press any button on the key or
insert the key into the ignition lock. The Intel-
ligent Key and all of its associated features
are available again.
CHANGING THE SETTINGS OF
THE LOCKING SYSTEM
You can change the settings of the locking
system. This means that only the driver's door
and the fuel-filler lid are unlocked when the
vehicle is unlocked. This is useful if you fre-
quently travel alone.To change the setting:simultaneously
press theandbuttons for approxi-
mately 6 seconds.
NOTE
If the setting of the locking system is
changed within the signal range of the ve-
hicle, pressing the
andbutton will
lock or unlock the vehicle.
The key now functions as follows:
To unlock the driver's door:press the
button once.
To unlock centrally:press the
button
twice.
To lock centrally:press the
button.
The Intelligent Key function is changed as
follows:
To unlock the driver's door:touch the inner
surface of the door handle on the driver's
door.
To unlock centrally:touch the inner surface
of the door handle on the front passenger
door or the rear door.
To lock centrally:touch the outer sensor sur-
face on one of the door handles
To restore the factory settings:
simultane-
ouslypress theandbutton for ap-
proximately 6 seconds.
Pre-driving checks and adjustments3-11
