5. Wipe the engine oil filter sealing surface
with a clean rag.
CAUTION
•Be sure to remove any old gasket mate-
rial remaining on the sealing surface of
the engine. Failure to do so could lead to
an oil leak and engine damage.
•The dipstick must be inserted in place to
prevent oil spillage from the dipstick
hole when filling the engine with oil.
6. Coat the gasket on the new filter with
clean engine oil.
7. Screw on the oil filter until a slight resis-
tance is felt, then tighten an additional
2/3 turn.
Engine oil filter tightening torque: 19 ft-lb,
25 N•m
8. Start the engine and check for leakage
around the oil filter. Correct as required.
9. Turn the engine off and wait more than
15 minutes. Check the oil level. Add engine
oil if necessary.It is recommended that you visit an INFINITI
retailer if checking or replacement is required.
CAUTION
•Use only Shell DCT-M1 or equivalent.
Do not mix with other fluids.
•Using automatic transmission fluid
other than Shell DCT-M1 may cause de-
terioration in driveability and automatic
transmission durability, and may dam-
age the automatic transmission. Dam-
age caused by the use of fluids other
than as recommended is not covered by
the warranty.
WARNING
•Use only new fluid. Old, inferior, or con-
taminated fluid may damage the brake
systems. The use of improper fluids can
damage the brake system and affect the
vehicle's stopping ability.
•Clean the filler cap before removing.
•Brake fluid is poisonous and should be
stored carefully in marked containers
out of the reach of children.
CAUTION
•Do not spill the fluid on painted surfaces.
This will damage the paint. If fluid is
spilled, wash with water.
NDI1599
AUTOMATIC TRANSMISSION FLUID
(ATF)BRAKE FLUID
Do-it-yourself8-7

Check the fluid level in the reservoir. If the
brake fluid is below the MIN line
2, the brake
warning light will illuminate. Add brake fluid
up to the MAX line
1. Use Genuine INFINITI
brake fluid DOT4+ or equivalent. Never mix
different types of fluids. For additional infor-
mation on the recommended type of brake
fluid, refer "Recommended fluids/lubricants
and capacities".
If the brake fluid must be added frequently,
the brake system should be thoroughly
checked. It is recommended that you visit an
INFINITI retailer for this service.Fill the windshield-washer fluid reservoir pe-
riodically. Add fluid when the low washer
fluid warning appears on the vehicle informa-
tion display.
To fill the windshield-washer fluid reservoir,
lift the cap off the reservoir and pour the
windshield-washer fluid into the reservoir
opening.
Add a washer solvent to the washer for bet-
ter cleaning. In the winter season, add a
windshield-washer antifreeze. Follow the
manufacturer’s instructions for the mixture
ratio.
Refill the reservoir more frequently when
driving conditions require an increased
amount of windshield-washer fluid.Recommended fluid is Genuine INFINITI
Windshield Washer Concentrate Cleaner &
Antifreeze or equivalent.CAUTION
•Do not substitute engine antifreeze
coolant for window washer solution.
This may result in damage to the paint.
•Do not fill the window washer reservoir
tank with washer fluid concentrates at
full strength. Some methyl alcohol
based washer fluid concentrates may
permanently stain the grille if spilled
while filling the window washer reser-
voir tank.
•Pre-mix washer fluid concentrates with
water to the manufacturer’s recom-
mended levels before pouring the fluid
into the window washer reservoir tank.
Do not use the window washer reservoir
tank to mix the washer fluid concentrate
and water.
NDI1601
WINDOW WASHER FLUID
8-8Do-it-yourself

Parking brake*:
Check the parking brake operation regularly.
Also make sure that the vehicle is held se-
curely on a fairly steep hill when only the
parking brake is applied. If the parking brake
needs adjustment, it is recommended you
visit an INFINITI retailer for this service.
Seats:
Check seat position controls such as seat
adjusters, seatback recliner, etc. to ensure
they operate smoothly and that all latches
lock securely in every position. Check that the
head restraints move up and down smoothly
and that the locks (if so equipped) hold se-
curely in all latched positions.
Seat belts:
Check that all parts of the seat belt system
(for example, buckles, anchors, adjusters and
retractors) operate properly and smoothly,
and are installed securely. Check the belt
webbing for cuts, fraying, wear or damage.
Steering wheel:
Check for changes in the steering condition,
such as excessive free play, hard steering or
strange noises.
Warning lights and chimes:
Make sure that all warning lights and chimes
are operating properly.Windshield defroster:
Check that the air comes out of the defroster
outlets properly and in good quantity when
operating the heater or air conditioner.
Windshield wiper and washer*:
Check that the wipers and washer operate
properly and that the wipers do not streak.
Under the hood and vehicle
The maintenance items listed here should be
checked periodically (for example, each time
you check the engine oil or refuel).
Battery*:
Except for maintenance free battery, check
the fluid level in each cell. It should be be-
tween the “UPPER” and “LOWER” lines.
NOTE
Care should be taken to avoid situations
that can lead to potential battery discharge
and potential no-start conditions such as:
1. Installation or extended use of electronic
accessories that consume battery power
when the engine is not running (Phone
chargers, GPS, DVD players, etc.)
2. Vehicle is not driven regularly and/or
only driven short distances.
In these cases, the battery may need to be
charged to maintain battery health.Brake fluid level*:
Make sure that the brake fluid level is be-
tween the “MAX” and “MIN” lines on the res-
ervoir.
Coolant level*:
Check the coolant level when the engine is
cold.
Engine drive belt(s)*:
Make sure that no belt is frayed, worn,
cracked or oily.
Engine oil level*:
Check the level after parking the vehicle on a
level spot and turning off the engine. Wait
more than 15 minutes for the oil to drain back
into the oil pan.
Exhaust system:
Make sure there are no loose supports,
cracks or holes. If the sound of the exhaust
seems unusual or there is a smell of exhaust
fumes, immediately have the exhaust system
inspected. It is recommended you visit an
INFINITI retailer for this service. See "Precau-
tions when starting and driving".
Fluid leaks:
Check under the vehicle for fuel, oil, water or
other fluid leaks after the vehicle has been
parked for a while. Water dripping from the
9-4Maintenance and Schedules

Aftermarket fuel additives
INFINITI does not recommend the use of any
aftermarket fuel additives (Example: fuel in-
jector cleaner, octane booster, intake valve
deposit removers, etc.) which are sold com-
mercially. Many of these additives intended
for gum, varnish or deposit removal may con-
tain active solvent or similar ingredients that
can be harmful to the fuel system and engine.
Octane rating tips
Using unleaded gasoline with an octane rat-
ing lower than recommended above can
cause persistent, heavy spark knock. (Spark
knock is a metallic rapping noise.) If severe,
this can lead to engine damage. If you detect
a persistent heavy spark knock even when
using gasoline of the stated octane rating, or
if you hear steady spark knock while holding
a steady speed on level roads, it is recom-
mended you have an INFINITI retailer cor-
rect the condition. Failure to correct the con-
dition is misuse of the vehicle, for which
INFINITI is not responsible.
Incorrect ignition timing will result in knock-
ing, after-run and/or overheating. This in turn
may cause excessive fuel consumption or
damage to the engine. If any of the above
symptoms are encountered, have your ve-
hicle checked. It is recommended you visit an
INFINITI retailer.However, now and then you may notice light
spark knock for a short time while accelerat-
ing or driving up hills. This is no cause for
concern, because you get the greatest fuel
benefit when there is light spark knock for a
short time under heavy engine load.
ENGINE OIL AND OIL FILTER
RECOMMENDATIONS
Selecting the correct oil
It is essential to choose the correct grade,
quality, and viscosity engine oil to ensure sat-
isfactory engine life and performance. For
additional information, refer to "Recom-
mended fluids/lubricants and capacities"
earlier in this section.
Select only engine oils that meet the MB229.5
specification and SAE viscosity standard. These
oils have the MB229.5 specification label on the
container. Oils which do not have the specified
quality label should not be used as they could
cause engine damage.
Oil additives
INFINITI does not recommend the use of oil
additives. The use of an oil additive is not
necessary when the proper oil type is used
and maintenance intervals are followed.
Oil which may contain foreign matter or has
been previously used should not be used.
Oil viscosity
The engine oil viscosity or thickness changes
with temperature. Because of this, it is impor-
tant that the engine oil viscosity be selected
based on the temperatures at which the vehicle
will be operated before the next oil change.
Choosing an oil viscosity other than that recom-
mended could cause serious engine damage.
Outside Temperature Range
Anticipated Before Next Oil Change
GASOLINE ENGINE OIL
JVT0428X
Technical information10-5

For Canada:
If you believe that your vehicle has a defect
which could cause a crash or could cause
injury or death, you should immediately in-
form Transport Canada in addition to notify-
ing INFINITI.
If Transport Canada receives complaints, it
may open an investigation, and if it finds that
a safety defect exists in a group of vehicles, it
may request that INFINITI conduct a recall
campaign. However, Transport Canada can-
not become involved in individual problems
between you, your retailer, or INFINITI.
You may contact Transport Canada’s Defect
Investigations and Recalls Division toll free
at 1-800-333- 0510. You may also report
safety defects online at:
https://wwwapps.tc.gc.ca/Saf-Sec- Sur/7/
PCDB-BDPP/Index.aspx.
Additional information concerning motor
vehicle safety may be obtained from Trans-
port Canada’s Road Safety Information
Center at 1-800-333- 0371 or online at
www.tc.gc.ca/roadsafety (English speakers)
or www.tc.gc.ca/securiteroutiere (French
speakers).
To notify INFINITI of any safety concerns
please contact our Consumer Information
Center toll free at 1-800- 361-4792.WARNING
A vehicle equipped with All-Wheel Drive
(AWD) should never be tested using a two
wheel dynamometer (such as the dyna-
mometers used by some states for emis-
sions testing), or similar equipment. Make
sure you inform test facility personnel that
your vehicle is equipped with AWD before
it is placed on a dynamometer. Using the
wrong test equipment may result in trans-
mission damage or unexpected vehicle
movement which could result in serious ve-
hicle damage or personal injury.
Due to legal requirements in some states and
Canadian Provinces, your vehicle may be re-
quired to be in what is called the “ready con-
dition” for an Inspection/Maintenance (I/M)
test of the emission control system.
The vehicle is set to the “ready condition”
when it is driven through certain driving pat-
terns. Usually, the “ready condition” can be
obtained by ordinary usage of the vehicle.
If a powertrain system component is repaired
or the battery is disconnected, the vehicle
may be reset to a “not ready condition”. Be-
fore taking the I/M test, check the vehicle’s
inspection/maintenance test readiness con-
dition. Place the ignition switch in the ON
position without starting the engine. If theMalfunction Indicator Light (MIL) comes on
steady for 20 seconds and then blinks for
10 seconds, the I/M test condition is “not
ready”. If the MIL does not blink after 20 sec-
onds, the I/M test condition is “ready”.
It is recommended you contact an INFINITI
retailer to set the “ready condition” or to pre-
pare the vehicle for testing.
READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST
10-18Technical information

11 Index
A
ABS (Anti-lock Braking System).......2-9
Warninglight ................2-9
Active sound enhancement.........5-69
Operation..................5-69
Adaptive Front lighting System.......2-67
Aids.......................5-62
Forward emergency braking system . .5-62
Hill Start Assist (HSA)..........5-95
Intelligent Parking Assist (IPA).....5-70
Air bags....................1-45
Front passenger air bag switch.....1-45
Overview...................0-2
Repair and replacement.........1-54
Supplemental Restraint System.....1-37
Warninglight............1-53,2-12
Air cleaner filter................8-13
Air conditioner................4-29
Heater and air conditioner........4-29
Refrigerantandlubricant ........10-6
Servicing..................4-38
Specification label............10-11
Air fresheners..................7-4
Antenna....................4-39
Anti-theft alarm system...........2-60
Around View Monitor............4-11
Moving object detection (MOD)....4-24Settings...................4-20
Audible reminders..............2-14
Automatic transmission............8-7
Fluid (ATF)..................8-7
Operation..................5-18
B
Battery......................8-9
Caution label................8-9
Cold weather...............5-96
Jump-starting...............6-10
Replacement - Intelligent Key......8-20
Saver system................2-89
Vehicle battery...............8-9
Blind Spot Warning (BSW) system.....5-36
Boosterseats.................1-34
Precautions.................1-34
Brakes .....................8-17
ABS(Anti-LockBrakingSystem)....5-91
Adjustment.................8-17
Fluid......................8-7
Forward emergency braking system . .5-62
Parking brake...............5-27
Precautions ................5-90
System...................5-90
Warninglight ................2-9
Break-in schedule..............5-84Brightness...................2-71
Instrument panel..............2-71
C
Capacities and recommendations.....10-2
Coolant...................10-2
Fuel.....................10-2
Oil......................10-2
Refrigerant.................10-2
Cardholder ..................2-81
CBradio....................4-39
Changing....................8-4
Engine coolant...............8-4
Engine oil...................8-5
Engine oil filter...............8-6
Tires and wheels.............8-34
Checking.....................8-4
Coolant level.................8-4
Engine oil level...............8-5
Child restraints................1-19
Anchorage.................1-22
ISOFIX installation............1-23
Precautions.................1-19
Childsafety ..................1-17
Rear door locks...............3-7
Cleaning.....................7-3
Alloy wheels.................7-3

Chromeparts.................7-3
Exterior ....................7-2
Glass......................7-3
Interior.....................7-4
Leatherseatcovers.............7-6
Removing spots...............7-3
Seat belts...................7-5
Underbody..................7-3
Washing....................7-2
Waxing.....................7-2
Clock.......................2-79
Adjusting time................2-79
Coat hooks...................2-83
Cockpit......................0-6
Overview................0-6,2-2
Cold weather..................5-96
Battery....................5-96
Drivingonsnoworice...........5-97
Engine coolant...............5-96
Precautions.................5-96
Special equipment.............5-97
Tire equipment...............5-96
Compartment.................2-89
Coolant.....................10-2
Capacities..................10-2
Changing engine coolant..........8-4
Checking coolant level...........8-4
Cold weather................5-96
Engine cooling system...........8-3
Temperature gauge.............2-6Corrosionprotection..............7-7
Environmental factors............7-7
Cruisecontrol .................5-46
Canceling..................5-48
Operation..................5-47
Cupholders...................2-82
D
Defroster....................2-64
Switch....................2-64
Dimensions...................10-8
Engine....................10-7
Tires.....................10-8
Display......................2-71
Brightness..................2-71
Vehicle information display........2-15
Warningsandindicators .........2-29
Doors.......................3-7
Liftgate....................3-7
Lockingkey..................3-5
Locks.....................3-4
Mappocket.................2-84
Drivebelts....................8-12
Driving......................5-18
Automatic Transmission..........5-18
Cold weather................5-96
Idle Stop/Start System..........5-29
Onsnoworice...............5-97
Precautions..................5-2
E
Emergency key..................3-2
Engine......................5-16
Before starting...............5-16
Changing engine coolant..........8-4
Changing engine oil.............8-5
Changing oil filter..............8-6
Checking coolant level...........8-4
Checking engine oil level..........8-5
Coldweather................5-96
Compartment.............0-9,8-3
Coolingsystem................8-3
Data .....................10-7
Oil .......................8-5
Serial number...............10-10
Spark plugs.................8-12
Starting...................5-16
Eventdatarecorders(EDR) ........10-19
Exhaust gas...................5-2
Precautions..................5-2
Exterior......................7-2
Cleaning....................7-2
Lights ....................8-23
Overview...................0-3
Exterior rear view mirrors..........3-18
11-2Index

Vanity mirror................3-18
Vanity mirror lights.............2-89
Moving object detection (MOD)......4-24
O
Oil........................10-2
Capacities and recommendations....10-2
Changing engine oil.............8-5
Changing engine oil filter..........8-6
Checking engine oil level..........8-5
Overheating ..................6-13
Engine....................6-13
Engine coolant temperature gauge....2-6
Overview.....................0-6
Cockpit .................0-6,2-2
Engine compartment.........0-9,8-3
Exterior....................0-3
Interior.....................0-5
Seats, Seat belts, Supplemental restraint
system.....................0-2
P
Parcelshelf...................2-85
Installation..................2-86
Removal...................2-85
Parking.....................5-87
Brake.....................5-27
Parking sensor system...........5-76Sonar function...............5-76
Parkingsensors ................5-81
OFF switch.................5-81
Phone......................4-39
Power.......................3-6
Door lock switch...............3-6
Outlet ....................2-79
Seat adjustment...............1-4
Steering...................5-89
Windows..................2-74
Precautions...................1-34
Boosterseats................1-34
Brake.....................5-90
Child restraints...............1-19
Intelligent Parking Assist (IPA)......5-70
Maintenance.................8-2
Safety.....................4-2
Seat belt usage...............1-10
Starting and driving.............5-2
Supplemental Restraint System.....1-37
Tire Pressure Monitoring System
(TPMS)....................5-3
Pregnant women................1-12
Protection ....................7-7
Corrosion...................7-7
Push-button ignition.............5-14
Push-starting..................6-12
R
Rear seats....................1-5
Folding.....................1-6
RearView monitor................4-3
Maintenance................4-11
Repairing....................8-25
Headlights..................8-25
Replacement..................1-54
Airbags ...................1-54
Air cleaner filter...............8-13
Engine coolant................8-4
Engine oil...................8-5
Engine oil filter................8-6
Intelligent Key battery...........8-20
Spark plugs.................8-12
Tires and wheels..............8-34
Wiper blades................8-13
Roof.......................2-78
Glass.....................2-78
Sunshade operation............2-78
Roof Rack....................2-86
S
Safety......................1-17
Children ...................1-17
Child safety rear door locks........3-7
Head restraints................1-7
Injuredpersons...............1-12
Index11-5
