2019 INFINITI QX30 engine

occupant is too close to, or is against, the
front air bag module during inflation. The
front air bags deflate quickly after a collision.
The front air bags operate only when the
ignition switch is placed in the ON position.
After placing the ignition switch in the ON
position, the supplemental air bag warning
light illuminates. The supplemental air bag
warning light will turn off a few seconds af-
ter the engine starts if the system is opera-
tional.
Front passenger air bag and status
light
WARNING
The front passenger air bag is designed to
automatically turn OFF under some condi-
tions. Read this section carefully to learn
how it operates. Proper use of the seat,
seat belt and child restraints is necessary
for most effective protection. Failure to
follow all instructions in this manual con-
cerning the use of seats, seat belts and
child restraints can increase the risk or se-
verity of injury in an accident.
1indi-
cator light
2in-
dicator light
Status light
The front passenger seat is equipped with an
occupant classification sensor (pressure sen-
sor) that turns the front passenger air bag on
or off depending on the weight applied to the
front passenger seat. The indicator lights in-
form you whether the front passenger front
air bag is disabled or enabled.
Place the ignition in the ON position. The
system carries out a self-diagnosis.The and SENGER AIRBAG ON> indicator lights will
light up simultaneously for approximately six
seconds.
The indicator lights display the status of the
front passenger front air bag:
• lights up: the
front passenger front air bag is enabled. If,
in the event of an accident, all deployment
criteria are met, the front passenger front
air bag is deployed.
• lights up:
the front passenger front air bag is dis-
abled. It will then not be deployed in the
event of an accident.
If the status of the front passenger front air
bag changes while the vehicle is in motion, an
air bag display message appears in the ve-
hicle information display. When the front
passenger seat is occupied, always pay at-
tention to the
and indicator
lights. Be aware of the status of the front
passenger front air bag both before and dur-
ing the journey.
If neither the
or the indicator
lights light up, or if either indicator light only
lights up intermittently during the journey, the
front passenger seat may not be used for a
NIC2740
Safety — seats, seat belts and supplemental restraint system1-45

Front seat-mounted side-impact
supplemental air bag and
roof-mounted curtain side-impact
and rollover supplemental air bag
systems
The side air bags are located in the outside of
the seatback of the front seats. The curtain
air bags are located in the side roof rails.All of
the information, cautions and warnings in
this manual apply and must be followed.The
side air bags and curtain air bags are de-
signed to inflate in higher severity side colli-
sions, although they may inflate if the forces
in another type of collision are similar to
those of a higher severity impact. They are
designed to inflate on the side where the
vehicle is impacted. They may not inflate in
certain side collisions. Curtain air bags are
also designed to inflate in certain types ofrollover collisions or near rollovers. As a re-
sult, certain vehicle movements (for example,
during severe off-roading) may cause the
curtain air bags to inflate.
Vehicle damage (or lack of it) is not always an
indication of proper side air bag and curtain
air bag operation.
When the side air bags and curtain air bags
inflate, a fairly loud noise may be heard, fol-
lowed by release of smoke. This smoke is not
harmful and does not indicate a fire. Care
should be taken not to inhale it, as it may
cause irritation and choking. Those with a
history of a breathing condition should get
fresh air promptly.
Side air bags, along with the use of seat belts,
help to cushion the impact force on the chest
of the front occupants. Curtain air bags help
to cushion the impact force to the head of
occupants in the front and rear outboard
seating positions in all rows. They can help
save lives and reduce serious injuries. How-
ever, an inflating side air bag or curtain air
bag may cause abrasions or other injuries.
Side air bags and curtain air bags do not
provide restraint to the lower body.
The seat belts should be correctly worn and
the driver and front passenger seated upright
as far as practical away from the side air bag.
Rear seat passengers should be seated as faraway as practical from the door finishers and
side roof rails. The side air bags and curtain
air bags inflate quickly in order to help protect
the occupants. Because of this, the force of
the side air bags and curtain air bags inflating
can increase the risk of injury if the occupant
is too close to, or is against, these air bag
modules during inflation. The side air bag will
deflate quickly after the collision is over.
The curtain air bag will remain inflated for a
short time.
The side air bags and curtain air bags oper-
ate only when the ignition switch is placed in
the ON position. After placing the ignition
switch in the ON position, the supplemental
air bag warning light illuminates. The
supplemental air bag warning light will turn
off a few seconds after the engine starts if
the system is operational.
WARNING
•Do not place any objects near the seat-
back of the front seats. Also, do not
place any objects (an umbrella, bag, etc.)
between the front door finisher and the
front seat. Such objects may become
dangerous projectiles and cause injury if
a side air bag inflates.
SSS0978Z
1-50Safety — seats, seat belts and supplemental restraint system

•Right after inflation, several side air bag
and curtain air bag system components
will be hot. Do not touch them; you may
severely burn yourself.
•No unauthorized changes should be
made to any components or wiring of
the side air bag and curtain air bag sys-
tems. This is to prevent damage to or
accidental inflation of the side air bag
and curtain air bag systems.
•Do not make unauthorized changes to
your vehicle’s electrical system, suspen-
sion system or side panel. This could af-
fect proper operation of the curtain air
bag systems.
•Tampering with the side air bag system
may result in serious personal injury. For
example, do not change the front seats
by placing material near the seatbacks
or by installing additional trim material,
such as seat covers, around the side air
bag.
•It is recommended that you visit an
INFINITI retailer for work on and around
the front air bag. It is also recommended
that you visit an INFINITI retailer for
installation of electrical equipment. The
SRS wiring harnesses* should not be
modified or disconnected. Unauthorizedelectrical test equipment and probing
devices should not be used on the side air
bag or curtain air bag systems.
Driver and passenger supplemental
knee air bags
The driver's knee air bag deploys under the
steering column, while the passenger's knee
air bag deploys under the glove box. All of the
information, cautions and warnings in this
manual apply and must be followed. The driv-
er's and passenger's knee air bags are trig-
gered together with the front air bag. The
knee air bags are designed to inflate in higher
severity frontal collisions, although they may
inflate if the forces in another type of collision
are similar to those of a higher severity fron-
tal impact. They may not inflate in certain
collisions.
Vehicle damage (or lack of it) is not always an
indication of proper knee air bag operation.
When a knee air bag inflates, a fairly loud
noise may be heard, followed by release of
smoke. This smoke is not harmful and does
not indicate a fire. Care should be taken not
to inhale it, as it may cause irritation and
choking. Those with a history of a breathing
condition should get fresh air promptlyThe knee air bags help to cushion the impact
force on the knees of the driver and front
passenger. They can help reduce serious inju-
ries. However, an inflating knee air bag may
cause abrasions or other injuries. The knee air
bag provides restraint to the lower body.
The knee air bag inflates quickly in order to
help protect the occupants. Because of this,
the force of the knee air bag inflating can
increase the risk of injury if the occupant is
too close to, or is against, this air bag module
during inflation. The knee air bag will deflate
quickly after the collision is over OR the knee
air bag will remain inflated for a short time.
The knee air bags operate only when the ig-
nition switch is placed in the ON position.
After placing the ignition switch in the ON
position, the supplemental air bag warning
light illuminates. The supplemental air bag
warning light will turn off a few seconds af-
ter the engine starts if the system is opera-
tional.
WARNING
•Do not place any objects between the
knee bolster and the driver’s seat. Such
objects may become dangerous projec-
tiles and cause injury if a knee air bag
inflates.
Safety — seats, seat belts and supplemental restraint system1-51

irritation and choking. Those with a history of
a breathing condition should get fresh air
promptly. After the pretensioner(s)'s activa-
tion, load limiters allow the seat belt to re-
lease webbing (if necessary) to reduce forces
against the chest. The supplemental air bag
warning light is used to indicate malfunctions
in the pretensioner system. For additional
information, refer to Supplemental air bag
warning light in this section. If the operation
of the supplemental air bag warning light
indicates there is a malfunction, have the sys-
tem checked. It is recommended that you visit
an INFINITI retailer for this service. When
selling your vehicle, we request that you in-
form the buyer about the pretensioner sys-
tem and guide the buyer to the appropriate
sections in this Owner's Manual.
SUPPLEMENTAL AIR BAG
WARNING LABELS
Warning labels about the supplemental front
impact air bag system are placed in the ve-
hicle as shown in the illustration.
WARNING
Do not use a rear-facing child restraint on a
seat protected by an air bag in front of it.
If the air bag deploys, it may cause serious
injury or death.
SUPPLEMENTAL AIR BAG
WARNING LIGHT
The supplemental air bag warning light, dis-
playingin the instrument panel, moni-
tors the circuits for the air bag systems, pre-
tensioner(s) and all related wiring.
When the ignition switch is placed in the ON
position, the supplemental air bag warning
light illuminates. The air bag warning light will
turn off within a few seconds after the engine
is started, if the system is operational.
If any of the following conditions occur, the
front air bag, side air bag, curtain air bag and
pretensioner systems need servicing:
•The supplemental air bag warning light
remains on after approximately 7 seconds.
SSS1016ZSPA1097Z
Safety — seats, seat belts and supplemental restraint system1-53

2 Instruments and controls
Cockpit............................2-2
Instrument panel......................2-3
Meters and gauges.....................2-4
Speedometer and odometer.............2-4
Outside temperature display.............2-5
Tachometer.......................2-6
Engine coolant temperature gauge.........2-6
Fuel gauge........................2-7
Warning lights, indicator lights and audible
reminders...........................2-8
Checking lights.....................2-8
Warning lights......................2-9
Indicator lights.....................2-13
Audible reminders...................2-14
Vehicle information display...............2-15
Menus and submenus................2-16
Display Messages...................2-29
Security system......................2-60
Immobiliser.......................2-60
Anti-theft alarm system (if equipped)......2-60
Wiper and washer switch................2-61
Switching the windshield wipers on/off.....2-62
Switching the rear window wiper on/off. . . .2-63
Rear window and outside mirror defroster
switch............................2-64
Windshield de-icer switch (if equipped).......2-64
Headlight and turn signal switches..........2-65Headlight switch...................2-65
Combination switch.................2-67
Adaptive front lighting system
(LED headlight only) (if equipped).........2-67
High beam assist (LED headlight only)......2-69
Headlights misted up on the inside........2-71
Instrument brightness control...........2-71
Fog light switch (If so equipped)............2-71
Front fog lights....................2-71
Rear fog light......................2-72
Horn.............................2-72
Seat heating (if equipped)................2-73
Windows..........................2-74
Power windows....................2-74
Fixed glass roof (if equipped)..............2-78
Sunshade operation.................2-78
Clock.............................2-79
Adjusting time.....................2-79
Power outlet........................2-79
Storage...........................2-80
Glove box........................2-80
Front console compartment............2-81
Console box......................2-81
Card holder.......................2-81
Cup holders.......................2-82
Coat hooks.......................2-83
Cargo tie-down hooks................2-83

1. Speedometer (P. 2-4)
2. Vehicle information display (P. 2-15)
— Odometer/twin trip odometer (P. 2-15)
3. Upper information display (P. 2-15)
4. Tachometer (P. 2-6)5. Engine coolant temperature gauge
(P. 2-6)
6. Fuel gauge (P. 2-7)NOTE
The needle indicators may move slightly af-
ter the ignition switch is put in the “OFF”
position. This is not a malfunction.
CAUTION
•For cleaning, use a soft cloth, dampened
with water. Never use a rough cloth,
alcohol, thinner or any kind of solvent or
paper towel with a chemical cleaning
agent. They will scratch or cause discol-
oration to the lens.
•Do not spray any liquid such as water on
the meter lens. Spraying liquid may
cause the system to malfunction.
SPEEDOMETER AND
ODOMETER
This vehicle is equipped with a speedometer
and odometer. The speedometer is located
on the right side of the meter cluster. The
odometer is located below the vehicle infor-
mation display.
NIC2651
METERS AND GAUGES
2-4Instruments and controls

TACHOMETER
The tachometer indicates the engine speed in
revolutions per minute (rpm).Do not rev the
engine in the red zone.
CAUTION
When engine speed approaches the red
zone, shift to a higher gear or reduce engine
speed. Operating the engine in the red zone
may cause serious engine damage.
ENGINE COOLANT
TEMPERATURE GAUGE
The gauge indicates the engine coolant tem-
perature. The engine coolant temperature is
within the normal range
1when the gauge
needle points within the zone shown in the
illustration. The engine coolant temperature
varies with the outside air temperature and
driving conditions.
CAUTION
If the gauge indicates coolant temperature
near the hot (H) end of the normal range,
reduce vehicle speed to decrease tempera-
ture. If the gauge is over the normal range,
stop the vehicle as soon as safely possible.
If the engine is overheated, continued op-
eration of the vehicle may seriously dam-
age the engine. For additional information,
refer to "If your vehicle overheats" for im-
mediate action required.
NIC2829NIC2831
2-6Instruments and controls

Anti-lock Braking System (ABS)
warning lightSeat belt (driver and front passenger)
warning lightHigh beam assist indicator light *
Brake warning light (red)Supplemental Restraint System (SRS)
air bag warning lightHigh beam indicator light
Low tire pressure warning light*Low fuel warning lightRear fog light indicator light
Malfunction indicator light (yellow)Vehicle Dynamic Control (VDC)
warning lightSide light indicator light
Distance warning light*Turn signal/hazard indicator lightsFront passenger air bag status light**
Electric parking brake warning light (red)Low beam indicator light
Electric parking brake warning light
(yellow)Vehicle Dynamic Control (VDC) OFF
indicator light
Coolant warning lightFront fog light indicator light* *: if equipped
**: located above heater and air conditioner controls
Some indicators and warnings are also dis-
played in the vehicle information display be-
tween the speedometer and tachometer see
"Vehicle information display".CHECKING LIGHTS
With all doors closed, apply the parking brake,
fasten the seat belts and place the ignition
switch in the ON position without starting the
engine. The following lights (if so equipped) will
come on, ,
,,,,
,,,,. These lights
should go out within a few seconds after start-
ing the engine. If any light fails to come on oroperates in a way other than described, it may
indicate a burned out bulb and/or a system
malfunction. Have the system checked. It is rec-
ommended you visit an INFINITI retailer for this
service.
WARNING LIGHTS, INDICATOR
LIGHTS AND AUDIBLE REMINDERS
2-8Instruments and controls
