2019 HONDA CIVIC COUPE sensor

525
uuHonda Sensing ®*uFront Sensor Camera
Driving
1Front Sensor Camera
If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:
•Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed toward the camera.
•Start driving the vehicle to lower the windshield
temperature, which cool s down the area around
the camera.
If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:
•Park your vehicle in a sa fe place, and clean the
windshield. If the message does not disappear after
you have cleaned the winds hield and driven for a
while, have your vehicle checked by a dealer.
19 CIVIC 2D HCM (KA KL KC)-31TBG6300.book 525 ページ ２０１８年９月４日　火 曜日　午後１時３８分

526
uuHonda Sensing ®*uRadar Sensor
Driving
Radar Sensor
The radar sensor is in the lower bumper.1Radar Sensor
Avoid strong impacts to the radar sensor cover.
For the CMBS to work properly:
•Always keep the radar sensor cover clean.•Never use chemical solvents or polishing powder
for cleaning the sensor cove r. Clean it with water
or a mild detergent.
•Do not put a sticker on th e radar sensor cover or
replace the radar sensor cover.
If you need the radar sensor to be repaired, or
removed, or the radar se nsor cover is strongly
impacted, turn off the syst em by using the CMBS OFF
button and take your vehicle to a dealer.
2 CMBS
TM On and Off P. 475
If the vehicle is involved in any of the following
situations, the radar sensor may not work properly.
Have your vehicle checked by a dealer:
•Your vehicle is involved in a frontal collision.•Your vehicle drives th rough deep water or is
submerged in deep water.
•Your vehicle strongly strikes a bump, curb, chock,
or embankment that coul d jar the radar sensor.
Radar Sensor
The radar sensor is in
the lower bumper.
19 CIVIC 2D HCM (KA KL KC)-31TBG6300.book 526 ページ ２０１８年９月４日　火 曜日　午後１時３８分

592
Maintenance
Battery
Checking the Battery
The condition of the battery is monitored by a
sensor located on the negative terminal of the
battery. If there is a problem with this sensor,
the driver information in terface will display a
warning message. If this happens, have your
vehicle inspected by a dealer.
Check the battery terminals for corrosion
monthly.
If your vehicle’s battery is disconnected or goes dead:
• The audio system is disabled.
2 Reactivating the audio system P. 215
•The clock resets.
2 Adjusting the Clock P. 134
•
The immobilizer system needs to be reset.
2 Immobilizer System Indicator P. 87
1Battery
WARNING: Battery post, terminals,
and related accessories contain lead
and lead compounds.
Wash your hands after handling.
3WARNING
The battery gives off explosive hydrogen
gas during normal operation.
A spark or flame can cause the battery to
explode with enough force to kill or
seriously hurt you.
When conducting any battery
maintenance, wear prot ective clothing and
a face shield, or have a skilled technician do
it.
Canadian models only
19 CIVIC 2D HCM (KA KL KC)-31TBG6300.book 592 ページ ２０１８年９月４日　火 曜日　午後１時３８分

597Continued
Maintenance
Cleaning
Interior Care
Use a damp cloth with a mixture of mild detergent and warm water to remove dirt.
Use a clean cloth to remove detergent residue.
Use a soft brush with a mixture of mild soap and warm water to clean the seat belts.
Let the belts air dry. Wipe the loops of the seat belt anchors using a clean cloth.
Wipe using a glass cleaner.
■Cleaning Seat Belts
1 Interior Care
Do not spill liquids inside the vehicle. Electrical
devices and systems may ma lfunction if liquids are
splashed on them.
Do not use silicone based sp rays on electrical devices
such as audio devices and switches. Doing so may
cause the items to malfunction or cause a fire inside
the vehicle.
If a silicone based spray is inadvertently used on
electrical devices, consult a dealer.
Depending on their compos ition, chemicals and
liquid aromatics may cause discoloration, wrinkles,
and cracking to resin-ba sed parts and textiles.
Do not use alkali solvents or organic solvents such as
benzene or gasoline.
After using chemical s, make sure to gently wipe them
away using a dry cloth.
Do not place used cloths on top of resin based parts
or textiles for long periods of time without washing.
Loop
■Cleaning the Window1Cleaning the Window
Wires are mounted to the in side of the rear window.
Wipe along the same direct ion as the wires with a
soft cloth so as not to damage them.
Be careful not to spill flui ds, such as water or glass
cleaner, on or around the co ver of both the front
sensor camera and the rainfall/light sensor
*.
Models with Front Sensor Camera
* Not available on all models
19 CIVIC 2D HCM (KA KL KC)-31TBG6300.book 597 ページ ２０１８年９月４日　火 曜日　午後１時３８分

642
uuFuses uFuse Locations
Handling the Unexpected
*2:Models without SPORT mode
*3:Models with SPORT mode
*5:1.5L engine models
Circuit ProtectedAmps
17Daytime Running Lights10 A
18 Back Up 10 A
19Audio15 A
20 Audio AMP*(30 A)
21Interior Lights10 A
22 Front Fog Lights*(15 A)
23A/C Compressor(10 A)
24 Horn 10 A
25Left Headlight Low Beam10 A
26 Right Headlight Low Beam 10 A
27VB ACT*5(10 A)
28 Left Headlight High Beam 10 A
29Right Headlight High Beam10 A
30 − −
31−(15 A)
32 − (20 A)*2
−*3
33−*2
Adaptive Damper System*3(20 A)
15 A
34 − −
35−−
36 − −
Located under the dashboard.
Fuse locations are shown on the label on
the side panel.
Locate the fuse in question by the fuse
number and label number.
■Circuit protected and fuse rating
■Interior Fuse Box
Fuse Label
Circuit ProtectedAmps
1Accessory10 A
2−*1
Key Lock*2−
(5 A)
3−−
4Front Sensor Camera*1, *3
Transmission*2, *4(5 A)
(10 A)
5Option10 A
6SRS Indicator10 A
7Meter10 A
8Fuel Pump15 A
*1:Models with smart entry system
*2:Models without smart entry system
*3:Models with CMBS
TM
*4:Continuously variable transmission models
9AIRCON10 A
10−−
11Engine Control5A
12Passenger Side Door Lock10 A
13−(10 A)
14−(20 A)
15Passenger’s Side Power
Window20 A
16Door Lock20 A
17Transmission*1, *4
Front Sensor Camera*2, *3(10 A)(5 A)
18−−
19Moonroof*(20 A)
20−−
21ACG10 A
22Daytime Running Lights10 A
23−−
24Front Sensor Camera*(5 A)
25Driver’s Door Lock10 A
26Passenger Side Door Unlock10 A
27−(20 A)
28Driver’s Power Window20 A
Circuit ProtectedAmps
* Not available on all models
19 CIVIC 2D HCM (KA KL KC)-31TBG6300.book 642 ページ ２０１８年９月４日　火 曜日　午後１時３８分

Index
663
Index
Index
Numbers
7-Speed Manual Shift Mode................... 446
Operation ............................................... 447
A
ABS (Anti-lock Brake System) .................. 533
Accelerator Position Meter ..................... 120
Accessories and Modifications ................ 602
Accessory Power Socket ........................... 196
Adaptive Cruise Control (ACC) .......... 91, 497
Adaptive Cruise Control (ACC) with Low Speed Follow (LSF) ........................... 91, 481
Adaptive Damper System ........................ 453
Adding the Coolant ................................. 566
Additives
Coolant .................................................. 565
Engine Oil ............................................... 558
Washer ................................................... 569
Additives, Engine Oil ............................... 558
Adjusting
Armrest .................................................. 189
Clock ...................................................... 134
Front Head Restraints .............................. 184
Front Seats.............................................. 181
Mirrors.................................................... 178
Rear Seats ............................................... 188
Steering Wheel ....................................... 177
Temperature ........................................... 118
Adjusting the Clock ................................. 134
Adjusting the Sound ........................ 224, 259 Agile Handling Assist
............................... 459
Air Conditioning System (Climate Control
System) .................................................... 202
Changing the Mode ................ 202, 203, 204
Defrosting the Windshield and
Windows ............................................... 206
Dust and Pollen Filter ............................... 596
Recirculation/Fresh Air Mode ................... 205
Sensors .................................................... 209
Synchronization Mode ............................. 208
Using Automatic Climate Control ............ 202
Air Pressure ............................... 583, 651, 653
Airbags ........................................................ 46
Advanced Airbags ..................................... 52
After a Collision ......................................... 49
Airbag Care ............................................... 59
Event Data Recorder .................................... 0
Front Airbags (SRS) .................................... 49
Indicator .............................................. 57, 82
Passenger Front Airbag Off Indicator ......... 58
Sensors ...................................................... 46
Side Airbags .............................................. 53
Side Curtain Airbags .................................. 55
AM/FM Radio .................................... 226, 266
Android Auto ............................................ 303
Anti-lock Brake System (ABS) .................. 533
Indicator .................................................... 82
Apple CarPlay ........................................... 300
Armrest ..................................................... 189
Audio Remote Controls ............................ 216 Audio System
............................ 212, 219, 237
Adjusting the Sound........................ 224, 259
Audio/Information Screen................ 220, 238
Changing the Home Screen Icon Layout ................................................... 242
Changing the Screen Interface ................ 256
Closing Apps ........................................... 258
Customizing the Meter............................ 243
Display Setup .................................. 225, 260
Error Messages ........................................ 307
General Information ................................ 310
Home Screen........................................... 249
iPod ................................................ 228, 278
Limitations for Manual Operation .............................. 261, 366, 393
Menu Customize ..................................... 257
MP3/WMA/AAC .............................. 231, 287
Reactivating ............................................ 215
Recommended Devices............................ 311
Remote Controls ..................................... 216
Security Code .......................................... 215
Selecting an Audio Source ....................... 261
Status Area ............................................. 255
Theft Protection ...................................... 215
USB Flash Drives ...................................... 311
USB Port(s) .............................................. 213
Wallpaper Setup.............................. 222, 247
Audio/Information Screen ............... 220, 238
Authorized Manuals ................................ 661
Auto Door Locking/Unlocking ................. 149
Customize ....................................... 130, 360
19 CIVIC 2D HCM (KA KL KC)-31TBG6300.book 663 ページ ２０１８年９月４日　火 曜日　午後１時３８分

664
Index
Auto High-Beam....................................... 170
Indicator .................................................... 82
Automatic Brake Hold .............................. 530
Indicator ............................................ 78, 530
Automatic Brake Hold System
Indicator ............................................ 78, 530
Automatic Lighting .................................. 167
Average Fuel Economy ............................. 117
Average Speed .......................................... 117
B
Battery....................................................... 592
Charging System Indicator ................. 79, 635
Jump Starting .......................................... 629
Maintenance (Checking the Battery) ........ 592
Maintenance (Replacing).......................... 594
Belts (Seat) .................................................. 38
Beverage Holders ...................................... 194
Bluetooth ® Audio ............................. 234, 290
Bluetooth ® HandsFreeLink ®............. 365, 391
Booster Seats (For Children) ....................... 72
Brake System ............................................. 527
Anti-lock Brake System (ABS) ................... 533
Automatic Brake Hold.............................. 530
Brake Assist System ................................. 534
Fluid ........................................................ 568
Foot Brake ............................................... 529
Indicator (Red) ........................... 76, 637, 638
Parking Brake .......................................... 527
Braking Pressure Meter ............................ 120 Brightness Control
(Instrument Panel).... 175
Built-in Key ............................................... 136
Bulb Replacement .................................... 570
Brake Lights, Tail/Rear Si de Marker Lights, Rear
Turn Signal Lights and Back-Up Lights ... 577
Fog Lights ............................................... 572
Front Side Marker Lights.......................... 575
Front Turn Signal Lights ........................... 574
Headlights ............................................... 570
High-Mount Brake Light .......................... 578
Parking/Daytime Running Lights .............. 576
Rear License Plate Light ........................... 578
Side Turn Signal/Emergency Indicator Lights .................................................... 576
Taillight ................................................... 578
Bulb Specifications ........................... 650, 652
C
Carbon Monoxide Gas ............................... 73
Carrying Cargo ................................. 427, 429
Certification Label .................................... 654
Changing Bulbs ........................................ 570
Charging System Indicator ................. 79, 635
Child Safety ................................................. 60
Emergency Trunk Opener ........................ 152
Child Seat .................................................... 60
Booster Seats ............................................ 72
Child Seat for Infants................................. 62
Child Seat for Small Children ..................... 63 Installing a Child Seat wi
th a Lap/Shoulder Seat
Belt ......................................................... 67
Larger Children ......................................... 71
Rear-facing Child Seat............................... 62
Selecting a Child Seat ............................... 64
Using a Tether .......................................... 69
Cleaning the Exterior ............................... 599
Cleaning the Interior ............................... 597
Climate Control System ........................... 202
Changing the Mode................ 202, 203, 204
Defrosting the Windshield and
Windows .............................................. 206
Dust and Pollen Filter .............................. 596
Recirculation/Fresh Air Mode................... 205
Sensors ................................................... 209
Synchronization Mode ............................ 208
Using Automatic Climate Control............ 202
CMBS
TM (Collision Mitigation Braking
SystemTM) ................................................ 471
Coat Hooks ............................................... 200
Collision Mitigation Braking System
TM
(CMBSTM) ................................................. 471
Compact Spare Tire .................. 607, 651, 653
Console Compartment ............................. 193
Continuously Variable Transmission
Creeping................................................. 441
Fluid ....................................................... 567
Kickdown ............................................... 441
Operating the Shift Lever ................ 443, 445
Shift Lever Does Not Move ...................... 632
Shifting ........................................... 442, 444
19 CIVIC 2D HCM (KA KL KC)-31TBG6300.book 664 ページ ２０１８年９月４日　火 曜日　午後１時３８分

666
Index
Floor Mats................................................. 598
Fluids
Brake/Clutch ............................................ 568
Continuously Variable Transmission (CVT) ..................................................... 567
Engine Coolant ........................................ 565
Manual Transmission ............................... 567
Windshield Washer .................................. 569
FM/AM Radio .................................... 226, 266
Fog Light Indicator ..................................... 86
Folding Down the Rear Seats ................... 188
Foot Brake ................................................. 529
Front Airbags (SRS) ..................................... 49
Front Head Restraints ............................... 184
Front Seats ................................................ 181
Adjusting ................................................. 182
Front Sensor Camera ................................ 524
Fuel ...................................................... 24, 539
Economy ................................................. 542
Gauge ..................................................... 111
Instant Fuel Economy ............................... 118
Low Fuel Indicator ..................................... 82
Range ...................................................... 117
Recommendation .................................... 539
Refueling ......................................... 539, 648
Fuel Economy ............................................ 542
Fuel Fill Door ............................... 24, 540, 646
Fuses .......................................................... 641
Inspecting and Changing ......................... 644
Locations ......................................... 641, 642G
Gasoline (Fuel) Economy ................................................. 542
Gauge ..................................................... 111
Information ............................................. 539
Instant Fuel Economy .............................. 118
Low Fuel Indicator ..................................... 82
Refueling......................................... 539, 648
Gauges ...................................................... 111
Gear Shift Lever Positions Manual Transmission ............................... 448
Glass (care) ........................................ 597, 600
Glove Box .................................................. 192
G-Meter ..................................................... 120
H
Halogen Bulbs .................................. 570, 573
Handling the Unexpected ........................ 605
HandsFreeLink ® (HFL) ....................... 365, 391
Automatic Import of Cellular Phonebook and
Call History .................................... 380, 404
Automatic Transferring............................ 377
Displaying Messages................................ 418
HFL Buttons..................................... 365, 391
HFL Menus ...................................... 367, 394
HFL Status Display ........................... 366, 393
In Case of Emergency .............................. 422
Limitations for Manual Operation .... 366, 393
Making a Call .................................. 385, 412
Options During a Call ...................... 390, 415 Phone Setup ................................... 371, 399
Phonebook Phonetic M
odification........... 408
Receiving a Call............................... 389, 415
Receiving a Text/E-mail Message ............. 416
Ring Tone ....................................... 378, 403
Selecting a Mail Account......................... 417
Speed Dial ...................................... 381, 405
To Set Up Text/E-mail Message Options ................................................. 402
Hazard Warning Button .............................. 4
HD Radio
TM............................................... 267
Headlights ................................................ 166
Aiming.................................................... 570
Auto High-Beam ..................................... 170
Automatic Operation .............................. 167
Dimming......................................... 166, 169
Operating ............................................... 166
Heaters (Seat) ........................................... 201
HFL (HandsFreeLink ®) ...................... 365, 391
High Beam Indicator .................................. 86
Hill Start Assist System ..................... 434, 439
HomeLink ® Universal Transceiver ........... 362
Honda App License Agreement .............. 312
Honda Sensing ®................................. 25, 468
HondaLink ®.............................................. 292
I
Identification Numbers
Vehicle Identification............................... 654
Ignition Switch ......................................... 160
19 CIVIC 2D HCM (KA KL KC)-31TBG6300.book 666 ページ ２０１８年９月４日　火 曜日　午後１時３８分
