Weights (kg) 1.3 MultiJet 95 HP1.6 Multijet 120 HP / 1.6 Multijet 120 HP ECO /
1.6 Multijet 115 HP(°°)/ 1.6 Multijet 115 HP
ECO(°°)
Versions: TIPO 5 DOORTIPO STATION
WAGONTIPO 5 DOORTIPO STATION
WAGON
Maximum load on roof(****)55 75 55 75
(°°) Version for specific markets
(****) The value shown includes the weight on the roof bars
231

Weights (kg)1.6 Multijet 120 HP / 1.6 Multijet 120 HP ECO
dual-clutch automatic transmission1.6 Multijet 115 HP(°°)/ 1.6 Multijet 115 HP
ECO(°°)dual-clutch automatic transmission
Versions:TIPO 5 DOOR TIPO STATION
WAGONTIPO 5 DOOR TIPO STATION
WAGON
Unladen weight (with all
fluids, fuel tank filled to
90% and without
optional equipment)1390 / 1320
(°°)1400 / 1350(°°)1390 / 1320(°°)1400 / 1350(°°)
Payload including the
driver(*)500 550 500 550
Maximum permitted
loads
(**)
– front axle 1050 1050 1050 1050
– rear axle 900 950 900 950
– total
1890 / 1820
(°°)1950 / 1900(°°)1890 / 1820(°°)1950 / 1900(°°)
Maximum combined
vehicle load
(vehicle+trailer)
(***)2890 / 2820(°°)2950 / 2900(°°)2890 / 2820(°°)2950 / 2900(°°)
Towable loads
– braked trailer 1300 1300 1300 1300
– trailer without brakes 500 500 500 500
Maximum load on tow
hitch (trailer with brakes)60 60 60 60
(°°) Version for specific markets
(*) If special equipment is fitted, the unladen vehicle weight increases, thus reducing the specified payload.
(**) Loads not to be exceeded. The user should carry goods in the luggage compartment and/on load carrying platform within the maximum permitted loads.
(***) Never exceed the maximum combined vehicle load value: the maximum towable load is only allowed if it does not exceed the maximum combined vehicleload.
232
TECHNICAL DATA

Weights (kg)1.6 Multijet 120 HP / 1.6 Multijet 120 HP ECO
dual-clutch automatic transmission1.6 Multijet 115 HP(°°)/ 1.6 Multijet 115 HP
ECO(°°)dual-clutch automatic transmission
Versions:TIPO 5 DOOR TIPO STATION
WAGONTIPO 5 DOOR TIPO STATION
WAGON
Maximum load on roof(****)55 75 55 75
(°°) Version for specific markets
(****) The value shown includes the weight on the roof bars
233

REFUELLING
1.4 16V 95 HP 1.4 T-jet 120 HP 1.6 E.TorQ(°)Prescribed fuels and
original lubricants
Fuel tank (litres) 50 50 50
Unleaded petrol with RON
no lower than 95
(EN228 specifications)
(*)including a reserve of
(litres)777
Engine cooling system
(litres)4.6 5.2 5.4Mixture of distilled water
and PARAFLU
UPliquid at
50%
(**)
Engine sump (litres) 2.8 2.8 4.4SELENIA K P.E. (1.4 16V
95 HP version, 1.4 T-jet
120 HP versions) /
SELENIA DIGITEK P.E.
(1.6 E.TorQ version
(°))
Engine sump and filter
(litres)2.95 3.4 4.7
Gearbox
casing/differential (litres)1.76 1.8 6.2TUTELA TRANSMISSION
GEARFORCE (1.4 16V
95 HP versions, 1.4 T-jet
120 HP versions) /
TUTELA TRANSMISSION
GI/VI (1.6 E.TorQ
vehicle
(°))
Hydraulic brake circuit
(kg)0.74 0.74 0.74 TUTELA TOP 4/S
Windscreen washer fluid
reservoir (litres)333Mixture of water and
liquid PETRONAS
DURANCE SC 35
(°) where provided
(*)The maximum engine power and the car’s performance can only be guaranteed with lead-free petrol with an R.O.N. of 95 or higher.
(**)When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLU
UPand demineralised water.
234
TECHNICAL DATA

1.4 T-jet 120 HP LPGRecommended fuels and original
lubricants
Fuel tank (litres)
50/42(*)Unleaded petrol not less than 95 RON (EN
228 specification)/LPG
(EN589 specification)
(**)including a reserve of (litres)
7/8(*)
Engine cooling system (litres) 5.2Mixture of distilled water and PARAFLUUP
liquid at 50%(***)
Engine sump (litres) 2.8
SELENIA MULTIPOWER GAS 5W-40
Engine sump and filter (litres) 3.4
Transmission/differential casing (litres) 1.8 TUTELA TRANSMISSION GEARFORCE
Hydraulic brake circuit (kg) 0.74 TUTELA TOP 4/S
Windscreen washer fluid reservoir (litres) 3Mixture of water and liquid PETRONAS
DURANCE SC 35
(*) LPG Tank
(**)The maximum engine power and the car’s performance can only be guaranteed with lead-free petrol with an RON of 95 or higher.
(***)When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60% PARAFLUUP and 40% demineralised water.
235

1.3 MultiJet 95 HP1.6 Multijet 120 HP
/ 1.6 Multijet
115 HP(***)Prescribed fuels and original lubricants
Fuel tank (litres) 50 50
Diesel for motor vehicles (EN590 Specification)
including a reserve of (litres) 7 7
Engine cooling system (litres) 6.1 6.1Mixture of distilled water and PARAFLU
UP
50%(**)
Engine sump (litres) 3.7 4.4SELENIA WR FORWARD 0W-30 (excluding engines
with UREA)
SELENIA WR FORWARD 0W-20 (for 1.6 Multijet
engine with UREA)
SELENIA ECO2 (for 1.3 Multijet engine with UREA) Engine sump and filter (litres) 3.9 4.8
Gearbox casing/differential (litres) 2.0 1.8 TUTELA TRANSMISSION GEARFORCE
Hydraulic brake circuit (kg) 0.74 0.74 TUTELA TOP 4/S
Windscreen washer fluid reservoir
(litres)33Mixture of water and liquid PETRONAS DURANCE
SC 35
UREA tank (for versions/markets,
where provided) approximate
capacity (litres)12.5 12.5
AdBlue®(water-UREA solution) standard DIN
70 070 and ISO 22241-1
91) 92)
(***)Version for specific markets (**) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLU
UPand demineralised water.
236
TECHNICAL DATA

IMPORTANT
91)The distribution companies are responsible for the compliance of their product. Observe the precautions of storage and maintenance, in
order to preserve the initial qualities. The manufacturer will not recognise any guarantee in case of malfunctions and damage caused to the
car due to the use of UREA (
AdBlue®
) not in accordance with regulations.
92)Use
AdBlue®
only according to DIN 70 070 and ISO 22241-1. Other fluids may cause damage to the system: also exhaust emissions
would no longer comply with the law.
237

FLUIDS AND LUBRICANTS
Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of
the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission
specifications. Lubricant quality is crucial for engine operation and duration.
If lubricants conforming to the specific request are not available, products that meet the indicated specifications can be used to
top up; in this case optimal performance of the engine is not guaranteed.
93)
PRODUCT SPECIFICATIONS
Use Features SpecificationOriginal fluids and
lubricantsReplacement interval
Lubricant for petrol
engines (1.4 16V 95 HP,
1.4 T-jet 120 HP
versions)SAE 5W-40
ACEA C3 / API SN9.55535-S2SELENIA K P.E.
Contractual Technical
Reference N° F603.C07According to Scheduled
Servicing Plan
Lubricant for petrol
engines (1.6 E.TorQ
versions
(°))
SAE 0W-30
ACEA C2 / API SN9.55535-GS1SELENIA DIGITEK P.E.
Contractual Technical
Reference N° F020.B12According to Scheduled
Servicing Plan
Lubricant for diesel
engines without UREASAE 0W-30
ACEA C29.55535-DS1 or
MS.90047SELENIA WR
FORWARD
Contractual Technical
Reference N° F842.F13According to Scheduled
Servicing Plan
Lubricant for 1.6 Multijet
diesel engines with
UREASAE 0W-20
ACEA C29.55535-DSXSELENIA WR
FORWARD
Contractual Technical
Reference N° F013.K15According to Scheduled
Servicing Plan
Lubricant for 1.3 Multijet
engines with UREASAE 0W-20
ACEA C59.55535-DM1SELENIA ECO2
Contractual Technical
Reference N° F049.C18According to Scheduled
Servicing Plan
(°) where provided
238
