2019 FIAT 500L LIVING Owner handbook (in English)

PERFORMANCE
Top speeds after the initial period of usage of the car.
500L VERSIONS
Versionskm/h
1.4 16V 95 HP176
1.4 16V 95 HP PRO176
1.3 16V 95 HP Multijet171
1.3 16V 95 HP Multijet PRO171
1.3 16V 95CV MultiJet Dualogic169
1.6 16V 120 HP MultiJet189
1.6 16V 120 HP Multijet PRO189
183

500L CROSS VERSIONS
Versionskm/h
1.4 16V 95 HP162
1.3 16V 95 HP Multijet166
1.3 16V 95CV MultiJet Dualogic163
1.6 16V 120 HP MultiJet183
184
TECHNICAL DATA

500L WAGON VERSIONS
Versionskm/h
1.4 16V 95 HP176
1.3 16V 95 HP Multijet171
1.3 16V 95CV MultiJet Dualogic169
1.6 16V 120 HP MultiJet189
185

WEIGHTS
NOTE Towing trailers is not permitted on versions for Cyprus.
500L / 500L CROSS / 500L PRO VERSIONS
Weights (kg)1.4 16V 95 HP
500L versions Cross versions PRO versions
Unladen weight (with all fluids,
fuel tank 90% full and without
optional equipment):1300 1320 1300
Payload including the driver
(A)505 480 505
Maximum permitted loads
(B)
- front axle:1050
– rear axle:1000
- total: 1805 1800 1805
Towable loads
– braked trailer: 1000
– non-braked trailer: 400
Maximum load on roof: 60
Maximum load on ball joint
(braked trailer):60
(A) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to themaximum
permissible loads.
(B) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
186
TECHNICAL DATA

Weights (kg)1.3 16V 95 HP Multijet
500L versions Cross versions PRO versions
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1400 1420 1400
Payload including the driver
(A)510 505 510
Maximum permitted loads
(B)
- front axle:1050
– rear axle:1000
- total: 1910 1925 1910
Towable loads
– braked trailer:1000
– non-braked trailer:400
Maximum load on roof:60
Maximum load on ball joint (braked trailer): 60
(A) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to themaximum
permissible loads.
(B) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
187

Weights (kg) 1.3 16V 95CV MultiJet Dualogic
500L versions Cross versions PRO versions
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1410 1430 1410
Payload including the driver
(A)505 500 505
Maximum permitted loads
(B)
- front axle:1050
– rear axle:1000
- total: 1915 1930 1915
Towable loads
– braked trailer:1000
– non-braked trailer:400
Maximum load on roof:60
Maximum load on ball joint (braked trailer): 60
(A) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to themaximum
permissible loads.
(B) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
188
TECHNICAL DATA

Weights (kg)1.6 16V 120 HP MultiJet
500L versions Cross versions PRO versions
Unladen weight (with all fluids,
fuel tank 90% full and without
optional equipment):1425 1444 1425
Payload including the driver
(****)545 541 565
Maximum permitted loads
(*****)
- front axle:1050
– rear axle:1000
- total: 1970 1985 1990
Towable loads
– braked trailer: 1000
– non-braked trailer: 400
Maximum load on roof: 60
Maximum load on ball joint
(braked trailer):60
(****) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation tothe maximum
permissible loads.
(*****) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum
permitted loads.
189

Weights (kg)1.4 16V 120 HP
5-seater versions
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1320
Payload including the driver
(*)520
Maximum permitted loads
(**)
- front axle:1050
– rear axle:1000
- total:1840
Towable loads
– braked trailer:1000
– non-braked trailer:400
Maximum load on roof:60
Maximum load on ball joint (braked trailer): 60
(*) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to themaximum
permissible loads.
(**) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted loads.
190
