3.6L Engine —The level of the coolant in the pressurized
coolant bottle should be between the “COLD” and “FULL”
range on the bottle when the engine is cold.
The radiator normally remains completely full, so there is
no need to remove the radiator cap unless checking for
coolant freeze point or replacing engine coolant (anti-
freeze). Advise your service attendant of this. As long as
the engine operating temperature is satisfactory, the cool-
ant bottle need only be checked once a month. When
additional engine coolant (antifreeze) is needed to main-
tain the proper level, it should be added to the coolant
bottle. Do not overfill. See “Adding Coolant” section for
additional information.
Points To Remember
NOTE: When the vehicle is stopped after a few miles/
kilometers of operation, you may observe vapor coming
from the front of the engine compartment. This is normally
a result of moisture from rain, snow, or high humidity
accumulating on the radiator and being vaporized when
the thermostat opens, allowing hot engine coolant (anti-
freeze) to enter the radiator.
If an examination of your engine compartment shows no
evidence of radiator or hose leaks, the vehicle may be
safely driven. The vapor will soon dissipate. •
Do not overfill the coolant expansion bottle.
• Check the coolant freeze point in the radiator and in the
coolant expansion bottle. If engine coolant (antifreeze)
needs to be added, the contents of the coolant expansion
bottle must also be protected against freezing.
• If frequent engine coolant (antifreeze) additions are
required, the cooling system should be pressure tested
for leaks.
• Maintain engine coolant (antifreeze) concentration at a
minimum of 50% OAT coolant (conforming to
MS.90032) and distilled water for proper corrosion pro-
tection of your engine which contains aluminum com-
ponents.
• Make sure that the coolant expansion bottle overflow
hoses are not kinked or obstructed.
• Keep the front of the radiator clean. If your vehicle is
equipped with air conditioning, keep the front of the
condenser clean.
• Do not change the thermostat for Summer or Winter
operation. If replacement is ever necessary, install ONLY
the correct type thermostat. Other designs may result in
unsatisfactory engine coolant (antifreeze) performance,
poor gas mileage, and increased emissions.
8
SERVICING AND MAINTENANCE 335
for diagnosing fluid leaks. Avoid using transmission seal-
ers as they may adversely affect seals.
CAUTION!
Do not use chemical flushes in your transmission as
the chemicals can damage your transmission compo-
nents. Such damage is not covered by the New Vehicle
Limited Warranty.
Fluid Level Check — Four-Speed Automatic
Transmission
Use the following procedure to check the transmission
fluid level properly:
1. Park the vehicle on level ground.
2. Run the engine at normal idle speed for at least 60seconds, and leave the engine running for the rest of this
procedure.
3. Fully apply the parking brake, and press the brake pedal.
4. Place the gear selector momentarily into each gear position (allowing time for the transmission to fully
engage in each position), ending with the transmission
in PARK. 5. Wipe the area around the dipstick clean to prevent dirt
from entering the transmission.
6. Remove the dipstick and determine if the fluid is hot or cold. You can also read the transmission fluid tempera-
ture using the instrument cluster. Refer to Instrument
Cluster Display inGetting To Know Your Instrument
Panel for further information. Hot fluid is approxi-
mately 180°F (82°C), which is the normal operating
temperature after the vehicle is driven at least 15 miles
(24 km). Hot fluid cannot be held comfortably between
the fingertips. Cold fluid is at a temperature of approxi-
mately 80°F (27°C).
7. Wipe the dipstick clean and reinsert it until seated. Then, remove the dipstick and note the fluid level on
both sides. The fluid level reading is only valid if there
is a solid coating of oil on both sides of the dipstick.
Note that the holes in the dipstick will be full of fluid if
the actual level is at or above the hole.
• If the fluid is hot, the fluid level should be in the
crosshatched area marked “HOT” (between the upper
two holes in the dipstick).
• If the fluid is cold, the fluid level should be between
the lower two holes in the area marked “COLD”.
338 SERVICING AND MAINTENANCE
BRAKE SYSTEM
Your vehicle is equipped with dual hydraulic
brake systems. If either of the two hydraulic
systems loses normal capability, the remaining
system will still function. However, there will be
some loss of overall braking effectiveness. This will be
evident by increased pedal travel during application and
greater pedal force required to slow or stop the vehicle. In
addition, if the malfunction is caused by a leak in the
hydraulic system, the “Brake Warning Light” will turn on
as the brake fluid level drops in the master cylinder.
In the event power assist is lost for any reason (i.e.,
repeated brake applications with the engine OFF) the
brakes will still function. However, the effort required to
brake the vehicle will be much greater than that required
with the power system operating.
WARNING!
• Riding the brakes can lead to brake failure and
possibly a collision. Driving with your foot resting or
riding on the brake pedal can result in abnormally
high brake temperatures, excessive lining wear, and
possible brake damage. You would not have your
full braking capacity in an emergency.
• Driving a vehicle with the “Brake Warning Light” on
is dangerous. A significant decrease in braking per-
formance or vehicle stability during braking may
occur. It will take you longer to stop the vehicle or
will make your vehicle harder to control. You could
have a collision. Have the vehicle checked immedi-
ately.
WHEEL AND TIRE TORQUE SPECIFICATIONS
Proper lug nut/bolt torque is very important to ensure that
the wheel is properly mounted to the vehicle. Any time a
wheel has been removed and reinstalled on the vehicle, the
lug nuts/bolts should be torqued using a properly cali-
brated torque wrench using a high quality six sided (hex)
deep wall socket.
9
TECHNICAL SPECIFICATIONS 373
NOTE:
•FCA US LLC or your dealer may contact you directly
regarding software updates.
• To help further improve vehicle security and minimize
the potential risk of a security breach, vehicle owners
should:
• Routinely check www.driveuconnect.com/support/
software-update.html (U.S. Residents) or www.driveu-
connect.ca (Canadian Residents) to learn about avail-
able Uconnect software updates.
• Only connect and use trusted media devices (e.g.
personal mobile phones, USBs, CDs).
Privacy of any wireless and wired communications cannot
be assured. Third parties may unlawfully intercept infor-
mation and private communications without your consent.
For further information, refer to “Onboard Diagnostic
System (OBD II) Cybersecurity” in “Getting To Know Your
Instrument Panel”.
UCONNECT SETTINGS
The Uconnect system uses a combination of buttons on the
touchscreen and buttons on the faceplate located on the
center of the instrument panel that allows you to access
and change the customer programmable features.
Customer Programmable Features — Radio 4.3
Settings
In this mode the Uconnect system allows you to access
programmable features that may be equipped such as Dis-
play, Clock, Safety & Driving Assistance, Lights, Doors &
Locks, Auto-On Comfort & Remote Start, Engine Off Op-
tions, Compass Settings, Audio, Phone/Bluetooth, and Sirius
Setup through buttons on the faceplate and touchscreen.
NOTE: Only one touchscreen area may be selected at a
time.
Radio 4.3 Buttons On The Faceplate and Touchscreen
1 — Uconnect Buttons On The Faceplate
2 — Uconnect Buttons On The Touchscreen
388 MULTIMEDIA
Setting NameSelectable Options
Subscription Info Sirius ID
NOTE:
New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your
radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription
Information screen to re-subscribe.
1. Press the “Subscription Info” button on the touchscreen to access the Subscription Information screen.
2. Write down the Sirius ID numbers for your receiver. To reactivate your service, either call the number listed on the screen or visit the provider online.
Customer Programmable Features — Uconnect 3/3
NAV Settings
Press the “More” button on the touchscreen, then press the
“Settings” button on the touchscreen to display the menu
setting screen. In this mode the Uconnect system allows
you to access programmable features that may be
equipped such as Display, Clock, Safety & Driving Assis-
tance, Lights, Doors & Locks, Auto-On Comfort & Remote
Start, Engine Off Options, Compass Settings, Audio,
Phone/Bluetooth, SiriusXM Setup, and Accessibility.
NOTE: Only one touchscreen area may be selected at a
time. When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired
mode, press and release the preferred setting until a
check-mark appears next to the setting, showing that
setting has been selected.
Once the setting is complete press the Back Arrow button
on the touchscreen to return to the previous menu or press
the “X” button on the touchscreen to close out of the
settings screen. Pressing the Up or Down Arrow buttons on
the touchscreen on the right side of the screen will allow
you to toggle up or down through the available settings.
400 MULTIMEDIA
Automatic Temperature Control (ATC)..........86, 99
Automatic Transmission ..................236, 340
Adding Fluid .................338, 339, 340, 384
Fluid And Filter Change ...................340
Fluid Change .......................... .340
Fluid Level Check .................337, 338, 339
Fluid Type ............................ .384
Special Additives ........................ .337
Autostick ............................... .241
Auxiliary Electrical Outlet (Power Outlet) .........126
Back-Up Lights ........................... .282
Battery .............................. .148, 321
Charging System Light ....................148
Keyless Key Fob Replacement ................20
Location .............................. .321
Belts, Seat ............................... .223
Bluetooth Phone ................435, 436, 453, 455, 467, 473
Body Mechanism Lubrication ..................327
B-Pillar Location .......................... .347
Brake Assist System ........................ .161
Brake Control System, Electronic ................161
Brake Fluid .............................. .384
Brake, Parking ............................ .234Brakes
................................. .373
Brake System ......................... .336, 373
Fluid Check ........................ .336, 384
Master Cylinder ........................ .336
Parking .............................. .234
Warning Light .......................... .146
Brake/Transmission Interlock ..................237
Brightness, Interior Lights .....................68
Bulb Replacement ......................... .278
Bulbs, Light .......................... .226, 278
Camera, Rear ............................ .255
Capacities, Fluid .......................... .381
Caps,
Filler
Oil (Engine) ........................ .318, 323
Power Steering ......................... .245
Radiator (Coolant Pressure) .................334
Carbon Monoxide Warning ................223, 378
Cargo Vehicle Loading ......................110,259
Cargo Area Cover .......................110,111
Cargo Compartment ........................110
Luggage Carrier ........................ .131
Cargo Load Floor ..........................110
Cargo Management System ...................110
12
INDEX 503
Rollaway Tonneau Cover...................111
Tri-Fold Load Floor .......................110
Cargo Tie-Downs ...........................112
Car Washes .............................. .367
Cellular Phone ........................... .479
Certification Label ......................... .259
Chains, Tire ............................. .362
Changing A Flat Tire ....................... .341
Chart, Tire Sizing .......................... .343
Check Engine Light (Malfunction Indicator Light). . . .156
Checking Your Vehicle For Safety ...............222
Checks, Safety ............................ .222
Child Restraint ........................... .201
Child Restraints Booster Seats ........................... .207
Child Seat Installation .....................218
How To Stow An unused ALR Seat Belt ........215
Infant And Child Restraints .................203
Locating The LATCH Anchorages .............211
Lower Anchors And Tethers For Children .......209
Older Children And Child Restraints ...........204
Seating Positions ........................ .208
Using The Top Tether Anchorage .............220
Clean Air Gasoline ........................ .375Cleaning
Wheels ............................... .361
Climate Control ............................73
Automatic ..............................86
Manual ................................73
Rear ............................... .79, 92
Coin Holder ............................. .122
Cold Weather Operation ..................... .231
Compact Disc (CD) Maintenance ................493
Compact Spare Tire ........................ .359
Console Floor ................................ .122
Contract, Service .......................... .498
Cooling Pressure Cap (Radiator Cap) ............334
Cooling System ........................... .331
Adding
Coolant (Antifreeze) .................333
Coolant Level ....................... .331, 334
Cooling Capacity ........................ .381
Disposal Of Used Coolant ..................334
Drain, Flush, And Refill ....................332
Inspection ............................. .334
Points To Remember ..................... .335
Pressure Cap ........................... .334
Selection Of Coolant (Antifreeze) .......332, 381, 382
Corrosion Protection ....................... .366
504 INDEX
Break-In Recommendations.................233
Checking Oil Level ...................... .320
Compartment ....................... .318, 319
Compartment Identification .................319
Coolant (Antifreeze) ...................331, 382
Cooling .............................. .331
Exhaust Gas Caution ...................223, 378
Fails To Start ........................... .232
Flooded, Starting ........................ .232
Fuel Requirements ....................... .375
Jump Starting .......................... .300
Oil ........................... .322, 381, 382
Oil Filler Cap ....................... .318, 323
Oil Filter .............................. .324
Oil Reset ............................. .139
Oil Selection ........................ .322, 381
Oil Synthetic ........................... .324
Overheating ........................... .303
Starting ........................... .229, 230
Engine Oil Viscosity ........................ .323
Engine Oil Viscosity Chart ....................323
Enhanced Accident Response Feature .........198, 309
Ethanol ............................. .376, 378
Exhaust Gas Cautions ....................223, 378
Exhaust System ....................... .223, 329Exterior Lights
...................... .63, 64, 226
Filters Air Cleaner ............................ .324
Air Conditioning ........................ .101
Engine Oil ......................... .324, 382
Engine Oil Disposal ...................... .324
Flashers ................................ .278
Hazard Warning ........................ .278
Turn Signals ..................... .66, 154, 226
Flash-To-Pass ..............................64
Flexible Fuel Vehicles Cr
uising Range ......................... .380
Engine Oil ............................ .380
Fuel Requirements ....................378, 379
Maintenance ........................... .380
Replacement Parts ....................... .380
Starting .............................. .380
Flooded Engine Starting ..................... .232
Floor Console ............................ .122
Fluid, Brake ............................. .384
Fluid Capacities ........................... .381
Fluid Leaks .............................. .226
Fluid Level Checks Automatic Transmission ................338, 339
506 INDEX
