Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12163007) - 2019 - CRC - 11/5/18
58 Seats and Restraints
Remote Start Auto Heated Seats
During a remote start, the heated
seats can be turned on
automatically. When it is cold
outside, the heated seats will turn
on followed by the heated steering
wheel, if equipped. If the vehicle has
auto heated seats, the seat heating
level will automatically change to
the level required by the vehicle's
interior temperature.
The indicator lights on the heated
seat and heated steering wheel
buttons do not turn on during a
remote start.
The heated seats will not turn on
during a remote start unless the
heated seats feature is enabled in
vehicle personalization. SeeVehicle
Personalization 0137.Rear Seats
Rear Seat Reminder
If equipped, the message REAR
SEAT REMINDER LOOK IN REAR
SEAT displays under certain
conditions indicating there may be
an item or passenger in the rear
seat. Check before exiting the
vehicle.
This feature will activate when a
second row door is opened while
the vehicle is on or up to 10 minutes
before the vehicle is turned on.
There will be an alert when the
vehicle is turned off. The alert does
not directly detect objects in the rear
seat; instead, under certain
conditions, it detects when a rear
door is opened and closed,
indicating that there may be
something in the rear seat.
The feature is active only once each
time the vehicle is turned on and off,
and will require reactivation by
opening and closing the second row
doors. There may be an alert even
when there is nothing in the rear
seat; for example, if a child entered the vehicle through the rear door
and left the vehicle without the
vehicle being shut off.
The feature can be turned on or off.
See
Vehicle Personalization 0137.
Folding the Seatback
{Warning
If either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
{Warning
A seat belt that is improperly
routed, not properly attached,
or twisted will not provide the
protection needed in a crash. The
person wearing the belt could be
seriously injured. After raising the
(Continued)

Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12163007) - 2019 - CRC - 11/5/18
Seats and Restraints 59
Warning (Continued)
rear seatback, always check to be
sure that the seat belts are
properly routed and attached, and
are not twisted.
To fold the seatback down:
Caution
Folding a rear seat with the seat
belts still fastened may cause
damage to the seat or the seat
belts. Always unbuckle the seat
belts and return them to their
normal stowed position before
folding a rear seat.1. Pull the seatback release lever to unlock the seatback.
A tab near the lever raises
when the seatback is unlocked.
2. Fold the seatback forward.
Raising the Seatback
Caution
Damage to the seat belt or
seatback locking mechanism can
occur if the seat belt is caught
between the rear seatback and
the seatback locking mechanism. (Continued)
Caution (Continued)
The seat belt must be out of the
way when the rear seat is raised
to the upright, locked position.
If the seat belt is damaged, see
your dealer and have it replaced.
To raise the seatback:
1. The seat belt should not cross the seatback locking
mechanism when raising the
seatback.

Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12163007) - 2019 - CRC - 11/5/18
90 Seats and Restraints
Securing a Child Restraint
Designed for the LATCH
System
{Warning
A child could be seriously injured
or killed in a crash if the child
restraint is not properly attached
to the vehicle using either the
LATCH anchors or the vehicle
seat belt. Follow the instructions
that came with the child restraint
and the instructions in this
manual.
{Warning
To reduce the risk of serious or
fatal injuries during a crash, do
not attach more than one child
restraint to a single anchor.
Attaching more than one child
restraint to a single anchor could
cause the anchor or attachment(Continued)
Warning (Continued)
to come loose or even break
during a crash. A child or others
could be injured.
{Warning
Children can be seriously injured
or strangled if a shoulder belt is
wrapped around their neck. The
shoulder belt can tighten but
cannot be loosened if it is locked.
The shoulder belt locks when it is
pulled all the way out of the
retractor. It unlocks when the
shoulder belt is allowed to go all
the way back into the retractor,
but it cannot do this if it is
wrapped around a child’s neck.
If the shoulder belt is locked and
tightened around a child’s neck,
the only way to loosen the belt is
to cut it.(Continued)
Warning (Continued)
Buckle any unused seat belts
behind the child restraint so
children cannot reach them. Pull
the shoulder belt all the way out
of the retractor to set the lock,
and tighten the belt behind the
child restraint after the child
restraint has been installed.
Caution
Do not let the LATCH
attachments rub against the
vehicle’s seat belts. This may
damage these parts. If necessary,
move buckled seat belts to avoid
rubbing the LATCH attachments.
Do not fold the rear seatback
when the seat is occupied. Do not
fold the empty rear seat with a
seat belt buckled. This could
damage the seat belt or the seat.(Continued)

Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12163007) - 2019 - CRC - 11/5/18
Seats and Restraints 91
Caution (Continued)
Unbuckle and return the seat belt
to its stowed position, before
folding the seat.
If you need to secure more than one
child restraint in the rear seat, see
Where to Put the Restraint 085.
1. Attach and tighten the lower attachments to the lower
anchors. If the child restraint
does not have lower
attachments or the desired
seating position does not have
lower anchors, secure the child
restraint with the top tether and
the seat belts. Refer to the
child restraint manufacturer
instructions and the
instructions in this manual.
1.1. Find the lower anchors for the desired seating
position.
1.2. Put the child restraint on the seat. If the head restraint
interferes with the proper
installation of the child
restraint, adjust the head
restraint upward.
1.3. Attach and tighten the lower attachments on the
child restraint to the lower
anchors.
2. If the child restraint manufacturer recommends that
the top tether be attached,
attach and tighten the top
tether to the top tether anchor,
if equipped. Refer to the child
restraint instructions and the
following steps:
2.1. Find the top tether anchor on the back of the rear
seatback.
2.2. Route, attach, and tighten the top tether according
to your child restraint
instructions and the
following instructions:
If the position you are
using does not have a
headrest or head restraint
and you are using a
single tether, route the
tether over the seatback.
If the position you are
using does not have a
headrest or head restraint

Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12163007) - 2019 - CRC - 11/5/18
168 Driving and Operating
{Warning
Things inside the vehicle can
strike and injure people in a
sudden stop or turn, or in a
crash.
.Put things in the cargo
area of the vehicle. In the
cargo area, put them as
far forward as possible.
Try to spread the weight
evenly.
.Never stack heavier
things, like suitcases,
inside the vehicle so that
some of them are above
the tops of the seats.
(Continued)
Warning (Continued)
. Do not leave an
unsecured child restraint
in the vehicle.
.Secure loose items in the
vehicle.
.Do not leave a seat
folded down unless
needed.
Starting and
Operating
New Vehicle Break-In
The vehicle does not require a
break-in period. Vehicle break-in is
performed during manufacturing.
Power Button
The vehicle has an electronic
pushbutton start. The POWER
O
light flashes when the driver door is
open and the vehicle is not on. The
flashing light will eventually time out.

Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12163007) - 2019 - CRC - 11/5/18
364 Index
Driving for Better EnergyEfficiency . . . . . . . . . . . . . . . . . . . . . . 27
E
Electric Drive Unit . . . . . . . . . . . . . . 181
Electric Drive Unit Shift LockControl Function Check . . . . . . . 257
Electric Mode . . . . . . . . . . . . . . . . . . . 174
Electric Parking Brake . . . . . . . . . . 183
Electric Parking Brake Light . . . . 117
Electrical Equipment, Add-On . . . . . . . . . . . . . . . . . . . . . . . 233
Electrical Requirements for Battery Charging . . . . . . . . . . . . . . 228
Electrical System Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 264
Fuses and Circuit Breakers . . . 264
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 267
Overload . . . . . . . . . . . . . . . . . . . . . 263
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 270
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 350
Energy Efficiency
Driving . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Energy Information . . . . . . . . . . . . . 131 Engine
Air Cleaner/Filter . . . . . . . . . . . . . 245
Check Light (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . .114
Compartment Overview . . . . . . . 240
Coolant Temperature Warning Light . . . . . . . . . . . . . . . 120
Cooling System . . . . . 246, 250, 251
Drive Belt Routing . . . . . . . . . . . . 334
Exhaust . . . . . . . . . . . . . . . . . . . . . . 180
Oil Life System . . . . . . . . . . . . . . . 243
Oil Pressure Light . . . . . . . . . . . . 121
Overheating . . . . . . . . . . . . . . . . . . 252
Running While Parked . . . . . . . . 180
Engine Air Filter Life System . . . . 244
Engine Unavailable Out of Fuel . . . . . . . . . . . . . . . . . . . 177
Entry Lighting . . . . . . . . . . . . . . . . . . . 148
Event Data Recorders . . . . . . . . . . 347
Exit Lighting . . . . . . . . . . . . . . . . . . . . 148
Extended Parking . . . . . . . . . . . . . . . 173
Extended Range Mode . . . . . . . . . 174
Extender, Seat Belt . . . . . . . . . . . . . . 66
Exterior Lamp Controls . . . . . . . . . 142
Exterior Lighting Battery Saver . . . . . . . . . . . . . . . . . . . . . . . . . 148
F
Filter,Engine Air Cleaner . . . . . . . . . . . 245
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 144
Flashers, Hazard Warning . . . . . . 145
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 291
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 317
Fluid Brakes . . . . . . . . . . . . . . . . . . . . . . . . 254
Washer . . . . . . . . . . . . . . . . . . . . . . . 252
Folding Mirrors . . . . . . . . . . . . . . . . . . 49
Forward Automatic Braking . . . . . 208
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 206
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 345
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 54
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 57
Fuel Additives . . . . . . . . . . . . . . . . . . . . . 230
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 232
Filling the Tank . . . . . . . . . . . . . . . 230
Foreign Countries . . . . . . . . . . . . 230
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . 111
Low Fuel Warning Light . . . . . . . 121
Prohibited Fuels . . . . . . . . . . . . . . 229

Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12163007) - 2019 - CRC - 11/5/18
Index 367
Lower Anchors and Tethersfor Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 87
Lumbar Adjustment . . . . . . . . . . . . . . 55 Front Seats . . . . . . . . . . . . . . . . . . . . . 55
M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . . . 331
Maintenance and Care Additional . . . . . . . . . . . . . . . . . . . . . 326
Maintenance Modes . . . . . . . . . . . . 177
Maintenance Schedule . . . . . . . . . 321
Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 329
Malfunction Indicator Lamp . . . . . 114
Messages Propulsion Power . . . . . . . . . . . . . 136
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 135
Vehicle Speed . . . . . . . . . . . . . . . . 136
Mirrors
Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . . . 49
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 48
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 49
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 49
Manual Rearview . . . . . . . . . . . . . . . 49
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Mirrors, Interior Rearview . . . . . . . . 49
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Driver Control . . . . . . . . . . . . . . . . . 188
Electric . . . . . . . . . . . . . . . . . . . . . . . 174
Extended Range . . . . . . . . . . . . . . 174
Hold Light . . . . . . . . . . . . . . . . . . . . .118
Modes
Driver Selected . . . . . . . . . . . . . . . 174
Maintenance . . . . . . . . . . . . . . . . . . 177
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 280
Mountain Mode Light . . . . . . . . . . . 118
N
Navigation Connected Services . . . . . . . . . . 357
New Vehicle Break-In . . . . . . . . . . . 168
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . 110
Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Off-Road
Recovery . . . . . . . . . . . . . . . . . . . . . 160
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 241
Engine Oil Life System . . . . . . . 243
Pressure Light . . . . . . . . . . . . . . . . 121
Older Children, Restraints . . . . . . . 80
Online Owner Center . . . . . . . . . . . 338 OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 348
OnStar Additional
Information . . . . . . . . . . . . . . . . . . . . 351
OnStar Emergency . . . . . . . . . . . . . 350
OnStar Overview . . . . . . . . . . . . . . . 349
OnStar Security . . . . . . . . . . . . . . . . 351
Out of Fuel/Engine Unavailable . . . . . . . . . . . . . . . . . . . 177
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 104
Overheating, Engine . . . . . . . . . . . . 252
P
Park
Shifting Into . . . . . . . . . . . . . . . . . . . 171
Shifting Out of . . . . . . . . . . . . . . . . 172
Park Assist . . . . . . . . . . . . . . . . . . . . . 202
Parking
Brake and P (Park)Mechanism Check . . . . . . . . . . 257
Extended . . . . . . . . . . . . . . . . . . . . . 173
Over Things That Burn . . . . . . . 173
Parking or Backing Assistance Systems . . . . . . . . . . 202
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 113
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 155
