Chevrolet Camaro High Performance Owner Manual Supplement (GMNA-
Localizing-U.S./Canada/Mexico-12461812) - 2019 - crc - 11/7/18
24 Driving and Operating
lower gear keeping engine speed
above approximately 3000 rpm.
If the vehicle is then driven for a
short time at a steady speed, and
without high cornering loads, the
transmission will upshift one gear at
a time, until 10 (Tenth) gear. After
shifting to 10 (Tenth) gear, or coming
to a complete stop, the transmission
will return to normal Sport Mode
shifting.Ride Control Systems
Competitive Driving Mode
Competitive Driving Mode,
Performance Traction Management,
and Launch Control are systems
designed to allow increased
performance while accelerating and/
or cornering. This is accomplished
by regulating and optimizing the
engine, brakes, and suspension
performance. These modes are for
use at a closed course race track
and are not intended for use on
public roads. They will not
compensate for driver inexperience
or lack of familiarity with the race
track. Drivers who prefer to allow
the system to have more control of
the engine, brakes, and suspension
are advised to turn the normal
Traction Control System (TCS) and
StabiliTrak/Electronic Stability
Control (ESC) on.
Caution
Attempting to shift when the drive
wheels are spinning and do not
have traction may cause damage
to the transmission. Damage
caused by misuse of the vehicle
is not covered by the vehicle
warranty. Do not attempt to shift
when the drive wheels do not
have traction.
Competitive Driving Mode allows full
engine power while StabiliTrak/ESC
helps maintain directional control of
the vehicle by selective brake
application. In this mode, TCS is off
and Launch Control is available.
Adjust your driving style to account
for the available engine power. See
“Launch Control” later in this
section.
Do not use cruise control in
performance driving situations.
When StabiliTrak/ESC is in a
performance driving state by
pressing
Ytwice for Competitive

Chevrolet Camaro High Performance Owner Manual Supplement (GMNA-
Localizing-U.S./Canada/Mexico-12461812) - 2019 - crc - 11/7/18
Driving and Operating 25
Driving Mode or Performance
Traction Management Mode, or by
pressing and holding
Yfor
five seconds to turn StabiliTrak/ESC
off, the cruise control buttons on the
left side of the steering wheel will be
inoperative.
To regain cruise control capability,
press
Yonce to return to regular
StabiliTrak/ESC operation.
Performance Traction
Management (PTM) (ZL1 Only)
PTM is not available on
convertibles. Convertibles have
Competitive Driving Mode instead.
See “Competitive Driving Mode”
previously in this section.
PTM integrates the TCS,
StabiliTrak/ESC, and Competitive
Driving Mode systems to provide
improved and consistent
performance when cornering. The
amount of available engine power is
based on the mode selected, track
conditions, driver skill, and radius of
each corner.
These lights are on when the
vehicle is in PTM Mode.
With Track Mode engaged, select
the optional handling mode by
pressing
Ytwo times. A menu with
the PTM modes will appear.
. Wet
. Dry
. Sport 1
. Sport 2
. Race
To experience the performance
benefit of PTM, after entering a
curve and at the point where you
would normally start to increase
acceleration, fully press the
accelerator pedal. The PTM system
will modify the level of engine power
for a smooth and consistent
corner exit.

Chevrolet Camaro High Performance Owner Manual Supplement (GMNA-
Localizing-U.S./Canada/Mexico-12461812) - 2019 - crc - 11/7/18
26 Driving and Operating
To select a mode while in PTM,
press MODE up or down.
PTM Wet
‐Intended for all driver skill levels.
‐ Ideal for wet or damp conditions
only; not intended for heavy rain
or standing water.
‐ StabiliTrak/ESC is on and engine
power is reduced based on
conditions.
PTM Dry
‐ For use by less experienced
drivers or while learning a new
track. ‐
Dry conditions only.
‐ StabiliTrak/ESC is on and engine
power is reduced based on
conditions.
PTM Sport 1
‐ For use by drivers familiar with
the track.
‐ Dry conditions only.
‐ StabiliTrak/ESC is on and more
engine power is available than
lower modes.
PTM Sport 2
‐ For use by drivers familiar with
the track.
‐ Dry conditions only.
‐ StabiliTrak/ESC is off and engine
power available is the same as in
Sport 1.
PTM Race
‐ For use by drivers familiar with
the track.
‐ Dry conditions only. ‐
StabiliTrak/ESC is off and engine
power is available for maximum
cornering speed.
In any PTM Mode, Launch Control
is available. Use PTM Race for the
most consistent performance during
drag strip use. See “Custom Launch
Control” in Track Events and
Competitive Driving in the owner ’s
manual.
Press and release
Yto turn off
PTM and return to TCS and
StabiliTrak/ESC. The traction off
light
iand StabiliTrak/ESC OFF
light
gwill go out.
Launch Control
If equipped, Launch Control is
available within Competitive Driving
Mode and Performance Traction
Management (PTM) to allow high
levels of vehicle acceleration in a
straight line. Launch Control is a
form of traction control that
manages tire spin while launching
the vehicle. This feature is intended
for use during closed course race

Chevrolet Camaro High Performance Owner Manual Supplement (GMNA-
Localizing-U.S./Canada/Mexico-12461812) - 2019 - crc - 11/7/18
Driving and Operating 27
events where consistent zero to
60 and quarter mile times are
desirable.
Launch Control is only available
when the following criteria are met:
.Competitive Driving Mode is
selected or any of the
Performance Traction
Management modes are
selected. The traction off light
comes on in the instrument
cluster and the appropriate
Driver Information Center (DIC)
message displays.
. The vehicle is not moving.
. The steering wheel is pointing
straight.
Manual Transmissions
. The clutch is fully pressed and
the transmission is in
1 (First) gear.
. The accelerator pedal is rapidly
applied and held to wide open
throttle. Launch Control will initially limit
engine speed as you rapidly apply
the accelerator pedal to wide open
throttle. Allow the engine rpm to
stabilize. A smooth, quick release of
the clutch, while maintaining the
fully pressed accelerator pedal, will
manage wheel slip.
Automatic Transmissions
.
The brake pedal is firmly
pressed to the floor, equivalent
to a panic brake event.
. The accelerator pedal is rapidly
applied to wide open throttle.
If the vehicle rolls due to wide
open throttle, release the
throttle, press the brake pedal
more firmly, and re-apply the
accelerator to wide open throttle.
Launch Control will initially limit
engine speed as you rapidly apply
the accelerator pedal to wide open
throttle. Allow the engine rpm to
stabilize. A smooth, quick release of
the brake pedal, while maintaining
the fully pressed accelerator pedal,
will manage wheel slip. After the vehicle is launched, the
system continues in Competitive
Driving Mode or PTM.
Competitive Driving Mode, PTM,
and Launch Control are systems
designed for a closed course race
track and not intended for use on
public roads. The systems are not
intended to compensate for lack of
driver experience or familiarity with
the race track.
Custom Launch Control may be
available through the Settings
menu, if equipped. See
“Custom
Launch Control” in Track Events
and Competitive Driving in the
owner ’s manual.
Limited-Slip Differential
The Electronic Limited-Slip
Differential (eLSD) is a hydraulically
actuated clutch system. It can
infinitely vary the clutch
engagement between 0 and
200Y(147 lb ft) of breakaway
torque between the rear wheels.
It responds to full engagement

Chevrolet Camaro High Performance Owner Manual Supplement (GMNA-
Localizing-U.S./Canada/Mexico-12461812) - 2019 - crc - 11/7/18
Driving and Operating 29
Fuel
Top Tier Fuel
GM recommends the use of TOP
TIER Detergent Gasoline to keep
the engine clean, reduce engine
deposits, and maintain optimal
vehicle performance. Look for the
TOP TIER Logo or see
www.toptiergas.com for a list of TOP
TIER Detergent Gasoline marketers
and applicable countries.
Recommended Fuel
Do not use any fuel labeled E85 or
FlexFuel. Do not use gasoline with
ethanol levels greater than 15% by
volume.
Use premium unleaded gasoline
meeting ASTM specification D4814
with a posted octane rating of 93.
If unavailable, unleaded gasoline
with a posted octane rating of
91 may be used, but with reduced
performance and fuel economy.
If the octane is less than 91, the
engine could be damaged and the
repairs would not be covered by the
vehicle warranty. If heavy knocking
is heard when using gasoline rated
at 93 octane, the engine needs
service.
Prohibited Fuels
Caution
Do not use fuels with any of the
following conditions; doing so
may damage the vehicle and void
its warranty:. For vehicles that are not
FlexFuel, fuel labeled
greater than 15% ethanol by
volume, such as mid-level
ethanol blends (16–50%
ethanol), E85, or FlexFuel.
. Fuel with any amount of
methanol, methylal,
ferrocene, and aniline.
These fuels can corrode
metal fuel system parts or
damage plastic and rubber
parts.
. Fuel containing metals such
as methylcyclopentadienyl
manganese tricarbonyl
(Continued)

Chevrolet Camaro High Performance Owner Manual Supplement (GMNA-
Localizing-U.S./Canada/Mexico-12461812) - 2019 - crc - 11/7/18
Vehicle Care 31
Vehicle Care
Vehicle Checks
Engine CompartmentOverview . . . . . . . . . . . . . . . . . . . . . 32
Engine Oil . . . . . . . . . . . . . . . . . . . . . 33
Engine Air Filter Life System . . . 35
Engine Air Cleaner/Filter . . . . . . . 36
Cooling System . . . . . . . . . . . . . . . . 37
Engine Overheating . . . . . . . . . . . . 38
Wheels and Tires
Low-Profile Tires . . . . . . . . . . . . . . . 38
Summer Tires . . . . . . . . . . . . . . . . . . 38
Tire Pressure for High-Speed Operation . . . . . . . . . . . . . . . . . . . . 39
Towing the Vehicle
Towing the Vehicle . . . . . . . . . . . . . 40
Appearance Care
Exterior Care . . . . . . . . . . . . . . . . . . 41

Chevrolet Camaro High Performance Owner Manual Supplement (GMNA-
Localizing-U.S./Canada/Mexico-12461812) - 2019 - crc - 11/7/18
32 Vehicle Care
Vehicle Checks
Engine Compartment Overview

Chevrolet Camaro High Performance Owner Manual Supplement (GMNA-
Localizing-U.S./Canada/Mexico-12461812) - 2019 - crc - 11/7/18
Vehicle Care 33
1. Windshield Washer FluidReservoir.
2. Engine Coolant Surge Tank and Pressure Cap.
3. Engine Oil Dipstick.
4. Engine Oil Fill Cap.
5. Brake/Clutch Fluid Reservoir.
6. Engine Air Cleaner/Filter.
7. Engine Cooling Fan (Out of View).
8. Engine Compartment Fuse Block.
9. Negative (–) Battery Terminal.
10. Positive (+) Battery Terminal.Engine Oil
To ensure proper engine
performance and long life, careful
attention must be paid to engine oil.
Following these simple, but
important steps will help protect
your investment:
. Use engine oil approved to the
proper specification and of the
proper viscosity grade. See
“Selecting the Right Engine Oil”
in this section.
. Check the engine oil level
regularly and maintain the
proper oil level. See “Checking
Engine Oil” and“When to Add
Engine Oil” in this section.
. Change the engine oil at the
appropriate time. See “Engine
Oil Life System” in the owner’s
manual.
. Always dispose of engine oil
properly. See “What to Do with
Used Oil” in this section.
Checking Engine Oil
Check the engine oil level regularly,
every 650 km (400 mi), especially
prior to a long trip. The engine oil
dipstick handle is a loop. See
Engine Compartment Overview 032
for the location.
{Warning
The engine oil dipstick handle
may be hot; it could burn you.
Use a towel or glove to touch the
dipstick handle.
If a low oil Driver Information Center
(DIC) message displays, check the
oil level.
Follow these guidelines:
. To get an accurate reading, park
the vehicle on level ground.
Check the engine oil level after
the engine has been off for at
least two hours. Checking the
engine oil level on steep grades
or too soon after engine shutoff
can result in incorrect readings.
Accuracy improves when
