2018 VOLKSWAGEN CC lights

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Engine coolant specifications

Only use maintenance-free vehicle batteries meeting standards
TL 825 06 and VW 7 50 73. These standards must date from Au-
gust 2008 or later.
Disconnecting the vehicle battery
If the battery must be disconnected from the vehicle's electrical sys-
tem, note the following:
Switch off all electrical systems and devices and the ignition.
Unlock the vehicle before disconnecting the battery; otherwise the
alarm system will go off.
First disconnect the negative cable (-) and then the positive cable
(+) ⇒ .
Connecting the vehicle battery
Prior to reconnecting the battery, switch off all electrical systems
and devices and the ignition.
Connect the positive cable (+) first and then the negative cable (-)
⇒ .
After the battery is connected and the ignition is switched on, different
indicator lights may come on. They should go out after you drive a
short distance at 10–12 mph (15–20 km/h). If the indicator lights do
not go out, contact an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility and have the vehicle checked.
If the battery was disconnected for a long time, the next scheduled
service may not be correctly calculated and displayed ⇒ page 12,
Instrument cluster. The maximum permissible service and mainte-
nance intervals are shown in the ⇒ Booklet Warranty and Mainte-
nance.
Vehicles with Keyless Access
If the ignition will not start after reconnecting the vehicle battery, lock
the vehicle from the outside and unlock it again ⇒  Unlocking or lock-
ing the vehicle with Keyless Access, ⇒  Unlocking or locking the vehi-
cle with Keyless Access. Then try to start the ignition again. If the
ignition cannot be switched on, contact an authorized Volkswagen
dealer, an authorized Volkswagen Service Facility, or another quali-
fied workshop for assistance.

Automatic electrical load deactivation
If the vehicle battery drain is high, the intelligent onboard electrical
system management automatically takes steps to help prevent bat-
tery drain.
The idle speed is increased so that the alternator provides more
power.
The power to devices that consume a lot of electricity is cut back or
switched off completely.
When the engine is started, the power supply to the 12 Volt sockets
is temporarily interrupted.
The onboard electrical system management cannot always keep the
battery from being drained. For example, the battery will drain if the
engine is not running, but the ignition is switched on or the parking
lights are left on for a long time when parked.
Battery disconnection in an accident with airbag deployment
In vehicles with a battery in the luggage compartment, the electrical
connection to the battery is disconnected automatically in a collision
with airbag deployment. This helps to prevent a short-circuit.
What drains the vehicle battery?
Long periods when the engine is not running, especially when the
ignition is on.
Using electrical systems or devices when the engine is switched
off.
Leaving the vehicle unlocked for several days when not in use.
The selector lever is left for a long period of time in any position
other than P when the ignition is switched off ⇒  Automatic transmis-
sion: Selector lever.
WARNING
Failure to use the proper battery with proper mounting and
connections may cause short circuits, fires, and serious per-
sonal injuries.
Always use only maintenance-free or cycle-free, leak-proof
batteries with the same specifications and dimensions as the
original equipment battery. Specifications are listed on the bat-
tery housing.

Rinse the sponge or glove thoroughly and often.
Clean the wheels and under the door sills last. Use a different sponge
or wash mitt.
WARNING
After the vehicle has been washed, the wet brakes or, in winter,
brake discs or pads coated with ice, react slower and need
longer stopping distances.
Always dry the brakes and clean off any ice coatings with a
few careful applications of the brake. Make sure not to endan-
ger other motorists or cyclists or disobey legal requirements.
CAUTION
Sharp edges under the vehicle can cut exposed skin.
Always protect your hands and arms from cuts on sharp
metal edges when cleaning the underbody, the inside of the
wheel housings, etc.
NOTICE
The water temperature must not be more than +140 °F
(+60 °C).
To help prevent damage to the paint, do not wash the vehicle
in direct sunlight.
Do not use insect sponges, abrasive kitchen sponges or simi-
lar things to clean the vehicle. These can damage the paint fin-
ish.
Never clean headlights with a dry cloth or sponge. Always use
a wet cloth or sponge. For best results use soapy water.
When washing or rinsing the vehicle in cold weather, do not
let water get into the lock cylinders or point the hose at gaps
around the doors, hood, or luggage compartment lid. The water
could freeze on the locks and seals and make it difficult to open
the vehicle!

Even if a wax solution is used regularly at the car wash, Volkswagen
recommends applying a coat of hard wax at least twice a year to pro-
tect the paint.
Polishing
Polish your vehicle if the paint has lost its shine and the gloss cannot
be brought back with wax.
The vehicle must be waxed after polishing if the polish used does not
contain wax compounds to seal the paint.
NOTICE
To help prevent damage, do not use hard wax or polish on
matte-finished parts, plastic parts, headlights or rear lights.
Do not wax or polish your vehicle if it is dirty, or in a sandy or
dusty place.
Caring for and cleaning chrome and aluminum parts

Indicator lights

As long as the indicator lights B or %0# are on, expect engine mal-
functions, increased fuel consumption, and loss of engine efficiency.
Catalytic converter

Description Possible causes,
among others Possible remedy
DSG® Direct Shift
Gearbox too hot.
Stop vehicle as soon as
you can safely do so.
Driver seat and
outside mirrors
move when vehi-
cle is unlocked.
Convenience
settings are stored.
Correct convenience
settings
Memory-seat set-
tings are stored.
– Reassign seat setting
– Clear memory-seat
memory
Front seats can-
not be adjusted
with power con-
trols.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if
necessary
No jack, spare
wheel, or com-
pact spare wheel
in the vehicle.
Equipment differs
depending on the
vehicle.
No direct corrective action
possible; depends on the
vehicle equipment. Con-
tact an authorized
Volkswagen dealer or an
authorized Volkswagen
Service Facility for assis-
tance.
Vehicle has run-flat
tires (mobility tires).
Features do not
work as de-
scribed in this
manual.
Settings were ad-
justed in the
Volkswagen Infor-
mation System.
Check and reset to factory
settings if necessary
Headlights do not
light up the road
as they should.
– Headlights incor-
rectly adjusted.
– Light bulbs burned
out.
– Low beams not
switched on.
– Have the headlight
range adjusted by an au-
thorized Volkswagen
dealer or an authorized
Volkswagen Service Fa-
cility.
– Change light bulbs
– Switch on low beams
