2018 VOLKSWAGEN CC engine

Remote Vehicle Access:
Feature Description
Remote
Status
Check
Current information about the vehicle can be viewed
through a computer or your Volkswagen Car-Net iPh-
one® or Android® app (text and data rates apply). You
can find out if the doors, luggage compartment and
engine hood are open or closed, whether the car lights
are on or off, the level of fuel in the tank, when the
vehicle needs to be serviced next and more.


Diagnostics & Maintenance:
Feature Description
Dealer
Scheduling
Press the • button in the 3-button module: The vehi-
cle will initiate a call to the Volkswagen Car-Net Re-
sponse Center where a Volkswagen Car-Net Custom-
er Specialist will connect you with an authorized
Volkswagen dealer to schedule your service appoint-
ment. The address of the dealer’s location can also be
sent by the Customer Specialist to your factory-
installed navigation system (if equipped).
Vehicle
Health
Report
View a vehicle health report to proactively manage
maintenance and other services and to receive up-to-
date diagnostics in a monthly email report or by im-
mediate request.

d For gasoline engines: Is unleaded fuel with the right octane rating
readily available?
d Are engine oil (⇒ Engine oil) and other operating fluids that meet
Volkswagen quality and performance requirements available where
you will be driving? For more information, please see
⇒ Booklet Warranty and Maintenance.
d Does the factory-installed navigation system work in the countries
where you will be driving, and is navigation data available?
d Are special or heavy-duty tires necessary for the kind of driving
expected?
NOTICE
Volkswagen is not responsible for mechanical damage that may
result from substandard fuel or service or the unavailability of
Genuine Volkswagen parts.
Driving through water on roads

WARNING
After driving through water, mud, sludge, etc., the brakes react
slower and need longer stopping distances.
Always dry the brakes and clean off any ice coatings with a
few careful applications of the brake. Make sure not to endan-
ger other motorists or cyclists or disobey legal requirements.
Avoid abrupt or sudden braking maneuvers immediately after
driving through water.
NOTICE
Vehicle components such as the engine, transmission, sus-
pension or electrical system may be severely damaged by driv-
ing through water.
Never drive through salt water. Salt causes vehicle corrosion.
Thoroughly rinse with fresh water all vehicle parts that were ex-
posed to salt water.

Important vehicle labels

Fig. 18 Vehicle identification label: Shown in the example with engine
identification code CBFA 3.

Fig. 19 Vehicle identification number (VIN).

conforming certificates, stickers, or labels to the same part of the new
components.
Vehicle identification number (VIN)
The vehicle identification number is on a plate on top of the instru-
ment panel on the driver side, and is visible from the outside through
the windshield ⇒ fig. 19 (arrow). The view window is on the side at the
bottom of the windshield. The vehicle identification number is also
stamped into the top of the right drip channel in the engine compart-
ment. The drip channel is between the spring strut tower and the right
fender. Open the engine hood to read the vehicle identification num-
ber

Tire inflation pressure label
A tire inflation pressure label is on the driver door jamb ⇒ Tires and
wheels.
Fuel grade sticker
An information sticker listing the correct fuel grade for your vehicle ⇒ 
Refueling.
Engine data

Length 189 in – 193 in (4802 –
4902 mm)
Width 73 in (1855 mm)
Height (unloaded) 55.7 – 56.1 in (1417 –
1425 mm)
Wheelbase 106.6 in (2708 mm)
Minimum turning circle diameter
(wall to wall)2
37.4 ft (11.4 m)
Track2, front 61.1 – 61.3 in (1552 –
1556 mm)
Track2, rear 61.3 – 61.5 in (1557 –
1562 mm)
Ground clearance (unloaded) 4.9 in (124 mm)

NOTICE
Please be careful when parking your vehicle in areas with
parking barriers or curbs. These vary in height and could dam-
age your bumper and related parts if the front of your vehicle
hits a barrier or curb that is too high while you are getting into or
out of a parking spot.
Always be careful when you enter a driveway or drive up or
down steep ramps or over curbs or other obstacles. Parts of the
vehicle close to the ground may be damaged (such as bumper
covers, spoilers, and parts of the engine, suspension, and ex-
haust systems).

2 Slight differences to these figures are possible, depending on wheel and tire size fitted and the level selected.

WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle. It
can be used to start the engine and operate vehicle systems
such as the power windows, leading to serious personal injury.
Children or other unauthorized persons could also lock the
doors and the luggage compartment.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key. This could leave people
trapped in the vehicle in an emergency. Depending on the time
of year, people trapped in the vehicle can be exposed to very
high or very low temperatures.
A closed vehicle can become very hot or very cold, depend-
ing on the season. Particularly in the summer, heat buildup in
the passenger and luggage compartment of a parked vehicle
can result in temperatures in the vehicle that are much higher
than the outside temperatures. Temperatures can quickly reach
levels that can cause unconsciousness and death, particularly
to small children.
Never remove the key from the ignition switch while the vehi-
cle is moving or rolling to a stop. The steering wheel will lock
and you will not be able to steer or control the vehicle.
Remote control vehicle keys

Fig. 20 Remote control vehicle key with panic button.
