2018 TOYOTA PRIUS steering wheel adjustment

PRIUS_OM_OM47B89U_(U)
1392. Instrument cluster
2
Instrument cluster
The operation contents of the driving support systems and settings
related to the combination meter display can be changed.
Driving support systems such as the PCS (Pre-Collision System) (if
equipped) and Blind Spot Monitor (if equipped) is turned on and off by sim-
ply pressing . Make sure not to cancel the systems accidentally.
■
Setting procedure
Press or of the meter cont rol switches on the steering
wheel and select .
Press or of the meter control switches and select the
item to change, and then press .
If the function is turned on and
off or the sensitivity, etc. is
changed on the setting screen,
the setting is changed each time
the is pressed.
For functions that allow opera-
tion contents, display contents,
etc., of a function to be selected,
the setting screen is displayed.
When the setting screen is displayed, select the setting or
desired value (time, etc.) with the meter control switches.
*1, 2
For selectable operation con-
tents and setting values, select
the desired setting or value, and
then press .
To stop the selection, press .
When the setting check screen
is displayed, select proceed or
cancel and press .
*1: Depending on the items, a subsequent setting screen may be displayed
after selecting an item.
*2: For items which set the adjustment level or time, after the item is set,the setting screen remains displayed until is pressed.
Settings display
1
2
3

1983-4. Adjusting the steering wheel and mirrors
PRIUS_OM_OM47B89U_(U)
Steering wheel
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
To sound the horn, press on or
close to the mark.
■After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
The horn may not sound if the steering wheel is not securely locked.
Adjustment procedure
1
2
Horn

2023-4. Adjusting the steering wheel and mirrors
PRIUS_OM_OM47B89U_(U)
Outside rear view mirrors
To select a mirror to adjust, turn
the switch.Left
Right
To adjust the mirror, operate the
switch. Up
Right
Down
Left
Push the mirror back in the direc-
tion of the vehicle’s rear.
Adjustment procedure
1
1
2
2
1
2
3
4
Folding the mirrors

363
PRIUS_OM_OM47B89U_(U)
4-5. Using the driving support systems
4
Driving
S-APGS (Simple Adva nced Parking Guidance
System)
∗
■Function summary
The Simple Advanced Parking Guidance System automatically
operates the steering wheel to provide support when backing into
an area near a target parking spot, and when departing from a par-
allel parking spot. (Shift lever operations and speed adjustment
when moving forward or backing up are not performed automati-
cally.)
● The Simple Advanced Parking Gu idance System does not park
the vehicle automatically. It is a system that provides support
when pulling out of a perpendicular or parallel parking spot.
● The Simple Advanced Parking Guidance System provides steer-
ing wheel operation assistance to guide the vehicle toward the
selected intended parking spot. The selected intended parking
spot may not always be reach able, depending on road and vehi-
cle conditions at the time of parking, and the distance to the
intended parking spot.
■Linking with the Intelligent Clearance Sonar function
While the Simple Advanced Parking Guidance System is operating,
if the system detects an obstacle that could result in a collision, the
emergency brakes operat e, regardless of whether the Intelligent
Clearance Sonar function is on or off. ( →P. 365)
∗: If equipped
Simple Advanced Parking Guidance System
WARNING
●When backing up or proceeding forward, be sure to directly confirm the
safety of the area to the front or rear, and the area around the vehicle, and
slowly back up or proceed forward while adjusting the vehicle speed by
depressing the brake pedal.
● If it seems the vehicle may make contact with a pedestrian, another vehi-
cle or any other obstacles, stop the vehicle by depressing the brake pedal,
and then press the S-APGS switch ( →P. 366) to turn the system off.

6818-2. Steps to take in an emergency
PRIUS_OM_OM47B89U_(U)
8
When trouble arises
WARNING
■When the electric power steerin g system warning light comes on
When the light comes on yellow, the assist to the power steering is
restricted. When the light comes on red, the assist to the power steering is
lost and handling operations of the steering wheel become extremely
heavy. When steering wheel operations are heavier than usual, grip the
steering wheel firmly and operate it using more force than usual.
■
If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could
cause a loss of vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire
inflation pressure immediately.
●Vehicles with spare tire: If the tire pressure warning light comes on
even after tire inflation pressure adjustment, it is probable that you
have a flat tire. Check the tires. If a tire is flat, change it with the spare
tire and have the flat tire repaired by the nearest Toyota dealer.
●Vehicles with emergency tire puncture repair kit: If the tire pressure
warning light comes on even after ti re inflation pressure adjustment, it
is probable that you have a flat tire . Check the tires. If a tire is flat,
repair the flat tire by using emer gency tire puncture repair kit.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

805Alphabetical index
PRIUS_OM_OM47B89U_(U)
CleaningAluminum wheels.................. 583
Camera sensor ..................... 277
Exterior ................................. 582
Hybrid battery (traction
battery) air intake vent ........ 637
Interior................................... 588
Radar sensor ........................ 276
Seat belts .............................. 589
Water-repellent coating......... 583
Coat hooks ............................... 565
Combination meter .................... 92
Clock adjustment .................... 97
Main display .......................... 107
Multi-information display ....... 114
Warning lights and indicators ............................ 100
Condenser ................................ 610
Console box ............................. 542
Coolant Capacity ................................ 750
Checking ............................... 608
Preparing and checking before winter....................... 418
Cooling system ........................ 608 Hybrid system overheating......................... 735
Consumption screen ....... 153, 158
Cruise control Cruise control........................ 319
Dynamic radar cruise
control with full-speed
range .................................. 304
Cup holders.............................. 543
Curtain shield airbags ............... 36
Customizable features ............ 770 Daytime running light
system.................................... 251
Deck board ............................... 546
Defogger Outside rear view
mirrors ........................ 520, 530
Rear window ................. 520, 530
Windshield .................... 520, 530
Dimension ................................ 744
Dinghy towing.......................... 230
Display BSM (Blind Spot Monitor) ..... 326
Drive information .................. 116
Dynamic radar cruise control with full-speed range .......... 304
Energy monitor ..... 117, 153, 158
Head-up display.................... 146
LDA (Lane Departure Alert with steering control) .......... 298
Multi-information display ....... 114
Parking assist
system ....... ................. 340, 367
Pre-collision warning ............ 281
Trip information..................... 109
Warning messages ............... 684
Do-it-yourself maintenance .... 598
Door courtesy lights ............... 538 Location ................................ 538
Wattage ................................ 754D

814Alphabetical index
PRIUS_OM_OM47B89U_(U)
Side mirrors ............................. 202Adjustment ............................ 202
Blind Spot Monitor ................ 326
Folding .................................. 202
Heaters ......................... 520, 530
Side windows Water-repellent coating......... 583
Simple Advanced Parking
Guidance System .................. 363
Smart key system .................... 182 Antenna location ................... 182
Entry functions ...................... 171
Starting the hybrid system .... 231
Snow tires ................................ 418
“SOS” button ........................... 574
Spare tire Inflation pressure .................. 752
Storage location .................... 692
Spark plug ................................ 750
Specifications .......................... 744
Speedometer ............................ 108
SRS airbags ............................... 36
Steering wheel Adjustment ............................ 198
Audio switches ...................... 428
Meter control switches ............ 93
Telephone switches .............. 488
TRIP switch............................. 93
Stop/tail lights .......................... 660
Storage feature ........................ 541
Storage precautions ................ 541 Stuck
If the vehicle becomes
stuck ................................... 740
Sun visors ................................ 555
Sunshade Moon roof ............................. 209
Switch Audio remote control
switches ............................. 428
Automatic High Beam switch ................................. 253
Cruise control switch .... 304, 319
Door lock switches................ 173
Driving mode select switch ................................. 324
Emergency flashers switch ................................. 664
Engine switch ....................... 231
EV drive mode switch ........... 237
Fog light switch ..................... 258
Garage door opener switches ............................. 567
“HUD” (Head-up display)
switch ................................. 146
Ignition switch ....................... 231
LDA (Lane Departure Alert with steering control)) ......... 297
Light switch ........................... 248
Moon roof switches............... 208
Meter control switches ............ 93
Outside rear view mirror switches ............................. 202
