2018 TOYOTA COROLLA iM Owners Manual (in English)

2095-3. Using the storage features
5
Interior features
COROLLA iM_U (OM12M42U)
Cup holders
FrontRear
●The insert for the front cup holders can
be removed for cleaning.
● The front cup holders can be adjusted to
the appropriate size for a cup or drink
can by changing the insert position.
WARNING
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.

2105-3. Using the storage features
COROLLA iM_U (OM12M42U)
Auxiliary boxes
Ty p e AType B
Push the lid to open. Pull the lid to open.
Type B only: The tray can be removed.
WARNING
● Keep the auxiliary boxes closed. In the event of sudden braking, an acci-
dent may occur due to an occupant being struck by an open auxiliary box
or the items stored inside.
● Type A only: Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.

2115-3. Using the storage features
5
Interior features
COROLLA iM_U (OM12M42U)
Cargo hooks are provided for
securing loose items.
Luggage compartment features
Cargo hooks
WARNING
To avoid injury, always return the cargo hooks to their positions when they
are not in use.
Grocery bag hooks
NOTICE
Do not hang any object heavier than 8.8 lb. (4 kg) on the grocery bag hook.\

2125-3. Using the storage features
COROLLA iM_U (OM12M42U)
Lift the deck mat tab and pull it
toward you to remove it.
Auxiliary boxes

2135-3. Using the storage features
5
Interior features
COROLLA iM_U (OM12M42U)
Unhook the cords.
Remove the cover from the anchors.
The cover can be removed by pulling it in the direction of the arrow
labeled “A”.
If this does not work, pull the co ver in the direction labeled “B”.
Removing the luggage cover
1
2

2145-3. Using the storage features
COROLLA iM_U (OM12M42U)
The luggage cover can be stowed on the back of the rear seats.
Insert one side of the luggage cover into the gap between the back of the
rear seat and deck side trim.
While moving the luggage cover toward the back of the rear seat, insert the
other side of the luggage cover.
Make sure that the luggage cover is securely installed.
When removing the luggage cover, reverse the steps listed.
NOTICE
Do not apply a strong impact to the stored luggage cover. Doing so may
damage the luggage cover.
1
2

215
5
Interior features
COROLLA iM_U (OM12M42U)
5-4. Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
Slide the cover to open.
The clock can be adjusted by pressing the buttons. Adjusts the hours
Adjusts the minutes
Rounds to the nearest hour
*
*: e.g.1:00 to 1:29 → 1:00
1:30 to 1:59 → 2:00
●The clock is displayed when the engine switch is in the “ACC” or “ON” posi-
tion.
● When the battery terminals are disconnected and reconnected, the clock
will automatically be set to 1:00.
Other interior features
Sun visors
1
2
Vanity mirrors
Clock
1
2
3

2165-4. Other interior features
COROLLA iM_U (OM12M42U)
Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power consumption of 120 W).
Pull the lid to open it, then open
the cover.
The power outlet can be used when the engine switch is in the “ACC” or “ON”
position.
Fold down the armrest for use.
Power outlet
NOTICE
● To avoid damaging the power outlet, close the power outlet cover when
the power outlet is not in use. Foreign objects or liquids that enter the
power outlet may cause a short circuit.
● To prevent battery discharge, do not use the power outlet longer than nec-
essary when the engine is off.
Armrest
NOTICE
To prevent damage to the armrest, do not apply too much load on the arm-
rest.
