2018 TOYOTA COROLLA iM display

5.AUDIO SETTINGS
SOUND SETTINGS
1Select from the top screen
of any of the active audio sources
(below example is from USB memory
playback) .
2Use the available buttons to adjust
the Equalizer (Treble, Mid, Bass) ,
Balance (L, R), Fade (Front,
Rear) , Equalizer (EQ ) or
Automatic Sound Levelizer (ASL) .
For more details about effect of
each setting, please see under
SETUP
( → P.103)and the Base
Display Audio owner’s manual.
Change the sound settings of the
Premium Audio System.
1.SOUND SETTINGS
51

5. TIPS FOR OPERATING THE AUDIO SYSTEM


6. TIPS FOR OPERATING THE AUDIO SYSTEM
 MP 3 (MPE G Audio Layer 3), WMA
(W indow s Med ia Audio) and AAC
(A dvance d Aud io Cod ing) are a udio
compression stan dards.
 This syste m can play MP3/WMA/AA C files
on USB memor y.
 When na ming an MP3/WMA/ AAC file, add
an a ppropriate fil e extens ion
(.m p3/.wma /.m 4a).
 Thi s sy stem p lays back file s
with
. mp3 /.wma /.m4a fi le ex tension s as
MP3/WMA/ AAC fi les re spective ly. To
pr event no ise and pla yback errors, use
t he
ap propri ate file ex tension.
 MP 3 file s ar e compat ible wi th the ID3 Tag
Ver. 1.0, Ver. 1.1, Ver. 2.2 and Ver. 2 .3
fo rma ts. This syste m cannot di splay
Al bum title, track title an d artis t n am e in
ot her for mats.
 W MA/AA C
files can co ntain a WMA /AAC
tag t hat is used in the same wa y as an ID3
t ag. WMA /AAC tags carry information
such as track title and artist n ame.
 The e mphas is fun ction is available only
whe n playing MP3 /WM A files record ed at
32, 44.1 and 48 kHz.
 This system can play back AAC files
en coded b y iTunes.
 The sound qu ality of MP3/WM A files
generally i mproves with hi gher bit rates.
In ord er to achieve a reasonab le level o f
sound quality, files create d with a b it ra te
of at l east 128 kbps are rec ommende d. 
MP3 i (MP 3 int eractive) and MP3PRO
form ats a re not compatible with the audio
p la yer.
 Th e pla yer
is compatible w ith VBR
(V ariable Bit Rate).
 When p laying b ack files recorded as VBR
(V ariab le B it Ra te) files, the play t ime will
not be correctly displayed if the fast
fo rwar d or re verse operation s ar e us ed.
 It is not possible to check fo lders that do
not i nclude MP3/WMA /AAC files.
 MP3 /WMA /AA C file s in fo lders up to 8
levels deep ca n be pl ayed. Howe ver, the
st ar t of playback may be delaye d when
t her e are n umerou s levels of fo lders. Fo r
this reason , we re commen d using no
more t han 2 leve ls o f fol ders.
 Th e order c hanges depend ing on the
perso nal compute r an d MP3/WMA /AAC
e ncoding software you use.
55

3

Bluetooth® HANDS-FREE SYSTEM

1
BASIC INFORMATION
BEFORE OPERATION

1. QUICK REFERENCE ...... .... ........ 58
2. HANDS -FREE SYSTEM... ........... 60
USING THE PHONE SWITCH OR
MICROPHONE..................................... 61
ABOUT THE PHONE BOOK IN THIS
SYS TEM............................................... 62
WHEN YOU SELL YOUR CAR............ 62
CONNECT A Bluetooth® PHON E....... 63
3. REGISTERING AN ENTRY ...... .... 64
REGISTERING A NEW ENTRY............ 64
DISPLAYING AND EDITING THE
ENTRY INFORMATION...................... 66
SENDING STORED CONTACTS TO A
USB MEMORY ................................... 67

2 PHO NE OP ERATION
1 . CALLING ON A Blu etooth ®
PHONE……………….. .......... . 68
BY DIAL ............................................. 68
BY FAVORITES LIST........................... 69
BY PH ONE BOOK ............................... 69
BY CALL LISTS ................................... 70
BY A SHORT MESSAGE….................. 71
BY POI* ENTRY. ................................... 71
2. RECEIVIN G CALLS ON A
Bluet ooth® PHONE
.... ..... ..... 72
3. TALKING ON A Blueto oth
®
PHONE .. .................................... 73
SEN DING TONES ............................... 74
DIALING A SECOND NUMBER ......... 75
AD JUSTING THE RECEIVER
VOLUME............................................. 76
3 SHORT MESSAGE FUNCTION

1. SHORT MESSAGE FUNCTION . 77
RECEIVING A SHORT MESSAGE ... 77
CHECKING RECEIVED SHORT
MESSA GES........................................ 77
CHECKING SENT SHORT
MESSA GES........................................ 78
SENDING A NEW SHORT
MESSAGE........................................... 79
4
WH AT TO DO IF...

1. TROUBLESHOOT ING. ..... ... ..... ... 82



Some of the functions cannot be operated
while driving.
*: Point of Interest



57

1. BASIC INFORMATION BEFORE OPERATION
1. QUICK REFERENCE



“Phone” MENU SCREEN






















No. Function Page
Select to display the “ Phone book” screen. An entry from the list of contacts can be selected and called. 69
Select to display the “ Dial” screen. A call can be made by dialing the number. 68
Select to display the “ Favorites ” screen listing the contacts stored within the Premium Audio System. 69
Select to display the “ Messages” screen. A list of received and sent short messages and a menu to create new short messages can be displayed. The sender of the message can also be called.
77
Select to display the “ Call lists” screen. An entry from the “ All” “Missed ”, “Received ” or “Dialed ” call lists can be selected and called. 70

Pressing the button allows access to the “Phone” screens.
Each time the button is pressed, the “ Phone” screen that was last
displayed will be shown.
Press from the “ Phone” screen other than the “Phone ” menu screen
to display the “Phone” menu screen.
1
2
3
4
5
58

1. BASIC INFORMATION BEFORE OPER ATION
3. REGISTERING AN ENTRY

REGISTERING A NEW ENTRY





6 C heck that the en try is reg istered in the
“Favorites ” list.

REGISTERI NG FROM THE
“Favor ites” SCREEN

1 Display the “Phon e” menu screen and
select “Favorites” . (→P.58)
2 Select “Create n ew e ntry” .

3 Select one of 4 ph one types ( ,
, or ) and en ter
a numb er.


 You can enter one phone number for
ea ch phone type.

4 Select .
5 Enter the entry name a nd then select
“OK” .






 Se lect t o dis pla y an d edi t the
entry inf ormation. (→P.6 9)

REGISTERING FAVOR ITES
FROM THE “ Dial” SC REEN

1 Display the “Pho ne” me nu scree n.
(→P. 58)
2 Select “Dial number ”.
3 Enter the num bers.
4 Select .
5 Follow the step s “REGIS TERING
FROM THE “ Favorites”
SCREEN ” from “STEP 5”. (→ P.64)
INFORMATION

The phone t ype is re gis tere d as .
Up to 200 numbers can be
register ed in the “Favorites” list of
the Premium Audio System.
64

1. BASIC INFORMATION BEFORE OPERATION

REGISTERING FAVORITES
FROM THE “Ph one bo ok”
SC REEN

1 Disp lay the “Phon e” menu screen an d
select “Phone b ook ”.
(→P.58)
2 Select for desired item.
3 Select “Add to favorites” .
4 Follow the step s “REGISTERING
FROM THE “ Favorites”
SCREEN ” from “STEP 5”. (→ P.64)
REGISTERING FAVORITES
FROM AN EXTERNAL DEVIC E∗


“vCard” formatted data can be
transferred from a USB memory to the
Premium Audio system. Transfe rred
addresses and numbers will be stored
in the “ Favorites” list and in the
“ Favorite destination ” list.(→P.69 ,
1 47)

INFORMA TION
• Th e phone t ype is re gis tere d as .
• If the contact includes an ad dress and
a phone number , they will be s tored in
the “ Favorites ” list and in the
“ Fav orite d est inati on” list. ( →P.69,
1 47)


RE GISTERING FROM THE
“Call lists” SCREEN

1 Display the “Phon e” menu screen an d
select
to display the “C all lists”
screen . (→P. 58)

2 Select ne xt to the de sired item.
3 Follow the step s “REGISTERING
FROM THE “ Favorites”
SCREEN ” from “STEP 5”. (→ P.64)

INFORMATION

The phone t ype is re gis tere d as .
65

1. BASIC INFORMATION BE FORE OPERATION


DISPLAYING
AND EDITING
THE ENTRY INFORMATION  Entry op tions screen of the
“Fa vorites ” list
Detailed information of entries in the
list can be displayed or edited.

1 Disp lay the “Phone ” menu scree n and
either s elect “Phone bo ok” or select
“Fav orites”. (→P.58)

2 Select next to the de sired e ntry.





 Entry o ptions scre en of the “ Phone
book ” list

No. Function
Select to display the phone numbers stored for the entry.
• Select the desired entry to call it.
Select to change the entry name. (→ P.67)
Select to edit phone numbers. (→ P.67)
Select to delete the entry.
Select to delete all entries.
Select to register the entry in the “Favor ites” list and the “Favorite
destination ” list. (→ P.69, 147)
1
2
3
4
5
6
66

How to make a call listPage
Bydial68
By“Favorites ”list69
By phone book69
Bycall lists70
By using a short messa ge71
ByPOI call71
2.PHONEOPERATION
After a Bluetooth®phone has been
co nnected; acall can be made using
the hands -fr ee system.BY DIAL
1Displ aythe “Phon e” menuscreen and
select “Dialnum ber” . (→P. 58)
2Ente r a ph one numb er.
3
3Select.
4Check that the conn ectingscreenis
displayed.
 To ca ncel a cal l,sel ect “End call”.
INFORM ATION
 Depending on the type of Bl uetooth®
phone beingconnect ed , it may be
necessary to perfor m add itional steps
on t heteleph one.
 When “Dial n umber ” is select ed,
t he l ast dia led num berwillbe sh own
gra yed out. Select to redia l the
nu mbe r.
 Se lect “0/+” to enter “0”. Select and
hold to en ter“+ ” for i nter nat ional calls.
 When the missed cal lsicon or new
short messag e icon isdisp lay ed at the
bottom, selecting t he i con w illdis pla y
t he l ist.
1.CALLING ON A Bluetooth® PHONE
68
