2018 SUBARU WRX ECO mode

(172,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Inside warning
chimeOutside warning
chimeOperation indicator
on push-button igni-
tion switchStatus Action
Ding, ding ...
(intermittent)——The driver’s door was opened while the
push-button ignition switch is“ACC”(in
CVT models, when the select lever is in
the“P”position.)Switch the push-button ignition switch to
“OFF”, or close the driver’s door.
*When exiting the vehicle, be sure to
switch the push-button ignition switch to
“OFF”.
The push-button ignition switch was
switched to“OFF”while the driver’s door
is open.Close the driver’s door.
DingShort beep
(2 seconds)—Lockout warning:
All doors were closed after the locking of
all doors was set by using the door lock
lever or power door locking switch while
the access key fob is inside the vehicle.Take out the access key fob from the
vehicle, and lock the doors.
*The doors cannot be locked while the
access key fob is inside the vehicle.
*A chirp sound will be heard, and all
doors will be unlocked.
—Short beep
(2 seconds)—Trunk lockout warning:
The trunk was closed with the access key
fob in it while all doors are locked (or
during the automatic lock time period).Take out the access key fob from the
trunk, and close the trunk.
*By pressing the trunk opener button
after this warning chime sounds, the
trunk can be unlocked.
Access key lock-in warning:
The door lock sensor was touched while
the push-button ignition switch is“OFF”
and the access key fob is inside the
vehicle.Take out the access key fob from the
vehicle, and lock the doors.
*If the access key fob is inside the
vehicle, the doors cannot be locked.
—Beep, beep ...
(5 beeps)—Door ajar warning:
The door lock sensor is touched while the
push-button ignition switch is in the
“OFF”position and another door or the
trunk is opened.Close the doors securely and lock them.
*If one of the doors is opened, the doors
cannot be locked.
Instruments and controls/Warning and indicator lights
3-30

(173,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Inside warning
chimeOutside warning
chimeOperation indicator
on push-button igni-
tion switchStatus Action
DingLong beep
(60 seconds max.)—Power warning:
The door lock sensor was touched while
carrying the access key fob and the
push-button ignition switch is in a posi-
tion other than“OFF”and the select lever
is in the“P”position.Open the door and return the access key
fob inside the vehicle, or switch the push-
button ignition switch to“OFF”.
*If the push-button ignition switch is not
switched to“OFF”, the doors cannot be
locked.
Ding, ding ...
(7 seconds)——Access key warning:
The vehicle was driven while the access
key fob is not inside the vehicle.Carry the access key fob, and drive the
vehicle.
Ding——Access key warning for engine start:
The push-button ignition switch was
pressed while the access key fob is not
inside the vehicle.Carry the access key fob, and press the
push-button ignition switch.
DingBeep, beep, beep
(3 beeps)—Access key takeout warning:
The driver exited the vehicle with the
access key fob and closed the driver’s
door while the push-button ignition
switch is in a position other than“OFF”
and the select lever is in the“P”position.Switch the push-button ignition switch to
“OFF”, and get out of the vehicle.
DingBeep, beep, beep
(3 beeps)—Passenger access key takeout warn-
ing:
A fellow passenger exited the vehicle
with the access key fob and closed a
door other than the driver’s door while
the push-button ignition switch is in a
position other than“OFF”.Return the access key fob to inside the
vehicle, or switch the push-button ignition
switch to“
OFF”.
Long beep
(continuous)Long beep
(continuous)—Access key takeout without“P”posi-
tion warning:
The driver exited the vehicle with the
access key fob and closed the driver’s
door while the push-button ignition
switch is in a position other than“OFF”
and the select lever is in a position other
than the“P”position.Shift the select lever to the“P”position,
switch the push-button ignition switch to
“OFF”and exit the vehicle.
–CONTINUED–
Instruments and controls/Warning and indicator lights
3-31
3

(174,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Inside warning
chimeOutside warning
chimeOperation indicator
on push-button igni-
tion switchStatus Action
Long beep
(continuous)——Select lever position warning:
.Case 1: The driver’s door was
opened while the push-button igni-
tion switch is in a position other than
“OFF”and the select lever is in a
position other than the“P”position.
.Case 2: The engine is turned off by
pressing the push-button ignition
switch and the select lever is in a
position other than the“P”position..Case 1: Shift the select lever to
the“P”position, switch the push-
button ignition switch to“OFF”and
exit the vehicle.
.Case 2: Start the engine, shift
the select lever to the“P”position,
switch the push-button ignition
switch to“OFF”and exit the vehicle.
Ding——The battery of the access key fob is low.Replace the battery of the access key
fob.
Ding—Flashes in green
(15 seconds max.)Steering lock warning:
The engine start procedure was per-
formed, but the steering is still locked.While turning the steering wheel right and
left lightly, depress the brake pedal and
press the push-button ignition switch.
Ding—Flashes in orangeSystem malfunction warning:
A malfunction was detected in the power
system or steering lock.Contact a SUBARU dealer immediately
and have the vehicle inspected.
NOTEAn electronic chirp will sound while the select lever is in the“R”position. In this case, the select lever position warning chime
will not sound.
Instruments and controls/Warning and indicator lights
3-32

(175,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&Security indicator lightThis indicator light shows the status of the
alarm system. It also indicates operation of
the immobilizer system.
!Alarm system
It blinks to show the driver the operational
status of the alarm system. For detailed
information, refer to“Alarm system”F2-
24.
!Immobilizer system
The security indicator light starts blinking
in the following conditions.
For models with“keyless access with
push-button start system”:
.Immediately after turning the push-
button ignition switch to the“OFF”position.
.Immediately after opening or closing
the driver’s door when all of the following
conditions are met.
–The push-button ignition switch is in
the“ON”or“ACC”position.
–The access key fob is outside the
vehicle.
–The engine is not running.
–In the event that an unauthorized
key is used (for example, the key is
unregistered or the ID code does not
match), the power is not switched to
“ON”and the security indicator lightcontinues blinking.
For models without“keyless access
with push-button start system”:
.Approximately 60 seconds after turning
the ignition switch from the“ON”position to
the“ACC”or“LOCK”position.
.Immediately after pulling out the key.
If the indicator light does not blink in the
above conditions, it may indicate that
immobilizer system may be malfunction-
ing. Contact your nearest SUBARU dealer
immediately.
In the event that an unauthorized key (for
example, an unauthorized duplicate) is
used, the security indicator light illumi-
nates. For details about the immobilizer
system, refer to“Immobilizer”F2-22.
NOTE.The security indicator light remains
off in the following conditions. It means
that the matching of the ID code is
completed and the immobilizer system
is deactivated, and it does not indicate
a malfunction.
Models with“keyless access with
push-button start system”:
–while the engine is running
–the push-button ignition switchhas been turned to the“ON”or
“ACC”position and the driver’s
door has not been opened or closed
Models without“keyless access
with push-button start system”:
–while the engine is running
–for approximately 60 seconds
after the ignition switch is turned
from the“ON”position to the“ACC”
or“LOCK”position
–when the ignition switch is in the
“ON”position.
.Even if a malfunction occurs, such
as the security indicator light flashes
irregularly, it will not affect the func-
tionality of the immobilizer system.
–CONTINUED–
Instruments and controls/Warning and indicator lights
3-33
3

(177,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
using the manual mode with the Sport
Sharp (S#) mode selected, the upshift/
downshift indicators will be on.&Turn signal indicator
lightsThese lights show the operation of the turn
signal or lane change signal.
If the indicator lights do not blink or blink
rapidly, the turn signal bulb may be burned
out. Replace the bulb as soon as possible.
Refer to“Replacing bulbs”F11-44.&High beam indicator
lightThis light shows that the headlights are in
the high beam mode.
This indicator light also illuminates when
the headlight flasher is operated.&High Beam Assist indi-
cator light (green) (if
equipped)This light illuminates when the High Beam
Assist function is activated. For details
about the High Beam Assist function, refer
to“High beam assist function (models with
the EyeSight system)”F3-65.
&High Beam Assist
warning indicator
(yellow) (if equipped)This warning indicator appears when the
High Beam Assist function malfunctions.
When this warning indicator appears, have
your vehicle inspected by your SUBARU
dealer.&Cruise control indicatorThis indicator appears when the cruise
control main button is pressed to activate
the cruise control function. For details,
refer to“To set cruise control”F7-54.
If this light blinks, do not use the cruise
control. In addition, if it blinks frequently,
contact your SUBARU dealer for an
inspection.
CAUTION
If the CHECK ENGINE warning light/
malfunction indicator light illumi-
nates, the cruise control indicator
flashes at the same time. At this
time, avoid driving at high speed and
have your vehicle inspected at a
SUBARU dealer as soon as possi-
ble.
&Cruise control set indi-
catorThis indicator appears when vehicle speed
has been set to use the cruise control
function. Refer to“To set cruise control”
F7-54.&Automatic headlight
beam leveler warning
light (models with LED
headlights)This light illuminates when the automatic
headlight beam leveler does not operate
normally.
If this light illuminates while driving or does
not turn off approximately 3 seconds after
turning the ignition switch to the“ON”
position, have your vehicle inspected at
your SUBARU dealer.&Front fog light indicator
light (if equipped)This indicator light illuminates while the
front fog lights are illuminated.&Headlight indicator
lightThis indicator light illuminates under the
following conditions.
–CONTINUED–
Instruments and controls/Warning and indicator lights
3-35
3

(179,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Warning indicatorAll the indicators will flash when the
driver’s control center differential has a
malfunction. Have the vehicle inspected
by your SUBARU dealer. For details, refer
to“Driver’s Control Center Differential (C.
DIFF/DCCD) (STI)”F7-18.
If a malfunction occurs in the vehicle (for
example, when the rear differential oil
becomes hot), all of the indicators may
disappear. In this case, the setting value
for the initial limited slip differential (LSD)
torque of the driver’s control center differ-
ential (C.DIFF/DCCD) will be cancelled.
However, it does not indicate a malfunction
of the C.DIFF/DCCD itself.
&REV indicator light (STI)This indicator light illuminates when the
engine speed reaches the level that was
previously set. This indicator light also
flashes when the tachometer needle en-
ters the red zone. For details, refer to“REV
indicator light and buzzer (STI)”F3-12.&Steering Responsive
Headlight warning indi-
cator/Steering Respon-
sive Headlight OFF indi-
cator (if equipped)This indicator appears when the Steering
Responsive Headlight is deactivated.
Also, the indicator flashes when a mal-
function occurs in the Steering Respon-
sive Headlight. Refer to“Steering Respon-
sive Headlight (SRH)”F3-69.&BSD/RCTA warning in-
dicator (if equipped)This warning indicator appears when the
BSD/RCTA is malfunctioning. In this case
the BSD/RCTA warning indicator will be
shown on the combination meter display
(color LCD). When this indicator appears,
have your vehicle inspected by your
SUBARU dealer as soon as possible.
&BSD/RCTA OFF indica-
tor (if equipped)The indicator appears when the BSD/
RCTA is deactivated. In this case the
BSD/RCTA OFF indicator will be shown
on the combination meter display (color
LCD). For details, refer to“BSD/RCTA”
F7-57.&RAB warning
indicator (if equipped)This indicator illuminates if the Reverse
Automatic Braking System malfunctions.
Refer to“Reverse Automatic Braking
System”F7-66.&RAB OFF indicator light
(if equipped)This indicator illuminates when the Re-
verse Automatic Braking System is turned
OFF, or when the Reverse Automatic
Braking System is suspended temporarily.
Refer to“Reverse Automatic Braking
System”F7-66.
Instruments and controls/Warning and indicator lights
3-37
3

(180,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Combination meter display
(color LCD)
WARNING
Always pay adequate attention to
safe driving when operating the
combination meter display (color
LCD) while the vehicle is in motion.
When operation of the combination
meter display (color LCD) interferes
with your ability to concentrate on
driving, stop the vehicle before
performing operations on the
screen. Also, do not concentrate on
the display while driving. Doing so
may cause you to look away from the
road and could result in an accident.
Various information will be shown on the
combination meter display (color LCD).
Also, a warning message will appear on
the display if a malfunction, etc. is
detected. In addition, several settings for
the displayed content can be performed.
Combination meter display (color LCD)
1) ECO gauge (refer to“ECO gauge”F3-
12.)
2) Warning screen (refer to“Warning
screen”F3-39.)/Basic screen (refer to
“Basic screens”F3-40.)
3) Cruise control information display/
C.DIFF/DCCD indicator4) Warning indication (refer to“Warning
indication”F3-41.)
5) Select lever/gear position indicator (refer
to“Select lever/gear position indicator
(CVT models)”F3-34.)
6) SI-DRIVE indicator light (refer to“SI-
DRIVE indicator”F3-34.)
7) Odometer (refer to“Odometer”F3-9.)/
double trip meter (refer to“Double trip
meter”F3-9.)
Control switch
1) Up (select)
2)
/SET (enter)
3) Down (select)
Instruments and controls/Combination meter display (color LCD)
3-38

(181,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&Basic operationPull“
”or“
”of the control switch
toward you to switch the screens and
selection items. Pull the“
/SET”switch
toward you to select and set the item.
If there are some useful messages, such
as vehicle information, warning informa-
tion, etc., they will interrupt the current
screen, and appear on the display accom-
panied by a beep. If such a screen is
displayed, take proper action according to
the message shown on the screen.
The warning screen will return to the
original screen after a few seconds. While
the“
”information reminder is shown on
the display, it may be possible to display
the warning screen again. To recall the
message marked with“
”on the display,
pull the“
/SET”switch toward you.
&Welcome screen (opening
animation) and Good-bye
screen (ending animation)When the driver’s door is opened and
closed after unlocking the door, the Wel-
come screen (opening animation) will
appear on the combination meter display
(color LCD) for approximately 20 seconds.
When the ignition switch is turned to the
“LOCK”/“OFF”position, the combination
meter display (color LCD) gradually turns
off while showing the Good-bye screen
(ending animation).NOTE.The welcome screen and the good-
bye screen may differ in the actual
words and appearance.
.Once the Welcome screen appears,
it takes a certain period of time to
display it again.
.The Welcome screen will disappear
after turning the ignition switch to the
“ON”position while the Welcome
screen is displayed.
.If you open any of the doors while
the Welcome screen is displayed, the
door ajar warning will appear.
.You can set the Welcome screen and
Good-byescreentoonoroff.For
details, refer to“Welcome Good-bye
Screen”F3-43.
&Warning screenExample of warningIf a warning or a malfunction is detected, a
message will appear. Take the appropriate
actions based on the messages indicated.
–CONTINUED–
Instruments and controls/Combination meter display (color LCD)
3-39
3
