2018 SKODA RAPID SPACEBACK Owners Manual

Fuse assignment in the dashboardFig. 266
Fuses:  - LHD /
 - RHD

No.Power consumer35Not assigned36USB charge function37Radar38Not assigned39Electrical auxiliary heating system40Not assigned41Rear window heater42Power windows - front passenger43Towing hitch44Cigarette lighter, 12-volt socket in the interior, 12-volt socket in theluggage compartment45Power windows - rear right46Front and rear window washer, operating lever under the steering
wheel47Towing hitch48Towing hitch49Fuel pump50Infotainment51Heating of the external mirror52KESSY53Steering lock (KESSY)54ABS or ESC55Not assigned56Not assigned57Not assigned58Heating of the rear seats59Not assignedFuses in the engine compartmentFig. 267
Cover for the fuse box - variant 1
Fig. 268
Cover for the fuse box - variant 2

CAUTIONThe cover of the fuse box in the engine compartment must always be used
correctly, otherwise water may penetrate into the fuse box

WARNING (Continued)
vBulbs H7 H8 and H15 are pressurised and may burst when changing the
bulb - risk of injury! We therefore recommended wearing gloves and safety
glasses when changing a bulb.
v
Do not carry out any work on the Xenon gas discharge lamps - risk of
death!
CAUTION

v Do not take hold of the glass bulb with naked fingers (even the smallest
amount of dirt reduces the working life of the light bulb). Use a clean cloth,
napkin, or similar.
v
The cap of the filament bulb must always be seated correctly in the head-
light, otherwise this may allow water and debris to enter the headlight - risk of
damage to the headlights.
Note
We recommend that a box of replacement bulbs always be carried in the vehi- cle.
Bulb arrangement in the halogen headlights
Fig. 270
Left headlight: Halogen headlight / halogen headlight with LED
daytime running lights

Remove / insert the bulb for parking light

Removing/installing taillightsFig. 277
Remove light / pull out connector
