Page 57 of 86
Navigation*Traffic reports and dynamic route
guidance (TRAFFIC)Fig. 45
Traffic reports
The Infotainment system constantly receives
traffic reports (TMC/TMCpro) in the back-
ground, provided a TMC traffic news station can be received at the current location. The
station being listened to does not have to be the traffic news station.
TMC traffic reports are displayed on the map with symbols
Page 58 of 86
Navigation*Predictive navigationFig. 46
Predictive navigation
When you activate Predictive navigation, the
system detects and stores in the background routes that are frequently followed, without
them being active destination routes. This
function has no navigation announcements unless the user requires them, getting them
by pressing the adjustment knob
Page 59 of 86
Navigation*Navigation with imagesFig. 47
Images main menu.
Selecting an image and starting routeguidance
Bear in mind the requirements and formats of
the compatible images
Page 60 of 86
Navigation*Navigation settingsSettings
Page 61 of 86
Navigation*Function button: function Note: My POIs: Audible announcement when
nearing a point of interest.Fuel options: To make adjustments relating to fuel. Select preferred fuel station: The selected petrol sta-
tion mark will be shown before other points of in-
terest in the search. Fuel warning: The warning to refuel is active. If the fuel level reaches the reserve level, the cor-
responding warning is generated which permits
the search for petrol stations.Version information: Information on the stored naviga-
tion data.Maximum speeds: Shows the speed limits, depending
on the road, for the current country.Advanced settings: To make advanced adjustments to
the navigation. Time display: displayed during route guidance. Estimated time of arrival: The estimated time of
arrival at the final destination is displayed. Duration: The estimated travelling time to the
final destination is displayed. Status line: displayed during route guidance. Destination: The distance calculated to final
destination is displayed. Next stopover: The calculated distance until
next stopover is displayed.Function button: function Note: National border crossed: Displays the speed
limits of the country in question when crossing the
border. Demo mode: When Demo mode is activated
and route guidance is started, virtual guidance to
the entered destination can be initiated
Page 62 of 86
Vehicle MenuVehicle MenuIntroduction to using the V e h i c l e
menu
By pressing button ! 2 / of the infotainment
system you will access its main menu with the following options:
Page 63 of 86
Vehicle Menu2. Since refuelling
Display and storage of the values for the jour- ney and the consumption. By refuelling, the
memory will be erased automatically.
3. Long-term
The memory records the values for a specific number of partial trips, up to a total of 19
hours and 59 minutes or 99 hours and 59 mi- nutes, or 1999.9 km (or miles) for 9999 km (ormiles), depending on the model of instrumentpanel.
When one of these values is reached (de- pending on the version of the instrument pan-el), the memory is automatically deleted and it starts counting from 0 again.
Ecotrainer*
Fig. 50
CAR Menu Ecotrainer.
Fig. 51
Driving style symbols.
Open ECOTRAINER menu
Page 64 of 86
