2018 PEUGEOT EXPERT service reset

12
With LCD text instrument panel
A.Resetting the service indicator.
Reminder of servicing information or the
remaining range with the SCR system
and the AdBlue
®.
Depending on version: go back up a level,
cancel the current operation.
B. General lighting dimmer.
Depending on version: navigation in a
menu, a list; changing a value.
C. Resetting the trip distance recorder.
Depending on version: entry in the
configuration menu (press and hold),
validation of a choice (short press).
With matrix instrument panel
A.Resetting the service indicator.
Reminder of servicing information or the
remaining range with the SCR system
and the AdBlue
®.
Depending on version: go back up a level,
cancel the current operation.
B. General lighting dimmer.
Depending on version: navigation in a
menu, a list; changing a value.
C. Resetting the trip distance recorder.
Depending on version: entry in the
configuration menu (press and hold),
validation of a choice (short press).
You can also modify the lighting
dimmer via the touch screen.
Rev counter
Rev counter (x 1,000 rpm).
Instruments

29
Resetting the service indicator
The ser vice indicator must be reset after each
service.
If you have carried out the ser vice on your
vehicle yourself, switch off the ignition:F

P
ress and hold this
button.
F

S
witch on the ignition; the distance recorder
display begins a countdown.
F

W
hen the display indicates =0, release the
button; the spanner disappears. If you have to disconnect the battery
following this operation, lock the vehicle
and wait at least five minutes for the reset
to be registered.
Retrieving the service information
You can access the ser vice information at any
time.
F

P
ress this button.
The ser vice information is
displayed for a few seconds,
then disappears.
Engine coolant temperature
With engine running, when the needle or bar
graph (depending on version) is:
-

i
n zone A , the temperature of the engine
coolant is correct,
-

i
n zone B , the temperature of the engine
coolant is too high; the maximum
temperature and the central STOP warning
lamps come on, accompanied by an audible
signal and a warning message in the touch
screen.
You must stop as soon as it is safe to do so.
Wait a few minutes before switching off the
engine.
Contact a PEUGEOT dealer or a qualified
workshop.
1
Instruments

16
The ser vices offered with connected
navigation are as follows.
A Connected Services pack:
-

Weather,
-

F
illing stations,
-
C

ar park,
-


Tr a f f i c ,
-

P
OI local search.
A Danger zone pack (option).
The principles and standards
are constantly changing; for the
communication process between the
smartphone and the system to work
correctly, we recommend that you
update the operating system of the
smar tphone as well as the date and
time of the smar tphone and the
system.Settings specific to
connected navigation
In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with the
possibility of entering a multitude of
settings (radio presets, audio settings,
navigation history, contact favourites, etc.);
these settings are taken into account
automatically.
or Press Navigation
to display the
primary page.
Press the " MENU" button to go to the
secondary page.
Select "Settings ".
Select " Map". Activate or deactivate:
-
"
Allow declaration of danger
zones ".
- "
Guidance to final destination
on foot ".
- "Authorise sending
information ".
These settings must be made
according to each profile.
Select " Alerts".
Activate or deactivate " Warn of
danger zones ".
Select this button.
Activate: Give an audible warning
For access to connected navigation, you
have to select the option: " Authorise
sending information ".
The display of danger zones depends on
the legislation in force and subscription to
the service.
PEUGEOT Connect Nav

7
Display of the list of all radio stations
and "multiplexes".
Terrestrial digital radio
Digital radio provides a superior audio
quality and also additional categories of
traffic announcements (TA INFO).
The different "multiplex ser vices" offer a
choice of radio stations in alphabetical
o r d e r.Change of band (FM1, FM2, DAB,
e t c .)
Change of station within the same
"multiplex service". Starting of a search for the previous/
next "multiplex service".
Long press: selection of the
categories of news desired among
Transport, News, Entertainment and
Special Flash (available according to
the station).
When the radio station is displayed in
the screen, press " OK" to display the
contextual menu.
(Frequency search (RDS), DAB/FM
auto tracking, Radio Text (TXT) display,
Information on the station, etc.)
DAB/FM auto tracking
"DAB" does not have 100% coverage of
the country.
When the digital signal is weak,
"DAB/FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding analogue FM station
(if it exists).
When the "DAB/FM auto tracking" is
active, the DAB station will be selected
automatically. Press the MENU
button.
Select " Multimedia " and confirm.
Select " DAB/FM auto tracking " and
confirm.
If "DAB/FM auto tracking" tracking is
enabled, there is a lag of a few seconds
when the system switches to FM analogue
radio sometimes with a change in volume.
If the "DAB" station you are listening to
is not available on FM (" DAB/FM" option
barred), or if "DAB/FM auto tracking" is not
on, the sound will be cut when the digital
signal is too weak.
When changing region, an update of the
list of preset radio stations is advisable.
.
Bluetooth® audio system

310
SSafety, children .....................154, 157-160, 164,
16 8 -170, 172-173
Saturation of the particle filter (Diesel)
.........2 51
Screen, instrument panel


..........................35-36
Screen menu map


........................................... 13
Screen, multifunction (with audio system)


........4
Screenwash


.................................................. 140
Screenwash, rear


.......................................... 13 9
SCR (Selective Catalytic Reduction)


............252
Seat and bench seat, rear, fixed


............102-105
Seat and bench seat, rear, on rails
...............105
Seat belts


...................................... 15 0 -15 3, 163
Seat belts, rear


.............................................. 151
Seat, bench front, 2-seat
........................ 9

2 , 151
Seat, rear bench


........................................... 105RRadio ................................... 23 -24, 27, 7, 11, 4- 6
Radio, digital (Digital Audio Broadcasting – DAB)
............................25, 9, 6
Range


........................................................ 36 -37
Range, AdBlue


........................................... 31- 32
RDS
................

....................................... 24-25, 7
Rear screen, demisting


..........................121-12 2
Recharging the battery


.........................289-290
Recirculation, air


............................. 117-11 8 , 12 0
Reduction of electrical load


..........................243
Regeneration of the particle filter
.................2 51
Reinitialisation of the under- inflation detection system


...........................235
Reinitialising the remote control
... 4

5 - 46, 59 - 60
Reminder, key in ignition

...............................18

1Reminder, lighting on
.............................
13
1-132
Remote control

.......................
39 - 42, 44, 46 -50,
57-61, 63-64
Removing a wheel ................................
2 6 9 -271
Removing the mat

.........................................
108
Replacing bulbs
..................... 2
72-273, 278-282
Replacing fuses

....................................
283-286
Replacing the air filter
................................... 25
0
Replacing the oil filter
................................... 25
0
Replacing the passenger compartment filter

......................................
250
Reservoir, headlamp wash
........................... 24
9
Reservoir, screenwash

.................................
249
Reset journey
.................................................. 36
R
esetting the service indicator

.......................
29
Resetting the trip recorder

........................
33-34
Reversing camera
...............................
..
230-233
Reversing camera (on interior mirror) ..........
229
Reversing lamp

............................
278, 280, 282
Roof bars

...............................................
243 -244
Running out of fuel (Diesel) ..........................
257
Pads, brake

............................................
251-252
Paint colour code ..........................................
305
Parking brake

...........................
14, 185, 251-252
Parking sensors, audible and visual

.....
228-229
Parking sensors, front

...........................
228-229
Parking sensors, rear ............................227-229
Passenger's airbag
......................................... 20
P
EUGEOT Connect Nav ...................................
1
PEUGEOT Connect Radio
...............................
1
P
lates, identification
...................................... 305
Player, Apple
® ...................................... 2 7, 11, 10
Player, MP3

CD ............................... ......2 6 , 9 -10
Player, USB

........................................... 26, 10, 8
Port, USB

...................................... 111, 26, 10, 8
Power steering
...............................

.................21
Pressures, tyres


............................ 261, 265, 305
Pre-tensioning seat belts


.............................. 15 3
Priming the fuel system
................................ 257
Profiles


...................................................... 3 4, 18
Protecting children


................ 154, 157-160, 164,
16 8 -170, 172-173
Puncture


................................................ 260-265
PSeats, electric ........................................... 89-90
Seats, front ............................... ...........87, 89 -90
Seats, heated


............................................ 91-93
Seats, rear


............................................... 9 9 -10 4
Selector, gear


......................................... 19 4 -197
Serial number, vehicle


..................................305
Service indicator


....................................... 2 7, 2 9
Servicing
......................................................... 2

7
Settings, system


........................................ 35, 19
Sidelamps
............. 1

30, 273 -275, 278, 280, 282
Side repeater


................................................ 2 74
Sliding side door, electric


....................... 41- 42, 48, 54-56, 66 -73
Sliding side door, hands-free
.....................74 -7 6
Sliding side door, manual
................... 6

4- 66, 70
Sliding side window
...................................... 11

4
Snow chains


.................................. 234, 241, 268
Snow chains, link


.................................. 2 41, 2 6 8
Socket, 12
V accessory ................................111
Socket, auxiliary
.................................... 2

6, 10, 9
Socket, JACK


................................ 112, 26, 10, 9
Sockets, audio
........................................ 111

-112
Speed limiter
................................. 202

, 204-208
Speed limit recognition
........................ 20

2-204,
206 -215, 217-218
Stability control (ESC)...................... 21, 145 -14 6
Starting a Diesel engine
............................... 24

0
Starting the engine
................................ 17

8 -179
Starting the vehicle
....................... 18

1, 183 -18 4,
18 6, 189 -197
Starting using another battery


......................288
Station, radio
...............................

.......23 -25, 7, 4
Stay, bonnet


.................................................. 246
Steering mounted controls, audio
............ 3

, 3, 3
Steering wheel, adjustment
............................ 85
S

topping the vehicle

...............181-18 4, 189 -197
Stop & Start


........................ 19, 25, 37, 121, 124,
198 -200, 237, 246, 291
Stop (warning lamp)


........................................ 14
Storage


...................................... 9 4, 98, 10 6 -109
Alphabetical index
